AGA Legacy 44 User's Manual & Installation Instructions

Dual fuel range
Hide thumbs Also See for Legacy 44:
Table of Contents

Advertisement

Quick Links

See also: Installer and User Manual
Dual Fuel Range
Users Guide
&

Installation Instructions

This book contains many important safety messages.
Always read and obey all safety messages.
Installer:Leave these instructions with the appliance
U104011-05
www.agamarvel.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Legacy 44 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AGA Legacy 44

Summary of Contents for AGA Legacy 44

  • Page 1: Installation Instructions

    Dual Fuel Range Users Guide & Installation Instructions This book contains many important safety messages. Always read and obey all safety messages. Installer:Leave these instructions with the appliance U104011-05 www.agamarvel.com...
  • Page 2 WARNING If the information in this manual is not followed exactly, a re or explosion may result causing property damage, personal injury or death. Do not store or use gasoline or other ammable vapors and liquids in the vicinity of this or any other appliance. WHAT TO DO IF YOU SMELL GAS Do not try to light any appliance.

  • Page 3: Table Of Contents

    Using your Range Contents General Safety Instructions Page 08 Cooktop Burners Page 10 The Broiler Page 11 The Ovens Page 13 The Left-hand Multi-function Oven Page 13 The Right-hand Convection Oven Page 13 The Clock Page 14 Both ovens Page 16 Multi-function oven Page 17 Handyrack...

  • Page 4: Important Safety Information

    Read all instructions before using this appliance. Important Safety Information Save these instructions for future reference. Have your appliance properly installed In Case of Fire and grounded by a quali ed technician in Do not use water on grease res. Never pick up accordance with the National Electrical Code a aming pan.
  • Page 5 Read all instructions before using this appliance. Important Safety Information Save these instructions for future reference. unsafe for some items, such as volatile liquids, cleaners or aerosol sprays. Destroy the carton and plastic bags after Do Not Leave Children Alone unpacking the range.
  • Page 6 Read all instructions before using this appliance. Important Safety Information Save these instructions for future reference. Use dry oven gloves when applicable - using damp gloves might result in steam burns when you touch a hot surface. Never operate the range with wet hands.

  • Page 7: Cooktop Burners

    Read all instructions before using this appliance. Important Safety Information Save these instructions for future reference. liners may result in a risk of electric shock, or re and will damage the enamel nish. Never allow aluminum foil to contact the heating elements.

  • Page 8: General Safety Instructions

    Read all instructions before using this appliance. Important Safety Information Save these instructions for future reference. General Safety Instructions In the interests of hygiene and safety the range should be kept clean at all times as a build up in fats and other food stu could result in a re.
  • Page 9 Read all instructions before using this appliance. Important Safety Information Save these instructions for future reference. The range is designed for cooking foods only and must not be used for any other purpose. The oven should NOT be used for heating the kitchen, not only does this waste fuel but the control knobs may become overheated.

  • Page 10: Cooktop Burners

    Using your Range Cooktop Burners The drawing by each knob indicates which burner that knob controls. Each burner has a special safety device that stops the ow of gas if the ame goes out. Push in and turn a knob to the ( ) lighting position.
  • Page 11 Using your Range 3. Turn burner control knob to OFF position when nished. You can remove the burner cap and head for cleaning, see page 23. You should wipe the enamel top surface of the range around the cooktop burners as soon as possible after spills occur.

  • Page 12: The Broiler

    Using your Range The Broiler For best results preheat for 2 minutes with the broiler pan in position. After placing your food on the broiler pan grid, : Accessible parts may be hot when the AUTION slide the broiler carriage. Adjust the heat to suit by turning broiler is in use.

  • Page 13: The Ovens

    Using your Range The Ovens During use the appliance becomes hot. Care should be taken to avoid touching the heating elements inside the oven. The clock must be set to the time of day before the ovens will work. See ‘The Clock’ section for instructions on setting the time of day.

  • Page 14: The Clock

    Using your Range The Clock To stop the beeper when it sounds Turn the Adjusting knob counter clockwise Setting the time of day To stop automatically Use when you have started the oven manually. Turn the Setting knob to the ( ) position.
  • Page 15 Using your Range Turn the Setting knob to Keep holding the Setting the ( ) position. knob turned to the clock symbol [ ] and turn the The display will show the Adjusting knob clockwise current time of day plus until the key symbol the ‘cook period’...

  • Page 16: Both Ovens

    Using your Range Both ovens However, dishes can be ‘slowed down’ slightly by using small containers and covering them with aluminum foil, or ‘speeded up’ slightly by cooking Before using for the rst time, heat the ovens to smaller quantities or placing in larger containers. 400 °F for 30 minutes to expel manufacturing odors.

  • Page 17: Multi-Function Oven

    Using your Range Multi-function oven Convection oven The left hand oven of your range is Multi-function. It has many varied uses. We suggest you keep a This function operates the fan and the heating careful eye on your cooking until you are familiar element around it.

