protech BM-0962 User Manual

Mini itx motherboard supports intel bay trail soc with dvi/ lvds/ audio/ 2lan/6com
Hide thumbs Also See for BM-0962:
Table of Contents

Advertisement

Quick Links

Download this manual
USER'S
MANUAL
BM-0962
BM-0962
Mini ITX Motherboard supports
Intel ® Bay Trail SOC with
DVI/ LVDS/ Audio/ 2LAN/6COM
M3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BM-0962 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for protech BM-0962

Summary of Contents for protech BM-0962

  • Page 1 USER’S MANUAL BM-0962 Mini ITX Motherboard supports Intel ® Bay Trail SOC with DVI/ LVDS/ Audio/ 2LAN/6COM BM-0962...
  • Page 2 BM-0962 Mini ITX MotherBoard supports Intel® Bay Trail SOC With DVI/ LVDS/ Audio/ 2LAN/ 6COM COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in Dec. 2016. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual…............System Specification…............1-3 Safety Precautions…............. CHAPTER 2 HARDWARE CONFIGURATION Jumper & Connector Quick Reference Table…....Component Locations….…........... How to Set Jumpers…............Clear CMOS Data Selection……………………………….. LVDS Power Selection…….……………………………..Backlight/Inverter PWM Voltage Selection…….…………. Power-On Mode Selection…………………......
  • Page 5 Contents 2-26 LAN & USB2.0 Port…………………..……………….…... 2-25 2-27 LAN & USB2.0/3.0 Port…………………..…………...…... 2-26 2-28 LVDS Connector…………………………..…………...…... 2-27 2-29 SATA Connector…………………..……..…………….…... 2-28 2-30 SATA Power Connector…………………..…………...…... 2-28 2-31 USB Connector…………………………..……..……...…... 2-28 2-32 Mini PCIE Connector……………………..…………...…... 2-29 2-33 PCIE Bus………..………………………..……..……...…... 2-30 2-34 LPC Connector.………………………..……..……...…..2-31 CHAPTER 3 SOFTWARE UTILITIES Introduction……………..........…..

  • Page 6: Memory Map

    Contents Memory Map….…………………………………………………… I/O Map…..................Watchdog Timer Configuration….………………...……………… B-11 Flash BIOS Update…..........…....B-14...

  • Page 7: Chapter 1 Introduction

    CHAPTER INTRODUCTION This chapter gives you the information for BM-0962. It also outlines the system specifications. The following sections are included:  About This Manual  System Specifications  Safety Precautions Experienced users can go to chapter 2 on page 2-1 for a quick start.

  • Page 8: About This Manual

    Atom E3815/ E3827/ J1900/ N2930/ N2807 processor, enhanced with LAN, VGA, 6 USB & 6COM, which is fully PC/AT compatible. The BM-0962 provides faster processing speed, greater expandability and can handle more tasks than before. This manual is designed to assist you how to install and set up the system. It contains four chapters.

  • Page 9: System Specification

    * If there is only one SO-DIMM, SO-DIMM1 should be inserted first instead of SO-DIMM2. BIOS Watchdog 1~255 seconds Power Supply DC 12V in Dimension 170 mm x 170 mm (6.69” x 6.69”) Certificate CE/FCC Class A  Page: 1-3 BM-0962 USER S MANUAL...
  • Page 10  COM4, 5, 6: 2.0mm pitch pin header  COM3,4 support +5/+12V *COM 5/6 support RS-232/422/485 function via the daughter board. * BM-0962-07N and BM-0962-W5N SPEC do not support COM5 and COM6. USB Port 6 USB ports:  5 x USB2.0: (3 x stack w/ LAN connector, rear IO, 2 x onboard Connector) ...
  • Page 11 1 x DVI-I, rear IO 1 x LVDS(DP), Dual channel 18/24bit  *Only support two independent displays  * BM-0962- 07N SPEC does not support LVDS. LED Indicator HDD LED, Power LED, Power Switch, Reset Switch Speaker Internal buzzer Environment Operating Temp.

  • Page 12: Safety Precautions

    Disconnect the power supply when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system.  Page: 1-6 BM-0962 USER S MANUAL...

  • Page 13: Chapter 2 Hardware Configuration

    CHAPTER HARDWARE CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. The following sections are included:  Jumper & Connector Quick Reference Table  Component Locations  Configuration and Jumper settings  Connector’s Pin Assignments Page 2-1...

  • Page 14: Jumper & Connector Quick Reference Table

    LAN & USB2.0 Port JLAN_USB1 LAN& USB2.0/3.0 Port JLAN_USB2 LVDS Connector JLVDS1 SATA Connector JSATA1, JSATA2 SATA Power Connector JSATA_PWR1, JSATA_PWR2 USB Connector JUSB1 MINI PCIE Connector M_PCI_E1 PCIE BUS PCI_E1 LPC Connector JLPC1  Page: 2-2 BM-0962 USER S MANUAL...

