Menu Item Descriptions

Smart Tune
An automatic scanning function that identifies a usable
frequency and sets the receiver on it. After the scan is
complete, an option will appear to transfer the settings
to an IR enabled transmitter. The receiver will remain
set on the newly discovered frequency whether or not
the IR transfer option was used.
Frequency
Allows manual selection of the operating frequency.
IR Sync
Transfers frequency, step size and compatibility mode
from the receiver to the associated transmitter.
RF Scan
Launches the manual spectrum scanning function.
Clear Scan
Erases scan results from memory.
Audio Level
Adjusts the audio output level of the receiver.
Step Size
Selects 100 kHz or 25 kHz steps in the frequency
adjustments.
Tx Battery
Selects the type of battery being used in the associ-
ated transmitter for accurate battery status monitoring.
The transmitter battery timer option is included in this
setup screen.
Rx Battery
Selects the type of battery being used in the receiver
for accurate battery status monitoring.
Compat. Mode
Selects the compatibility mode for use with a wide vari-
ety of Lectrosonics and other brands of transmitters.
Polarity
Selects the audio polarity (phase) of the receiver out-
put to match other components and different micro-
phone capsule wiring.
Smart NR
Selects the level of noise reduction applied to the
audio signal.
Sq. Bypass
Defeats the audio muting (squelch) to allow audio
output from the receiver regardless of the presence
or lack of a matching transmitter. Used for diagnostic
purposes.
Rio Rancho, NM
Backlight
Selects the length of time the backlight on the LCD
remains turned on.
LCD Mode
Selects the text/background appearance of the LCD.
Default
Returns all settings to the factory defaults:
Menu Item Setting
Frequency 8,0 (middle of lowest frequency
block)
Audio Level 0 dBu
Compat.Mode NA Dig. Hybrid
Smart NR Normal
Polarity Normal (not inverted)
Step Size 100 kHz
LCD Mode White characters on dark
background
Tx Battery AA alkaline
Rx Battery Alkaline
Battery Timer Reset to 0
Sq. Bypass Normal (squelch operational)
Tone output Off (in Audio Level setup
screen)
Backlight Always on
Keypad status Not locked

The Power Menu

Pressing the power
eral options. Use the UP and DOWN arrows to select
the option and press MENU/SEL to select the function
or open a setup screen.
Resume
Returns to the previous screen and settings.
LockUnlock
Opens a setup screen with options to Lock or Unlock
the buttons.
About
Displays the splash screen shown at bootup, which
includes the firmware version.
Power Off
Turns the power off.
Compact Portable Receiver
button opens a menu with sev-
