protech Prox-1720 User Manual

Pentium 4 full-size cpu card with vga/sound/lan
Hide thumbs
Table of Contents

Advertisement

Quick Links

USER'S
MANUAL
Prox-1720 M0
ProX-1720
Pentium
4
®
Full-size CPU Card
With VGA/Sound/LAN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Prox-1720 and is the answer not in the manual?

Questions and answers

Related Manuals for protech Prox-1720

Summary of Contents for protech Prox-1720

  • Page 1 USER’S MANUAL ProX-1720 Pentium ® Full-size CPU Card With VGA/Sound/LAN Prox-1720 M0...
  • Page 2 Copyright Notice Prox-1720 Pentium® 4 Full-size CPU Card With VGA/Sound/LAN OPERATION MANUAL COPYRIGHT NOTICE This operation manual is meant to assist both Embedded Computer manufacturers and end users in installing and setting up the system. The information contained in this document is subject to change without any notice.
  • Page 3 Copyright Notice FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual ............System Specification ............Safety Precautions ............CHAPTER 2 HARDWARE CONFIGURATION Jumper & Connector Quick Reference Table ....Component Locations ............ How to Set the Jumpers ..........COM Port Connector ……..…………………………... RS232/422/485 (COM2) Selection .......
  • Page 5 Contents 2-30 ATX +12V Power Connector ......... 2-26 2-31 Memory Installation …..……………………….………. 2-26 2-32 Reset / NMI / Clear Watchdog Selection ……….…….. 2-27 2-33 Sound Connector ………………………………………. 2-28 2-34 CD-IN Connector ……………………………………… 2-28 2-35 PPCI Connector ……………….……………….………. 2-29 2-36 Compact Flash Card Master/Slave Selection ………….. 2-30 CHAPTER 3 SOFTWARE UTILITIES Introduction …………..........…..
  • Page 6 Contents APPENDIX A EXPANSION BUS ISA Bus Pin Assignment ..........…..PCI Bus Pin Assignment ..........…..APPENDIX B TECHNICAL SUMMARY Block Diagram ................Interrupt Map ................RTC & CMOS RAM Map ............Timer & DMA Channels Map ..........I/O & Memory Map ..........…....APPENDIX C TROUBLE SHOOTING Trouble Shooting for Error Messages ......…....
  • Page 7 Contents...

  • Page 8: Chapter 1 Introduction

    CHAPTER INTRODUCTION This chapter gives you the information for Prox-1720. It also outlines the System specification. Section includes: About This Manual System Specifications Safety precautions Experienced users can skip to chapter 2 on page 2-1 for Quick Start. Page:1-1...

  • Page 9: About This Manual

    Chapter 1 Introduction 1-1. ABOUT THIS MANUAL Thank you for purchasing our Prox-1720 Socket 478 Embedded Card enhanced with VGA / Sound / LAN, which is fully PC / AT compatible. Prox- 1720 provides faster processing speed, greater expandability and can handle more task than before.

  • Page 10: System Specification

    One additional 5-pin External keyboard connector UNIVERSAL SERIAL BUS : Universal Serial Bus Connector on board Supports up to four USB 2.0 ports. DISK-ON-CHIPS SOCKET : One 32-pin socket supports up to 288MB disk-on-chip. ′ Page: 1-3 Prox-1720 USER S MANUAL...
  • Page 11 Programmable Baud Rate Generator SOUND INTERFACE : AC '97 Codec. Fully Compliant AC '97 Analog I/O Component Interface: Line-In, Line-Out, Microphone, and CD Audio-In. PARALLEL PORT : One port supports SPP / ECP / EPP Function. ′ Page: 1-4 Prox-1720 USER S MANUAL...
  • Page 12 DC Voltage: +5V, minimum +4.75V, maximum +5.25V. DC Ampere: 2.5A. DC Voltage: +12V, minimum +11.4V, maximum +12.6V. DC Ampere: 4.7A. BOARD DIMENSION : 338.5mm x 122mm (13.3” x 4.8”) BOARD NET WEIGHT : 420 grams (0.92 lb) ′ Page: 1-5 Prox-1720 USER S MANUAL...

  • Page 13: Safety Precautions

    3. Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. ′ Page: 1-6 Prox-1720 USER S MANUAL...

  • Page 14: Chapter 2 Hardware Configuration

    CHAPTER HARDWARE CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. Section includes: Jumper & Connector Quick Reference Table Component Locations Configuration and Jumper settings Connector’s Pin Assignments Page 2-1...

