Vertex Standard VX-2500U Service Manual

Hide thumbs Also See for VX-2500U:
Table of Contents

Advertisement

Quick Links

See also: Operating Manual
UHF FM Transceiver
VX-2500U
Service Manual
©
2004 VERTEX STANDARD CO., LTD.
This manual provides technical information necessary for servicing the VX-2500U Transceiver.
Servicing this equipment requires expertise in handling surface-mount chip components. Attempts by non-qualified
persons to service this equipment may result in permanent damage not covered by the warranty, and may be illegal in
some countries.
Two PCB layout diagrams are provided for each double-sided circuit board in the transceiver. Each side of thr board is
referred to by the type of the majority of components installed on that side ("leaded" or "chip-only"). In most cases one
side has only chip components, and the other has either a mixture of both chip and leaded components (trimmers, coils,
electrolytic capacitors, ICs, etc.), or leaded components only.
While we believe the technical information in this manual to be correct, Vertex Standard assumes no liability for dam-
age that may occur as a result of typographical or other errors that may be present. Your cooperation in pointing out any
inconsistencies in the technical information would be appreciated.
Specifications ..................................................... 2
DSUB 9-pin Accessory Connector .................. 3
Block Diagram .................................................... 5
Interconnection Diagram ................................. 9
Circuit Description .......................................... 11
VERTEX STANDARD CO., LTD.
4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan
VERTEX STANDARD
US Headquarters
10900 Walker Street, Cypress, CA 90630, U.S.A.
YAESU EUROPE B.V.
P.O. Box 75525, 1118 ZN Schiphol, The Netherlands
YAESU UK LTD.
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
VERTEX STANDARD HK LTD.
Unit 5, 20/F., Seaview Centre, 139-141 Hoi Bun Road,
Kwun Tong, Kowloon, Hong Kong
Contents
Alignment ...................................................... 13
RF Unit Jumper Information ...................... 23
Clone ............................................................... 24
Board Unit (Schematics, Layouts & Parts)
RF Unit .......................................................................... 25
RF-1- Unit ...................................................................... 43
RF-2- Unit ...................................................................... 57
Panel Unit ..................................................................... 69
1

Advertisement

Table of Contents
loading

Related Manuals for Vertex Standard VX-2500U

Summary of Contents for Vertex Standard VX-2500U

  • Page 1: Table Of Contents

    ICs, etc.), or leaded components only. While we believe the technical information in this manual to be correct, Vertex Standard assumes no liability for dam- age that may occur as a result of typographical or other errors that may be present. Your cooperation in pointing out any inconsistencies in the technical information would be appreciated.

  • Page 2: Specifications

    Specifications General Frequency range: 400-470 MHz (Ver. CS1) 450-490 MHz (Ver. D) 450-520 MHz (Ver. DS1) Number of Groups: Number of Channels : 128 channels PLL Steps: 5.0 kHz/6.25kHz Power Supply Voltage: 13.8V DC ±15 % Channel Spacing: 12.5 / 25.0 kHz Current Consumption (Approx.): TX: 6 A RX: 700 mA...

  • Page 3: Dsub 9-Pin Accessory Connector

    DSUB 9-pin Accessory Connector Pin 1: Output Logic squelch (Will be effective this output during Data transmission – Inputting logic Low level signal to the Pin #4 as the DTR signal) High: Radio receiving the signal with the correct CTCSS, DCS, or LTR ID. Low: Radio not receiving the signal with the correct CTCSS, DCS, or LTR ID.

  • Page 4: Exploded View & Miscellaneous Parts

    Exploded View & Miscellaneous Parts REF. VXSTD P/N DESCRIPTION QTY. U20206002 BINDING HEAD SCREW M2.6 x 6 NI U20306002 BINDING HEAD SCREW M3 x 6 NI U20308002 BINDING HEAD SCREW M3 x 8 NI U24306002 TAPTITE SCREW M3 x 6 NI U24308001 TAPTITE SCREW M3 x 8 U31206007...