  • Page 15: Component Locations

    JSYS_FAN1 JINV1 JLVDS1 JBAT1 15 16 JUSB1 17 18 JDIO1 JLPC1 51 52 JP14 JP15 Intel® Bay Trail-I/M/D JSATA_PWR1 JSATA_PWR2 JCPU_FAN1 JDC_PWR1 DIMM2 JSATA2 JSATA1 BM-0962 Connector, Jumper and Component Locations (Front Side)  Page: 2-3 BM-0962 USER S MANUAL...

  • Page 16: How To Set Jumpers

    PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent.  Page: 2-4 BM-0962 USER S MANUAL...

  • Page 17: Jumper Settings

    Jumper Block looks like this Jumper Settings 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this  Page: 2-5 BM-0962 USER S MANUAL...

  • Page 18: Clear Cmos Data Selection

    JP1: Clear CMOS Data Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING Clear CMOS Note: Manufacturing default is NC. 2-5. LVDS POWER SELECTION JP4: LVDS Power Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING 3.3V Note: Manufacturing default is 3.3V.  Page: 2-6 BM-0962 USER S MANUAL...

  • Page 19: Backlight/Inverter Pwm Voltage Selection

    Chapter 2 Hardware Configuration 2-6. Backlight Inverter PWM Voltage Selection JP5: Backlight Inverter PWM Voltage Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING 3.3V Note: Manufacturing default is 3.3V.  Page: 2-7 BM-0962 USER S MANUAL...

  • Page 20: Power-On Mode Selection

    Select by BIOS Auto-on Note 1: Manufacturing default is Note 2: Manufacturing default for BS-H292 (SBOX) is "NC". Note 3: Auto-On means that system will turn on automatically whenever the main power is restored.  Page: 2-8 BM-0962 USER S MANUAL...

  • Page 21: Backlight Enable Selection

    Chapter 2 Hardware Configuration 2-8. BACKLIGHT ENABLE SELECTION JP9: BACKLIGHT ENABLE Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING 3.3V Note: Manufacturing default is 5V.  Page: 2-9 BM-0962 USER S MANUAL...

  • Page 22: Vga/Dvi Selection

    Chapter 2 Hardware Configuration 2-9. VGA/DVI SELECTION JP10: VGA/DVI Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING (1-3) (5-6) JP10 (1-2) (4-6) JP10 Note: Manufacturing default is DVI.  Page: 2-10 BM-0962 USER S MANUAL...

  • Page 23: Lvds Resolution Selection

    JP14(1-3) JP15(2-4) 1920x1080 JP15(1-3) 2CH/24bit JP14(2-4) JP14 JP15 JP14(3-5) JP15(2-4) 1600x1200 JP15(1-3) 2CH/24bit JP14(4-6) JP14 JP15 JP14(1-3) JP15(2-4) 1680x1050 JP15(1-3) 2CH/24bit JP14(4-6) JP14 JP15 JP14(3-5) JP15(2-4) JP15(3-5) 1600x900 2CH/24bit JP14(2-4) JP15 JP14 JP14(1-3)  Page: 2-11 BM-0962 USER S MANUAL...
  • Page 24 JP14(3-5) JP15(4-6) 1366x768 JP15(1-3) 1CH/18bit JP14(2-4) JP15 JP14 JP14(1-3) JP15(4-6) 1280x1024 JP15(1-3) 2CH/24bit JP14(2-4) JP14 JP15 JP14(3-5) JP15(4-6) 1280x960 JP15(1-3) 1CH/24bit JP14(4-6) JP14 JP15 JP14(1-3) JP15(4-6) JP15(1-3) 1280x800 1CH/18bit JP14(4-6) JP14 JP15 JP14(3-5)  Page: 2-12 BM-0962 USER S MANUAL...
  • Page 25 JP14(1-3) JP15(4-6) 1024x768 JP15(3-5) 1CH/24bit JP14(2-4) JP14 JP15 JP14(3-5) JP15(4-6) 1024x768 JP15(3-5) 1CH/18bit JP14(4-6) JP14 JP15 JP14(1-3) JP15(4-6) 800x600 JP15(3-5) 1CH/18bit JP14(4-6) JP14 JP15 JP14(3-5) Note: Manufacturing default is 1 CH/24 bit 1024x768.  Page: 2-13 BM-0962 USER S MANUAL...

  • Page 26: Com3 Voltage Selection

    Chapter 2 Hardware Configuration 2-11. COM3 VOLTAGE SELECTION JP_COM3: COM3 Voltage Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING JP_COM3 JP_COM3 JP_COM3 Note: Manufacturing default is RI.  Page: 2-14 BM-0962 USER S MANUAL...

  • Page 27: Com4 Voltage Selection

    Chapter 2 Hardware Configuration 2-12. COM4 VOLTAGE SELECTION JP_COM4: COM4 Voltage Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING JP_COM4 JP_COM4 JP_COM4 Note 1: Manufacturing default is RI. Note 2: Manufacturing default for BS-H292 (SBOX)) is 5V (5-6).  Page: 2-15 BM-0962 USER S MANUAL...