  • Page 15: Jumper & Connector Quick Reference Table

    ATX +12V Power Connector …………………………. Memory Installation ........…..……… DIMM1, DIMM2 Reset/NMI/Clear Watchdog Selection .………….…….. Sound Connector ………………………….…………… CD Audio-In Connector ……………………………….. CD-IN PPCI Connector ……………..………………….……… PPCI Compact Flash Card Master/Slave Selection ………….. Reserved Pin …………………………………………... JP12 ′ Page: 2-2 Prox-1720 USER S MANUAL...

  • Page 16: Component Locations

    Chapter 2 Hardware Configuration 2-2. COMPONENT LOCATIONS Prox-1720 Connector, Jumper and Component locations ′ Page: 2-3 Prox-1720 USER S MANUAL...

  • Page 17: How To Set The Jumpers

    You can connect PIN1 & PIN2 to create one setting and shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. ′ Page: 2-4 Prox-1720 USER S MANUAL...
  • Page 18 Jumper Block looks like this JUMPER SETTINGS 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this ′ Page: 2-5 Prox-1720 USER S MANUAL...

  • Page 19: Com Port Connector

    NSINA NSOUTA NDTRA NDSRA COM1 NRTSA NCTSA NRIA COM2 : COM2 Connector The COM2 is selectable as RS-232/422/485. The pin assignment is as follows : ASSIGNMENT RS-232 RS-422 RS-485 RTS- RTS+ CTS+ CTS- ′ Page: 2-6 Prox-1720 USER S MANUAL...

  • Page 20: Rs232/422/485 (Com2) Selection

    COM 2 Function Jumper Settings (pin closed) Jumper Illustrations RS-232 Open 1-2, 5-6, 7-8 RS-422 9-10, 11-12, 13-14 15-16, 17-18, 19-20 1-3, 4-6, 7-8, 9-10 RS-485 11-12, 13-14, 15-16 17-18, 19-20 *** Manufactory default --- RS-232. ′ Page: 2-7 Prox-1720 USER S MANUAL...

  • Page 21: Solid-State Disk Socket

    Chapter 2 Hardware Configuration 2-6. SOLID-STATE DISK SOCKET SSD: 32pin Disk-on-chip Socket The pin assignments are as follows: ASSIGNMENT ASSIGNMENT SA12 SA10 SA11 SA13 SA14 ′ Page: 2-8 Prox-1720 USER S MANUAL...

  • Page 22: Ssd Memory Mapping Selection

    Flash ROM SSD can be install as one of user’s hard disk drive. The SSD Memory Mapping Selections are as follows: JUMPER SETTING JUMPER (pin closed) SSD Memory Map ILLUSTRATION CC000h-CDFFFh D0000h-D1FFFh D4000h-D5FFFh D8000h-D9FFFh DC000h-DDFFFh *** Manufactory default --- CC000h--CDFFFh. ′ Page: 2-9 Prox-1720 USER S MANUAL...

  • Page 23: Keyboard Or Ps/2 Mouse Connector

    For Y-Cable user, please set the jumper same as AT keyboard. The jumper settings are as follows: JUMPER SETTING DEVICE JUMPER (pin closed) TYPE ILLUSTRATION KEYBOARD JP11 PS/2 MOUSE JP11 *** Manufactory default -- AT Keyboard ′ Page: 2-10 Prox-1720 USER S MANUAL...

  • Page 24: External Keyboard Connector

    EXKB : External Keyboard Connector The pin assignment is as follows : ASSIGNMENT KBCLK KBDATA EXKB 2-11. RESET CONNECTOR JP1 (18,20) : Reset Connector. The pin assignment is as follows : ASSIGNMENT HW RESET GROUND ′ Page: 2-11 Prox-1720 USER S MANUAL...

  • Page 25: Hard Disk Drive Led Connector

    JP1 (12,14) : Hard Disk Drive LED Connector The pin assignment is as follows : HDD_LED ASSIGNMENT HDD_LED 2-13. ATX POWER BUTTON JP1 (13,15) : ATX Power Button The pin assignment is as follows : ATX_BTN ASSIGNMENT PWR_BN1 PWR_BN2 ′ Page: 2-12 Prox-1720 USER S MANUAL...

  • Page 26: External Speaker Connector

    JP1 (2,4,6,8) : External Speaker Connector The pin assignment is as follows : ASSIGNMENT SPEAKER SIGNAL 2-15. POWER LED CONNECTOR JP1 (1,3,5) : Power LED Connector The pin assignment is as follows: PWR_LED ASSIGNMENT PW_LED PW_LED ′ Page: 2-13 Prox-1720 USER S MANUAL...

  • Page 27: Keylock Connector

    Note: To clear CMOS data, user must power-off the computer and set the jumper to “Clear CMOS” as illustrated above. After five to six seconds, set the jumper back to “Normal” and power-on the computer. ′ Page: 2-14 Prox-1720 USER S MANUAL...

