USER'S
MANUAL
SA-5942
SA-5942
High Performance Desktop Intel
4th Gen. CPU Book Size PC
With 2DVI, 4COM & 2LAN
M3
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SA-5942 and is the answer not in the manual?

Questions and answers

Related Manuals for protech SA-5942

Summary of Contents for protech SA-5942

  • Page 1 USER’S MANUAL SA-5942 High Performance Desktop Intel ® 4th Gen. CPU Book Size PC With 2DVI, 4COM & 2LAN SA-5942...
  • Page 2 SA-5942 ® High Performance Desktop Intel 4th Gen. CPU Book Size PC COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in June 2017. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual..............System Illustration..............System Specifications..............Safety Precautions..............CHAPTER 2 SYSTEM CONFIGURATION System External I/O Ports & Pin Assignment......Mainboard Component Locations & Jumper Settings....CHAPTER 3 SOFTWARE UTILITIES Introduction................® Chipset Software Installation Utility…..……....Intel Intel®...
  • Page 5 Contents APPENDIX A SYSTEM DIAGRAMS Exploded Diagram for Whole System of SA-5942....... APPENDIX B TECHNICAL SUMMARY Block Diagram..................Interrupt Map..................DMA Channels Map……..............I/O Map....................Memory Map………………………………………………………….. B-12 Watchdog Timer Configuration…………..…………………………... B-14 Flash BIOS Update……………………………………………………. B-17...

  • Page 6: Chapter 1 Introduction

    CHAPTER INTRODUCTION This chapter gives you the information for SA-5942. It also outlines the System specification. Section includes: About This Manual System Specifications Safety Precautions Experienced users can skip to chapter 2 on page 2-1 for Quick Start. Page:1-1...

  • Page 7: About This Manual

    This chapter indicates you how to set up the BIOS configurations. Appendix A System Diagrams This appendix gives you the exploded diagrams and part numbers of the SA-5942 Appendix B Technical Summary This appendix gives you the information about the Technical maps, Watchdog-timer configuration, and Flash BIOS Update.

  • Page 8: System Illustration

    Chapter 1 Introduction 1-2. SYSTEM ILLUSTRATION Front View Rear View 300.2 Top View Bottom View Side View Quarter View 272.79 Unit: mm ′ Page: 1-3 SA-5942 USER S MANUAL...

  • Page 9: System Specifications

    Dual ports, support Wake-on-LAN ® LAN1: Intel I217-LM/V ® LAN2: Intel I210-AT Audio Realtek ALC888S-VD2-GR High Definition audio codec Line-in/Line-out/MIC Option: S/PDIF Keyboard/Mouse 1 x PS/2 Expansion Bus 1 x PCIe (16x) Gen. 2 ′ Page: 1-4 SA-5942 USER S MANUAL...
  • Page 10 Built-in processor to share the system memory. 1 x DVI-I 1 x DVI-D 1 x Display Port Environment Operating Temp. 0 ~ 40°C (32 ~ 104°F) Storage Temp. -20 ~ 60°C (-4 ~ 140°F) Humidity 20~90% ′ Page: 1-5 SA-5942 USER S MANUAL...

  • Page 11: Safety Precautions

    The range of operating voltage should be between 100V~ 240V. Otherwise, the system could be damaged. Place your SA-5942 on a sturdy & level surface. Be sure to allow enough space to have easy access around the system. Avoid moving the system rapidly from a hot place to a cold one and vice versa because condensation may come from inside of the system.
  • Page 12 CHAPTER HARDWARE CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. Section includes: System External I/O Ports & Pin Assignment Mainboard Component Locations & Jumper Settings Page 2-1...

  • Page 13: System External I/O Ports & Pin Assignment

    Chapter 2 Hardware Configuration 2-1. SYSTEM EXTERNAL I/O PORTS & PIN ASSIGNMENT I/O View COM4 COM2 LAN1 COM3 COM1 LAN2 PS/2 KB & MS Jack DVI-I USB 2.0 Line-in DVI-D USB 3.0 Line-out Mic-in ′ Page: 2-2 SA-5942 USER S MANUAL...
  • Page 14 COM4: fixed as RS-232, co-lay with the on-board COM4 connector ASSIGNMENT ASSIGNMENT DCD# DSR# RTS# CTS# COM1/ DTR# COM3/ COM4/ COM2: COM2 Connector, selectable as RS-232/422/485 ASSIGNMENT RS-232 RS-422 RS-485 DCD# RS-485- RS-485+ COM2 DTR# DSR# RTS# CTS# ′ Page: 2-3 SA-5942 USER S MANUAL...

  • Page 15: Lan Port

    MDI_1N MDI_3N LAN2/ LAN LED Indicator: Left Side LED Red Color On Giga LAN Speed Indicator No LAN switch/hub connected. Right Side LED Orange Color Blinking LAN Message Active No LAN Message Active ′ Page: 2-4 SA-5942 USER S MANUAL...