  • Page 28: Audio Port

    Chapter 2 Hardware Configuration 2-13. AUDIO PORT JAUDIO1: Line-In, Line-Out & Microphone The connector can also support only Microphone. Line-In: ASSIGNMENT LINE-IN-L LINE-IN-R Line-Out: ASSIGNMENT LINE-OUT-L LINE-OUT-R JAUDIO1 Mic-In: ASSIGNMENT MIC_L MIC_R Others: ASSIGNMENT  Page: 2-16 BM-0962 USER S MANUAL...

  • Page 29: Battery Wafer

    Chapter 2 Hardware Configuration 2-14. BATTERY WAFER JBAT1: Battery Wafer ASSIGNMENT RTC_BAT JBAT1 2-15. COM PORT JCOM2_3: COM Port ASSIGNMENT JCOM2_3  Page: 2-17 BM-0962 USER S MANUAL...

  • Page 30: Com4 Connector

    Chapter 2 Hardware Configuration 2-16. COM4 CONNECTOR JCOM4: COM4 Connector ASSIGNMENT JCOM4  Page: 2-18 BM-0962 USER S MANUAL...

  • Page 31: Com5 Connector

    Chapter 2 Hardware Configuration 2-17. COM5 CONNECTOR JCOM5: COM5 Connector ASSIGNMENT JCOM5 2-18. COM6 CONNECTOR JCOM6: COM6 Connector ASSIGNMENT JCOM6  Page: 2-19 BM-0962 USER S MANUAL...

  • Page 32: Dvi-I & Com Port

    2-19. DVI-I & COM PORT JCOM_DVII1: DVI-I & COM PORT DVI-I: DVI Connector ASSIGNMENT ASSIGNMENT TMDS_D2- TMDS_D2+ DDC_CLK DDC_DATA VSYNC TMDS_D1- TMDS_D1+ TMDS_D0- TMDS_D0+ TMDS_CLK+ TMDS_CLK- GREEN BLUE HSYNC COM1: COM Connector ASSIGNMENT JCOM_DVII1  Page: 2-20 BM-0962 USER S MANUAL...

  • Page 33: Fan Connector

    Chapter 2 Hardware Configuration 2-20. FAN CONNECTOR JCPU_FAN1, JSYS_FAN1: Fan Connector ASSIGNMENT FAN_CONTROL FAN_SIGNAL JCPU_FAN1/ JSYS_FAN1 2-21. DC 12V CONNECTOR JDC_PWR1: DC 12V Connector ASSIGNMENT JDC_PWR1  Page: 2-21 BM-0962 USER S MANUAL...

  • Page 34: Dio Wafer

    DIN0 DIN1 JDIO1 DIN2 DIN3 DOUT0 DOUT1 DOUT2 DOUT3 2-23. FRONT CONNECTOR JFP1: Front Connector ASSIGNMENT ASSIGNMENT HDD_LED+ RESET SWITCH PWR_LED+ SPEAKER SIGNAL HDD_LED- POWER BUTTON PWR_LED- SPEAKER SIGNAL SPK_VCC SPEAKER SIGNAL JFP1  Page: 2-22 BM-0962 USER S MANUAL...

  • Page 35: Inverter Wafer

    Chapter 2 Hardware Configuration 2-24. INVERTER WAFER JINV1: Inverter Wafer ASSIGNMENT JINV1 PWM SIGNAL BACKLIGHT EN  Page: 2-23 BM-0962 USER S MANUAL...

  • Page 36: Kb/Ms Port

    Chapter 2 Hardware Configuration 2-25. KB/MS PORT JKB_MS1: KB/MS Port Keyboard: ASSIGNMENT DATA Mouse: ASSIGNMENT DATA JKB_MS1  Page: 2-24 BM-0962 USER S MANUAL...

  • Page 37: Lan & Usb2.0 Port

    2-26. LAN & USB2.0 PORT Yellow Orange/ Green JLAN1_USB1: LAN & USB2.0 PORT LAN: USB2.0: ASSIGNMENT ASSIGNMENT TX_D1+ TX_D1- RX_D2+ BI_D3+ BI_D3- RX_D2- BI_D4+ BI_D4- JLAN1_USB1 BM-0962-00N, BM-0962-30N, BM- BM-0962-07N and BM-0962-W5N 0962-W7N and BM-0962-E5N  Page: 2-25 BM-0962 USER S MANUAL...

  • Page 38: Lan & Usb2.0/3.0 Port

    Chapter 2 Hardware Configuration 2-27. LAN& USB2.0/3.0 PORT JLAN1_USB2: LAN & USB2.0/3.0 PORT Yellow Orange/ Green LAN: ASSIGNMENT TX_D1+ TX_D1- RX_D2+ BI_D3+ BI_D3- RX_D2- BI_D4+ BI_D4- USB2.0: ASSIGNMENT VBUS JLAN1_USB2 STDA_SSRX- STDA_SSRX+ STDA_SSTX- STDA_SSTX+  Page: 2-26 BM-0962 USER S MANUAL...

