Page 1 USER’S MANUAL BM-0962 Mini ITX Motherboard supports Intel ® Bay Trail SOC with DVI/ LVDS/ Audio/ 2LAN/6COM BM-0962...
Page 2 BM-0962 Mini ITX Mother Board supports ® Intel Bay Trail SOC With DVI/ LVDS/ Audio/ 2LAN/ 6COM COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in Dec. 2020. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 4: Table Of Contents
Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual…............System Specification…............1-3 Safety Precautions…............. CHAPTER 2 HARDWARE CONFIGURATION Jumper & Connector Quick Reference Table…....Component Locations….…........... How to Set Jumpers…............Clear CMOS Data Selection……………………………….. LVDS Power Selection…….……………………………..Backlight/Inverter PWM Voltage Selection…….…………. Power-On Mode Selection…………………......
Page 5 Contents 2-26 LAN & USB2.0 Port…………………..……………….…... 2-25 2-27 LAN & USB2.0/3.0 Port…………………..…………...…... 2-26 2-28 LVDS Connector…………………………..…………...…... 2-27 2-29 SATA Connector…………………..……..…………….…... 2-28 2-30 SATA Power Connector…………………..…………...…... 2-28 2-31 USB Connector…………………………..……..……...…... 2-28 2-32 Mini PCIE Connector……………………..…………...…... 2-29 2-33 PCIE Bus………..………………………..……..……...…... 2-30 2-34 LPC Connector.………………………..……..……...…..2-31 CHAPTER 3 SOFTWARE UTILITIES Introduction……………..........…..
Page 6 Contents Interrupt Map…................Memory Map….…………………………………………………… I/O Map…..................Watchdog Timer Configuration….………………...……………… B-11 Flash BIOS Update…..........…....B-14...
Page 7: Chapter 1 Introduction
CHAPTER INTRODUCTION This chapter gives you the information for BM-0962. It also outlines the system specifications. The following sections are included: About This Manual  System Specifications  Safety Precautions  Experienced users can go to chapter 2 on page 2-1 for a quick start.
Page 8: About This Manual
E3815/ E3827/ E 3 8 4 5 / J1900/ N2930/ N2807 processor, enhanced with LAN, VGA, 6 USB & 6 COM, which is fully PC/AT compatible. The BM-0962 provides faster processing speed, greater expandability and can handle more tasks than before.
Page 9: System Specification
* If there is only one SO-DIMM, SO-DIMM1 should be inserted first instead of SO-DIMM2. BIOS Watchdog 1~255 seconds Power Supply DC 12V in Dimension 170 mm x 170 mm (6.69” x 6.69”) Certificate CE/FCC Class A Page: 1-3 ′ BM-0962 USER S MANUAL...
Page 10 Mic In, audio jack, rear I/O. Keyboard/Mouse 1 x PS/2 Expansion Bus 1 x PCIe (1x) 1 x Mini-PCIe GPIO/ DIO GPIO 4in / 4out 1 x LPC pin head (supports TPM module for expansion) Page: 1-4 ′ BM-0962 USER S MANUAL...
Page 11 LED Indicator HDD LED, Power LED, Power Switch, Reset Switch Speaker Internal buzzer Environment Operating Temp. 0°C~60°C (32°F ~140°F), Wide temp SKU: -40°C ~ 85°C Storage Temp. -40°C~80°C (-40°F ~176°F) Operating Humidity 5%~90% (non-condensing) Page: 1-5 ′ BM-0962 USER S MANUAL...
Page 12: Safety Precautions
Disconnect the power supply when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. Page: 1-6 ′ BM-0962 USER S MANUAL...
Page 13: Chapter 2 Hardware Configuration
CHAPTER HARDWARE CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. The following sections are included: Jumper & Connector Quick Reference Table  Component Locations  Configuration and Jumper settings  Connector’s Pin Assignments ...
Page 14: Jumper & Connector Quick Reference Table
LAN & USB2.0 Port JLAN_USB1 LAN& USB2.0/3.0 Port JLAN_USB2 LVDS Connector JLVDS1 SATA Connector JSATA1, JSATA2 SATA Power Connector JSATA_PWR1, JSATA_PWR2 USB Connector JUSB1 MINI PCIE Connector M_PCI_E1 PCIE BUS PCI_E1 LPC Connector JLPC1 ′ Page: 2-2 BM-0962 USER S MANUAL...
Page 15: Component Locations
JSYS_FAN1 JINV1 JLVDS1 JBAT1 15 16 JUSB1 17 18 JDIO1 JLPC1 51 52 JP15 JP14 Intel® Bay Trail-I/M/D JSATA_PWR1 JSATA_PWR2 JCPU_FAN1 JDC_PWR1 DIMM2 JSATA2 JSATA1 BM-0962 Connector, Jumper and Component Locations (Front Side) ′ Page: 2-3 BM-0962 USER S MANUAL...
Page 16: How To Set Jumpers
PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. ′ Page: 2-4 BM-0962 USER S MANUAL...
Page 17 Jumper Block looks like this Jumper Settings 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this ′ Page: 2-5 BM-0962 USER S MANUAL...
Page 18: Clear Cmos Data Selection
JP1: Clear CMOS Data Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING Clear CMOS Note: Manufacturing default is NC. 2-5. LVDS POWER SELECTION JP4: LVDS Power Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING 3.3V Note: Manufacturing default is 3.3V. ′ Page: 2-6 BM-0962 USER S MANUAL...