  • Page 28: Cpu Fan Connector

    2-18. CPU FAN CONNECTOR FAN1 : CPU Fan connector The pin assignment is as follows: ASSIGNMENT FAN1 +12V 2-19. SYSTEM FAN CONNECTOR FAN2 : System Fan connector The pin assignment is as follows: FAN2 ASSIGNMENT +12V ′ Page: 2-15 Prox-1720 USER S MANUAL...

  • Page 29: Vga Crt Connector

    Chapter 2 Hardware Configuration 2-20. VGA CRT CONNECTOR VGA : VGA CRT Connector The pin assignments are as follows: ASSIGNMENT GREEN BLUE VGA DDA HSYNC VSYNC VGA DDC CLK ′ Page: 2-16 Prox-1720 USER S MANUAL...

  • Page 30: Dvo Connector

    The pin assignments are as follows : DVO1 ASSIGNMENT ASSIGNMENT VCC12 DVOC_BLANK# DVOC_D5 DVOC_FLDSTL DVOC_D6 DVOC_CLK VCC 3_3 DVOC_D7 DVOC_D0 DVOC_CLK# VCC3_3 DVOC_D8 DVOC_D1 DVOC_VSYNC VDDQ DVOC_D9 DVOC_D2 DVOC_HSYNC 5VFTSDA DVOC_D10 DVOC_D3 MDVI_CLK 5VFTSCL DVOC_D11 DVOC_D4 MDVI_DATA ′ Page: 2-17 Prox-1720 USER S MANUAL...
  • Page 31 The pin assignments are as follows : DVO2 ASSIGNMENT ASSIGNMENT DVOBC_INTR# DVOB_BLANK# DVOB_D5 DVOB_FLDSTL DVOB_D6 DVOB_CLK PCIRST# DVOB_D7 DVOB_D0 DVOB_CLK# MI2C_CLK DVOB_D8 DVOB_D1 DVOB_VSYNC MI2C_DATA DVOB_D9 DVOB_D2 DVOB_HSYNC MDDC_CLK DVOB_D10 DVOB_D3 DVOB_CCLKINT# MDDC_DATA DVOB_D11 DVOB_D4 GAGPREF ′ Page: 2-18 Prox-1720 USER S MANUAL...

  • Page 32: Hard Disk Drive Connector

    Chapter 2 Hardware Configuration 2-22. HARD DISK DRIVE CONNECTOR IDE1: Hard Disk Drive Connector The Prox-1720 possesses two HDD connectors, IDE1 and IDE2. The pin assignments are as follows: IDE1 ASSIGNMENT ASSIGNMENT IDERST PDD7 PDD8 PDD6 PDD9 PDD5 PDD10 PDD4...
  • Page 33 IDERST SDD7 SDD8 SDD6 SDD9 SDD5 SDD10 SDD4 SDD11 SDD3 SDD12 SDD2 SDD13 SDD1 SDD14 SDD0 SDD15 SDREQ SDIOW# SDIOR# SIORDY PULL LOW SDDACK# IRQ15 SDA1 S66 DETECT SDA0 SDA2 SDCS#1 SDCS#3 IDEACTS# ′ Page: 2-20 Prox-1720 USER S MANUAL...

  • Page 34: Floppy Disk Drive Connector

    34-pin flat cable to attach the FDD on the board, and the other side is attaches two FDDs. The pin assignments are as follows : FDD1 ASSIGNMENT ASSIGNMENT RWC# DS1# INDEX MOA# DSB# DSA# MOB# DIR# STEP# TRK0# RDATA# HEAD# DSKCHG ′ Page: 2-21 Prox-1720 USER S MANUAL...

  • Page 35: Printer Connector

    As to link the Printer to the card, you need a cable to connect both DB25 connector and parallel port. The pin assignments are as follows : LPT1 ASSIGNMENT ASSIGNMENT AFD# PDR0 ERROR# PDR1 PAR_INIT# PDR2 SLIN# PDR3 PDR4 PDR5 PDR6 PDR7 ACK# BUSY SLCT ′ Page: 2-22 Prox-1720 USER S MANUAL...

  • Page 36: Universal Serial Bus Connector

    Chapter 2 Hardware Configuration 2-25. UNIVERSAL SERIAL BUS CONNECTOR USB1: Universal Serial Bus Connector The Prox-1720 possesses two USB connectors, USB1 and USB2. The pin assignments are as follows: ASSIGNMENT DATA0− DATA0+ USB1 DATA1− DATA1+ USB2: Universal Serial Bus Connector...