  • Page 5: Block Diagram

    Block Diagram (1)
  • Page 6 Block Diagram (2)
  • Page 7 Block Diagram (3)
  • Page 8 Block Diagram (4)

  • Page 9: Interconnection Diagram

    Interconnection Diagram...
  • Page 10 Note...

  • Page 11: Circuit Description

    Detected audio from Q1029 is applied to Q2016 (AK2345) 1. Overview and audio low-pass filter. After volume adjustment by The VX-2500U is a UHF FM mobile transceiver designed Q2014 (M62364FP), the audio signal is amplified by the to operate in the frequency range of 400 to 520 MHz.

  • Page 12: Power Supply Circuits

    Circuit Description While receiving, VCO Q1013 oscillates between 355.75 and 7. Power Supply Circuits 475.75 MHz according to the transceiver version and the 7-1 All 13.8V programmed receiving frequency. The VCO generates 13.8V is always supplied to Power AMP Q1014 355.75 to 475.75 MHz for providing to the first local sig- (RA30H4452M:Ver.

  • Page 13: Alignment

    Alignment Introduction Required Test Equipment RF Signal Generator with calibrated output level The VX-2500U is carefully aligned at the factory for the at 1000MHz specified performance across the frequency range speci- Deviation Meter (linear detector) fied for each version. Realignment should therefore not...
  • Page 14 Alignment Setup the test equipment as shown below, apply 13.8V PLL VCV DC power to the transceiver. Connect the positive lead of the DC voltmeter to the test point TP1007 (VCV) on the RF-Unit, as The transceiver must be programmed for use in the in- indicated in the figure, and the negative lead to tended system before alignment is attempted.
  • Page 15 Alignment The alignment tool outline Menu of the tool Enter to the alignment mode TX Power (High) To enter the alignment mode, turn the receiver off, select This parameter is used to align TX High power. "Radio" then "Alignment" parameter on Clone Editor Set the transceiver to CH#1 via the "Channel"...
  • Page 16 Alignment Move the Slide bar, as needed, to set the power When the 5Watt level is attained, press the "OK" output to the following specification, as indicated box to lock in the new data. on the external wattmeter. TX Power (High): 25[W] (±0.5W) When the 25Watt level is attained, press the "OK"...
  • Page 17 Alignment Move the Slide bar, as needed, to set the Max To adjustment click the left mouse button on the Deviation (Wide) to the following specification, "Modulation balance" then "Start" button. as indicated on the deviation meter. Max Deviation (Wide): 2.8[kHz](±0.1[kHz]) When the desired deviation level is attained, press "OK"...
  • Page 18 Alignment DCS Modulation CTCSS Modulation This parameter is used to align CTCSS deviation. This parameter is used to align DCS deviation. Set the transceiver to CH#1 via the "Channel" box Set the transceiver to CH#1 via the "Channel" box located upper right corner on the "Alignment" located upper right corner on the "Alignment"...
  • Page 19 Alignment RX Tune Tight Noise SQL This parameter is used to RX Tune. This parameter is used to Tight Noise SQL. Set the transceiver to CH#1 via the "Channel" box Set the transceiver to CH#1 via the "Channel" box located upper right corner on the "Alignment" located upper right corner on the "Alignment"...
  • Page 20 Alignment Set the transceiver to CH#2 via the "Channel" box Threshold Noise SQL located upper right corner on the "Alignment" This parameter is used to Threshold noise SQL. window previously. Set the transceiver to CH#1 via the "Channel" box located upper right corner on the "Alignment" window previously.
  • Page 21 Alignment Set the transceiver to CH#2 via the "Channel" box located upper right corner on the "Alignment" window previously. Set the SG output level to -7dBµ EMF with 1.5 kHz deviation. To adjustment click the left mouse button on the "Threshold noise SQL"...
  • Page 22 Note...