Page 19: Backlight/Inverter Pwm Voltage Selection
Chapter 2 Hardware Configuration 2-6. Backlight Inverter PWM Voltage Selection JP5: Backlight Inverter PWM Voltage Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING 3.3V Note: Manufacturing default is 3.3V. ′ Page: 2-7 BM-0962 USER S MANUAL...
Page 20: Power-On Mode Selection
Select by BIOS Auto-on Note 1: Manufacturing default is Note 2: Manufacturing default for BS-H292 (SBOX) is "NC". Note 3: Auto-On means that system will turn on automatically whenever the main power is restored. ′ Page: 2-8 BM-0962 USER S MANUAL...
Page 21: Backlight Enable Selection
Chapter 2 Hardware Configuration 2-8. BACKLIGHT ENABLE SELECTION JP9: BACKLIGHT ENABLE Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING 3.3V Note: Manufacturing default is 5V. ′ Page: 2-9 BM-0962 USER S MANUAL...
Page 22: Vga/Dvi Selection
Chapter 2 Hardware Configuration 2-9. VGA/DVI SELECTION JP10: VGA/DVI Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING (1-3) (5-6) JP10 (1-2) (4-6) JP10 Note: Manufacturing default is DVI. ′ Page: 2-10 BM-0962 USER S MANUAL...
Page 23: Lvds Resolution Selection
JP14(1-3) JP15(2-4) 1920x1080 JP15(1-3) 2CH/24bit JP14(2-4) JP14 JP15 JP14(3-5) JP15(2-4) 1600x1200 JP15(1-3) 2CH/24bit JP14(4-6) JP14 JP15 JP14(1-3) JP15(2-4) 1680x1050 JP15(1-3) 2CH/24bit JP14(4-6) JP14 JP15 JP14(3-5) JP15(2-4) 1600x900 JP15(3-5) 2CH/24bit JP14(2-4) JP15 JP14 JP14(1-3) ′ Page: 2-11 BM-0962 USER S MANUAL...
Page 24 JP14(3-5) JP15(4-6) 1366x768 JP15(1-3) 1CH/18bit JP14(2-4) JP15 JP14 JP14(1-3) JP15(4-6) 1280x1024 JP15(1-3) JP14(2-4) 2CH/24bit JP14 JP15 JP14(3-5) JP15(4-6) 1280x960 JP15(1-3) 1CH/24bit JP14(4-6) JP14 JP15 JP14(1-3) JP15(4-6) 1280x800 JP15(1-3) JP14(4-6) 1CH/18bit JP14 JP15 JP14(3-5) ′ Page: 2-12 BM-0962 USER S MANUAL...
Page 25 JP14(1-3) JP15(4-6) 1024x768 JP15(3-5) 1CH/24bit JP14(2-4) JP14 JP15 JP14(3-5) JP15(4-6) 1024x768 JP15(3-5) 1CH/18bit JP14(4-6) JP14 JP15 JP14(1-3) JP15(4-6) 800x600 JP15(3-5) 1CH/18bit JP14(4-6) JP14 JP15 JP14(3-5) Note: Manufacturing default is 1 CH/24 bit 1024x768. ′ Page: 2-13 BM-0962 USER S MANUAL...
Page 26: Com3 Voltage Selection
Chapter 2 Hardware Configuration 2-11. COM3 VOLTAGE SELECTION JP_COM3: COM3 Voltage Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING JP_COM3 JP_COM3 JP_COM3 Note: Manufacturing default is RI. ′ Page: 2-14 BM-0962 USER S MANUAL...
Page 27: Com4 Voltage Selection
Chapter 2 Hardware Configuration 2-12. COM4 VOLTAGE SELECTION JP_COM4: COM4 Voltage Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING JP_COM4 JP_COM4 JP_COM4 Note 1: Manufacturing default is RI. Note 2: Manufacturing default for BS-H292 (SBOX)) is 5V (5-6). ′ Page: 2-15 BM-0962 USER S MANUAL...
Page 28: Audio Port
Chapter 2 Hardware Configuration 2-13. AUDIO PORT JAUDIO1: Line-In, Line-Out & Microphone The connector can also support only Microphone. Line-In: ASSIGNMENT LINE-IN-L LINE-IN-R Line-Out: ASSIGNMENT LINE-OUT-L LINE-OUT-R JAUDIO1 Mic-In: ASSIGNMENT MIC_L MIC_R Others: ASSIGNMENT ′ Page: 2-16 BM-0962 USER S MANUAL...
Page 29: Battery Wafer
Chapter 2 Hardware Configuration 2-14. BATTERY WAFER JBAT1: Battery Wafer ASSIGNMENT RTC_BAT JBAT1 2-15. COM PORT JCOM2_3: COM Port ASSIGNMENT JCOM2_3 ′ Page: 2-17 BM-0962 USER S MANUAL...
Page 30: Com4 Connector
Chapter 2 Hardware Configuration 2-16. COM4 CONNECTOR JCOM4: COM4 Connector ASSIGNMENT JCOM4 ′ Page: 2-18 BM-0962 USER S MANUAL...