  • Page 37: Irda Connector

    LED – SP LED PULL HI Green LED – LI LED Yellow LED – ACT LED The green LED detect power link, and the Yellow LED is used to detect data active transfer signal. ′ Page: 2-24 Prox-1720 USER S MANUAL...

  • Page 38: Atx Power Connector

    PW1 : ATX Power Connector The pin assignments are as follows: ASSIGNMENT VCC12 VCC5_SB PS_ON 2-29. ATX POWER SIGNAL CONNECTOR JP6 : ATX Power Signal Connector The pin assignments are as follows: ASSIGNMENT +5V SB PS_ON ′ Page: 2-25 Prox-1720 USER S MANUAL...

  • Page 39: Atx +12V Power Connector

    CN1 : ATX +12V Power Connector The pin assignments are as follows: ASSIGNMENT +12V +12V 2-31. MEMORY INSTALLATION Prox-1720 CPU Card can support up to 2GB in two DIMM sockets. DRAM BANK CONFIGURATION DIMM 1 DIMM 2 TOTAL MEMORY 128MB...

  • Page 40: Reset/Nmi/Clear Watchdog Selection

    Non-Maskable Interrupt, is used for serious conditions that demand the processor’s immediate attention, it cannot be ignored by the system unless it is shut off specifically. To clear NMI command, user should short the “Clear Watchdog” pin via push button. ′ Page: 2-27 Prox-1720 USER S MANUAL...

  • Page 41: Sound Connector

    This connector is to be connected to W-Sound Adapter Card, for more information, please refer to Appendix A. 2-34. CD Audio-IN CONNECTOR CD-IN : CD Audio-In Connector The pin assignments are as follows: ASSIGNMENT CD-IN AUX L AUX R ′ Page: 2-28 Prox-1720 USER S MANUAL...

  • Page 42: Ppci Connector

    Chapter 2 Hardware Configuration 2-35. PPCI CONNECTOR You will find a PPCI connector in our Prox-1720. This connector is used to connect our SCSI daughter boards. The pin assignments are as follows: PPCI ASSIGNMENT ASSIGNMENT AD10 AD11 AD12 AD13 AD14...

  • Page 43: Compact Flash Card Master/Slave Selection

    Chapter 2 Hardware Configuration 2-36. CF CARD MASTER/SLAVE SELECTION JP2 : Compact Flash Card Master/Slave Selection. The selections are as follows: JUMPER JUMPER SETTING FUNCTION ILLUSTRATION (pin closed) Master Slave Open ′ Page: 2-30 Prox-1720 USER S MANUAL...

  • Page 44: Chapter 3 Software Utilities

    CHAPTER SOFTWARE UTILITIES This chapter comprises the detailed information of VGA driver, LAN driver, and Flash BIOS update. It also describes how to install the watchdog timer configuration. Section includes: VGA Driver Utility Flash BIOS Update LAN Driver Utility Sound Driver Utility Intel®...

  • Page 45: Introduction

    Chapter 3 Software Configuration 3-1. INTRODUCTION Enclosed with our Prox-1720 package is our driver utility, which may comes in a form of a CD ROM disc or floppy diskettes. For CD ROM disc user, you will only need some of the files contained in the CD ROM disc, please...

  • Page 46: Vga Driver Utility

    Chapter 3 Software Configuration 3-2. VGA DRIVER UTILITY The VGA interface embedded with our Prox-1720 can support a wide range of display. You can display CRT, LVDS and PanelLink™ simultaneously with the same mode. 1. Win 9X program 2. Win NT4.0 program 3.

  • Page 47: Flash Bios Update

    Utility Disk for system BIOS and VGA BIOS update. 3-3-2. To update VGA BIOS for LCD Flat Panel Display: As Prox-1720 user, you have to update the VGA BIOS for your specific LCD flat panel you are going to use. For doing this, you need two files.
  • Page 48 File Name to Program: H20bxxxx.bin Checksum: XXXXX Reset System or Power off to accomplish update process! F1: Reset F10: Exit Please reset or power off the system, and then the Flash BIOS is fully implemented. ′ Page:3-5 Prox-1720 USER S MANUAL...

  • Page 49: Lan Driver Utility

    Chapter 3 Software Configuration 3-4. LAN DRIVER UTILITY 3-4-1. Introduction Prox-1720 is enhanced with LAN function that can support various network adapters. Installation programs for LAN drivers are listed as follows: 1. Win 2000/XP program 2. Win NT4.0 program 3. Linux 4.

