Lock Interface Overview
Key Insertion
LockUp Logo must be
upright and facing to the left
Pull Handle
Key Guide:
Manager Flex Key (black)
• Provides management access
• Provides external power
• Each lock accepts up to (25) Manager Flex Key(s)
• Minimum of (1) required per location
Key Insert
1 2 3
4 5 6
7 8 9
C 0
C Button Key Symbol Button
ADA User Key (Blue)
• ADA Compliant User Key
• Optional
13
LED Usage Indicator
Numeric Keypad