  • Page 16: Usb Ports

    USB3.0 Ports: USB Double Stack Connector ASSIGNMENT ASSIGNMENT VCC5 VCC5 USBP0N USBP1N USBP0P USBP1P RX1_DN RX2_DN USB3.0 RX1_DP RX2_DP TX1_DN TX2_DN TX1_DP TX2_DP USB2.0 Ports: USB Double Stack Connector ASSIGNMENT ASSIGNMENT VCC5 VCC5 USBP2N USBP3N USBP2P USBP3P USB2.0 ′ Page: 2-5 SA-5942 USER S MANUAL...
  • Page 17 C1 C2 ASSIGNMENT ASSIGNMENT DP_Data2- Ground C3 C4 DP_Data2+ HOT Plug Detect DVI-I Ground DP_Data0- DP_Data0+ Ground DP_Ctrl_Clock DP_Ctrl_ Data CRT_VSYNC Ground DP_Data1- DP_Clock+ DP_Data1+ DP_Clock- Ground CRT_RED CRT_GREE CRT_BLUE +5V Power CRT_HSYNC ′ Page: 2-6 SA-5942 USER S MANUAL...
  • Page 18 Chapter 2 Hardware Configuration 2-1-6. Audio Jack Line-in (Blue), Line-out (Green) & Mic-in (Pink): The connector can also support only Microphone. Line-in: ASSIGNMENT HD_LINE-IN-L HD_LINE-IN-R Line-out: ASSIGNMENT LINE-OUT-L LINE-OUT-R Line-in/ Mic-in: ASSIGNMENT Line-out/ Mic-in HD_MIC1-L_L HD_MIC1-R_L ′ Page: 2-7 SA-5942 USER S MANUAL...

  • Page 19: Mainboard Component Locations & Jumper Settings

    COM3 COM4 ATX_PWR2 JLPC1 ATX_PWR1 ® Intel Gen. ® Intel Core™ i5/i7     H81/Q87 (LGA1150) DIMM2 SATA3 SATA2 CPU_FAN1 SATA1 DIMM1 SYS_FAN1 Mainboard Connectors, Jumpers and Component Locations - front ′ Page: 2-8 SA-5942 USER S MANUAL...
  • Page 20 Chapter 2 Hardware Configuration Component Location - back Mainboard ′ Page: 2-9 SA-5942 USER S MANUAL...
  • Page 21 Intel ME Selection Clear CMOS Data Selection BIOS Recovery Mode Selection Fan Connector CPU_FAN1, SYS_FAN1, SYS_FAN2 SATA Connector SATA1, SATA2, SATA3 USB Connector USB3, USB4 Display Port Connector ATX Power Connector ATX_PWR1, ATX_PWR2 ′ Page: 2-10 SA-5942 USER S MANUAL...

  • Page 22: How To Set Jumpers

    PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. ′ Page: 2-11 SA-5942 USER S MANUAL...

  • Page 23: Jumper Settings

    Jumper Block looks like this Jumper Settings 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this ′ Page: 2-12 SA-5942 USER S MANUAL...
  • Page 24 2-2-3. COM Port COM1: COM Port, fixed as RS-232 ASSIGNMENT ASSIGNMENT DCD# DSR# RTS# CTS# COM1 DTR# COM2: COM2 Connector, selectable as RS-232/422/485 ASSIGNMENT RS-232 RS-422 RS-485 DCD# RS-485- RS-485+ COM2 DTR# DSR# RTS# CTS# ′ Page: 2-13 SA-5942 USER S MANUAL...