  • Page 50: Sound Driver Utility

    “D:\Sound\pathname” refers to the full path to the source files. 3. Click on the OK button or press the ENTER key. 4. Click on the “Next” and OK prompts as they appear. 5. Reboot the system to complete the driver installation. ′ Page:3-7 Prox-1720 USER S MANUAL...

  • Page 51: Intel Chipset Software Installation Utility

    3. Click Setup.exe file for utility installation. 4. Follow the instructions on the screen to complete the installation. 5. Once installation is completed, shut down the system and restart in order for the changes to take effect. ′ Page:3-8 Prox-1720 USER S MANUAL...

  • Page 52: Usb2.0 Software Installation Utility

    5. Double Click “USB Root Hub”. 6. Select “Driver”. 7. Click “Install” to install the driver. 8. Follow the instructions on the screen to complete the installation. 9. Click “Finish” after the driver installation is complete. ′ Page:3-9 Prox-1720 USER S MANUAL...

  • Page 53: Scsi And Storage_Ata Software Installation

    5. Double Click “SCSI Controller”. 6. Select “Driver”. 7. Click “Install” to install the driver. 8. Follow the instructions on the screen to complete the installation. 9. Click “Finish” after the driver installation is complete. ′ Page:3-10 Prox-1720 USER S MANUAL...
  • Page 54 3. Click Setup.exe file for driver installation. 4. Follow the instructions on the screen to complete the installation. 5. Once installation is completed, shut down the system and restart in order for the changes to take effect. ′ Page:3-11 Prox-1720 USER S MANUAL...

  • Page 55: Watchdog Timer Configuration

    I/O port 441H, the system will run the command to stop the Watchdog function. In Prox-1720 watchdog function, you must write your program so when it writes I/O port address 443 for enable watchdog and write I/O port address 441 for disable watchdog.

  • Page 56: Chapter 4 Award Bios Setup

    CHAPTER AWARD BIOS SETUP This chapter shows how to set up the Award BIOS. Section includes: Introduction Entering Setup The Standard CMOS Features The Advanced BIOS Features The Advanced Chipset Features Integrated Peripherals Power Management Setup PNP/PCI Configuration PC Health Status Frequency Control Load Fail-Safe Defaults Load Optimized Defaults...

  • Page 57: Introduction

    4-1. INTRODUCTION This chapter will show you the function of the BIOS in managing the features of your system. The Prox-1720 Pentium® 4 Full-size CPU Card is equipped with the BIOS for system chipset from Award Software Inc. This page briefly explains the function of the BIOS in managing the special features of your system.

  • Page 58: Entering Setup

    You may use the cursor the up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. ′ Page: 4-3 Prox-1720 USER S MANUAL...

  • Page 59: The Standard Cmos Features

    < Hour >, < Minute >, and < Second >. Use 24 hour clock format, i.e., for PM numbers, add 12 to the hour. For example: 4: 30 P.M. You should enter the time as 16:30:00. ′ Page: 4-4 Prox-1720 USER S MANUAL...
  • Page 60 Head – Set the number of read/write heads. c. Precomp - ***Warning! Setting a value of 65535 means no HDD. d. Landing Zone e. Sector – Set the number of sector per track ′ Page: 4-5 Prox-1720 USER S MANUAL...
  • Page 61 BASE MEMORY: Displays the amount of conventional memory detected during boot up. EXTENDED MEMORY: Displays the amount of extended memory detected during boot up. TOTAL MEMORY: Displays the total memory available in the system. ′ Page: 4-6 Prox-1720 USER S MANUAL...
  • Page 62 1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 65535 1023 65535 1024 65535 1023 1024 65535 1023 65535 65535 65335 AUTO Award Hard Disk Type Table ′ Page: 4-7 Prox-1720 USER S MANUAL...

  • Page 63: The Advanced Bios Features

    This item allows you to choose the Virus Warning feature for IDE Hard Disk boot sector protection. If this function is enabled and someone attempt to write data into this area, BIOS will show a warning message on screen and alarm beep. ′ Page: 4-8 Prox-1720 USER S MANUAL...
  • Page 64 For example, if you press and hold down the "A" key, the letter "a" will repeatedly appear on your screen on your screen until you release the key. When enabled, the typematic rate and typematic delay can be selected. ′ Page: 4-9 Prox-1720 USER S MANUAL...
  • Page 65 Setup freely. OS SELECT FOR DRAM >64MB : Select the operating system that is running with greater than 64MB or RAM on the system. You may choose OS2 or Non-OS2. ′ Page: 4-10 Prox-1720 USER S MANUAL...

