S S Y Y S S T T E E M M O O V V E E R R V V I I E E W W
T T h h e e P P o o w w e e r r T T a a p p S S y y s s t t e e m m
The PowerTap system includes a power-measuring hub which measures torque and wheel
speed. This information is then transmitted via digital radio frequency to a receiver mounted on
the seat stay. The data is wired to the PowerTap computer mounted on the handlebar. The com-
puter receives the signal from the heart rate monitor chest strap to provide heart rate information.
All of this information is then processed for display on the computer.
P P r r e e p p a a r r i i n n g g f f o o r r I I n n s s t t a a l l l l a a t t i i o o n n
The PowerTap hub comes either in a pre-built wheel or alone, ready to build into a wheel. The
power measuring hub must be built into a complete wheel prior to installation. Other items nec-
essary for installation are a cassette, spoke protector, reflectors, skewer, rim strip, tire, and tube
(clincher rim) or glue and tubular tire (tubular rim). Please read all instructions prior to installation.
Also take a moment to verify the package contents. The installation procedure with a complete
wheel requires only a trimmer to clip the cable ties. However, assembling the wheel, cassette and
other parts requires the proper tools and experience. If you are unsure of any step of the proce-
dure or do not have all of the tools necessary for installation, contact your local dealer
for assistance.
P P a a c c k k a a g g e e C C o o n n t t e e n n t t s s
Qty Item
1 PowerTap hub (or built wheel)
1 PowerTap computer
1 Receiver
1 Chest strap
4 Foam mounting tapes
12 Cable ties
1 Training With Power guide by CTS
1 Product registration card
1 PowerLink Lite CD
1 Link cable
1 Cadence Magnet (Pro Model Only)
10 Cadence Sensor Cable Ties
1 Extra CPU Battery
