7. OPERATION

To operate the CC-8521B, enter the
valid 3, 4, 5 or 6-digit PIN code on the
Keypad. When the valid PIN code is
entered, the green LED on the Keypad
will illuminate and the door lock will
release.
The CC-8521B Keypad has a built-in
visitor annunciator button. Pressing the
# key causes an annunciator to sound in
the Control Unit. If an external sounding
device is connected as shown in Figure
5-1, it will also sound when this button is
pressed.
If an incorrect PIN code is entered, the
system will enter a penalty mode and
will not recognize any digits for a time
period of 5 to 60 seconds. If five
successive invalid PINs are entered, the
Table 7-1, Alarm Sequences
Alarm Type
Visitor
Invalid PIN
Door Propped
Forced Door
Low Battery
Activated by # button on keypad
- - - - -
_____ _____ _____
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
- - -
penalty time is set to 60 seconds until
the valid PIN is entered. After the
penalty time has elapsed, the unit will
return to normal operation and entering
the valid PIN code on the Keypad will
release the door.
If the external Release Button has been
installed, it can be used by an attendant
to release the lock from a location on
the secure side of the door.
Various alarm situations activate
different sequences of sounds on the
beeper in the Control Unit. If an external
annunciator is connected to the system,
it will sound the same sequences as the
beeper in the Control Unit. Table 7-1
lists these alarm sequences and their
meaning.
Alarm Sequence
Five short
beeps
_____ _____ Continuous
long beeps
Continuous
short beeps
- - Chirp every 15
seconds
12
Silenced by:
After five short beeps
Door closed or time out
set by code *23*N*
Valid PIN or code *24*0*
Apply AC power