  • Page 25: Com Connector

    ASSIGNMENT ASSIGNMENT DCD# DSR# RTS# CTS# DTR# COM3/ COM4/ 2-2-5. Keyboard & Mouse Ports KB_MS1: PS/2 Keyboard & Mouse Port Keyboard: ASSIGNMENT ASSIGNMENT KBDATA VCC5 KBCLK Mouse: ASSIGNMENT ASSIGNMENT MSDATA VCC5 MSCLK KB_MS1 ′ Page: 2-14 SA-5942 USER S MANUAL...
  • Page 26 C1 C2 ASSIGNMENT ASSIGNMENT DP_Data2- Ground C3 C4 DP_Data2+ HOT Plug Detect DVI-I Ground DP_Data0- DP_Data0+ Ground DP_Ctrl_Clock DP_Ctrl_ Data CRT_VSYNC Ground DP_Data1- DP_Clock+ DP_Data1+ DP_Clock- Ground CRT_RED CRT_GREE CRT_BLUE +5V Power CRT_HSYNC ′ Page: 2-15 SA-5942 USER S MANUAL...
  • Page 27 No LAN switch/hub connected. LAN1_USB1 Right Side LED Orange Color Blinking LAN Message Active No LAN Message Active USB3.0 signal: ASSIGNMENT ASSIGNMENT VCC5 VCC5 USBP0N USBP1N USBP0P USBP1P RX1_DN RX2_DN RX1_DP RX2_DP TX1_DN TX2_DN TX1_DP TX2_DP ′ Page: 2-16 SA-5942 USER S MANUAL...
  • Page 28 Red Color On Giga LAN Speed Indicator No LAN switch/hub connected. LAN2_USB2 Right Side LED Orange Color Blinking LAN Message Active No LAN Message Active USB2.0 signal: ASSIGNMENT ASSIGNMENT VCC5 VCC5 USBP2N USBP3N USBP2P USBP3P ′ Page: 2-17 SA-5942 USER S MANUAL...
  • Page 29 Chapter 2 Hardware Configuration 2-2-8. Audio Jack AUDIO1: Line-in, Line-out & Microphone The connector can also support only Microphone. Line-in: ASSIGNMENT HD_LINE-IN-L HD_LINE-IN-R Line-out: ASSIGNMENT LINE-OUT-L LINE-OUT-R AUDIO1 Mic-in: ASSIGNMENT HD_MIC1-L_L HD_MIC1-R_L ′ Page: 2-18 SA-5942 USER S MANUAL...
  • Page 30 2-2-9. COM Port RI & Voltage Selection JP_COM1 & JP_COM2: COM1 & COM2 Ports RI & Voltage Selection SELECTION JUMPTER JUMPER ILLUSTRATION SETTING COM1 COM2 JP_COM2 JP_COM1 JP_COM2 JP_COM1 JP_COM2 JP_COM1 Note: Manufacturing default is RI. ′ Page: 2-19 SA-5942 USER S MANUAL...
  • Page 31 1-2, RS-422 3-4, 9-10 1-2, RS-485 5-6, Note: Manufacturing default is RS-232. 2-2-11. COM2 Auto-Detect Selection JP7: COM2 Auto-detect Selection SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION Normal Auto Gating Note: Manufacturing default is Normal. ′ Page: 2-20 SA-5942 USER S MANUAL...
  • Page 32 2-2-12. Front Panel Connector & Selection FP1: Front Panel Connector SELECTION PIN & JUMPER JUMPER ASSIGNMENT SETTINGS ILLUSTRATION 1. HDD_LED+ HDD LED 3. HDD_LED- 2. PWR_LED+ Power LED 4. PWR_LED- 5. GND Reset Button 7. RST_BTN ′ Page: 2-21 SA-5942 USER S MANUAL...
  • Page 33 9. GND ATX Power 9-11 Button 11. PWRBTNSW ® 2-2-13. Intel ME Selection ® JP3: Intel ME Selection SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION Normal Open ME Disabled Close Note: Manufacturing Default is Normal. ′ Page: 2-22 SA-5942 USER S MANUAL...

  • Page 34: Clear Cmos Data Selection

    CMOS” as illustrated above. After five to six seconds, set the jumper back to “Normal” and power-on the computer. 2-2-15. BIOS Recovery Mode Selection JP1: BIOS Recovery Mode Selection SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION Recovery Open Normal Close Note: Manufacturing Default is Normal. ′ Page: 2-23 SA-5942 USER S MANUAL...

  • Page 35: Fan Connector

    SYS_FAN1: System Fan Connector ASSIGNMENT VCC12 CPU_FAN1/ SYS_FAN1/ SYS_FAN2: System Fan Connector ASSIGNMENT VCC12 SYS_FAN2 2-2-17. SATA Connector SATA1, SATA2, SATA3: Three Serial ATA Connectors ASSIGNMENT ASSIGNMENT RXNC SATA1/ TXPC RXPC SATA2/ TXNC SATA3/ ′ Page: 2-24 SA-5942 USER S MANUAL...

  • Page 36: Usb Connector

    VCC5 USBP USB3/ VCC5 USB4/ USBN USBN USBP 2-2-19. Display Connector DP1: Display Port Connector ASSIGNMENT ASSIGNMENT 19 20 DATA0+ DATA3- DATA0- AUX_ENJ DATA1+ AUX+ DATA1- DATA2+ AUX- VCC3_3 DATA2- VCC5 DATA3+ VCC3_3 ′ Page: 2-25 SA-5942 USER S MANUAL...

  • Page 37: Atx Power Connector

    Chapter 2 Hardware Configuration 2-2-20. ATX Power Connector ATX_PWR1: ATX Power Connector ASSIGNMENT ASSIGNMENT +3.3V +3.3V +3.3V -12V PSON 5VSB +12V +12V +3.3V ATX_PWR1 ATX_PWR2: ATX Power Connector ASSIGNMENT ASSIGNMENT +12V +12V ATX_PWR2 ′ Page: 2-26 SA-5942 USER S MANUAL...

  • Page 38: Chapter 3 Software Utilities

    CHAPTER SOFTWARE UTILITIES This chapter comprises the detailed information of VGA driver, LAN driver, and Sound driver. Sections included:  Introduction.  ® Intel Chipset Software Installation Utility ®  Intel Rapid Storage Technology Utility  ® Intel USB3.0 eXtensible Host Controller Utility ...

