500 SERIES FWD
500 SERIES FWD
523 SERIES 18
525 SERIES 18
526 SERIES 18
MAINTENANCE MANUAL
PLEASE LEAVE WITH OPERATOR
A34/020 R8
ECN 8569 February 2019
1 |
P a g e

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 500 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for IMC 500 Series

  • Page 1 500 SERIES FWD 500 SERIES FWD 523 SERIES 18 525 SERIES 18 526 SERIES 18 MAINTENANCE MANUAL PLEASE LEAVE WITH OPERATOR A34/020 R8 ECN 8569 February 2019 P a g e...
  • Page 2 EN61000-6-1:2007 Immunity and EN61000-6-3: 2007 Emissions (plus product specific standards). IMC’s product range also satisfy the essential health and safety requirements of the Low Voltage Directive 2014/35/EU and are manufactured in accordance with standards BS EN 60335-1 and relevant product specific standards.
  • Page 3: Table Of Contents

    500 SERIES FWD CONTENTS GUARANTEE ....................... 4 WASTE OUTLET CONNECTION ................. 4 WATER SUPPLY CONNECTION ................ 5 ELECTRICAL CONNECTION ................5 MAINTENANCE ....................6 DO’S AND DON’TS ....................6 RELEASING A JAM ..................... 7 FAULT DIAGNOSIS ..................... 8 WIRING DIGRAMS. Figure 1 - Wiring Diagram, Single Phase ......9 WIRING DIAGRAM.
  • Page 4: Guarantee

    500 SERIES FWD GUARANTEE This machine is guaranteed by IMC for 1 Year from the date of purchase from IMC or from one of its stockists, dealers or distributors. The guarantee is limited to the replacement of faulty parts or products and excludes any consequential loss or expense incurred by purchasers.
  • Page 5: Water Supply Connection

    A stopcock should be fitted to the water supply. The 523 disposer draws its water supply from the sink tap. The 500 series machine is to be fed by a cistern tank not mains water supply. ELECTRICAL CONNECTION All electrical work must be carried out by a qualified electrician and in accordance with the IEE Codes of Practice.
  • Page 6: Maintenance

    Failure to maintain the seals will result in water ingress to the motor. Check for bearing wear by the sound of motor and side to side movement of rotor Regular inspection of catering equipment can extend its working life. Please phone IMC for details of service contracts.
  • Page 7: Releasing A Jam

    Food Waste Disposers can jam under overload or if unsuitable materials are placed inside. IMC machines are designed to withstand this and no damage will normally result as the machine will switch itself off. It is necessary to clear the jam as follows: Switch off at the mains isolating switch.
  • Page 8: Fault Diagnosis

    500 SERIES FWD FAULT DIAGNOSIS Machine does not start Cause Action Electrical supply is not turned on. Switch on supply. The fuses have blown or the circuit breaker Call site electrician to change fuse or reset has tripped. circuit breaker. If problem persists contact service personnel.
  • Page 9: Wiring Digrams. Figure 1 - Wiring Diagram, Single Phase

    500 SERIES FWD WIRING DIGRAMS. FIGURE 1 - WIRING DIAGRAM, SINGLE PHASE For supply: 230 –1 – 50, 115 – 1 – 60, 220 – 1 – 60 & 254 – 1 – 60 P a g e...
  • Page 10: Wiring Diagram. Figure 2 - Wiring Diagram, 3 Phase 4 Wire

    500 SERIES FWD WIRING DIAGRAM. FIGURE 2 - WIRING DIAGRAM, 3 PHASE 4 WIRE For supply: 400 – 3 – 50, 220 – 3 – 50, 440/460 – 3 – 60 & 230 – 3 – 60. 10 | P a g e...
  • Page 11: Wiring Diagram. Figure 3 - Wiring Diagram, 3 Phase 5 Wire

    500 SERIES FWD WIRING DIAGRAM. FIGURE 3 - WIRING DIAGRAM, 3 PHASE 5 WIRE For supply 400 – 3 - 50 11 | P a g e...
  • Page 12: Basic Unit Exploded View

    500 SERIES FWD BASIC UNIT EXPLODED VIEW **NOTE SINGLE PHASE MOTOR ILLUSTRATED** NOTE ORIENTATION OF LIP SEALS 12 | P a g e...
  • Page 13: Parts List

    500 SERIES FWD PARTS LIST Item number Part number Description A02/050 BROWN LIP SEAL A02/051 BLACK LIP SEAL A02/054 SPEEDI SLEEVE A028/704 WARNING LABEL C14/014-M1 CUTTER C14/023-M1 ROTOR D14/012 D19/039 M6X16L HEX SCREW D25/020 WASHER D26/010 TENSION PIN G40/238 MOTOR 1ph...
  • Page 14: 523 Exploded View

    500 SERIES FWD 523 EXPLODED VIEW 14 | P a g e...
  • Page 15: Parts List

    CLIP. HOSE 40-60MM DIA J06/014 CLIP. HOSE 150-180MM DIA S52/010 BASIC UNIT 1PH 500 SERIES S52/020 BASIC UNIT 3PH 500 SERIES When ordering spare parts or accessories always quote the SERIES NUMBER of the machine, found on the rating label.
  • Page 16: 525 Exploded View

    500 SERIES FWD 525 EXPLODED VIEW 16 | P a g e...
  • Page 17: Parts List

    HOSE CLIP 150-180mm DIA J06/039 HOSE CLIP K07/063 SILICONE OIL K09/027 LOCTITE 542 S52/010 BASIC UNIT 1PH 500 SERIES S52/020 BASIC UNIT 3PH 500 SERIES S52/025 ELECTRICS PLATE ASSY 500 FWD 1PH S52/026 ELECTRICS PLATE ASSY 500 FWD 3PH S52/031...
  • Page 18: 526 Exploded View

    500 SERIES FWD 526 EXPLODED VIEW ONLY ADDITIONAL PARTS TO THE 525 ASSEMBLY ARE ILLUSTRATED. 18 | P a g e...
  • Page 19: Parts List

    500 SERIES FWD PARTS LIST Parts List ITEM PART NUMBER DESCRIPTION A10/134 BLIND GROMMET A10/280 M20 CABLE GLAND BLACK A13/064 INSERT SQ.TUBE A13/056 ADJUSTABLE FOOT M8 x40 A13/065 INSERT M8 THREAD SQ. TUBE D21/038 SCREW M4 X 12MM PAN S.S.
  • Page 20: Material Content

    For installations outside the UK, please contact your supplier. For information on IMC spares and service support (if applicable), please call IMC on +44 (0)1978 661155. Alternatively, contact us via email or fax: IMC Spares Desk...