  • Page 23: Rf Unit Jumper Information

    RF Unit Jumper Information JP1501 (JP1): Determine the output supply voltage at pin 8 of DSUB 9-pin Accessory Connector. Close: +5.0 V (Maximum 100 mA) Open: No Action JP1502 (JP2): Determine the output supply voltage at pin 8 of DSUB 9-pin Accessory Connector. Close: +13.8 V (Maximum 100 mA) Open: No Action JP1503 (JP3): Determine the Rx discriminator output characteristic at pin 2 of DSUB 9-pin Accessory Connec-...

  • Page 24: Clone

    Clone [ Ch. Up ] Button on the source trans- The VX-2500 includes a convenient “Clone” feature, Press the which allows the programming data from one trans- ceiver, "SENDING" will appear on the source ceiver to be transferred to another VX-2500. Here is transceiver, and the data will be transferred.

  • Page 25: Rf Unit

    RF Unit (Ver. D: Lot. 1~5) Circuit Diagram (1) WIDE: 4.4 V NARROW: 4.9 V 5.0 V RX: 0 V RX: 0 V RX: 0 V TX: 7.2 V TX: 7.2 V TX: 7.7 V RX: 0.6 ~ 2.3 V RX: 0 V 1.0 V TX: 1.6 V...
  • Page 26 RF Unit (Ver. D: Lot. 1~5) Circuit Diagram (2) 4.8 V 2.2 V 1.2 V 0.7 V 1.3 V RX WIDE: 0.2 ~ 3.8 V RX NARROW: 0.2 ~ 3.5 V TX: 0.2 V RX WIDE: 0.8 ~ 3.8 V RX NARROW: 0.8 ~ 3.1 V RX: 0.3 V TX: 0.8 V...
  • Page 27 RF Unit (Ver. D: Lot. 1~5) Parts Layout (side A) TDA2003H SA7025DK NJM2902V M5223 2SA1602A (MF) 2SB1301 (ZQ) 2SC4154 (E) 2SK508 (K52) IMH6A (H6) 3SK228 (XR) RT1N241M (N2) HSM88AS (C1) (Q1509) (Q1023) (Q1503) (Q1003, 1019) (Q1505) (Q1511) (Q1501) (Q1013) (Q1017) (Q1026) (Q1002, 1006, (D1011, 1012)
  • Page 28 RF Unit (Ver. D: Lot. 1~5) Parts Layout (Side B) 1SS321 (F9) (D1022) MC2848 (A6) (D1024, 1026) MC2850 (A7) (D1501, 1502, 1503) RT1N241M (N2) (Q1012, 1030, 1516, 1517) PDTC114TE (24) (Q1508, 1510) RA30H4452M TA31136FN 2SB1201S 2SA1602A (MF) 2SB1132 (BA) 2SC4116 (LG) 2SC5415E (EA) 2SJ125D (JD) DTB123EK (F12)
  • Page 29 RF Unit (Ver. D: Lot. 6~) Circuit Diagram (1)
  • Page 30 RF Unit (Ver. D: Lot. 6~) Circuit Diagram (2)
  • Page 31 RF Unit (Ver. D: Lot. 6~) Parts Layout (side A) TDA2003H SA7025DK NJM2902V M5223 2SA1602A (MF) 2SB1301 (ZQ) 2SC4154 (E) 2SK508 (K52) IMH6A (H6) 3SK228 (XR) RT1N241M (N2) HSM88AS (C1) (Q1509) (Q1023) (Q1503) (Q1003, 1019) (Q1505) (Q1511) (Q1501) (Q1013) (Q1017) (Q1026) (Q1002, 1006, (D1011, 1012)
  • Page 32 RF Unit (Ver. D: Lot. 6~) Parts Layout (Side B) RA30H4452M 2SB1201S (Q1014) (Q1005) 2SA1602A (MF) 2SC4116 (LG) 2SC5415E (EA) 2SJ125D (JD) DTB123EK (F12) IMH6A (H6) MM1216ENRE NJM78L05 PDTC114TE (24) RT1N241M (N2) MC2850 (A7) 1SS321 (F9) (Q1031) (Q1001) (Q1022) (Q1515) (Q1008) (Q1010) (Q1004)