  • Page 39: Lvds Connector

    2-28. LVDS CONNECTOR JLVDS1: LVDS Connector JLVDS1 ASSIGNMENT ASSIGNMENT ASSIGNMENT LVDS_VCC LVDS1_D3+ LVDS1_D3- LVDS0_D1+ LVDS1_CLK- LVDS1_D0+ LVDS0_D1- LVDS1_CLK+ LVDS1_D0- LVDS0_D0+ LVDS1_D2- LVDS0_CLK+ LVDS0_D0- LVDS1_D2+ LVDS0_CLK- LVDS0_D3+ LVDS0_D3- LVDS1_D1- LVDS0_D2+ LVDS_VCC LVDS1_D1+ LVDS0_D2- LVDS_VCC  Page: 2-27 BM-0962 USER S MANUAL...

  • Page 40: Sata Connector

    2-29. SATA CONNECTOR JSATA1, JSATA2: Two Serial ATA Connectors ASSIGNMENT JSATA1/ JSATA2 2-30. SATA POWER CONNECTOR JSATA_PWR1, JSATA_PWR2: SATA Power Connector ASSIGNMENT JSATA_PWR1/ JSATA_PWR2 2-31. USB CONNECTOR JUSB1: USB Connector ASSIGNMENT ASSIGNMENT JUSB1  Page: 2-28 BM-0962 USER S MANUAL...

  • Page 41: Mini Pcie Connector

    Chapter 2 Hardware Configuration 2-32. MINI PCIE CONNECTOR M_PCI_E1: MINI PCIE Connector M_PCI_E1 ASSIGNMENT ASSIGNMENT WAKE# 3.3V 1.5V SMB_CLK PETn0 1.5V SMB_DATA CLKREQ# PETp0 USB_D- REFCLK- USB_D+ REFCLK+ 3.3V 3.3V PERST# 1.5V PERn0 3.3V PERp0 3.3V  Page: 2-29 BM-0962 USER S MANUAL...

  • Page 42: Pcie Bus

    Chapter 2 Hardware Configuration 2-33. PCIE BUS PCI_E1: PCIE BUS ASSIGNMENT ASSIGNMENT SMB_CLK SMB_DATA 3.3V PCI_E1 3.3V 3.3V 3.3V_SB PWRGD WAKE# REFCLK+ REFCLK- HSOP0 HSON0 HSIP0 HSIN0 PRSNT#  Page: 2-30 BM-0962 USER S MANUAL...

  • Page 43: Lpc Connector

    Chapter 2 Hardware Configuration 2-34. LPC CONNECTOR JLPC1: LPC Connector ASSIGNMENT ASSIGNMENT LAD0 FRAME SMBCLK JLPC1 SMBDATA RESET 3VSB VCC5 SERIRQ LAD3 LAD2 CLK RUN VCC3 SUS_TAT LAD1 DREQ0  Page: 2-31 BM-0962 USER S MANUAL...
  • Page 44 Chapter 3 Software Utilities 3-1. INTRODUCTION Enclosed with our BM-0962 package are our driver utilities that are stored in a provided CD-ROM. Refer to the following table for the driver locations: FILENAME (Assume that CD-ROM drive is D:) PURPOSE  D:\Driver\Platform\Win7,Win8,Win8.1(32-bit)\...
  • Page 45 CHAPTER BIOS SETUP This chapter shows how to set up the AMI BIOS. The following sections are included:  Introduction  Entering Setup  Main  Advanced  Chipset  Boot  Security  Save & Exit Page: 4-1...

  • Page 46: Introduction

    Chapter 4 BIOS Setup 4-1. INTRODUCTION The board BM-0962 uses an AMI Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the BIOS Setup program, Power-on Self-Test (POST), the PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.
  • Page 47 The BIOS Setup program can be used to view and change the BIOS settings for the computer. The BIOS Setup program is accessed by pressing the <Del> or <F2> key after the POST memory test begins and before the operating system boot begins. The settings are shown below.  Page: 4-3 BM-0962 USER S MANUAL...

  • Page 48: Entering Setup

    Chapter 4 BIOS Setup 4-2. ENTERING SETUP When the system is powered on, the BIOS will enter the Power-On Self Test (POST) routines and the following message will appear on the lower screen:  Page: 4-4 BM-0962 USER S MANUAL...
  • Page 49 You may move the cursor by up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen.  Page: 4-5 BM-0962 USER S MANUAL...

  • Page 50: Main

    (project) and BIOS Build Date and Time. Main Screen BIOS Setting Options Description/Purpose BIOS Vendor No changeable options Displays the BIOS vendor. Core Version No changeable options Displays the current BIOS core version.  Page: 4-6 BM-0962 USER S MANUAL...
  • Page 51 Displays the current TXE version. System Language English BIOS Setup language. System Date Month, day, year Specifies the current date. System Time Hour, minute, second Specifies the current time. Access Level Administrator Displays the user access level.  Page: 4-7 BM-0962 USER S MANUAL...

