Summary of Contents for Comprehensive CSW-HD440EXT
- Page 1 USER MANUAL CSW-HD440EXT Table of Contents 1.0 Introduction................1 2.0 Specifications...............2 3.0 Package Contents..............2 4.0 Panel Descriptions...............3 5.0 Connection and Operation..........3 C a b l e a n d C o n n e c t i v i t y C o m p a n y...
- Page 2 HDMI SWITCH SPLITTER 4×4 （matrix）by Cat5 HDMI SWITCH SPLITTER Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. 1.0 INTRODUCTION This 4X4 Matrix HDMI SWITCH SPLITTER by cat5e/6 offers unprecedented flexibility and convenience by routing high definition audio/video from any of four...
-
Page 3: Specifications
HDMI S WITCH S PLITTER 4 4 ! matrix" by Cat5 2.0 SPECIFICATIONS Signal Inputs/Output HDMI Connector type A 19 pin female Input DDC Signal 5 volts p-p (TTL) Control Port RS-232 Female, Mini-Stereo Output Signal HDMI output, UTP output Operating Frequency Vertical Frequency Range 50/60Hz... -
Page 4: Panel Descriptions
HDMI SWITCH SPLITTER 4×4 （matrix）by Cat5 2) Remote Control 3) IR extension cable.(IR) 4) 5.5V@4A DC Power Supply 5) User’s Manual. Packaging of Accessories 6) Four Receivers 7) Four pieces of Remote Control for Receivers 8) Four pieces of External infrared emitter (IE) 9) Four pieces of 5V DC @2A Power Supply. - Page 5 HDMI SWITCH SPLITTER 4×4 （matrix）by Cat5 receivers and main unit over cat5e/6 cable, and then connect output of receivers to displays. (Note: HDMI and UTP of each output can not be connected simultaneously) 3) Connect the 5.5V@4A power supply to the Switch Splitter, and 5V@2A power supply to each receiver.
- Page 6 HDMI SWITCH SPLITTER 4×4 （matrix）by Cat5 parameter as follow: Baud frequency：4800 Data bit: 8 Parity bit: N Stop bit: 1 Data stream: NON C. Inputting your instruction. The instruction should be two or three letter, and finish with “Enter” button. Please input next instruction in three seconds or the”Overtime instruction”...
- Page 7 HDMI S WITCH S PLITTER 4 4 ! matrix" by Cat5 5.3 CONECTION DIAGRAM 55 Ruta Ct. South Hackensack, NJ 07606 Toll Free: 800 526-0242 Email: sales@comprehensivecable.com customerservice@comprehensivecable.com www.comprehensivecable.com...
