VHF FM Transceiver
VX-2100 Series
VX-2200 Series
Service Manual
©
2011 VERTEX STANDARD CO., LTD.
VX-2100 Series
Introduction
This manual provides the technical information necessary for servicing the VX-2100/-2200 Series Mobile Transceiver.
Servicing this equipment requires expertise in handing surface-mount chip components. Attempts by non-qualified
persons to service this equipment may result in permanent damage not covered by the warranty, and may be illegal
in some countries.
Two PCB layout diagrams are provided for each double-sided board in this transceiver. Each side of the board is
referred to by the type of the majority of components installed on that side ("Side A" or "Side B"). In most cases one
side has only chip components (surface-mount devices), and the other has either a mixture of both chip and leaded
components (trimmers, coils, electrolytic capacitors, ICs, etc.), or leaded components only.
As described in the pages to follow, the advanced microprocessor design of the VX-2100/-2200 allows a complete
alignment of this transceiver to be performed without opening the case of the radio; all adjustments can be performed
from the personal computer, using with the Vertex Standard VPL-1 Programming Cable and CE82 Software.
While we believe the information in this manual to be correct, Vertex Standard assumes no liability for damage that
may occur as a result of typographical or other errors that may be present. Your cooperation in pointing out any
inconsistencies in the technical information would be appreciated.
This transceiver was assembled using Pb (lead) free solder, based on the RoHS specification.
Only lead-free solder (Alloy Composition: Sn-3.0Ag-0.5Cu) should be used for repairs performed on this ap-
paratus. The solder stated above utilizes the alloy composition required for compliance with the lead-free
specification, and any solder with the above alloy composition may be used.
Specifications ........................................................... A-1
DSUB 15-pin Accessory Connector ...................... B-1
Block Diagram ......................................................... D-1
Circuit Description .................................................. E-1
Alignment ................................................................. F-1
Installation of Option ............................................ G-1
VX-2100/-2200 ( VHF ) Service Manual
EC061N90H
Important Note
Contents
Board Units (Schematics, Layouts & Parts)
MAIN-2 Unit (50 W: Lot. 33 ~) .......................... h-1
FRONT-A Unit ( VX-2100 ) ................................... I-1
FRONT-B Unit ( VX-2200 ) ................................... J-1
Optional Units (Schematics, Layouts & Parts)
VERTEX STANDARD CO., LTD.
4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan
VERTEX STANDARD U.S.A. Inc.
6125 Phyllis Drive, Cypress, California 90630, U.S.A.
YAESU UK LTD.
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
VERTEX STANDARD HK LTD.
Unit 1306-1308, 13F., Millennium City 2, 378 Kwun Tong Road,
Kwun Tong, Kowloon, Hong Kong
VERTEX STANDARD ( AUSTRALIA ) PTY., LTD.
Tally Ho Business Park, 10 Wesley Court, East Burwood, VIC, 3151
VX-2200 Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VX-2200 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Vertex Standard VX-2200 Series

  • Page 1: Table Of Contents

    Vertex Standard VPL-1 Programming Cable and CE82 Software. While we believe the information in this manual to be correct, Vertex Standard assumes no liability for damage that may occur as a result of typographical or other errors that may be present. Your cooperation in pointing out any inconsistencies in the technical information would be appreciated.
  • Page 2: Specifications

    Specifications (VTX/EXP Version) General Frequency Ranges: 134 -174 MHz Number of Groups: 1 groups (VX-2100 Series) 8 groups (VX-2200 Series) Number of Channels: 8 channels (VX-2100 Series) 128 channels (VX-2200 Series) Power Supply Voltage: 13.6 V ± 15% Channel Spacing: 6.25 / 12.5 / 25 kHz...
  • Page 3 Specifications (EU Version) General Frequency Ranges: 134 -174 MHz Number of Groups: 1 groups (VX-2100 Series) 8 groups (VX-2200 Series) Number of Channels: 8 channels (VX-2100 Series) 128 channels (VX-2200 Series) Power Supply Voltage: 10.8 - 15.6 V DC Channel Spacing: 12.5 / 20 / 25 kHz...
  • Page 4: Dsub 15-Pin Accessory Connector

    DSUB 15-pin Accessory Connector Pin 1: AF IN ( A Pin 6: EXT PTT NALOG NPUT External Microphone Input. Nominal input level is 6 Shorting this port to ground causes the transceiver to mV at 600-ohm. be placed in the Transmit mode, while opening the When connect the External Microphone to this port, connection to this port returns the transceiver to the insert a 0.1 μF coupling capacitor between the micro-...
  • Page 5: Exploded View & Miscellaneous Parts

    Exploded View & Miscellaneous Parts   VX-2100 FRONT PANEL   FRONT-A-UNIT RA0790200 TOP CASE RA0787600 RA080360A LIGHT GUIDE (x3 pcs) RA0841400 RUBBER PACKING BLIND SHEET  RA078750A HOLDER RA0800600 T9318283  SPONGE RUBBER  RA0845300 WIRE ASSY (RED) RUBBER KNOB This nut are attached to ...
  • Page 6 Exploded View & Miscellaneous Parts Note: VX-2100/-2200 ( VHF ) Service Manual...
  • Page 7: Block Diagram

    Block Diagram VX-2100/-2200 ( VHF ) Service Manual...
  • Page 8 Block Diagram Note: VX-2100/-2200 ( VHF ) Service Manual...
  • Page 9: Circuit Description

    Circuit Description 1. Circuit Configuration by Frequency 2-4. Audio amplifier Detected signal from Q1036 (NJM2591V) is inputted to The receiver is a double-conversion superheterodyne with Q1042 (LM2902PW) and is output through the band pass a first intermediate frequency (IF) of 67.65 MHz and a filter inside Q1042 (LM2902PW).
  • Page 10: Transmitter System

    Circuit Description 3. Transmitter System 3-4-1. VCO While the radio is receiving, the RX oscillator Q1029 3-1. Mic Amplifier (2SK508) in the VCO generates a programmed frequency There are two micrphone inputs, J1004 (front) and J1006 between 201.65 and 241.65 MHz as 1st local signal. While (D-Sub).
  • Page 11: Alignment

     Regulated DC Power Supply (standard 13.6V DC, 15A) ponent replacement and service should be performed only  Frequency Counter: ±0.2 ppm accuracy at 200 MHz by an authorized Vertex Standard representative, or the  AF Signal Generator warranty policy may be voided.