  • Page 52: Advanced

    Configuration, IDE Configuration, CSM Configuration and USB Configuration. Advanced Screen BIOS Setting Options Description/Purpose Trusted computing Sub-Menu Trusted computing Settings ACPI Settings Sub-Menu System ACPI Parameters. F81866 Super IO Sub-Menu Super I/O Chip Configuration. Configuration  Page: 4-8 BM-0962 USER S MANUAL...
  • Page 53 Sub-Menu F81866 Watchdog Parameters. CPU Configuration Sub-Menu CPU Configuration. Parameters. IDE Configuration Sub-Menu SATA Configuration Parameters. CSM Selection Sub-Menu Configure Option ROM execution, boot options filters, etc.. USB Configuration Sub-Menu USB Configuration Parameters.  Page: 4-9 BM-0962 USER S MANUAL...

  • Page 54: Trusted Computing

    - TPM 2.0 devices. TPM2.0 will restrict support to TPM 2.0 devices. Auto will support both with the - Auto default value set to TPM2.0 devices if not found. TPM1.2 devices will be enumerated.  Page: 4-10 BM-0962 USER S MANUAL...
  • Page 55 Menu Path Advanced > ACPI Settings The ACPI Settings allows users to configure relevant ACPI (Advanced Configuration and Power Management Interface) settings, such as enable/disable Hibernation and ACPI Sleep State. ACPI Settings Screen  Page: 4-11 BM-0962 USER S MANUAL...

  • Page 56: Super Io Configuration

    • Suspend Disabled disables ACPI sleep RAM) feature. • S3 allows the platform to enter Suspend to RAM mode. 4-4-3. Super IO Configuration Menu Path Advanced > F81866 Super IO Configuration Super IO Configuration Screen  Page: 4-12 BM-0962 USER S MANUAL...
  • Page 57 Serial Port 3 Configuration Sub-menu Sets Parameters for COMC. Serial Port 4 Configuration Sub-menu Sets Parameters for COMD. Serial Port 5 Configuration Sub-menu Sets Parameters for COME. Serial Port 6 Configuration Sub-menu Sets Parameters for COMF.  Page: 4-13 BM-0962 USER S MANUAL...

  • Page 58: Serial Port 1 Configuration

    -Enabled Device Settings No changeable options Displays current settings of serial port 1. Change Settings -IO=3F8h; IRQ=4 Select IRQ and I/O resource for the serial port 1. -IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=3E8h;IRQ=3,4,5,6,7,9,10,11,12 -IO=2E8h;IRQ=3,4,5,6,7,9,10,11,12  Page: 4-14 BM-0962 USER S MANUAL...

  • Page 59: Serial Port 2 Configuration

    -Enabled Device Settings No changeable options Displays current settings of serial port 2. Change Settings -IO=2F8h; IRQ=3 Select IRQ and I/O resource for the serial port 2. -IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=3E8h;IRQ=3,4,5,6,7,9,10,11,12 -IO=2E8h;IRQ=3,4,5,6,7,9,10,11,12  Page: 4-15 BM-0962 USER S MANUAL...

  • Page 60: Serial Port 3 Configuration

    -Enabled Device Settings No changeable options Displays current settings of serial port 3. Change Settings -IO=3E8h; IRQ=10 Select IRQ and I/O resource for the serial port 3. -IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=2F0h;IRQ=3,4,5,6,7,9,10,11,12 -IO=2E0h;IRQ=3,4,5,6,7,9,10,11,12  Page: 4-16 BM-0962 USER S MANUAL...

  • Page 61: Serial Port 4 Configuration

    Enables or disables serial port 4. -Enabled Device Settings No changeable options Displays current settings of serial port 4. Change Settings -IO=2E8h; IRQ=5 Select IRQ and I/O resource for the serial port 4. -IO=3E8h;IRQ=3,4,5,6,7,9,10,11,12 -IO=2E8h;IRQ=3,4,5,6,7,9,10,11,12 -IO=2F0h;IRQ=3,4,5,6,7,9,10,11,12 -IO=2E0h;IRQ=3,4,5,6,7,9,10,11,12  Page: 4-17 BM-0962 USER S MANUAL...

  • Page 62: Serial Port 5 Configuration

    Enable or disable serial port 5. -Enabled Device Settings No changeable options Displays current settings of serial port 5. Change Settings -IO=2F0h; IRQ=7 Select IRQ and I/O resource for the serial port 5. -IO=3E8h;IRQ=3,4,5,6,7,9,10,11,12 -IO=2E8h;IRQ=3,4,5,6,7,9,10,11,12 -IO=2F0h;IRQ=3,4,5,6,7,9,10,11,12 -IO=2E0h;IRQ=3,4,5,6,7,9,10,11,12  Page: 4-18 BM-0962 USER S MANUAL...

  • Page 63: Serial Port 6 Configuration

    Enables or disables serial port 6. -Enabled Device Settings No changeable options Displays current settings of serial port 6. Change Settings -IO=2E0h; IRQ=7 Select IRQ and I/O resource for the serial port 6. -IO=3E8h;IRQ=3,4,5,6,7,9,10,11,12 -IO=2E8h;IRQ=3,4,5,6,7,9,10,11,12 -IO=2F0h;IRQ=3,4,5,6,7,9,10,11,12 -IO=2E0h;IRQ=3,4,5,6,7,9,10,11,12  Page: 4-19 BM-0962 USER S MANUAL...

