2.

SPECIFICATIONS

Power required: 115 VAC, 60 Hz, 25W
Output: 12VDC or 24VDC, 2A
continuous, 16A in-rush current
Relay contacts: 10A, SPDT (Form C)
Battery back-up: 12VDC or 24VDC,
automatic transfer and charging
(batteries optional, Moniteq p/n CC-
BATT)
Battery monitoring: Warning lamp,
beeper and output signal activate when
battery is low
PIN code length: 3, 4, 5 or 6 digits
Open duration: Adjustable, 3 to 60
seconds
Penalty function: Invalid PIN attempts
temporarily disable operation and can
be set to sound an alarm
3.

SUPPLIED EQUIPMENT

The CC-8521B consists of two main
units, the Keypad and Control Unit, and
various accessories and mounting
hardware to facilitate installation.
QTY
1 Control Unit
Keypad with 15' cable
1
1 Manual, Crypto Lock CC-8421V2 (this manual)
1 AC power cord
2 Threaded rod, #8 X 12"
1* Cam Lock w/ two keys
2* Screw, slotted, Sheet metal, #6, 1/2"
2* Battery cables, #18 AWG, black/red
2* Fuse, 2A, Slo-Blo
4* Hex Nut, #8
2* Acorn nut, #8
6* Lock washer, #8
2* Washer, #8, 1-1/2 in. dia.
8* Pan head combo drive screw, #8 x 1-1/2"
2* Bushing, black nylon, 7/8"
2* Cradle mount, nylon, adhesive back, 1" x 1"
6* Tie wrap, nylon, 4"
Vent plug, black nylon, 7/8"
2*
1 Template, Keypad mounting holes
* Items packed in poly bag
ITEM
6
Penalty time: Adjustable, 3 to 60
seconds, set to 60 seconds after five
invalid PIN attempts
Remote release input: Dry contact
closure
Door monitoring functions: Door
propped open alarm, forced door alarm,
anti-tailgating
Keypad cable: 10-conductor, #22
supplied cable: 15 ft., 10-cond., #22
maximum length: 1,000 ft.
Enclosure: 19 gauge steel, powder
coated paint, gray color, knock-outs for
conduit, and cam-lock (included), holes
for padlock (not included)
Dimensions: 12H x 9W x 4.5D in.
Options available: CC-BATT: 12 VDC,
7AH rechargeable battery (2 required for
24VDC operation); CC-BRUTE: surface
mount electric lock.
The table below lists all of the items that
comprise the Model CC-8521B along
with a brief description of each to aid in
their identification and use.
PURPOSE
Main processor and power supply
Accepts PIN code entries
Installation and operating instructions
Connection to AC power
Keypad mounting, thru-wall
Lock Control Unit door
Hold Control Unit door closed
Connect batteries to Lock Driver Board
Spares
Keypad mounting
Keypad mounting, thru-wall
Keypad mounting
Keypad mounting, thru-wall
Keypad and Control Unit mounting
Protects cables going into Control Unit
Secure wires within Control Unit
Secure cables within Control Unit
Ventilate Control Unit in warm environments
Keypad installation