Page 31: Com5 Connector
Chapter 2 Hardware Configuration 2-17. COM5 CONNECTOR JCOM5: COM5 Connector ASSIGNMENT JCOM5 2-18. COM6 CONNECTOR JCOM6: COM6 Connector ASSIGNMENT JCOM6 ′ Page: 2-19 BM-0962 USER S MANUAL...
Page 32: Dvi-I & Com Port
2-19. DVI-I & COM PORT JCOM_DVII1: DVI-I & COM PORT DVI-I: DVI Connector ASSIGNMENT ASSIGNMENT TMDS_D2- TMDS_D2+ DDC_CLK DDC_DATA VSYNC TMDS_D1- TMDS_D1+ TMDS_D0- TMDS_D0+ TMDS_CLK+ TMDS_CLK- GREEN BLUE HSYNC COM1: COM Connector ASSIGNMENT JCOM_DVII1 ′ Page: 2-20 BM-0962 USER S MANUAL...
Page 33: Fan Connector
Chapter 2 Hardware Configuration 2-20. FAN CONNECTOR JCPU_FAN1, JSYS_FAN1: Fan Connector ASSIGNMENT FAN_CONTROL FAN_SIGNAL JCPU_FAN1/ JSYS_FAN1 2-21. DC 12V CONNECTOR JDC_PWR1: DC 12V Connector ASSIGNMENT JDC_PWR1 ′ Page: 2-21 BM-0962 USER S MANUAL...
Page 34: Dio Wafer
DIN0 DIN1 JDIO1 DIN2 DIN3 DOUT0 DOUT1 DOUT2 DOUT3 2-23. FRONT CONNECTOR JFP1: Front Connector ASSIGNMENT ASSIGNMENT HDD_LED+ RESET SWITCH PWR_LED+ SPEAKER SIGNAL HDD_LED- POWER BUTTON PWR_LED- SPEAKER SIGNAL SPK_VCC SPEAKER SIGNAL JFP1 ′ Page: 2-22 BM-0962 USER S MANUAL...
Page 35: Inverter Wafer
Chapter 2 Hardware Configuration 2-24. INVERTER WAFER JINV1: Inverter Wafer ASSIGNMENT JINV1 PWM SIGNAL BACKLIGHT EN ′ Page: 2-23 BM-0962 USER S MANUAL...
Page 36: Kb/Ms Port
Chapter 2 Hardware Configuration 2-25. KB/MS PORT JKB_MS1: KB/MS Port Keyboard: ASSIGNMENT DATA Mouse: ASSIGNMENT DATA JKB_MS1 ′ Page: 2-24 BM-0962 USER S MANUAL...
Page 37 2-26. LAN & USB2.0 PORT Yellow Orange/ JLAN1_USB1: LAN & USB2.0 PORT Green LAN: USB2.0: ASSIGNMENT ASSIGNMENT TX_D1+ TX_D1- RX_D2+ BI_D3+ BI_D3- RX_D2- BI_D4+ BI_D4- JLAN1_USB1 BM-0962RB-01N, BM-0962RB-32N, BM-0962RB-08N and BM-0962RB-W6N BM-0962RB-W7N and BM-0962RB–E6N ′ Page: 2-25 BM-0962 USER S MANUAL...
Page 38 Chapter 2 Hardware Configuration 2-27. LAN& USB2.0/3.0 PORT JLAN1_USB2: LAN & USB2.0/3.0 PORT Yellow Orange/ Green LAN: ASSIGNMENT TX_D1+ TX_D1- RX_D2+ BI_D3+ BI_D3- RX_D2- BI_D4+ BI_D4- USB 3.0: ASSIGNMENT VBUS JLAN1_USB2 STDA_SSRX- STDA_SSRX+ STDA_SSTX- STDA_SSTX+ ′ Page: 2-26 BM-0962 USER S MANUAL...
Page 39 2-28. LVDS CONNECTOR JLVDS1: LVDS Connector JLVDS1 ASSIGNMENT ASSIGNMENT ASSIGNMENT LVDS_VCC LVDS1_D3+ LVDS1_D3- LVDS0_D1+ LVDS1_CLK- LVDS1_D0+ LVDS0_D1- LVDS1_CLK+ LVDS1_D0- LVDS0_D0+ LVDS1_D2- LVDS0_CLK+ LVDS0_D0- LVDS1_D2+ LVDS0_CLK- LVDS0_D3+ LVDS0_D3- LVDS1_D1- LVDS0_D2+ LVDS_VCC LVDS1_D1+ LVDS0_D2- LVDS_VCC ′ Page: 2-27 BM-0962 USER S MANUAL...
Page 40 2-29. SATA CONNECTOR JSATA1, JSATA2: Two Serial ATA Connectors ASSIGNMENT JSATA1/ JSATA2 2-30. SATA POWER CONNECTOR JSATA_PWR1, JSATA_PWR2: SATA Power Connector ASSIGNMENT JSATA_PWR1/ JSATA_PWR2 2-31. USB CONNECTOR JUSB1: USB Connector ASSIGNMENT ASSIGNMENT JUSB1 ′ Page: 2-28 BM-0962 USER S MANUAL...
Page 41 Chapter 2 Hardware Configuration 2-32. MINI PCIE CONNECTOR M_PCI_E1: MINI PCIE Connector M_PCI_E1 ASSIGNMENT ASSIGNMENT WAKE# 3.3V 1.5V SMB_CLK PETn0 1.5V SMB_DATA CLKREQ# PETp0 USB_D- REFCLK- USB_D+ REFCLK+ 3.3V 3.3V PERST# 1.5V PERn0 3.3V PERp0 3.3V ′ Page: 2-29 BM-0962 USER S MANUAL...