  • Page 66: Advanced Chipset Features

    The default settings have been chosen because they provide the best opera- ting conditions for the system. The only time you might consider making any changes would be if you discovered that data was being lost while using your system. ′ Page: 4-11 Prox-1720 USER S MANUAL...
  • Page 67 VIDEO BIOS CACHEABLE: Select Enabled allows caching of the video BIOS, resulting in better system performance. However, if any program writes to this memory area, a system error may result. ′ Page: 4-12 Prox-1720 USER S MANUAL...
  • Page 68 This field allows you to enable or disable IO channel check NMI. Before selecting this function, the user should check first that NMI function is enabled as described in chapter 2 (Reset/NMI/Clear Watchdog Selection). ′ Page: 4-13 Prox-1720 USER S MANUAL...

  • Page 69: Integrated Peripherals

    F6: Fail-Safe Defaults F7:Optimized Defaults Integrated Peripherals Setup Screen By moving the cursor to the desired selection and by pressing the <F1> key, the all options for the desired selection will be displayed for choice. ′ Page: 4-14 Prox-1720 USER S MANUAL...
  • Page 70 This item allows you to enable/disable to support AC97 Audio. INIT DISPLAY FIRST: This item allows you to decide to active whether PCI Slot or on-chip VGA first. BIOS FLASH FUNCTION: This item allows you to enable the BIOS Flash function. ′ Page: 4-15 Prox-1720 USER S MANUAL...
  • Page 71 This item allows you to select the IR half/full duplex function. USE IR PINS: This item allows you to select IR transmission routes, one is RxD2m, TxD2 (COM Port) and the other is IR-Rx2Tx2. ′ Page: 4-16 Prox-1720 USER S MANUAL...
  • Page 72 Select a DMA channel for the parallel port for use during ECP mode. PWRON AFTER PWR-FAIL: This item allows you to select if you want to power on the system after power failure. The choice: Off, On, Former-Sts. ′ Page: 4-17 Prox-1720 USER S MANUAL...

  • Page 73: Power Management Setup

    ACPI SUSPEND TYPE: This item allows the user to set the ACPI suspend type to be used. POWER MANAGEMENT: This item allows you to select the Power Management mode. ′ Page: 4-18 Prox-1720 USER S MANUAL...
  • Page 74 Enabled, even when the system is in a power down mode. (1) Primary IDE 0 (2) Primary IDE 1 (3) Secondary IDE 0 (4) Secondary IDE 1 (5) FDD, COM, LPT Port ′ Page: 4-19 Prox-1720 USER S MANUAL...

  • Page 75: Pnp/Pci Configuration

    This section covers technical items, which is strongly recommended for experienced users only. PNP OS INSTALLED: This item allows you to determine install PnP OS or not. ′ Page: 4-20 Prox-1720 USER S MANUAL...
  • Page 76 DMA RESOURCES: When resources are controlled manually, assign each system DMA channel a type, depending on the type of device using the DM channel. PCI/VGA PALETTE SNOOP: Leave this field at disabled. ′ Page: 4-21 Prox-1720 USER S MANUAL...

  • Page 77: Pc Health Status

    CURRENT CPU TEMPERATURE: This item shows you the current CPU temperature. CURRENT CPU FAN SPEED: This item shows you the current CPUFAN speed. VCORE: This item shows you the current system voltage. ′ Page: 4-22 Prox-1720 USER S MANUAL...

  • Page 78: Frequency Control

    Enabling pulse spectrum spread modulation changes the extreme values from spikes to flat curves, thus reducing EMI. This benefit may in some cases be outweighed by problems with timing- critical devices such as a clock-sensitive SCSI device. ′ Page: 4-23 Prox-1720 USER S MANUAL...

  • Page 79: Load Fail-Safe Defaults

    When you press <Enter> on this category, you get a confirmation dialog box with a message similar to the following: Load Optimized Defaults ( Y/N ) ? N Pressing "Y" loads the default values that are factory setting for optimal performance system operations. ′ Page: 4-24 Prox-1720 USER S MANUAL...

  • Page 80: Password Setting

    PASSWORD DISABLED!!! Press any key to continue... Press the < Enter > key again and the password will be disabled. Once the password is disabled, you can enter Setup freely. ′ Page: 4-25 Prox-1720 USER S MANUAL...

  • Page 81: Save & Exit Setup

    You may always call up the setup program at any time to adjust any of the individual items by pressing the <Del> key during boot up. ′ Page: 4-26 Prox-1720 USER S MANUAL...

  • Page 82: Exit Without Saving

    Set Supervisor Password ►Power Management word Quit Without Saving (Y/N)? N ►PnP/PCI Configura etup ►PC Health Status Saving Esc : Quit ↑↓→← : Select Item F10 : Save & Exit Setup Abandon all Datas ′ Page: 4-27 Prox-1720 USER S MANUAL...
  • Page 83 Chapter 4 Award BIOS Setup ′ Page: 4-28 Prox-1720 USER S MANUAL...