  • Page 33: Parts List

    RF Unit (Ver. D) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR PCB with Components CB1731001 Printed Circuit Board AC031U000 FR007620C FR007620D C 1001 CHIP CAP. 470pF GRM39CH471J50PT K22174249 C 1002 CHIP CAP. 0.001uF 630V GHM1030R102K630PT K22281801...
  • Page 34 RF Unit (Ver. D) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR C 1080 CHIP CAP. 220pF GRM39CH221J50PT K22174243 C 1081 CHIP CAP. 470pF GRM39CH471J50PT K22174249 C 1082 CHIP CAP. 220pF GRM39CH221J50PT K22174243 C 1083 CHIP CAP.
  • Page 35 RF Unit (Ver. D) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR C 1165 CHIP CAP. 0.5pF GRM39CK0R5C50PT K22174201 C 1166 CHIP CAP. GRM39CJ030C50PT K22174204 C 1167 CHIP CAP. GRM39CH060D50PT K22174207 C 1168 CHIP CAP. 470pF GRM39CH471J50PT K22174249...
  • Page 36 RF Unit (Ver. D) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR C 1236 CHIP CAP. GRM39CJ030C50PT K22174204 4-5 A C 1237 CHIP CAP. 0.01uF GRM39B103M50PT K22174823 1-5 B C 1238 CHIP CAP. 0.001uF GRM39B102K50PT K22174821 C 1239...
  • Page 37 RF Unit (Ver. D) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR C 1531 CHIP CAP. 0.0047uF GRM39B472K50PT K22174833 C 1532 CHIP CAP. GRM39CH060D50PT K22174207 C 1533 CHIP CAP. GRM39F105Z10PT K22105001 C 1534 CHIP TA.CAP. 10uF TEMSVA1A106M-8R K78100028...
  • Page 38 RF Unit (Ver. D) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR L 1014 M.RFC 0.39uH C1608CA-R39G L1691107 L 1015 CHIP COIL 0.017uH LQN1A17NJ04 L1690249 L 1016 M.RFC 0.1uH C1608CA-R10J L1691063 L 1017 COIL E2 0.35-1.6-4T-L L0022456 L 1018...
  • Page 39 RF Unit (Ver. D) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR Q 1511 TRANSISTOR 2SB1301-T2 ZQ G3213017Q Q 1512 TRANSISTOR RT1N241M-T11-1 G3070249 Q 1515 2SJ125D-T12-1D G3701257D Q 1516 TRANSISTOR RT1N241M-T11-1 G3070249 Q 1517 TRANSISTOR RT1N241M-T11-1 G3070249...
  • Page 40 RF Unit (Ver. D) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR R 1069 CHIP RES. 1/16W RMC1/16 183JATP J24185183 R 1069 CHIP RES. 8.2k 1/16W RMC1/16 822JATP J24185822 R 1070 CHIP RES. 4.7k 1/16W RMC1/16 472JATP J24185472...
  • Page 41 RF Unit (Ver. D) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR R 1138 CHIP RES. 1/16W RMC1/16 000JATP J24185000 R 1139 CHIP RES. 1/16W RMC1/16 101JATP J24185101 R 1140 CHIP RES. 1/16W RMC1/16 123JATP J24185123 R 1141 CHIP RES.
  • Page 42 RF Unit (Ver. D) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR R 1553 CHIP RES. 1/16W RMC1/16 473JATP J24185473 R 1554 CHIP RES. 1/16W RMC1/16 223JATP J24185223 R 1556 CHIP RES. 4.7k 1/16W RMC1/16 472JATP J24185472 R 1557...