Page 42 Chapter 2 Hardware Configuration 2-33. PCIE BUS PCI_E1: PCIE BUS ASSIGNMENT ASSIGNMENT SMB_CLK SMB_DATA 3.3V PCI_E1 3.3V 3.3V 3.3V_SB PWRGD WAKE# REFCLK+ REFCLK- HSOP0 HSON0 HSIP0 HSIN0 PRSNT# ′ Page: 2-30 BM-0962 USER S MANUAL...
Page 43 Chapter 2 Hardware Configuration 2-34. LPC CONNECTOR JLPC1: LPC Connector ASSIGNMENT ASSIGNMENT LAD0 FRAME SMBCLK JLPC1 SMBDATA RESET 3VSB VCC5 SERIRQ LAD3 LAD2 CLK RUN VCC3 SUS_TAT LAD1 DREQ0 ′ Page: 2-31 BM-0962 USER S MANUAL...
Page 44 SOFTWARE CHAPTER UTILITIES This chapter comprises the detailed information of Main Chip driver, TXE driver, KMDF driver for Windows 7, Graphics driver, LAN driver, Sound driver and USB 3.0 driver for Windows 7. The following sections are included:  Introduction. ...
Page 45 Chapter 3 Software Utilities 3- 3-1. INTRODUCTION Enclosed with our BM-0962 package are our driver utilities that are stored in a provided DVD-ROM. Refer to the following table for the driver locations: Windows 7 (32bit/64bit), Windows 8/8.1 (32bit/64bit) Filename (Assume that...
Page 46 Intel CPU For Graphics Driver installation 32bit or 64bit Intel I210IT & I210AT For LAN Driver D:\Driver\Platform\LAN\Win10 installation Realtek ALC888 For Sound driver D:\Driver\Platform\Sound\Win10 installation Note: Be sure to install the Utility right after the OS fully installed. Page:3-3 ′ BM-0962 USER S MANUAL...
Page 47 OS installation. Please follow the steps below: Insert the driver disk into a DVD-ROM device. Under the Windows system, go to the directory where the Utility driver is located. Run the application with the Administrator privilege. Page:3-4 ′ BM-0962 USER S MANUAL...
Page 48 3-3-2. Installation Instructions for Windows 7/8/8.1/10 2016 Insert the driver disk into a DVD-ROM device. Under the Windows system, go to the directory where the driver is located. Run the application with the Administrator privilege. Page:3-5 ′ BM-0962 USER S MANUAL...
Page 49 Chapter 3 Software Utilities 3-4. Graphics DRIVER UTILITY 3-4-1. Introduction The Graphics interface embedded with our BM-0962 can support a wide range of display. You can display DVI simultaneously in the same mode. 3-4-2. Installation of Graphics Driver for Windows 7/8/8.1/10 2016 To install the Graphics Driver, simply follow the steps below: Insert the driver disk into a DVD-ROM device.
Page 50 Chapter 3 Software Utilities 3-5. LAN DRIVER UTILITY 3-5-1. Introduction BM-0962 is enhanced with LAN function that can support various network adapters. The installation programs for LAN drivers are listed as follows: 1. Win 7 Series 2. Win 8/8.1 Series 3.
Page 51 Run the application with the Administrator privilege. Follow the on-screen instructions to complete the installation. Once the installation is completed, shut down the system and restart it in order for the changes to take effect. Page:3-8 ′ BM-0962 USER S MANUAL...
Page 52 CHAPTER BIOS SETUP This chapter shows how to set up the AMI BIOS. Sections included: Introduction  Entering Setup  Main  Advanced  Chipset  Security  Boot  Save & Exit  Page: 4-1...
Page 53 Chapter 4 BIOS Setup 4-1. INTRODUCTION The board BM-0962 uses an AMI Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the BIOS Setup program, Power-on Self-Test (POST), the PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.
Page 54 The BIOS Setup program can be used to view and change the BIOS settings for the computer. The BIOS Setup program is accessed by pressing the <Del> or <F2> key after the POST memory test begins and before the operating system boot begins. The settings are shown below. ′ Page: 4-3 BM-0962 USER S MANUAL...
Page 55 Chapter 4 BIOS Setup 4-2. ENTERING SETUP When the system is powered on, the BIOS will enter the Power-On Self Test (POST) routines and the following message will appear on the lower screen: ′ Page: 4-4 BM-0962 USER S MANUAL...
Page 56 You may move the cursor by up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. ′ Page: 4-5 BM-0962 USER S MANUAL...
Page 57 Displays the current UEFI version. Project Version No changeable options Displays the version of the BIOS currently installed on the platform. Build Date and Time No changeable options Displays the date of current BIOS version. ′ Page: 4-6 BM-0962 USER S MANUAL...
Page 58 System Language English BIOS Setup language. System Date Month, day, year Specifies the current date. System Time Hour, minute, second Specifies the current time. Access Level Administrator Displays Access level. 4-4. ADVANCED Advanced Screen ′ Page: 4-7 BM-0962 USER S MANUAL...