  • Page 84: Appendix A Expansion Bus

    APPENDIX EXPANSION BUS This appendix indicates the pin assignments. Section includes: ISA BUS Pin Assignment PCI BUS Pin Assignment Page: A-1...

  • Page 85: Isa Bus Pin Assignment

    SA16 DRQ7 SD12 -DRQ3 SA15 SD13 -DACK1 SA14 -MASTER SD14 -DRQ1 SA13 SD15 -REFRESH SA12 BCLK SA11 IRQ7 SA10 SA09 IRQ5 SA08 IRQ4 SA07 IRQ3 SA06 SA05 SA04 BALE SA03 SA02 SA01 SA00 ′ Page: A-2 Prox-1720 USER S MANUAL...

  • Page 86: Pci Bus Pin Assignment

    AD10 +5V(I/O) REQ2# AD09 AD31 AD30 AD08 C/BE0# AD29 AD07 AD28 AD06 AD27 AD26 AD05 AD04 AD25 AD03 AD24 AD02 C/BE3# GNT2# AD01 AD00 AD23 +5V(I/O) +5V(I/O) AD22 ACK64# REQ64# AD21 AD20 AD19 ′ Page: A-3 Prox-1720 USER S MANUAL...
  • Page 87 Appendix A Expansion Bus ′ Page: A-4 Prox-1720 USER S MANUAL...
  • Page 88 APPENDIX TECHNICAL SUMMARY This section introduce you the maps concisely. Section includes: Block Diagram Interrupt Map RTC & CMOS RAM Map Timer & DMA Channels Map I / O & Memory Map Page: B-1...

  • Page 89: Appendix B Technical Summary Block Diagram

    DDRAM MODULES UDMA/100 AC'97 LINK AC'97 2.1 AD1881 ICH4 USB2.0 USB 2/2 LAN1 82562ET/EM BRIDGE PCI BUS ISA BUS LPC SIO IT8888TF W83627HF WatchDog DiskOnChip Floppy KB/MS PRN1 COM 1 COM 2 232/422/485 ′ Page: B-2 Prox-1720 USER S MANUAL...

  • Page 90: Interrupt Map

    Appendix B Technical Summary INTERRUPT MAP ASSIGNMENT System TIMER Keyboard Cascade Serial port 2 Serial port 1 Available Floppy Parallel port 1 RTC clock Available Available Available PS/2 Mouse Math coprocessor IDE1 IDE2 ′ Page: B-3 Prox-1720 USER S MANUAL...

  • Page 91: Rtc & Cmos Ram Map

    Extension memory low byte Extension memory high byte Reserved for extension memory low byte Reserved for extension memory high byte Date Century byte Information Flag 34-3F Reserve 40-7f Reserved for Chipset Setting Data ′ Page: B-4 Prox-1720 USER S MANUAL...

  • Page 92: Timer & Dma Channels Map

    TIMER & DMA CHANNELS MAP Timer Channel Map : Timer Channel Assignment System timer interrupt DRAM Refresh request Speaker tone generator DMA Channel Map : DMA Channel Assignment Available Available Floppy Available Cascade Available Available Available ′ Page: B-5 Prox-1720 USER S MANUAL...

  • Page 93: I/O & Memory Map

    Parallel port-2 2B0-2DF Graphics adapter controller 2F8-2FF Serial port-2 360-36F Net work ports 378-37F Parallel port-1 3B0-3BF Monochrome & Printer adapter 3C0-3CF EGA adapter 3D0-3DF CGA adapter 3F0-3F7 Floppy disk controller 3F8-3FF Serial port-1 ′ Page: B-6 Prox-1720 USER S MANUAL...

  • Page 94: Appendix C Trouble Shooting

    APPENDIX TROUBLE SHOOTING This section outlines the errors may occur when you operate the system. It also gives you the suggestions on solving the problems. Section includes: Trouble Shooting for Error Messages Trouble Shooting for POST Code Page: C-1...

