User Manual
KPH/KVS/KVH Series: USB Hub KVM Switch 8/16 port with
1/2 user console
14628 Central Ave,
Chino, CA 91710
tel:909.597.7588, fax:909.597.1939
KPH/KVS/KVH Series
KVM Rear Kit for LCD Console Drawer
© Copyright 2013 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product
information, please visit Acnodes' web site at www.acnodes.com.
Advertisement
Table of Contents
Related Manuals for Acnodes KPH802
Summary of Contents for Acnodes KPH802
-
Page 1: User Manual
1/2 user console © Copyright 2013 Acnodes, Inc. All rights reserved. Product description and product specifications 14628 Central Ave, are subject to change without notice. For latest product Chino, CA 91710 information, please visit Acnodes’ web site at www.acnodes.com. tel:909.597.7588, fax:909.597.1939... - Page 2 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents < Part 1 > USB Hub DB-15 2-console KVM KPH802 KPH1602 Package contents KVM port connection IP console connection IP console setting P.2 - 3 Built-in USB hub usage & connection Specifications < Part 2 > USB Hub DB-15 2-console KVM... -
Page 4: Part 1 > Usb Hub
< Part 1 > USB Hub DB-15 < 1.1 > Package Contents KPH802 KPH1602 KVM Rear Kit back The power of the KVM rear kit may be changed to external power design based on the LCD console drawer series and model. -
Page 5: Kvm Port Connection
< 1.2 > KVM port connection CB-6 / CB-10 / CB-15 USB Servers ■ 6 / 10 / 15 ft USB KVM cable ■ Support USB server USB KVM port Drawer KVM Rear Kit CB - 6 / 10 / 15 USB KVM cable support USB server USB Servers... -
Page 6: Ip Console Setting
< 1.4 > IP console setting After the cable connection, please take the following steps to configure the IP KVM : 1. Download IPKVMsetup.exe 2. Double click IPKVMsetup.exe to configure the IP KVM by device setup as below. 3. Click Refresh Device to search the connected IP KVM 4. -
Page 7: Built-In Usb Hub Usage & Connection
< 1.5 > Built-in USB Hub Usage & Connection 2 x USB 2.0 ( USB hub for device connection ) Flash Disk Hard disk storage Keyboard / Mouse Scanner Printer Camera... -
Page 8: Specifications
< 1.6 > Specifications KPH802 KPH1602 KVM Port ▀ Number of ports: 8 or 16 Connector: Combo connector Connectivity: Combo 2-in-1 VGA + USB KVM cable, 6, 10 or 15 feet USB Hub 2 x USB type A for sharing other peripheral devices among the computers ▀... -
Page 9: Part 2. Usb Hub Db-15 2-Console Kvm
Part 2. USB Hub DB-15 2-console KVM < 2.1 > Package Contents KVS802 / 1602 • Receiver box for remote console x 1 • Power adapter w/ power cord ( for receiver ) x 1 • 6ft Combo KVM cable for receiver box x 1 KVM Rear Kit back The power of the KVM rear kit may be changed to external power design... -
Page 10: Kvm Port Connection
< 2.2 > KVM port connection CB-6 / CB-10 / CB-15 USB Servers ■ 6 / 10 / 15 ft USB KVM cable ■ Support USB server USB KVM port Drawer KVM Rear Kit CB - 6 / 10 / 15 USB KVM cable support USB server USB Servers... - Page 11 How to use a receiver to connect a remote console Receiver Local Computer Monitor Remote I/O Front Power Rear Local Remote Mouse Button Button KVM switch The receiver provides a hotkey function for remote console. Please refer to P.18 Drawer KVM Rear Kit Monitor Remote Console...
-
Page 12: Built-In Usb Hub Usage & Connection
< 2.4 > Built-in USB Hub Usage & Connection 2 x USB 2.0 ( USB hub for device connection ) Flash Disk Hard disk storage Keyboard / Mouse Scanner Printer Camera... -
Page 13: Specifications
< 2.5 > Specifications KVS802 KVS1602 KVM Port ▀ Number of ports: 8 or 16 Connector: Combo connector Connectivity: Combo 2-in-1 VGA + USB KVM cable, 6, 10 or 15 feet USB Hub 2 x USB type A for sharing other peripheral devices among the computers ▀... -
Page 14: Part 3. Usb Hub Db-15 Kvm
Part 3. USB Hub DB-15 KVM < 3.1 > Package Contents KVH801 / 1601 KVM Rear Kit back The power of the KVM rear kit may be changed to external power design based on the LCD console drawer series and model. KVH801 Power 2 x USB 2.0... -
Page 15: Kvm Port Connection
< 3.2 > KVM port connection CB-6 / CB-10 / CB-15 USB Servers ■ 6 / 10 / 15 ft USB KVM cable ■ Support USB server USB KVM port Drawer KVM Rear Kit CB - 6 / 10 / 15 USB KVM cable support USB server USB Servers... -
Page 16: Built-In Usb Hub Usage & Connection
< 3.3 > Built-in USB Hub Usage & Connection 2 x USB 2.0 ( USB hub for device connection ) Flash Disk Hard disk storage Keyboard / Mouse Scanner Printer Camera... -
Page 17: Specifications
< 3.4 > Specifications KVH801 KVH1601 ▀ KVM Port Number of ports: 8 or 16 Connector: Combo connector Connectivity: Combo 2-in-1 VGA + USB KVM cable, 6, 10 or 15 feet 2 x USB type A for sharing other peripheral devices among the computers ▀... -
Page 18: Part 4. Usage
Part 4. Usage 4.1 KVM Button Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch finally computer Front Panel - Port LED Indications USB Hub DB-15 KVM 8 ports Bank no. -
Page 19: Password
4.2 Password The password is enabled by default, the default password is “00000000” eight zeros (Do not use “0” on number pad) ■ Enable password Scroll Lock + Scroll Lock + U Press the KVM hotkey Scroll Lock + Scroll Lock + P 2. -
Page 20: Kvm Osd
4.3 KVM OSD OSD Menu OSD operation next to the system name The PC is powered on next to the system name The PC is selected Access F1 MAIN MENU Logout the OSD menu Previous menu Cancel / Quit Enter Complete / Switch to selected port Switch to previous or next port F1 Main Menu... - Page 21 Local Console Hotkey Function Scroll Lock + Scroll Lock + Space Bar Calling OSD menu Right-button mouse + Esc Calling OSD menu Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port Scroll Lock + Scroll Lock + Port no.
-
Page 22: Dc Power 12V, 24V, 48V Input
4.5 DC Power 12V, 24V, 48V Input Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V Input current - No load 50 mA 50 mA 50 mA - Full load 4950 mA 2450 mA 1220 mA...