  • Page 18: Handyrack

    Using your Range Handyrack Conventional oven (top and base heat) This function combines the heat from the top and base elements. It is particularly suitable for roasting and baking pastry, cakes and biscuits. Food cooked on the top rack will brown and crisp faster than on the lower rack, because the heat is greater at the top of the oven than at the base, as in ‘Convection assisted oven’...

  • Page 19: Oven Racks

    Using your Range Oven racks Steam When cooking foods with high water content (e.g. oven fries) there may be some steam visible at the grille at the rear of the cooktop. This is perfectly normal. Oven light the rack guard should be at the back pointing upwards As well as the at racks some models are supplied with drop racks The drop racks increases the possibilities for oven rack spacing.

  • Page 20: Storage

    Using your Range Storage To refit the drawer Make sure the inner rail is forwards Pull the side runners fully out. Make sure the inner The bottom drawer is for storing oven trays and runner is forwards. other cooking utensils. It can get very warm, don’t store anything in it which may melt or catch re.

  • Page 21: Multi-Function (Left Hand) Oven Cooking Guide

    Using your Range Multi-function (Left-hand) Oven cooking guide Remember - not all modes will be suitable for all food types. The oven control settings and cooking times given are intended to be used only as a guide. Individual tastes may require the temperature to be altered to provide a preferred result.

  • Page 22: Cooking Chart

    Using your Range Cooking chart Conventional Oven Convection Oven Approximate Cooking Time Rack Food Temp Position Temp FISH 375°F 350°F Fillets 15-20mins. 375°F 350°F Whole 10mins.per lb + 10mins. 375°F 350°F Steaks according to thickness. ROAST MEATS Beef with bone 325°F 300°F 20-25mins.

  • Page 23: Cleaning Your Range

    Using your Range Cleaning your Range The central cooktop Essential information Before thorough cleaning isolate the electricity supply. Remember to switch on the electricity supply before use. Never use paint solvents, caustic cleaners, biological powders, bleach, chlorine based bleach cleaners, coarse abrasives or salt. Don’t mix di erent cleaning products - they may react together with hazardous results.

  • Page 24: Control Panel And Doors

    Using your Range electrode notch ignition electrode Now t the two trim rings, making sure that they are sitting down properly. Control Panel and Doors The control panel and control knobs should only be cleaned with a soft cloth wrung out in clean hot soapy water - but take care that no surplus water seeps into the appliance.
  • Page 25 Using your Range Cleaning the Broiler The side rails can be removed to make cleaning the broiler chamber easier by unhooking them from Before you remove any of the broiler parts for the broiler chamber sides. cleaning make sure that they are cool. Slides can be wiped clean with soft cloth and mild The broiler pan and grid should be washed in hot detergent.
  • Page 26 Using your Range not to disturb or wet the door insulation. Please note that the door is triple glazed but the inner two panels are xed. Do not try to remove the glass from the door. After cleaning carefully re t the outer door panel and replace the side xing screws.
  • Page 27 Using your Range Cleaning chart All Parts listed here can be cleaned using hot soapy water (dishwashing liquid detergent) and a soft cloth. For more di cult cleaning, follow the appropriate instruction. Check cleaner manufacturers guidelines for compatibility with the material of your range. Part Finish How to clean...

  • Page 28: Troubleshooting

    Using your Range Troubleshooting If you are cooking a large item, be prepared to turn it round during cooking. If two racks are used, check that space has been left Steam is coming from the oven for the heat to circulate. When a baking sheet is put When cooking foods with a high water content (e.g.
  • Page 29 Using your Range Make sure the oven is cool. Open the oven door and remove the Handyrack (if tted) and oven racks. Turn off the power supply. Unscrew the bulb cover by turning counter clockwise. Unscrew the old bulb. Screw in the new bulb, screw back the bulb cover.

  • Page 30: Service And Spares

    It may also be of bene t to keep Technical Services Dept. Aga-Ranges Inc. your purchase receipt with this lea et. You may be required to produce the receipt to validate a AGA Marvel warranty eld visit.

  • Page 31: Installation

    Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. Installation This book contains many important safety messages. Always read and obey all safety messages. Installer: Leave these instructions with the appliance...
  • Page 32 WARNING If the information in this manual is not followed exactly, a re or explosion may result causing property damage, personal injury or death. Do not store or use gasoline or other ammable vapors and liquids in the vicinity of this or any other appliance. WHAT TO DO IF YOU SMELL GAS Do not try to light any appliance.
  • Page 33 Installation Regulations Page 34 If you smell gas Page 34 Tools Page 34 Materials Page 34 Installation Safety Instructions Page 35 Dimensions and clearances Page 36 Location guidelines Page 37 Moving the Range Page 37 Checking the parts Page 38 Leveling the Range Page 38 Anti-Tip Device...