  • Page 95: Trouble Shooting For Error Messages

    Then reboot the system. DISKETTE DRIVES OR TYPES MISMATCH ERROR - RUN SETUP : Type of diskette drive installed in the system is different from the CMOS definition. Run Setup to reconfigure the drive type correctly. ′ Page: C-2 Prox-1720 USER S MANUAL...
  • Page 96 Cannot initialize controller. Make sure the cord is correctly and firmly installed in the bus. Be sure the correct hard drive is selected in Setup. Also check to see if any jumper needs to be set correctly on the hard drive. ′ Page: C-3 Prox-1720 USER S MANUAL...
  • Page 97 Memory has been added or removed since the last boot. In EISA mode use Configuration Utility to reconfigure the memory configuration. In ISA mode enter Setup and enter the new memory size in the memory fields. ′ Page: C-4 Prox-1720 USER S MANUAL...
  • Page 98 The board installed is not responding to the ID request, or no board ID has been found in the indicated slot. Note: When this error appears, the system will boot in ISA mode, which allows you to run the EISA Configuration Utility. ′ Page: C-5 Prox-1720 USER S MANUAL...
  • Page 99 Unable to recalibrate fixed disk. Hard Disk(S) Fail (08) : Sector Verify failed. Keyboard is locked out – Unlock the key : BIOS detect the keyboard is locked. P17 of keyboard controller is pulled low. ′ Page: C-6 Prox-1720 USER S MANUAL...
  • Page 100 BIOS ROM checksum error – System halted : The checksum of ROM address F0000H-FFFFFH is bad. Memory test fail : BIOS reports the memory test fail if the onboard memory is tested error. ′ Page: C-7 Prox-1720 USER S MANUAL...

  • Page 101: Trouble Shooting For Post Codes

    Reserved. 03h : Initial Superio_Early_Init switch. Reserved. 04h : 05h : 1. Blank out screen 2. Clear CMOS error flag Reserved 06h : 07h : 1. Clear 8042 interface 2. Initialize 8042 self-test ′ Page: C-8 Prox-1720 USER S MANUAL...
  • Page 102 Also set real-time clock power status, and then check for override. Reserved 13h : 14h : Program chipset default values into chipset. Chipset default values are MODBINable by OEM customers. Reserved 15h : 16h : Initial Early_Init_Onboard_Generator switch. ′ Page: C-9 Prox-1720 USER S MANUAL...
  • Page 103 PCI & DIMM slots. 5. Early PCI initialization: -Enumerate PCI bus number -Assign memory & I/O resource -Search for a valid VGA device & VGA BIOS, and put it into C000:0. ′ Page: C-10 Prox-1720 USER S MANUAL...
  • Page 104 2Dh : 2. Put information on screen display, including Award title, CPU type, CPU speed … Reserved 2Eh : 2Fh : Reserved Reserved Reserved Reserved Reset keyboard except Winbond 977 series Super I/O chips. ′ Page: C-11 Prox-1720 USER S MANUAL...
  • Page 105 3Dh : 3Eh : Test 8259 interrupt mask bits for channel 1. Reserved 3Fh : Test 8259 interrupt mask bits for channel 2. Reserved Reserved Test 8259 functionality. Reserved Reserved Reserved Initialize EISA slot ′ Page: C-12 Prox-1720 USER S MANUAL...
  • Page 106 53h : 54h : Reserved 55h : Display number of processors (multi-processor platform) Reserved 56h : 57h : 1. Display PnP logo 2. Early ISA PnP initialization -Assign CSN to every PnP device. ′ Page: C-13 Prox-1720 USER S MANUAL...
  • Page 107 Reserved 64h : Reserved Initialize PS/2 Mouse 65h : 66h : Reserved 67h : Prepare memory size information for function call: INT 15h ax=E820h 68h : Reserved 69h : Turn on L2 cache. ′ Page: C-14 Prox-1720 USER S MANUAL...
  • Page 108 Detect & install all IDE devices: HDD, LS120, ZIP, CDROM….. 76h : Reserved Detect serial ports and parallel ports 77h : 78h : Reserved 79h : Reserved Detect and install co-processor 7Ah : ′ Page: C-15 Prox-1720 USER S MANUAL...
  • Page 109 4. Setup ACPI table at top of memory. 5. Invoke ISA adapter ROMs. 6. Assign IRQs to PCI devices. 7. Initialize APM. 8. Clear noise of IRQs. 86h : Reserved Reserved 87h : ′ Page: C-16 Prox-1720 USER S MANUAL...
  • Page 110 96h : 2. Build and update ESCD. 3. Set CMOS century to 20h or 19h. 4. Load CMOS time into DOS timer tick. 5. Build MSIRQ routing table. FFh : Boot attempt (INT 19h) ′ Page: C-17 Prox-1720 USER S MANUAL...
  • Page 111 Appendix C Trouble Shooting ′ Page: C-18 Prox-1720 USER S MANUAL...
  • Page 112 Appendix C Trouble Shooting ′ Page: C-19 Prox-1720 USER S MANUAL...
  • Page 113 Appendix C Trouble Shooting PRINTED IN TAIWAN ′ Page: C-20 Prox-1720 USER S MANUAL...