Page 59 Sub-Menu F81866 Watchdog Parameters. CPU Configuration Sub-Menu CPU Configuration. Parameters. IDE Configuration Sub-Menu SATA Configuration Parameters. Configures Option ROM CSM Configuration Sub-Menu execution, boot options filters, etc. USB Configuration Sub-Menu USB Configuration Parameters. ′ Page: 4-8 BM-0962 USER S MANUAL...
Page 60 - TPM 2.0 TPM 1.2 devices. - Auto TPM2.0 will restrict support to TPM 2.0 devices. Auto will support both with the default set to TPM2.0 devices. If not found, TPM1.2 devices will be enumerated. ′ Page: 4-9 BM-0962 USER S MANUAL...
Page 61 - Enabled This option may be not effective with some OS. ACPI Sleep State - Suspend Disabled Specifies the ACPI sleep state. Suspend Disabled disables - S3(Suspend to RAM)  ACPI sleep feature. ′ Page: 4-10 BM-0962 USER S MANUAL...
Page 62 Serial Port 1 Configuration Sub-Menu Sets Parameters for COMA. Serial Port 2 Configuration Sub-Menu Sets Parameters for COMB. Serial Port 3 Configuration Sub-Menu Sets Parameters for COMC. Serial Port 4 Configuration Sub-Menu Sets Parameters for COMD. ′ Page: 4-11 BM-0962 USER S MANUAL...
Page 63 Serial Port Serial Port 1. - Enabled Displays current settings Device Settings No changeable options of Serial Port 1. Change - Auto Selects IRQ and I/O Settings resource for Serial Port - IO=3F8h; IRQ=4 ′ Page: 4-12 BM-0962 USER S MANUAL...
Page 64 Serial Port 2 Configuration Screen BIOS Setting Options Description/Purpose - Disabled Enables or disables Serial Port Serial Port 2. - Enabled Displays current settings Device Settings No changeable options of Serial Port 2. ′ Page: 4-13 BM-0962 USER S MANUAL...
Page 65 - IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 - IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=3E8h;IRQ=3,4,5,6,7,9,10,11,12 - IO=2E8h;IRQ=3,4,5,6,7,9,10,11,12 4-4-3-3. Serial Port 3 Configuration Serial Port 3 Configuration Screen BIOS Setting Options Description/Purpose - Disabled Enables or disables Serial Port Serial Port 3. - Enabled ′ Page: 4-14 BM-0962 USER S MANUAL...
Page 66 - Auto Selects IRQ and I/O Settings resource for Serial Port - IO=3E8h; IRQ=10 - IO=3F8h; IRQ=6,7,10,11,12 - IO=2F8h; IRQ=6,7,10,11,12 - IO=2F0h;IRQ=6,7,10,11,12 - IO=2E0h;IRQ=6,7,10,11,12 4-4-3-4. Serial Port 4 Configuration Serial Port 4 Configuration Screen ′ Page: 4-15 BM-0962 USER S MANUAL...
Page 67 Selects IRQ and I/O Settings resource for Serial Port - IO=2E8h; IRQ=5 - IO=3E8h;IRQ=5,6, 11,12 - IO=2E8h;IRQ=5,6, 11,12 - IO=2F0h;IRQ=5,6, 11,12 - IO=2E0h;IRQ=5,6, 11,12 4-4-3-5. Serial Port 5 Configuration Serial Port 5 Configuration Screen ′ Page: 4-16 BM-0962 USER S MANUAL...
Page 68 Select IRQ and I/O Settings resource for Serial Port - IO=2F0h; IRQ=7 - IO=3E8h;IRQ=5,6,7, 11,12 - IO=2E8h;IRQ=5,6,7, 11,12 - IO=2F0h;IRQ=5,6,7, 11,12 - IO=2E0h;IRQ=5,6,7, 11,12 4-4-3-6. Serial Port 6 Configuration Serial Port 6 Configuration Screen ′ Page: 4-17 BM-0962 USER S MANUAL...
Page 69 Device Settings No changeable options of Serial Port 6. Change - IO=2E0h; IRQ=11 Select IRQ and I/O Settings resource for Serial Port - IO=3E8h;IRQ=5,6,7, 11,12 - IO=2E8h;IRQ=5,6,7, 11,12 - IO=2F0h;IRQ=5,6,7, 11,12 - IO=2E0h;IRQ=5,6,7, 11,12 ′ Page: 4-18 BM-0962 USER S MANUAL...
Page 70 System Fan Speed No changeable options Displays fan’s speed VCORE No changeable options Displays voltage level of the +VCORE in supply. 5VSB No changeable options Displays voltage level of the +VSB5 in supply. ′ Page: 4-19 BM-0962 USER S MANUAL...
Page 71 No changeable options Displays voltage level of the +VCC12 in supply. VCC3V No changeable options Displays voltage level of the VCC3V in supply. VSB3V No changeable options Displays voltage level of the VSB3V in supply. ′ Page: 4-20 BM-0962 USER S MANUAL...
Page 72 Smart Fan Mode selection for CPU Control - Auto Duty-Cycle Mode Fan. Manual mode fan control, user can Manual Duty Mode Numeric (from 1 to 100) write expected duty cycle (PWM fan type) 1-100. ′ Page: 4-21 BM-0962 USER S MANUAL...
Page 73 - Disabled Watchdog timer - 1s Selects seconds or minutes. unit - 60s Count for Timer Multiple options ranging Sets the desired value (seconds) (Seconds) from 1 to 255 for watchdog timer. ′ Page: 4-22 BM-0962 USER S MANUAL...
