P P O O W W E E R R T T A A P P S S L L G G E E N N E E R R A A L L O O P P E E R R A A T T I I O O N N
G G e e n n e e r r a a l l O O p p e e r r a a t t i i o o n n o o f f C C o o m m p p u u t t e e r r
The PowerTap SL has three main displays: power
display (top), speed display (middle), and multi-
function display (bottom). There are two main
modes of operation in the PowerTap: trip mode and
interval mode.
M M o o d d e e B B u u t t t t o o n n
Press the mode button to scroll between the
different displays. The active display is indicated by
small black triangles at the left and right side of the
display. Hold the mode button down for two sec-
onds to toggle between trip and interval modes. The
"INT" icon will illuminate when you enter interval
mode as well as the current interval number.
S S e e l l e e c c t t B B u u t t t t o o n n
Press the select button to select which function is
shown on the current display. The current function
will remain on the display even when the mode but-
ton is used to move to another display.
M M e e n n u u ( ( B B o o t t h h B B u u t t t t o o n n s s ) )
Hold both buttons for 2 seconds to enter the scroll-
ing menu. There are two options to select by releas-
ing the buttons: clr to clear all data and the main
menu to enter setup. See page XX for set up infor-
mation.
P P o o w w e e r r C C o o n n s s e e r r v v a a t t i i o o n n
The computer and hub have power saving features
to prolong battery life. The computer powers down
the display after 4 minutes of inactivity. Press one of
the buttons to activate the display. Similarly, the hub
powers down after two minutes of inactivity. The
transmission icon will not be visible when the hub is
asleep. Spin the wheel momentarily and the icon will
illuminate.
T T R R A A N N S S . .
I I C C O O N N
I I N N T T E E R R V V A A L L
D D I I S S P P L L A A Y Y
M M O O D D E E ( ( L L E E F F T T ) )
B B O O T T H H
Changes active
Clear data
mode
Enter setup
Figure 7: PowerTap button and display summary
P P O O W W E E R R
D D I I S S P P L L A A Y Y
S S P P E E E E D D
D D I I S S P P L L A A Y Y
M M U U L L T T I I
D D I I S S P P L L A A Y Y
S S E E L L E E C C T T ( ( R R I I G G H H T T ) )
Select function