  • Page 64: Hardware Monitor

    System Fan Speed No changeable options Displays the fan’s speed VCORE No changeable options Displays the voltage level of the +VCORE in supply. 5VSB No changeable options Displays the voltage level of the  Page: 4-20 BM-0962 USER S MANUAL...
  • Page 65 Displays the voltage level of the +VCC12 in supply. VCC3V No changeable options Displays the voltage level of the VCC3V in supply. VSB3V No changeable options Displays the voltage level of the VSB3V in supply.  Page: 4-21 BM-0962 USER S MANUAL...
  • Page 66 Watchdog timer unit - 60s as the time unit of Watchdog timer. Numeric (from 1 to 255) Sets the timeout for Watchdog timer. Count for Timer (Max. value: 255 seconds or (Seconds) minutes)  Page: 4-22 BM-0962 USER S MANUAL...

  • Page 67: Cpu Configuration

    Socket 0 CPU Information Sub-Menu Reports Socket 0 CPU information CPU Speed No changeable Reports the current CPU speed. options 64-bit No changeable Reports if the processor supports Intel options x86-64 (amd64) implementation.  Page: 4-23 BM-0962 USER S MANUAL...

  • Page 68: Socket 0 Cpu Information

    No changeable Reports the maximum CPU speed. options Min CPU Speed No changeable Reports the minimum CPU speed options Processor Cores No changeable Displays the number of physical cores in the options processor.  Page: 4-24 BM-0962 USER S MANUAL...
  • Page 69 Displays L1 Data Cache size. options L1 Code Cache No changeable Displays L1 Code Cache size. options L2 Cache No changeable Displays L2 Cache size. options L3 Cache No changeable Displays L3 Cache size. options  Page: 4-25 BM-0962 USER S MANUAL...

  • Page 70: Ide Configuration

    Enables or disables SATA Device. - Enabled SATA Test Mode - Disabled Enables or disables SATA Test Mode. - Enabled SATA Speed Support - Gen1 • Gen1 mode sets device to 1.5 Gbit/s  Page: 4-26 BM-0962 USER S MANUAL...
  • Page 71 Displays the drive installed on this SATA port 0. Shows [Empty] if no drive is installed. SATA Port 1 [drive] Displays the drive installed on this SATA port 1. Shows [Empty] if no drive is installed.  Page: 4-27 BM-0962 USER S MANUAL...

  • Page 72: Csm Configuration

    CSM16 Module No changeable Displays the current CSM (Compatibility Support Version options Module) version. Boot option filter - UEFI and Legacy This option controls what kind of devices system can boot. - Legacy only  Page: 4-28 BM-0962 USER S MANUAL...
  • Page 73 Controls the execution of UEFI and Legacy Video. - UEFI - Legacy Other PCI - Do not launch Selects the launch method for other PCI devices, such devices as NIC, mass storage or video card. - UEFI - Legacy  Page: 4-29 BM-0962 USER S MANUAL...

  • Page 74: Usb Configuration

    Displays the number of available USB devices. Legacy USB Support - Disabled Enables support for legacy USB. - Enabled - Auto EHCI Hand-off - Disabled This is a workaround for OSes without EHCI hand-off support. - Enabled  Page: 4-30 BM-0962 USER S MANUAL...
  • Page 75 100 ms, for a Hub port the delay is taken from Hub descriptor. Mass Storage - Auto Displays the device name and choose the Devices: device emulation type. - Force FDD - Hard Disk - CD-ROM  Page: 4-31 BM-0962 USER S MANUAL...

  • Page 76: Chipset

    This menu allows users to configure advanced Chipset settings such as North Bridge and South Bridge configuration parameters. Chipset Screen BIOS Setting Options Description/Purpose North Bridge Sub-menu Sets Parameter for (North Bridge) configuration. South Bridge Sub-menu Sets Parameter for (South Bridge) configuration.  Page: 4-32 BM-0962 USER S MANUAL...

  • Page 77: North Bridge

    No changeable Displays the DRAM information on the options platform. Total Memory No changeable Displays the DRAM size options Max TOLUD - 2 GB Maximum value of TOLUD. - 2.25 GB - 2.5 GB  Page: 4-33 BM-0962 USER S MANUAL...
  • Page 78 Primary IGFX Boot Display Selects the Video Device that will be - VBIOS Default activated during POST. - CRT - DVI - LVDS Secondary IGFX Boot Selects the secondary display - Disabled Display device.  Page: 4-34 BM-0962 USER S MANUAL...