  • Page 39: Introduction

    Chapter 3 Software Utilities 3-1. INTRODUCTION Enclosed with our SA-5942 package are our driver utilities, which come in a format of DVD ROM. Refer to the following table for driver locations: and go to the ® ® corresponding folder for the chipset Intel...
  • Page 40 I210-AT for LAN driver  D:\H81\Driver\Platform\Win7,Win8(64-bit)\LAN installation  D:\H81\Driver\Platform\Win7,Win8(32-bit)\Sound Realtek ALC888S for sound driver installation  D:\H81\Driver\Platform\Win7,Win8(64-bit)\Sound D:\H81\Driver\Flash BIOS BIOS update utility Note: Be sure to install the utility right after the OS is fully installed.  Page:3-3 SA-5942 USER S MANUAL...

  • Page 41: Intelc Hipset Software Installation Utility

    OS installation. Please follow the steps below: Insert the driver disk into a DVD ROM device. Under Windows system, go to the directory where the Utility driver is located. Run the application with administrative privileges.  Page:3-4 SA-5942 USER S MANUAL...

  • Page 42: Intel Rapidstorage Technology Option Rom

    Power-On Self-Test (POST). Option ROM prompt: In the user interface, the hard drive(s) and hard drive information listed for your system will differ from the example in the figure below: Option ROM user interface:  Page:3-5 SA-5942 USER S MANUAL...

  • Page 43: Intel Usb3.0 Extensible Host Controller Utility

    To install the utility, simply follow the following steps: Insert the driver disk into a DVD ROM device. Under Windows system, go to the directory where the driver is located. Run the application with administrative privileges.  Page:3-6 SA-5942 USER S MANUAL...

  • Page 44: Intel ® Management Engine Components Utility

    To install the utility, simply follow the following steps: Insert the driver disk into a DVD ROM device. Under Windows system, go to the directory where the driver is located. Run the application with administrative privileges.  Page:3-7 SA-5942 USER S MANUAL...

  • Page 45: Vga Driver Utility

    Chapter 3 Software Utilities 3-6. VGA DRIVER UTILITY 3-6-1. Introduction The VGA interface embedded with our SA-5942 can support a wide range of display. You can display DVI simultaneously with the same mode. 1. Win 7 Series 2. Win 8 Series 3-6-2.

  • Page 46: Lan Driver Utility

    Chapter 3 Software Utilities 3-7. LAN DRIVER UTILITY 3-7-1. Introduction SA-5942 is enhanced with LAN function that can support various network adapters. Installation programs for LAN drivers are listed as follows: 1. Win 7 Series 2. Win 8 Series For more details on Installation procedure, please refer to Readme.txt file found on LAN Driver Utility.

  • Page 47: Sound Driver Utility

    Run the application with administrative privileges.. Follow the instructions on the screen to complete the installation. Once the installation is completed, shut down the system and restart in order for the changes to take effect.  Page:3-10 SA-5942 USER S MANUAL...
  • Page 48 CHAPTER BIOS SETUP This chapter shows how to set up the AMI BIOS. Section includes: Introduction Entering Setup Main Advanced Chipset Boot Security Save & Exit Page: 4-1...

  • Page 49: Chapter 4 Ami Bios Setup

    Chapter 4 AMI BIOS Setup 4-1. INTRODUCTION The system SA-5942 uses an AMI (American Megatrends Incorporated) Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (4MB SPI Flash) and can be updated. The SPI Flash contains the BIOS (Basic Input Output System) setup menu, Power-on Self-test (POST), the PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.
  • Page 50 The BIOS setup menu is accessible by pressing the <Del> or <F2> key on keyboard during the POST stage, right before the operating system is loading. All the settings are described in chapter to be followed. ′ Page: 4-3 SA-5942 USER S MANUAL...

  • Page 51: Entering Setup

    <ESC> or <Del> key (the one that shares the decimal point at the bottom of the number keypad) to access the setup menu. In a moment, the main menu of the Aptio Setup Utility will appear on the screen: ′ Page: 4-4 SA-5942 USER S MANUAL...
  • Page 52 As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. The following table provides the list of keys available for BIOS setup menu. ′ Page: 4-5 SA-5942 USER S MANUAL...

  • Page 53: Bios Messages

    The CMOS battery is The battery may be losing power, replace the battery soon. bad or was recently Also, this message is displayed once the new battery was replaced. placed. ′ Page: 4-6 SA-5942 USER S MANUAL...

  • Page 54: Main

    Displays the date of current BIOS Time version. System Date Month, day, year Specifies the current date. System Time Hour, minute, second Specifies the current time. Access Level No changeable options Displays the current user level. ′ Page: 4-7 SA-5942 USER S MANUAL...

