- Page 1 500 SERIES FOOD WASTE DISPOSERS MAINTENANCE MANUAL PLEASE LEAVE WITH OPERATOR 523 SERIES 17 525 SERIES 17 526 SERIES 17 IMC Mainland Agent: The Green Machine Ind. Tel. +31 ( 0 ) 653192745 info@thegreenmachine.nl www.thegreenmachine.nl A34/020 R6 ECN 7872 August 2012...
- Page 2 EN61000-6-1:2001 Immunity and EN61000-6-3: 2001 Emissions (plus product specific standards). IMC’s product range also satisfy the essential health and safety requirements of the Low Voltage Directive 2006/95/EC and are manufactured in accordance with standards BS EN 60335-1 and relevant product specific standards.
- Page 3 500 Series Food Waste Disposer...
-
Page 4: Table Of Contents
500 Series Food Waste Disposer INDEX GUARANTEE ....................1 WASTE OUTLET CONNECTION..............1 WATER SUPPLY CONNECTION ..............2 ELECTRICAL CONNECTION .................2 RELEASING A JAM ..................3 NOTE.......................3 FAULT DIAGNOSIS ..................4 Machine does not start ................4 Unexpected system stop ................4 Waste not processed .................4 MAINTENANCE ....................5 ORDERING SPARE PARTS: ................5... -
Page 5: Guarantee
500 Series Food Waste Disposer GUARANTEE This machine is guaranteed by IMC for 1 Year from the date of purchase from IMC or from one of its stockists, dealers or distributors. The guarantee is limited to the replacement of faulty parts or products and excludes any consequential loss or expense incurred by purchasers. -
Page 6: Water Supply Connection
The 523 disposer draws its water supply from the sink tap. The 500 series machine is to be fed by a cistern tank not mains water supply. ELECTRICAL CONNECTION All electrical work must be carried out by a qualified electrician and in accordance with the IEE Codes of Practice. -
Page 7: Releasing A Jam
RELEASING A JAM Food Waste Disposers can jam under overload or if unsuitable materials are placed inside. IMC machines are designed to withstand this and no damage will normally result as the machine will switch itself off. It is necessary to clear the jam as follows: Switch off at the mains isolating switch. -
Page 8: Fault Diagnosis
500 Series Food Waste Disposer FAULT DIAGNOSIS Machine does not start Cause Action Electrical supply is not turned on. Switch on supply. The fuses have blown or the circuit Call site electrician to change fuse or breaker has tripped. reset circuit breaker. If problem persists contact service personnel. -
Page 9: Maintenance
For installations outside the UK please contact your supplier. For information on IMC spares and service support (if applicable), please call IMC on +44 (0)1978 661155. Alternatively, contact us via email or fax:... -
Page 10: Wiring Diagrams
500 Series Food Waste Disposer WIRING DIAGRAMS Figure 1 - Wiring Diagram, Single Phase For supply: 230 –1 – 50, 115 – 1 – 60, 220 – 1 – 60 & 254 – 1 – 60... -
Page 11: Figure 2 - Wiring Diagram, 3 Phase 4 Wire
500 Series Food Waste Disposer Figure 2 - Wiring Diagram, 3 Phase 4 Wire For supply: 400 – 3 – 50, 220 – 3 – 50, 440/460 – 3 – 60 & 230 – 3 – 60. -
Page 12: Figure 3 - Wiring Diagram, 3 Phase 5 Wire
500 Series Food Waste Disposer Figure 3 - Wiring Diagram, 3 Phase 5 Wire For supply: 400 – 3 – 50. -
Page 13: Basic Unit Exploded View
500 Series Food Waste Disposer BASIC UNIT EXPLODED VIEW NOTE ORIENTATION OF LIP SEALS **SINGLE PHASE MOTOR SHOWN... - Page 14 500 Series Food Waste Disposer Item Part number Description number A02/050 BROWN LIP SEAL A02/051 BLACK LIP SEAL A02/054 SPEEDI SLEEVE A028/704 WARNING LABEL C14/014-M1 CUTTER C14/023-M1 ROTOR D14/012 D19/039 M6X16L HEX SCREW D25/020 WASHER D26/010 TENSION PIN G40/238 MOTOR 1ph...
-
Page 15: 523 Exploded View
500 Series Food Waste Disposer 523 EXPLODED VIEW... - Page 16 500 Series Food Waste Disposer Parts List ITEM PART NUMBER DESCRIPTION RATING LABEL A10/280 CABLE GLAND A11/027 SINK OUTLET GASKET ANGLED E07/018 A RUBBER HOUSING E10/016 SINK OUTLET E10/017 CLAMP E10/018 SINK STOPPER E10/019 SILVER SAVER G30/360 500 1PH CONTROL BOX...
-
Page 17: 525 Exploded View
500 Series Food Waste Disposer 525 EXPLODED VIEW 14 19... - Page 18 500 Series Food Waste Disposer Parts List ITEM PART NUMBER DESCRIPTION A08/480 RATING LABEL A10/224 CABLE GLAND NUT A10/280 CABLE GLAND M20 BLACK A11/176 GASKET D21/038 SCREW M4 X 12L SS PAN D25/007 WASHER M4 SHAKEPROOF SS E07/020 RUBBER TOP HOUSING...
-
Page 19: 526 Exploded View
500 Series Food Waste Disposer 526 EXPLODED VIEW ONLY ADDITIONAL PARTS TO THE 525 ASSEMBLY ARE SHOWN... - Page 20 500 Series Food Waste Disposer Parts List ITEM PART NUMBER DESCRIPTION A10/134 BLIND GROMMET PV626 A10/280 CABLE GLAND A13-064 INSERT PLAIN 25x16G SQ TUBE A13/056 ADJUSTABLE FOOT M8x40 A13/065 INSERT M8 THREAD 25x16G SQ TUBE D21/038 SCREW M4 X 12L SS PAN...