Page 74 BIOS Setting Options Description/Purpose Socket 0 CPU Sub-Menu Reports CPU Information. Information CPU Speed No changeable options Reports the current CPU Speed. 64-bit No changeable options Reports if 64-bit is supported by processor. ′ Page: 4-23 BM-0962 USER S MANUAL...
Page 75 No changeable options Reports the minimum CPU Speed. Processor Cores No changeable options Displays number of physical cores in processor. Intel HT No changeable options Reports if Intel Hyper-Threading Technology Technology is supported by processor ′ Page: 4-24 BM-0962 USER S MANUAL...
Page 76 Displays size of L1 Data Cache L1 Code Cache No changeable options Displays size of L1 Code Cache L2 Cache No changeable options Displays size of L2 Cache. L3 Cache No changeable options Displays size of L3 Cache. ′ Page: 4-25 BM-0962 USER S MANUAL...
Page 77 (in case it is compatible). SATA Mode - IDE mode Configures SATA as following: - AHCI mode IDE: Sets SATA operation mode to IDE.  AHCI: SATA works as AHCI (Advanced  ′ Page: 4-26 BM-0962 USER S MANUAL...
Page 78 4-4-8. CSM Configuration CSM Configuration Screen BIOS Setting Options Description/Purpose - Disabled CSM Support Disables or Enables CSM support. - Enabled CSM16 Module Displays the current CSM Version No changeable options (Compatibility Support Module) version. ′ Page: 4-27 BM-0962 USER S MANUAL...
Page 79 Legacy Video. - UEFI - Legacy Other PCI - Do not launch Selects the launch method for other devices PCI devices, such as NIC, mass - UEFI storage or video card. - Legacy ′ Page: 4-28 BM-0962 USER S MANUAL...
Page 80 No changeable options devices. Legacy USB - Disabled Enables support for legacy USB. Support - Enabled - Auto XHCI Hand-off - Disabled This is a workaround for OSes without XHCI hand-off support. - Enabled ′ Page: 4-29 BM-0962 USER S MANUAL...
Page 81 100 ms, for a Hub port the delay is taken from Hub descriptor. Mass Storage - Auto Display the device name and choose Devices: the device emulation type. -Floppy - Force FDD - Hard Disk - CD-ROM ′ Page: 4-30 BM-0962 USER S MANUAL...
Page 82 Chapter 4 BIOS Setup 4-5. CHIPSET Chipset Screen BIOS Setting Options Description/Purpose North Bridge Sub-Menu Sets Parameter for (North Bridge) configuration. South Bridge Sub-Menu Sets Parameter for (South Bridge) configuration. ′ Page: 4-31 BM-0962 USER S MANUAL...
Page 83 No changeable options Information platform. Total Memory No changeable options Displays the DRAM size Max TOLUD - 2 GB Maximum Value of TOLUD. - 2.25 GB - 2.5 GB - 2.75 GB - 3.0 GB ′ Page: 4-32 BM-0962 USER S MANUAL...
Page 84 Selects the Video Device that - VBIOS Default Boot Display will be activated during POST. - CRT - DVI - LVDS Secondary IGFX Selects Secondary Display - Disabled Boot Display Device. - CRT - DVI - LVDS ′ Page: 4-33 BM-0962 USER S MANUAL...
Page 85 Power On makes system power on after  restores AC power to the board. Last State brings system back to the last  power state before AC power failed. ′ Page: 4-34 BM-0962 USER S MANUAL...
Page 86 Controls Detection of the Azalia Controller device. - Enabled Disabled: Azalia will be - Auto  unconditionally disabled. Enabled: Azalia will be  unconditionally enabled. Auto: Azalia will be enabled if  present disabled otherwise. ′ Page: 4-35 BM-0962 USER S MANUAL...
Page 87 Enables Enhanced Host Controller Support Interface 1 for high-speed USB - Enabled functions (USB 2.0). USB Per Port - Disabled Controls each of the USB ports (0~3). Enabled: Enables USB per port. - Enabled  ′ Page: 4-36 BM-0962 USER S MANUAL...
Page 88 Enables or Disables USB port 1. - Enabled (USB Hub 1~4) USB Port 2 - Disabled Enables or Disables USB port 2. - Enabled USB Port 3 - Disabled Enables or Disables USB port 3. - Enabled ′ Page: 4-37 BM-0962 USER S MANUAL...
Page 89 Chapter 4 BIOS Setup 4-6. SECURITY Security Screen BIOS Setting Options Description/Purpose Administrator Password can be 3-20 Specifies the administrator Password alphanumeric characters. password. User Password Password can be 3-20 Specifies the user password. alphanumeric characters. ′ Page: 4-38 BM-0962 USER S MANUAL...
Page 90 - Enabled Options - [Drive(s)] Allows setting boot option listed in Boot Option #1~#n - Disabled Hard Drive BBS Priorities. Allow users to select boot order of Hard Drive BBS Priorities Sub-Menu available drive(s). ′ Page: 4-39 BM-0962 USER S MANUAL...
Page 91 Priorities available drive(s). 4-7-1. Hard Drive BBS Priorities Hard Drive BBS Priorities Screen BIOS Setting Options Description/Purpose Boot Option #1 - #n - [Drive(s)] Change the boot order of available drive(s). - Disabled ′ Page: 4-40 BM-0962 USER S MANUAL...