  • Page 55: Advanced

    USB Configuration Parameters. F81866 Super IO Sub-Menu System Super IO Chip Parameters. Configuration F81866 HW Monitor Sub-Menu Monitor hardware status Network stack Sub-Menu UEFI network setting Switchable Graphics No changeable Switchable Graphics selections options ′ Page: 4-8 SA-5942 USER S MANUAL...
  • Page 56 - Both S1 and S3 S1 mode allows the CPU enter Stop available for OS to Clock mode to stop executing choose from instructions. S3 allows the platform to enter Suspend to RAM mode. ′ Page: 4-9 SA-5942 USER S MANUAL...
  • Page 57 Description/Purpose Both S1 and S3 available for OS to choose from allows the OS to choose the sleep state type. S3 Video Repost - Disabled Enable or Disable S3 video Repost - Enabled ′ Page: 4-10 SA-5942 USER S MANUAL...
  • Page 58 Trusted Computing screen BIOS Setting Options Description/Purpose Security Device - Disabled Enables or Disables BIOS support Support for security device - Enabled Current Status No changeable options Display current security device Information information ′ Page: 4-11 SA-5942 USER S MANUAL...
  • Page 59 Chapter 4 AMI BIOS Setup 4-4-3. Advanced – CPU Configuration CPU Configuration screen ′ Page: 4-12 SA-5942 USER S MANUAL...
  • Page 60 L2 Cache No changeable options Displays size of L2 Cache. L3 Cache No changeable options Displays size of L3 Cache. Active Processor - All Indicates the number of cores to Cores enable in processor. ′ Page: 4-13 SA-5942 USER S MANUAL...
  • Page 61 Enterprise 3 Update 3.) Intel - Disabled When enabled, a VMM can Virtualization utilize the additional hardware - Enabled Technology capabilities provided by Vander pool Technology. EIST - Disabled Enable or Disable EIST - Enabled ′ Page: 4-14 SA-5942 USER S MANUAL...
  • Page 62 Configures SATA as IDE, AHCI or Selection RAID (Q87 only) mode. - AHCI - RAID SATA 0/1/4 [drive] Displays the drive installed on this SATA port. Shows [Empty] if no drive is installed. ′ Page: 4-15 SA-5942 USER S MANUAL...
  • Page 63 Indicates the maximum speed the SATA Speed controller can support. - Gen2 - Gen3 Port 0/1/4 - Disabled Enables or disable SATA port. - Enabled Hot Plug - Disabled Designates this port as Hot Pluggable. - Enabled ′ Page: 4-16 SA-5942 USER S MANUAL...
  • Page 64 Solid State Drive or Hard Disk Drive. - Solid State Drive Spin Up Device - Disabled On an edge detect from 0 to 1, the PCH starts a COMRESET initialization sequence - Enabled to the device. ′ Page: 4-17 SA-5942 USER S MANUAL...
  • Page 65 - Disabled XHCI Hand-off - Enabled This is a workaround for OSes without XHCI hand-off support. - Disabled EHCI Hand-off - Disabled This is a workaround for OSes w/o EHCI hand-off support. - Enabled ′ Page: 4-18 SA-5942 USER S MANUAL...
  • Page 66 Host - Manual Controller. “Auto” uses default value: for a Root port it is 100 ms, for a Hub port the delay is taken from Hub descriptor. ′ Page: 4-19 SA-5942 USER S MANUAL...
  • Page 67 BIOS Setting Options Description/Purpose F81866 Super IO No changeable options Displays the super IO chip model and Chip its manufacturer. COM 1/2/3/4 Sub-menu Set Parameters for COM 1/2/3/4 F81866 Watchdog Sub-menu Set watchdog time ′ Page: 4-20 SA-5942 USER S MANUAL...
  • Page 68 Change Settings - Auto Specifies the base I/O address and interrupt - IO=3F8h; IRQ=4 request for the serial port - IO=3F8h; IRQ=3,4,5,6,7,10,11,12 0 if enabled. IO=2F8h; IRQ=3,4,5,6,7,10,11,12 - IO=3E8h; IRQ=3,4,5,6,7,10,11,12 - IO=2E8h; IRQ=3,4,5,6,7,10,11,12 ′ Page: 4-21 SA-5942 USER S MANUAL...
  • Page 69 4-4-6-2. F81866 Watchdog F81866 Watchdog screen BIOS Setting Options Description/Purpose Enable watchdog - Disabled Enable/Disable COM 1. - Enabled Count for Timer Timer value The number of second count for timer (Seconds) (1-255 seconds) ′ Page: 4-22 SA-5942 USER S MANUAL...
  • Page 70 No changeable options Displays voltage level of the +5V in supply. VCC5 No changeable options Displays voltage level of the +5V in supply. VCC12 No changeable options Displays voltage level of the +12V in supply. ′ Page: 4-23 SA-5942 USER S MANUAL...
  • Page 71 Smart Fan Mode Configuration screen BIOS Setting Options Description/Purpose CPUFan/ - Manual Duty Mode Smart Fan Mode select. SysFan Samrt - Auto Duty-Cycle Mode Fan Control Manual Duty Duty value Set duty cycle(PWM fan type) 1-100 Mode ′ Page: 4-24 SA-5942 USER S MANUAL...
  • Page 72 4-4-8. Advanced – Network Stack SMART Settings screen BIOS Setting Options Description/Purpose Network stack - Disabled Enable/Disable UEFI Network stack. - Enabled Ipv4/6 PXE - Disabled Enable Ipv4/6 PXE boot support Support - Enabled ′ Page: 4-25 SA-5942 USER S MANUAL...
  • Page 73 Chapter 4 AMI BIOS Setup 4-4-9. Advanced – Switchable Graphics NCT6106D Super IO Configuration screen BIOS Setting Options Description/Purpose SG Mode Select - Muxless Switchable Graphics selections ′ Page: 4-26 SA-5942 USER S MANUAL...

