700/800 SERIES
FOOD WASTE DISPOSERS
MAINTENANCE MANUAL
723 Series 1
725 Series 3
726 Series 3
800 Series 2
Imperial Machine Company Limited
Harvey Road, Croxley Green
Herts. WD3 3AX
Tel: +44 (0)1923 718000
Fax: +44 (0)1923 777273
Service Tel: +44 (0)1923 718017
Spares Tel: +44 (0)1923 718018 Fax: +44 (0)1923 896256
ECN 6461 July 2005
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for IMC 723
Summary of Contents for IMC 723
- Page 1 700/800 SERIES FOOD WASTE DISPOSERS MAINTENANCE MANUAL 723 Series 1 725 Series 3 726 Series 3 800 Series 2 Imperial Machine Company Limited Harvey Road, Croxley Green Herts. WD3 3AX Tel: +44 (0)1923 718000 Fax: +44 (0)1923 777273 Service Tel: +44 (0)1923 718017...
- Page 2 (Guarantee of Production Quality) We, Imperial Machine Company Limited of: Harvey Road, Croxley Green, Herts WD3 3AX, ENGLAND, Declare under our sole responsibility that the machines: 723 – Series 1 725 – Series 3 726 – Series 3 800 – Series 2...
-
Page 3: Table Of Contents
MAINTENANCE ....................5 ORDERING SPARE PARTS: ................5 MATERIAL CONTENT ..................5 WIRING DIAGRAMS ....................6 PARTS ILLUSTRATION, ..................9 723 ........................9 725, 726, 800 Series and Dump Station ............10 PARTS LIST .......................11 723 ........................11 725 & 726 Series....................12 800 Series and Dump Station...............13... -
Page 4: Guarantee
700/800 Series Food Waste Disposer GUARANTEE This machine is guaranteed by IMC for twelve months from the date of purchase from IMC or from one of its stockists, dealers or distributors. The guarantee is limited to the replacement of faulty parts or products and excludes any consequential loss or expense incurred by purchasers. -
Page 5: Water Supply Connection
700/800 Series Food Waste Disposer WATER SUPPLY CONNECTION A cold water supply with a minimum head of 0.2 to 10 bar is required. This is connected to the units at the water control valve using a 15mm compression joint, supplied with the machine. A stopcock should be fitted to the water supply. The rate of water flow for the disposal of normal food waste is 14-18 litres per minute for 700 Series machines and 18-27 litres per minute for 800 series machines. -
Page 6: Index
Food Waste Disposers can jam under overload or if unsuitable materials are placed inside. IMC machines are designed to withstand this and no damage will normally result as the machine will switch itself off. It is necessary to clear the jam... -
Page 7: Fault Diagnosis
700/800 Series Food Waste Disposer FAULT DIAGNOSIS Machine does not start Cause Action Electrical supply is not turned on. Switch on supply. The fuses have blown or the circuit Call site electrician to change fuse or breaker has tripped. reset circuit breaker. If problem persists contact service personnel. -
Page 8: Maintenance
In the event that spare parts or accessories need to be ordered, please always quote the SERIES NUMBER of the machine. This is to be found on the rating plate located on the motor. For information on IMC spares and service support please call the following numbers: IMC Service Desk... -
Page 9: Wiring Diagrams
700/800 Series Food Waste Disposer WIRING DIAGRAMS Figure 1 - Wiring Diagram, Single Phase... - Page 10 700/800 Series Food Waste Disposer Figure 2 - Wiring Diagram, 3 Phase 4 Wire...
- Page 11 700/800 Series Food Waste Disposer Figure 3 - Wiring Diagram, 3 Phase 5 Wire Note: 723 Disposer is not available as a 5 wire machine.
-
Page 12: Parts Illustration
700/800 Series Food Waste Disposer PARTS ILLUSTRATION, Note Item 10, 3 inch BSP externally threaded sink inlet assembly, is to be welded into the sink aperture prior to installation of the machine. -
Page 13: 725, 726, 800 Series And Dump Station
700/800 Series Food Waste Disposer 725, 726, 800 Series and Dump Station 700 SERIES FOOD WASTE DISPOSER... -
Page 14: Parts List
700/800 Series Food Waste Disposer PARTS LIST Item Part No Description Item Part No Description E60/021 Flange Plate Assembly J03/134 Ball valve / Strainer A11/250 Gasket S60/016 Release Key D25/008 Washer M6 E60/019 Sink Inlet Assembly D25/005 Washer M6 Shakeproof D20/013 Full Nut M6 J04/319... -
Page 15: 725 & 726 Series
700/800 Series Food Waste Disposer 725 & 726 Series. Item Part No Description Item Part No Description E60/001 Frame – 726 S60/004 Solenoid 230V (1ph & 5 wire 3ph) A10/481 Adjustable Foot S60/003 Solenoid 400V (4 wire 3ph) A13/054 Square Foot J04/073 Straight Coupler J01/080... -
Page 16: 800 Series And Dump Station
700/800 Series Food Waste Disposer 800 Series and Dump Station. Item Part No Description Item Part No Description E68/008 Frame – 826 S60/004 Solenoid 230V (5 wire 3ph) E68/005 Frame – Dump Station S60/003 Solenoid 400V (4 wire 3ph) A10/481 Adjustable Foot J04/073 Straight Coupler...