  • Page 79: South Bridge

    Configures Azalia HD Audio parameters. USB Configuration Sub-menu Configures USB parameters. Restore AC Power - Power Off Selects the AC power state when the power supply Loss - Power On is restored following a power failure.  Page: 4-35 BM-0962 USER S MANUAL...
  • Page 80 4-5-2-1. South Bridge – Azalia HD Audio Menu Path Chipset > South Bridge > Azalia HD Audio The Azalia HD Audio allows users to controls the detection of the Azalia device. Azalia HD Audio Setting Screen  Page: 4-36 BM-0962 USER S MANUAL...
  • Page 81 Chipset > South Bridge > USB Configuration USB Configuration Screen BIOS Setting Options Description/Purpose USB 2.0(EHCI) Support - Disabled Enables Enhanced Host Controller Interface 1 for high-speed USB functions (USB 2.0). - Enabled  Page: 4-37 BM-0962 USER S MANUAL...
  • Page 82 Enables or Disables USB port 1. - Enabled (USB Hub 1~4) USB Port 2 - Disabled Enables or Disables USB port 2. - Enabled USB Port 3 - Disabled Enables or Disables USB port 3. - Enabled  Page: 4-38 BM-0962 USER S MANUAL...

  • Page 83: Security

    Heed that a user password does not provide access to most of the features in the Setup utility. Security Screen BIOS Setting Options Description/Purpose Administrator Password can be 3-20 Specifies the administrator password. Password alphanumeric characters.  Page: 4-39 BM-0962 USER S MANUAL...

  • Page 84: Boot

    This menu provides control items for system boot configuration such as setting setup prompt timeout, enabling/disabling quiet boot and fast boot, changing the boot order from the available bootable device(s) and BBS option priorities. Boot Screen  Page: 4-40 BM-0962 USER S MANUAL...
  • Page 85 Defines the boot order for all the hard Hard Drive BBS Priorities Sub-Menu drives connected to the system, e.g. SATA, USB drive. Network Drive BBS Priorities Sub-Menu Allow users to select the boot order of available drive(s)  Page: 4-41 BM-0962 USER S MANUAL...
  • Page 86 Select Hard Drive BBS Priorities from the Boot menu to configure the boot order and priority of the available drives. Hard Drive BBS Priorities Screen BIOS Setting Options Description/Purpose Boot Option #1 - #n - [Drive(s)] Change the boot order of available drive(s). - Disabled  Page: 4-42 BM-0962 USER S MANUAL...

  • Page 87: Save & Exit

    Discard Changes and Reset to cancel the changed settings and restore the factory BIOS defaults. Load User Defaults You may simply press F3 at any time to load the Optimized Values which resets all BIOS settings to the factory defaults. Save & Exit Screen  Page: 4-43 BM-0962 USER S MANUAL...
  • Page 88 Restore Defaults No changeable options settings. Saves the changes done so far as User Save as User Defaults No changeable options Defaults. Forces to boot the system from Boot Override - [Drive(s)] selected [drive(s)].  Page: 4-44 BM-0962 USER S MANUAL...

  • Page 89: Expansion Bus

    EXPANSION APPENDIX This appendix indicates the pin assignments of expansion bus. The following section is included:  PCIe Bus Page: A-1...
  • Page 90 Appendix A Expansion Bus PCIE BUS PCI_E1 with 164 pins is optional on BM-0962. The pin assignments are as follows: PCI_E1 PCI_E1: PIN ASSIGNMENT PIN ASSIGNMENT PIN ASSIGNMENT ASSIGNMENT Reserved A42 GND +12V EXP_A_TX_6_D +12V A43 EXP_A_RX_6_D +12V +12V A44 EXP_A_RX_6_D...
  • Page 91 A78 Reserved B37 EXP_A_TX_5_D Reserved A38 GND A79 Reserved B38 EXP_A_TX_5_D Reserved A39 EXP_A_RX_5_D A80 Reserved B39 GND Reserved A40 EXP_A_RX_5_D A81 Reserved B40 GND Reserved A41 GND A82 Reserved B41 EXP_A_TX_6_D Reserved  Page: A-3 BM-0962 USER S MANUAL...
  • Page 92 APPENDIX TECHNICAL SUMMARY This section introduce you the maps concisely. The following sections are included:  Block Diagram  Interrupt Map  DMA Channel Map  I/O Map  Memory Map  Watchdog Timer Configuration  Flash BIOS Update Page: B-1...

  • Page 93: Block Diagram

    64Mbit SPI Flash ROM LOW PIN COUNT 80 port for Debug Connector COM 1/3/4/5/6 RS232 FINTEK Com1/2 support 5V/12V HW monitor LPC SIO COM2 F81846AD-I RS232/422/485 Keyboard Mouse VR12.5 ISL95816 3 Phase PWM TPS51216 For DDR3  Page: B-2 BM-0962 USER S MANUAL...