  • Page 74: Chipset

    Chapter 4 AMI BIOS Setup 4-5. Chipset Chipset screen BIOS Setting Options Description/Purpose PCH-IO Sub-menu Sets Parameter for Panther Point Configuration (South Bridge) configuration. System Agent Sub-menu Sets Parameter for Ivy Bridge (North (SA) Bridge) configuration. Configuration ′ Page: 4-27 SA-5942 USER S MANUAL...
  • Page 75 PCI Express Sub-menu PCI Express Configuration settings. Configuration Sub-menu USB Configuration setting Configuration PCH Azalia Sub-menu PCH Azalia Configuration settings. Configuration PCH LAN - Disabled Enable or disable onboard NIC Controller - Enabled ′ Page: 4-28 SA-5942 USER S MANUAL...
  • Page 76 SB CRID - Disabled Enable or disable SB CRID workaround - Enabled Restore AC - Power off Select AC power state when power is Power Loss re-applied after a power failure. - Power on ′ Page: 4-29 SA-5942 USER S MANUAL...
  • Page 77 PCIE Port 3 is No changeable options Display LAN 1 is locate at PCIE port 3 assigned to LAN PCI Express Root - Disabled Enable or disable PCIE port 4 for LAN Port 4 - Enabled ′ Page: 4-30 SA-5942 USER S MANUAL...
  • Page 78 USB Ports Per-Port - Enabled Main control to enable or disable USB Disable Control ports. - Disabled USB Port - Enabled Enable or disable each USB ports. #0/1/2/3/8/9/10/11 - Disabled USB30 Port #0/1 ′ Page: 4-31 SA-5942 USER S MANUAL...
  • Page 79 Options Description/Purpose Azalia - Enabled Enable or disable internal HDMI codec for Azalia. - Disabled - Auto Azalia Docking - Enabled Enable or disable Azalia Docking Support Support of Audio Controller - Disabled ′ Page: 4-32 SA-5942 USER S MANUAL...
  • Page 80 Report if VT-d support by processor VT-d - Enabled Enable or disable VT-d - Disabled Enable NB CRID - Enabled Enable or disable NB CRID workaround - Disabled Graphics Sub-menu Configure Graphic Settings. Configuration ′ Page: 4-33 SA-5942 USER S MANUAL...
  • Page 81 Chapter 4 AMI BIOS Setup BIOS Setting Options Description/Purpose NB PCIe Sub-menu NB PCIe Configuration setting Configuration Memory Sub-menu Memory Configuration Parameters Configuration ′ Page: 4-34 SA-5942 USER S MANUAL...
  • Page 82 - IGFX - PEG Aperture Size - 128MB Select the Aperture Size - 256MB - 512MB DVMT Pre- - 32M ~ 1024M Select DVMT 5.0 Pre-Allocated Allocated (Fixed) Graphics Memory size used by ′ Page: 4-35 SA-5942 USER S MANUAL...
  • Page 83 - MAX on application need. Once the application is closed, the memory that was allocated for graphics usage is then released and made available for system use. LCD Control Sub-menu Display devices active selection ′ Page: 4-36 SA-5942 USER S MANUAL...
  • Page 84 - DVI 2 modes will be supported only on primary display. Secondary IGFX - Disabled Select Secondary Display Device Boot Display - CRT (DVI-I) - DVI 1 (DVI-I) - Onboard DP - DVI 2 ′ Page: 4-37 SA-5942 USER S MANUAL...
  • Page 85 - Gen2 - Gen3 Enable PEG - Disabled Enable or disable the PEG - Enabled - Auto Detect Non- - Disabled Enable or disable Detect Non- Compliance Compliance Device in PEG - Enabled Device ′ Page: 4-38 SA-5942 USER S MANUAL...
  • Page 86 Chapter 4 AMI BIOS Setup 4-5-2-3. System Agent (SA) Configuration – Memory Configuration Memory Configuration screen BIOS Setting Options Description/Purpose Memory No changeable option Displays the detail DRAM information Information lists. on platform. ′ Page: 4-39 SA-5942 USER S MANUAL...