Page 92 Resets without saving any changes No changeable options and Reset made in BIOS settings. Loads the optimized defaults for Restore Defaults No changeable options BIOS settings. Boot Override Forces to boot from selected - [Drive(s)] [drive(s)]. ′ Page: 4-41 BM-0962 USER S MANUAL...
Page 93 EXPANSION APPENDIX This appendix indicates the pin assignments of expansion bus. The following section is included: PCIe Bus  Page: A-1...
Page 94 Appendix A Expansion Bus PCIE BUS PCI_E1 with 164 pins is optional on BM-0962. The pin assignments are as follows: PCI_E1 PCI_E1: PIN ASSIGNMENT PIN ASSIGNMENT PIN ASSIGNMENT ASSIGNMENT Reserved A42 GND +12V EXP_A_TX_6_DN +12V A43 EXP_A_RX_6_DP +12V +12V A44 EXP_A_RX_6_DN B3...
Page 95 B37 EXP_A_TX_5_DP B78 Reserved A38 GND A79 Reserved B38 EXP_A_TX_5_DN B79 Reserved A39 EXP_A_RX_5_DP A80 Reserved B39 GND Reserved A40 EXP_A_RX_5_DN A81 Reserved B40 GND Reserved A41 GND A82 Reserved B41 EXP_A_TX_6_DP B82 Reserved ′ Page: A-3 BM-0962 USER S MANUAL...
Page 96 APPENDIX TECHNICAL SUMMARY This section introduce you the maps concisely. The following sections are included: Block Diagram  Interrupt Map  DMA Channel Map  I/O Map  Memory Map  Watchdog Timer Configuration  Flash BIOS Update  Page: B-1...
Page 97 64Mbit SPI Flash ROM LOW PIN COUNT 80 port for Debug Connector COM 1/3/4/5/6 RS232 FINTEK Com1/2 support 5V/12V HW monitor LPC SIO COM2 F81846AD-I RS232/422/485 Keyboard Mouse VR12.5 ISL95816 3 Phase PWM TPS51216 For DDR3 Page: B-2 ′ BM-0962 USER S MANUAL...
Page 98: Interrupt Map
Microsoft ACPI-Compliant System IRQ 71 Microsoft ACPI-Compliant System IRQ 72 Microsoft ACPI-Compliant System IRQ 73 Microsoft ACPI-Compliant System IRQ 74 Microsoft ACPI-Compliant System IRQ 75 Microsoft ACPI-Compliant System IRQ 76 Microsoft ACPI-Compliant System ′ Page: B-3 BM-0962 USER S MANUAL...
Page 99 Microsoft ACPI-Compliant System IRQ 108 Microsoft ACPI-Compliant System IRQ 109 Microsoft ACPI-Compliant System IRQ 110 Microsoft ACPI-Compliant System IRQ 111 Microsoft ACPI-Compliant System IRQ 112 Microsoft ACPI-Compliant System IRQ 113 Microsoft ACPI-Compliant System Page: B-4 ′ BM-0962 USER S MANUAL...
Page 100 Microsoft ACPI-Compliant System IRQ 145 Microsoft ACPI-Compliant System IRQ 146 Microsoft ACPI-Compliant System IRQ 147 Microsoft ACPI-Compliant System IRQ 148 Microsoft ACPI-Compliant System IRQ 149 Microsoft ACPI-Compliant System IRQ 150 Microsoft ACPI-Compliant System ′ Page: B-5 BM-0962 USER S MANUAL...
Page 101 Microsoft ACPI-Compliant System IRQ 182 Microsoft ACPI-Compliant System IRQ 183 Microsoft ACPI-Compliant System IRQ 184 Microsoft ACPI-Compliant System IRQ 185 Microsoft ACPI-Compliant System IRQ 186 Microsoft ACPI-Compliant System IRQ 187 Microsoft ACPI-Compliant System Page: B-6 ′ BM-0962 USER S MANUAL...
Page 102 Microsoft ACPI-Compliant System IRQ 270 Microsoft ACPI-Compliant System IRQ 271 Microsoft ACPI-Compliant System IRQ 272 Microsoft ACPI-Compliant System IRQ 273 Microsoft ACPI-Compliant System IRQ 274 Microsoft ACPI-Compliant System IRQ 275 Microsoft ACPI-Compliant System ′ Page: B-7 BM-0962 USER S MANUAL...
Page 103 Microsoft ACPI-Compliant System IRQ 307 Microsoft ACPI-Compliant System IRQ 308 Microsoft ACPI-Compliant System IRQ 309 Microsoft ACPI-Compliant System IRQ 310 Microsoft ACPI-Compliant System IRQ 311 Microsoft ACPI-Compliant System IRQ 312 Microsoft ACPI-Compliant System Page: B-8 ′ BM-0962 USER S MANUAL...
Page 104 Microsoft ACPI-Compliant System IRQ 344 Microsoft ACPI-Compliant System IRQ 345 Microsoft ACPI-Compliant System IRQ 346 Microsoft ACPI-Compliant System IRQ 347 Microsoft ACPI-Compliant System IRQ 348 Microsoft ACPI-Compliant System IRQ 349 Microsoft ACPI-Compliant System ′ Page: B-9 BM-0962 USER S MANUAL...