  • Page 94: Interrupt Map

    Microsoft ACPI-Compliant System IRQ 93 Microsoft ACPI-Compliant System IRQ 94 Microsoft ACPI-Compliant System IRQ 95 Microsoft ACPI-Compliant System IRQ 96 Microsoft ACPI-Compliant System IRQ 97 Microsoft ACPI-Compliant System IRQ 98 Microsoft ACPI-Compliant System  Page: B-3 BM-0962 USER S MANUAL...
  • Page 95 Microsoft ACPI-Compliant System IRQ 130 Microsoft ACPI-Compliant System IRQ 131 Microsoft ACPI-Compliant System IRQ 132 Microsoft ACPI-Compliant System IRQ 133 Microsoft ACPI-Compliant System IRQ 134 Microsoft ACPI-Compliant System IRQ 135 Microsoft ACPI-Compliant System  Page: B-4 BM-0962 USER S MANUAL...
  • Page 96 Microsoft ACPI-Compliant System IRQ 167 Microsoft ACPI-Compliant System IRQ 168 Microsoft ACPI-Compliant System IRQ 169 Microsoft ACPI-Compliant System IRQ 170 Microsoft ACPI-Compliant System IRQ 171 Microsoft ACPI-Compliant System IRQ 172 Microsoft ACPI-Compliant System  Page: B-5 BM-0962 USER S MANUAL...
  • Page 97 Intel(R) I210 Gigabit Network Connection #3 4294967290 Intel(R) I210 Gigabit Network Connection #3 4294967291 Intel(R) I210 Gigabit Network Connection #3 4294967292 Intel(R) USB 3.0 eXtensible Host Controller 4294967293 Intel(R) Atom(TM) Processor E3800 Series/Intel(R) Celeron(R) 4294967294 Processor N2920/J1900  Page: B-6 BM-0962 USER S MANUAL...

  • Page 98: Memory Map

    Celeron(R) Processor N2920/J1900 Motherboard resources 0xE0000000-0xEFFFFFFF Motherboard resources 0xFED01000-0xFED01FFF Motherboard resources 0xFED03000-0xFED03FFF Motherboard resources 0xFED04000-0xFED04FFF Motherboard resources 0xFED0C000-0xFED0FFFF Motherboard resources 0xFED08000-0xFED08FFF 0xFED1C000-0xFED1CFFF Motherboard resources Motherboard resources 0xFEE00000-0xFEEFFFFF Motherboard resources 0xFEF00000-0xFEFFFFFF 0xD0600000-0xD08FFFFF PCI standard PCI-to-PCI bridge  Page: B-7 BM-0962 USER S MANUAL...
  • Page 99 Appendix B Technical Summary MEMORY MAP ASSIGNMENT 0xA0000-0xBFFFF PCI bus Intel(R) Atom(TM) Processor E3800 Series/Intel(R) 0xA0000-0xBFFFF Celeron(R) Processor N2920/J1900 0xC0000-0xDFFFF PCI bus 0xE0000-0xFFFFF PCI bus  Page: B-8 BM-0962 USER S MANUAL...

  • Page 100: I/O Map

    Programmable interrupt controller 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B2-0x000000B3 Motherboard resources 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000002E0-0x000002E7 Communications Port (COM6)  Page: B-9 BM-0962 USER S MANUAL...
  • Page 101 Standard AHCI 1.0 Serial ATA Controller 0x0000F050-0x0000F057 Standard AHCI 1.0 Serial ATA Controller 0x0000F060-0x0000F063 Standard AHCI 1.0 Serial ATA Controller 0x0000F070-0x0000F077 Standard AHCI 1.0 Serial ATA Controller 0x0000F080-0x0000F087 Intel(R) Atom(TM) Processor E3800 Series/Intel(R) Celeron(R) Processor N2920/J1900  Page: B-10 BM-0962 USER S MANUAL...

  • Page 102: Watchdog Timer Configuration

    To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode.  Page: B-11 BM-0962 USER S MANUAL...
  • Page 103 ;------ Enter extended function mode -------------------------------------------------------- ;------ Select Logical Device 7 of watchdog timer -------------------------------------------- ;------ Enable Watch dog feature ------------------------------------------------------------------ 030h ;------ Enable Watch PME-------------------------------------------------------------------------- 0FAh ;------ Set second as counting unit ---------------------------------------------------------------- 0f5h  Page: B-12 BM-0962 USER S MANUAL...
  • Page 104 Appendix B Technical Summary ;------ Set timeout interval as 30seconds and start counting ---------------------------------- 0f6h ;------ Exit the extended function mode ---------------------------------------------------------- 0aah  Page: B-13 BM-0962 USER S MANUAL...

  • Page 105: Flash Bios Update

    The system will go into the BIOS setup menu. Select [Boot] menu. Select [Hard Drive BBS Priorities] and set the USB bootable device as the boot device. Press <F4> to save the configuration and exit the BIOS setup menu.  Page: B-14 BM-0962 USER S MANUAL...
  • Page 106 The recommended options for BIOS ROM update consist of the following parameters: program main BIOS image program Boot Block program NVRAM don’t check ROM ID  Page: B-15 BM-0962 USER S MANUAL...
  • Page 107 BIOS ROM may be crashed and the system will be unable to boot up next time. After the BIOS update procedure is completed, the following messages will be shown: You can restart the system and boot up the system with the new BIOS configurations.  Page: B-16 BM-0962 USER S MANUAL...
  • Page 108 Appendix B Technical Summary The BIOS update procedure is complete after the system is restarted. Reboot the system and verify if the BIOS version shown on the initialization screen has been updated.  Page: B-17 BM-0962 USER S MANUAL...