  • Page 87: Boot

    Enable/Disable Quiet Boot Options - Enabled Boot Option - [Drive(s)] Allows setting boot option listed in #1~#3 Hard Drive BBS Priorities. - Disabled CSM16 Sub-menu CSM features selection Parameters CSM parameters Sub-menu CSM features selection ′ Page: 4-40 SA-5942 USER S MANUAL...
  • Page 88 Chapter 4 AMI BIOS Setup 4-6-1. Boot – Hard Drive BBS Priorities Hard drive BBS Priorities screen BIOS Setting Options Description/Purpose Boot Option #1 - - [Drive(s)] Allows setting the boot order of available drive(s). - Disabled ′ Page: 4-41 SA-5942 USER S MANUAL...
  • Page 89 - Keep Current INT19 Trap - Immediate When enabled it allows host adapters Response ROM BIOS to capture Interrupt 19 during - Postponed the boot process and eventually boot from disk(s) connected to those adapters. ′ Page: 4-42 SA-5942 USER S MANUAL...
  • Page 90 - UEFI only OpROM policy Legacy PXE OpROM - Legacy only - Do not launch Launch Storage Controls the execution of UEFI and - UEFI only OpROM policy Legacy Storage OpROM - Legacy only ′ Page: 4-43 SA-5942 USER S MANUAL...
  • Page 91 - Legacy only - Legacy first - UEFI first - UEFI OpROM Other PCI device For PCI devices other than Network, - Legacy OpROM ROM priority Mass storage or Video defines which OpROM to launch ′ Page: 4-44 SA-5942 USER S MANUAL...

  • Page 92: Security

    Options Description/Purpose Administrator Password can be 3-20 Specifies the administrator password. Password alphanumeric characters. User Password Password can be 3-20 Specifies the user password. alphanumeric characters. HDD Security Sub-menu Set HDD password. Configuration: ′ Page: 4-45 SA-5942 USER S MANUAL...
  • Page 93 Reports if there is security feature frozen. HDD User Pwd No changeable options Reports if there is HDD User Password Status installed. HDD Master Pwd No changeable options Reports if there is HDD Master Status Password installed. ′ Page: 4-46 SA-5942 USER S MANUAL...
  • Page 94 Set User Password can be up to Specifies the user password. (Need Password 32 alphanumeric TPM module) characters. Set Master Password can be up to Specifies the master password. Password 32 alphanumeric characters. ′ Page: 4-47 SA-5942 USER S MANUAL...

  • Page 95: Save & Exit

    Reset system without saving any and Reset changes Save Changes No changeable options Saves the changes done in BIOS settings so far. Discard Changes No changeable options Discards the changes done in BIOS settings so far. ′ Page: 4-48 SA-5942 USER S MANUAL...
  • Page 96 Save the changes done so far as User Defaults Defaults Restore User No changeable options Restore the User Defaults to all the Defaults setup options Boot Override - [Drive(s)] Forces to boot from selected [drive(s)]. ′ Page: 4-49 SA-5942 USER S MANUAL...

  • Page 97: System Assembly

    APPENDIX SYSTEM ASSEMBLY This appendix contains the exploded diagram of the system. Section includes: Exploded Diagram for Whole System of SA-5942 Page: A-1...

  • Page 98: Exploded Diagram For Whole System Of Sa-5942

    Appendix A System Assembly EXPLODED DIAGRAM FOR WHOLE SYSTEM OF SA-5942 15 16 ′ Page: A-2 SA-5942 USER S MANUAL...
  • Page 99 Appendix A System Assembly ′ Page: A-3 SA-5942 USER S MANUAL...
  • Page 100 APPENDIX TECHNICAL SUMMARY This section introduces you the maps concisely. Section includes: Block Diagram Interrupt Map DMA Channels Map I/O Map Memory Map Watchdog Timer Configuration Flash BIOS Update Page: B-1...
  • Page 101 64Mbit SPI Flash ROM LOW PIN COUNT 80 port for Debug Connector COM 1/3/4 RS232 FINTEK Com1/2 support 5V/12V HW monitor LPC SIO COM2 F81846AD-I RS232/422/485 Keyboard Mouse VR12.5 ISL95816 3 Phase PWM TPS51216 For DDR3 ′ Page: B-2 SA-5942 USER S MANUAL...

  • Page 102: Appendix B Technical Summary

    Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ′ Page: B-3 SA-5942 USER S MANUAL...
  • Page 103 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ′ Page: B-4 SA-5942 USER S MANUAL...
  • Page 104 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ′ Page: B-5 SA-5942 USER S MANUAL...
  • Page 105 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ® 4294967283 Intel I210 Gigabit Network Connection #3 ′ Page: B-6 SA-5942 USER S MANUAL...
  • Page 106 8 Series/C220 Series PCI Express Root Port #4 - 8C16 ® 4294967294 Intel 8 Series/C220 Series PCI Express Root Port #1 - 8C10 Note: The resource information were gathered on Windows 7. (The IRQ could be assigned differently depending on your OS.) ′ Page: B-7 SA-5942 USER S MANUAL...