  • Page 43: Rf-1- Unit

    RF-1-Unit (Ver. CS1) Circuit Diagram (1)
  • Page 44 RF-1-Unit (Ver. CS1) Circuit Diagram (2)
  • Page 45 RF-1-Unit (Ver. CS1) Parts Layout (side A) TDA2003H NJM2902V M5223 2SA1602A (MF) 2SB1301 (ZQ) 2SC4154 (E) 2SK508 (K52) IMH6A (H6) SGM2016AM (XR) RT1N241M (N2) HSM88AS (C1) (Q1509) (Q1503) (Q1003:Lot. 1~5) (Q1505) (Q1511) (Q1501) (Q1013) (Q1017) (Q1026) (Q1002, 1006, (D1011, 1012) (Q1003:Lot.
  • Page 46 RF-1-Unit (Ver. CS1) Parts Layout (Side B) RA30H4047M 2SB1201S (Q1014) (Q1005) 2SA1602A (MF) 2SC4116 (LG) 2SC5415E (EA) 2SB1132 (BA) DTB123EK (F12) IMH6A (H6) MM1216ENRE NJM78L05 PDTC114TE (24) RT1N241M (N2) MC2850 (A7) 1SS321 (F9) (Q1001) (Q1031) (Q1022) (Q1009) (Q1008) (Q1010) (Q1004) (Q1024) (Q1508, 1510) (Q1012, 1030,...
  • Page 47 RF-1-Unit (Ver. CS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR PCB with Components CB2728001 Printed Circuit Board AC031U000 FR010320B C 1001 CHIP CAP. 470pF GRM39CH471J50PT K22174249 14- A C 1002 CHIP CAP. 0.001uF 630V GHM1030R102K630PT K22281801...
  • Page 48 RF-1-Unit (Ver. CS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR C 1084 CHIP CAP. 0.001uF GRM39B102K50PT K22174821 14- B C 1085 CHIP CAP. 0.001uF GRM39B102K50PT K22174821 14- A C 1087 CHIP CAP. 470pF GRM39CH471J50PT K22174249 14- A...
  • Page 49 RF-1-Unit (Ver. CS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR C 1176 CHIP CAP. 220pF GRM39CH221J50PT K22174243 14- A C 1177 CHIP CAP. 0.001uF GRM39B102K50PT K22174821 14- B C 1178 CHIP TA.CAP. 10uF TEMSVA1A106M-8R K78100028 14- A...
  • Page 50 RF-1-Unit (Ver. CS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR C 1258 CHIP CAP. 470pF GRM39CH471J50PT K22174249 14- A C 1260 CHIP CAP. 470pF GRM39CH471J50PT K22174249 14- A C 1261 CHIP TA.CAP. 4.7uF TEMSVA1C475M-8R K78120031 14- B...
  • Page 51 RF-1-Unit (Ver. CS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR CD1001 CERAMIC DISC CDBC450CX24-TC H7901340 14- A CF1001 CERAMIC FILTER ALFYM450E-002S2=K H3900555 14- A CF1002 CERAMIC FILTER ALFYM450G-002S2=K H3900557 14- A D 1001 DIODE RLS135 TE-11 G2070128...
  • Page 52 RF-1-Unit (Ver. CS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR L 1037 M.RFC 0.068uH HK1608 68NJ-T L1690526 14- A L 1038 M.RFC 0.039uH HK1608 39NJ-T L1690523 14- A L 1039 M.RFC 0.047uH HK1608 47NJ-T L1690524 14- B L 1040...
  • Page 53 RF-1-Unit (Ver. CS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR R 1018 CHIP RES. 4.7k 1/16W RMC1/16 472JATP J24185472 14- A R 1019 CHIP RES. 4.7k 1/16W RMC1/16 472JATP J24185472 14- A R 1020 CHIP RES.
  • Page 54 RF-1-Unit (Ver. CS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR R 1095 CHIP RES. 1/16W RMC1/16 102JATP J24185102 14- A R 1096 CHIP RES. 1/16W RMC1/16 101JATP J24185101 14- B R 1097 CHIP RES. 1/16W RMC1/16 331JATP J24185331...
  • Page 55 RF-1-Unit (Ver. CS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR R 1512 CHIP RES. 4.7k 1/16W RMC1/16 472JATP J24185472 14- A R 1513 CHIP RES. 2.2k 1/16W RMC1/16 222JATP J24185222 14- A R 1514 CHIP RES.
  • Page 56 RF-1-Unit (Ver. CS1) Parts List Note DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR...