Page 105 Microsoft ACPI-Compliant System IRQ 381 Microsoft ACPI-Compliant System IRQ 382 Microsoft ACPI-Compliant System IRQ 383 Microsoft ACPI-Compliant System IRQ 384 Microsoft ACPI-Compliant System IRQ 385 Microsoft ACPI-Compliant System IRQ 386 Microsoft ACPI-Compliant System Page: B-10 ′ BM-0962 USER S MANUAL...
Page 106 Microsoft ACPI-Compliant System IRQ 418 Microsoft ACPI-Compliant System IRQ 419 Microsoft ACPI-Compliant System IRQ 420 Microsoft ACPI-Compliant System IRQ 421 Microsoft ACPI-Compliant System IRQ 422 Microsoft ACPI-Compliant System IRQ 423 Microsoft ACPI-Compliant System ′ Page: B-11 BM-0962 USER S MANUAL...
Page 107 Microsoft ACPI-Compliant System IRQ 455 Microsoft ACPI-Compliant System IRQ 456 Microsoft ACPI-Compliant System IRQ 457 Microsoft ACPI-Compliant System IRQ 458 Microsoft ACPI-Compliant System IRQ 459 Microsoft ACPI-Compliant System IRQ 460 Microsoft ACPI-Compliant System Page: B-12 ′ BM-0962 USER S MANUAL...
Page 108 Microsoft ACPI-Compliant System IRQ 492 Microsoft ACPI-Compliant System IRQ 493 Microsoft ACPI-Compliant System IRQ 494 Microsoft ACPI-Compliant System IRQ 495 Microsoft ACPI-Compliant System IRQ 496 Microsoft ACPI-Compliant System IRQ 497 Microsoft ACPI-Compliant System ′ Page: B-13 BM-0962 USER S MANUAL...
Page 109 IRQ 510 Microsoft ACPI-Compliant System IRQ 511 Microsoft ACPI-Compliant System IRQ 4294967292 Intel(R) Trusted Execution Engine Interface Intel(R) USB 3.0 eXtensible Host Controller - 1.0 IRQ 4294967293 (Microsoft) IRQ 4294967294 Standard SATA AHCI Controller Page: B-14 ′ BM-0962 USER S MANUAL...
Page 110: Memory Map
0x92210000-0x92213FFF High Definition Audio Controller 0xFF000000-0xFFFFFFFF Legacy device Intel(R) USB 3.0 eXtensible Host Controller - 1.0 0x92200000-0x9220FFFF (Microsoft) 0xA0000-0xBFFFF PCI Express Root Complex 0xA0000-0xBFFFF Microsoft Basic Display Adapter 0xC0000-0xDFFFF PCI Express Root Complex ′ Page: B-15 BM-0962 USER S MANUAL...
Page 111: I/O Map
0x00000080-0x0000008F Motherboard resources 0x00000092-0x00000092 Motherboard resources 0x000000A0-0x000000A1 Programmable interrupt controller 0x000000A4-0x000000A5 Programmable interrupt controller 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B2-0x000000B3 Motherboard resources 0x000000B4-0x000000B5 Programmable interrupt controller Page: B-16 ′ BM-0962 USER S MANUAL...
Page 112 Processor Platform Control Unit - SMBus Port - 0F12 0x0000E020-0x0000E03F Standard SATA AHCI Controller 0x0000E040-0x0000E043 Standard SATA AHCI Controller 0x0000E050-0x0000E057 Standard SATA AHCI Controller 0x0000E060-0x0000E063 Standard SATA AHCI Controller 0x0000E070-0x0000E077 Standard SATA AHCI Controller 0x0000E080-0x0000E087 Microsoft Basic Display Adapter ′ Page: B-17 BM-0962 USER S MANUAL...
Page 113: Watchdog Timer Configuration
To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. Page: B-18 ′ BM-0962 USER S MANUAL...
Page 114 ; ----------------------- Select Logical Device 7 of watchdog timer --------------------- ;---------------------------------Enable Watch dog feature ------------------------------ ; ---------------- Set timeout interval as 30seconds and start counting -------------- ;------------------------------- Enable Watch PME-------------------------------------------- ;-------------------------- Set second as counting unit -------------------------------------- ′ Page: B-19 BM-0962 USER S MANUAL...
Page 115 Appendix B Technical Summary ;-------------------------- Start the watchdog timer -------------------------------------- ;---------------------------------Exit the extended function mode ------------------------- Page: B-20 ′ BM-0962 USER S MANUAL...
Page 116: Flash Bios Update
(4) Select [Boot] menu. (5) Select [Hard Drive BBS Priorities] and set the USB bootable device as the 1st boot device. (6) Press <F4> to save the configuration and exit the BIOS setup menu. ′ Page: B-21 BM-0962 USER S MANUAL...
Page 117 The recommended options for BIOS ROM update consist of the following parameters: program main BIOS image program Boot Block program NVRAM don’t check ROM ID Page: B-22 ′ BM-0962 USER S MANUAL...
Page 118 After the BIOS update procedure is completed, the following messages will be shown: You can restart the system and boot up the system with the new BIOS configurations. The BIOS update procedure is completed after the system is restarted. ′ Page: B-23 BM-0962 USER S MANUAL...
Page 119 Appendix B Technical Summary Reboot the system and verify if the BIOS version shown on the initialization screen has been updated. Page: B-24 ′ BM-0962 USER S MANUAL...