  • Page 34: Regulations

    Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. Regulations Tools Installation of this range must conform with local You will need the following tools codes, or in the absence of local codes, with the 1.

  • Page 35: Installation Safety Instructions

    Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. Installation Safety Caution Items of interest to children should not be stored Instructions above a range - children climbing on the range to reach items could be seriously injured.

  • Page 36: Dimensions And Clearances

    Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. Dimensions and Clearances The maximum depth for cabinets installed above cooktops is 13’’ . Provide adequate clearances between the If the range is to be installed between 24’’ deep range and adjacent combustible surfaces.

  • Page 37: Location Guidelines

    Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. Location Guidelines Do not locate the range where it may be subject to strong drafts. Any openings in the oor or wall behind the range should be sealed. Make sure the openings around the base of the range that supply fresh air for combustion and ventilation are not obstructed by carpeting or woodwork.

  • Page 38: Checking The Parts

    Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. Checking the parts Check that the range has the following parts. 4 grates Broiler pan and grid ArtNo.010-0010 Lowering the rear rollers (90) Rear spacer Handyrack Make 10 complete (360°) turns clockwise.

  • Page 39: Anti-Tip Device

    Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. Leveling the Range Gas Connection Place the range in its intended position taking care Installation of this range must conform with local not to twist it within the gap between the kitchen codes or, in the absence of local codes, with the units as damage may occur to the range or the National Fuel Gas Code, ANSI Z223.1-latest edition.

  • Page 40: Check For Gas Leaks

    Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. The range is designed to operate at a manifold *Te on: Registered trademark of DuPont pressure of 4’’ of water column on natural gas. A A Install a manual gas line shut-o valve in the gas conversion kit for LP gas (propane or butane) is line in an easily accessed location outside of the...

  • Page 41: Electrical Connection

    Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. Electrical Connection Flexible Connector When installed the range must be electrically grounded in accordance with local codes or; in the absence of local codes with the National Electrical Code ANSI/NFPA 70, latest edition.
  • Page 42 Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. Recommended Electrical Outlet Locations Locate the electric supply as illustrated. Recommended acceptable electrical outlet area. Orient the electrical receptacle so the length is parallel to the oor. Slide the cover down to free the side tags.
  • Page 43 Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. A Ground strap is supplied in the conversion pack. ground strap. Fit the Ground strap to the ground and center terminal of the connector block - see the gure. Fit the wires to the ground post and terminal block NOTE: Make sure the wires are completely inserted into the terminals and secure connections are...
  • Page 44 Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. Seal the Openings Seal any openings in the wall behind the range and in the oor under the range when hookups are completed. When all Connections are Completed MAKE SURE THE FLOW OF COMBUSTION AND VENTILATION AIR TO THE RANGE IS...

  • Page 45: Assemble The Range

    Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. Assemble the Range Fit the Door Handles Remove the 4mm Hex headed screws from the doors with the hexagon key tool. Use the screws to t the door handles.
  • Page 46 Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. Assemble the Grates Screw the rear stays to the range back. Note: the stays are of di erent lengths. If you are not tting the splashback the splashback mounting holes can be blocked with the extra screws supplied.

  • Page 47: Range Operational Checks

    Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. To Adjust the Oven Door Angle Turn on the oven and check that the oven fan starts to turn and that the oven starts to heat up. Turn o The door bottom hinge can be adjusted to alter the oven.

  • Page 48: How To Remove The Range For Servicing

    SERVICING WARNING Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. How to Remove the Range for Servicing Follow these procedures to remove appliance for servicing: The range is very heavy. Take great care. We Normal ame appearance Burner not tted correctly recommend two people maneuver the range.

  • Page 49: Conversion To Propane

    SERVICING WARNING Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. Conversion to Propane Shut o the gas supply and disconnect electrical supply to appliance. Disconnect gas supply tubing to appliance and unplug the electrical supply cord. This appliance is supplied set for Natural gas.
  • Page 50 SERVICING WARNING Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. Valve adjustment Pull o all the control knobs. If the hand rail has been tted remove it - remove the plastic blanking plugs and remove the 2 end bracket xing screws. Remove the 2 cross headed screws that were hidden by the hand rail end brackets.

  • Page 51: Pressure Testing

    SERVICING WARNING Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. Stick on label Type 1 Unscrew the hexagonal nut in the front of the Stick the appropriate label on to the data badge to regulator.
  • Page 52 Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference.

  • Page 53: Schematic Diagram Of The Range

    Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference.
  • Page 54 Read all instructions before installing or using this appliance. Installation Instructions Save these instructions for future reference. Orifices A Wok burner B Large Burner C Medium Burners A valve bypass screw D Small Burner Ratings Natural Gas Propane Gas Ori ce Screw* Ori ce Screw* Cooktop...

  • Page 55: Technical Data