  • Page 57: Rf-2- Unit

    RF-2-Unit (Ver. DS1) Circuit Diagram (1)
  • Page 58 RF-2-Unit (Ver. DS1) Circuit Diagram (2)
  • Page 59 RF-2-Unit (Ver. DS1) Parts Layout (side A) TDA2003H NJM2902V M5223 2SA1602A (MF) 2SB1301 (ZQ) 2SC4154 (E) 2SK508 (K52) IMH6A (H6) SGM2016AM (XR) RT1N241M (N2) HSM88AS (C1) (Q1509) (Q1503) (Q1003:Lot. 1~5) (Q1505) (Q1511) (Q1501) (Q1013) (Q1017) (Q1026) (Q1002, 1006, (D1011, 1012) (Q1003:Lot.
  • Page 60 RF-2-Unit (Ver. DS1) Parts Layout (Side B) RA30H4452M 2SB1201S (Q1014) (Q1005) 2SA1602A (MF) 2SC4116 (LG) 2SC5415E (EA) 2SB1132 (BA) DTB123EK (F12) IMH6A (H6) MM1216ENRE NJM78L05 PDTC114TE (24) RT1N241M (N2) MC2850 (A7) 1SS321 (F9) (Q1001) (Q1031) (Q1022) (Q1009) (Q1008) (Q1010) (Q1004) (Q1024) (Q1508, 1510) (Q1012, 1030,...
  • Page 61 RF-2-Unit (Ver. DS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR PCB with Components CB2754001 Printed Circuit Board AC031U000 FR010320B C 1001 CHIP CAP. 470pF GRM39CH471J50PT K22174249 17- A C 1002 CHIP CAP. 0.001uF 630V GHM1030R102K630PT K22281801...
  • Page 62 RF-2-Unit (Ver. DS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR C 1084 CHIP CAP. 0.001uF GRM39B102K50PT K22174821 17- B C 1085 CHIP CAP. 0.001uF GRM39B102K50PT K22174821 17- A C 1087 CHIP CAP. 470pF GRM39CH471J50PT K22174249 17- A...
  • Page 63 RF-2-Unit (Ver. DS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR C 1177 CHIP CAP. 0.001uF GRM39B102K50PT K22174821 17- B C 1178 CHIP TA.CAP. 10uF TEMSVA1A106M-8R K78100028 17- A C 1179 CHIP CAP. 0.01uF GRM39B103M50PT K22174823 17- A...
  • Page 64 RF-2-Unit (Ver. DS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR C 1260 CHIP CAP. 470pF GRM39CH471J50PT K22174249 17- A C 1261 CHIP TA.CAP. 4.7uF TEMSVA1C475M-8R K78120031 17- B C 1262 CHIP CAP. 0.1uF GRM39B104K16PT K22124805 17- A...
  • Page 65 RF-2-Unit (Ver. DS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR L 1020 COIL E2 0.4-1.6-4T-L L0022855 17- A L 1021 M.RFC 0.39uH C1608CA-R39G L1691107 17- A L 1022 COIL E2 0.45-1.4-4T-L L0022391 17- B L 1023 COIL E2 0.35-1.6-4T-L...
  • Page 66 RF-2-Unit (Ver. DS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR R 1019 CHIP RES. 4.7k 1/16W RMC1/16 472JATP J24185472 17- A R 1020 CHIP RES. 1.2k 1/16W RMC1/16 122JATP J24185122 17- B R 1021 CHIP RES.
  • Page 67 RF-2-Unit (Ver. DS1) Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR R 1096 CHIP RES. 1/16W RMC1/16 101JATP J24185101 17- B R 1097 CHIP RES. 1/16W RMC1/16 331JATP J24185331 17- B R 1098 CHIP RES. 1/16W RMC1/16 102JATP J24185102...
  • Page 68 RF-2-Unit (Ver. DS1) Parts List Note DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR...