  • Page 107: Dma Channels Map

    Appendix B Technical Summary DMA CHANNELS MAP TIMER CHANNEL ASSIGNMENT Channel 4 Direct memory access controller ′ Page: B-8 SA-5942 USER S MANUAL...

  • Page 108: I/O Map

    0x00000063-0x00000063 Motherboard resources 0x00000064-0x00000064 Standard PS/2 Keyboard 0x00000065-0x0000006F Motherboard resources 0x00000065-0x0000006F Motherboard resources 0x00000067-0x00000067 Motherboard resources 0x00000070-0x00000070 Motherboard resources 0x00000070-0x00000070 System CMOS/real time clock 0x00000072-0x0000007F Motherboard resources 0x00000080-0x00000080 Motherboard resources 0x00000080-0x00000080 Motherboard resources ′ Page: B-9 SA-5942 USER S MANUAL...
  • Page 109 ® 0x000003C0-0x000003DF Intel HD Graphics 4600 0x000003E8-0x000003EF Communications Port (COM3) 0x000003F8-0x000003FF Communications Port (COM1) 0x000004D0-0x000004D1 Motherboard resources 0x000004D0-0x000004D1 Programmable interrupt controller 0x00000680-0x0000069F Motherboard resources 0x00000A00-0x00000A0F Motherboard resources 0x00000A10-0x00000A1F Motherboard resources 0x00000A20-0x00000A2F Motherboard resources ′ Page: B-10 SA-5942 USER S MANUAL...
  • Page 110 - 8C02 ® 0x0000F0C0-0x0000F0C3 Intel 8 Series/C220 Series SATA AHCI Controller - 8C02 ® 0x0000F0D0-0x0000F0D7 Intel 8 Series/C220 Series SATA AHCI Controller - 8C02 0x0000FFFF-0x0000FFFF Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources ′ Page: B-11 SA-5942 USER S MANUAL...

  • Page 111: Memory Map

    8 Series/C220 Series SATA AHCI Controller - 8C02 ® 0xF7D3F000-0xF7D3F00F Intel Management Engine Interface 0xFED00000-0xFED003FF High precision event timer ® 0xF7800000-0xF7BFFFFF Intel HD Graphics 4600 ® 0xE0000000-0xEFFFFFFF Intel HD Graphics 4600 0xF7D34000-0xF7D37FFF High Definition Audio Controller ′ Page: B-12 SA-5942 USER S MANUAL...
  • Page 112 8 Series/C220 Series SMBus Controller - 8C22 ® 0xA0000-0xBFFFF Intel HD Graphics 4600 0xA0000-0xBFFFF PCI bus 0xD0000-0xD3FFF PCI bus 0xD4000-0xD7FFF PCI bus 0xD8000-0xDBFFF PCI bus 0xDC000-0xDFFFF PCI bus 0xE0000-0xE3FFF PCI bus 0xE4000-0xE7FFF PCI bus 0x3E200000-0xFEAFFFFF PCI bus ′ Page: B-13 SA-5942 USER S MANUAL...

  • Page 113: Watchdog Timer Configuration

    To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. ′ Page: B-14 SA-5942 USER S MANUAL...
  • Page 114 ------ Enter to extended function mode -------------------------------------------------------- ------ Select Logical Device 7 of watchdog timer -------------------------------------------- ------ Enable watchdog feature ------------------------------------------------------------------ ------ Enable watch PME ------------------------------------------------------------------ 0FAh ------ Set second as counting unit -------------------------------------------------------------- 0f5h ′ Page: B-15 SA-5942 USER S MANUAL...
  • Page 115 Appendix B Technical Summary ------ Set timeout interval as 30seconds and start counting --------------------------------- 0f6h ------ Exit the extended function mode -------------------------------------------------------- 0aah ′ Page: B-16 SA-5942 USER S MANUAL...

  • Page 116: Flash Bios Update

    Select [Boot] menu as the picture shows below. e.) Select [Hard Drive BBS Priorities], set the USB bootable device as the 1 boot device. f.) Press <F4> key to save configuration and exit the BIOS setup menu. ′ Page: B-17 SA-5942 USER S MANUAL...
  • Page 117 The recommended options for BIOS ROM update consist of following parameters: program main BIOS image /B: program Boot Block /N: program NVRAM /X: don’t check ROM ID ′ Page: B-18 SA-5942 USER S MANUAL...
  • Page 118 You can restart the system and boot up with new BIOS now Update is complete after restart Verify during the following boot that BIOS version displayed at the initialization screen has changed. ′ Page: B-19 SA-5942 USER S MANUAL...
  • Page 119 Appendix B Technical Summary ′ Page: B-20 SA-5942 USER S MANUAL...