  • Page 69: Panel Unit

    PANEL Unit Circuit Diagram...
  • Page 70 PANEL Unit Note:...

  • Page 71: Panel Unit

    PANEL Unit Parts Layout (Side A) LC87F72C8A BU4066BF S-93C56AMFN LC73881M (Lot. 5~) S-80835CNMC 2SC4617 (BR) BRPG1211C DA221 (K) MC2846 (A4) (Q2013) (Q2024) (Q2011) (CONVENSIONAL) (Q2003) (Q2004, 2020) (D2004) (D2003, 2033, 2034) (D2011) (Q2027)
  • Page 72 PANEL Unit Parts Layout (Side B) AK2345 LA8630M NJM2902V NJM78L05 2SC4617 (BR) PDTC144EE (08) RT1N241M (N2) RT1P441U (P3) DA221 (K) (Q2016) (Q2017) (Q2015, 2021, 2022) (Q2006) (Q2001, 2002, (Q2019) (Q2008, 2010, 2025) (Q2009) (D2001, 2002, 2005, 2005, 2007) 2009, 2012, 2013, M62364FP 2036) (Q2014)
  • Page 73 Panel Unit Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR PCB with Component CB1732001 TYP D, LTR CB1732002 TYP D, CONVENTIONAL CB1732003 TYP CS-1, CONVENTIONAL CB1732004 TYP DS-1, CONVENTIONAL Printed Circuit Board FR007630E C 2001 CHIP CAP.
  • Page 74 Panel Unit Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR C 2076 CHIP CAP. GRM39F105Z10PT K22105001 C 2077 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 C 2081 CHIP CAP. 10pF UMK105CH100DW-F K22178258 C 2083 CHIP CAP. 820pF UMK105B821KW-F K22178828...
  • Page 75 J24189046 R 2060 CHIP RES. 1/16W RMC1/16S 103JTH J24189037 R 2061 CHIP RES. 330k 1/16W RMC1/16S 334JTH J24189055 R 2061 CHIP RES. 1.5M 1/16W RMC1/16S 155JTH J24189063 R 2061 CHIP RES. 820k 1/16W RMC1/16S 824JTH J24189060 Please contact VERTEX STANDARD.
  • Page 76 Panel Unit Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR R 2062 CHIP RES. 270k 1/16W RMC1/16S 274JTH J24189054 R 2063 CHIP RES. 180k 1/16W RMC1/16S 184JTH J24189052 R 2064 CHIP RES. 1/16W RMC1/16S 103JTH J24189037 R 2065 CHIP RES.
  • Page 77 Panel Unit Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR R 2151 CHIP RES. 1.5k 1/16W RMC1/16S 152JTH J24189027 R 2152 CHIP RES. 1/16W RMC1/16 000JATP J24185000 R 2153 CHIP RES. 470k 1/16W RMC1/16S 474JTH J24189057 R 2154 CHIP RES.
  • Page 78 Panel Unit Note:...
  • Page 79 Copyright 2004 VERTEX STANDARD CO., LTD. All rights reserved. No portion of this manual may be reproduced without the permission of VERTEX STANDARD CO., LTD.
