Engine
Cylinders (number) . . . . . . . . . . . . . . . . . 90° V-6
Displacement . . . . . . . . . . . . . . . . . . . . . 262 cubic inches (4.3 liters)
Firing order . . . . . . . . . . . . . . . . . . . . . . . 1 – 6 – 5 – 4 – 3 – 2
Bore and stroke. . . . . . . . . . . . . . . . . . . . 4.000 x 3.480 in. (101.60 x 88.39 mm)
Full throttle operating range . . . . . . . . . . 4400 – 4800 RPM
Idle RPM . . . . . . . . . . . . . . . . . . . . . . . . . 600 RPM
Fuel System
Fuel injection . . . . . . . . . . . . . . . . . . . . . . Port injection
Fuel pumps . . . . . . . . . . . . . . . . . . . . . . . Electric
Fuel filter . . . . . . . . . . . . . . . . . . . . . . . . . Volvo Penta P/N 3862228
Fuel filter location . . . . . . . . . . . . . . . . . . Refer to photographs on features pages.
Fuel type . . . . . . . . . . . . . . . . . . . . . . . . . Inside the U.S.: 87 octane (AKI) unleaded gasoline
Electrical System
Charging system . . . . . . . . . . . . . . . . . . . 12 volt 75 amp alternator, with internal transistorized voltage regulator
Battery size . . . . . . . . . . . . . . . . . . . . . . . 12 volt with 650 Cold Cranking Amp (CCA) rating (135 minute reserve
Starter . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 volt 1.7kW output, planetary reduction gear
Ignition System
Distributor . . . . . . . . . . . . . . . . . . . . . . . . Delco EST
Ignition timing . . . . . . . . . . . . . . . . . . . . . 10° BTDC Fixed
Spark plugs . . . . . . . . . . . . . . . . . . . . . . . Volvo Penta PN 3858997
Spark plug gap . . . . . . . . . . . . . . . . . . . . 1.50 mm (0.060 inches)
Spark plug installation torque . . . . . . . . . 27 N·m (20 ft. lb.)
Cooling System
Raw water pump . . . . . . . . . . . . . . . . . . . Crankshaft mounted variable volume flexible impeller pump
Recirculating pump . . . . . . . . . . . . . . . . . Fixed impeller belt driven pump on engine
Thermostat . . . . . . . . . . . . . . . . . . . . . . . 71°C (160°F) Volvo Penta PN 3587597
GXi-EF . . . . . . . . . . . . . . . . . . . . . . . . . . Closed cooling heat exchanger mounted on engine.
Closed Cooling System Thermostat . . . . 76°C (170°F) Volvo Penta PN 3831426
Coolant Type. . . . . . . . . . . . . . . . . . . . . . Ethylene glycol. Volvo Penta PN 381081.
Oil Capacity
Engine without filter. . . . . . . . . . . . . . . . . 4 quarts (3.8 liters)
Engine with filter . . . . . . . . . . . . . . . . . . . 5 quarts (4.7 liters)
Drive unit SX . . . . . . . . . . . . . . . . . . . . . . 2.2 quarts (2.1 liters)
Drive unit DP-S . . . . . . . . . . . . . . . . . . . . 2.5 quarts (2.4 liters)
Engine Oil filter . . . . . . . . . . . . . . . . . . . . Volvo Penta PN 3850559
Oil filter location. . . . . . . . . . . . . . . . . . . . Refer to photographs on features pages.
Oil Type
Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . Volvo Penta engine oil or suitable pure synthetic oil alternative with min.
Drive unit . . . . . . . . . . . . . . . . . . . . . . . . Volvo Penta SAE 75W/90 API service GL 5 synthetic gear oil
Power steering fluid U.S.. . . . . . . . . . . . . Volvo Penta power steering fluid PN 3851039
Power steering fluid non-U.S. . . . . . . . . . ATF oil Dexron 2 PN 1161941
Oil Pressure (Minimum)
@ 1000 RPM . . . . . . . . . . . . . . . . . . . . . 6 PSI (41 kPa)
@ 2000 RPM . . . . . . . . . . . . . . . . . . . . . 18 PSI (124 kPa)
@ 4000 RPM . . . . . . . . . . . . . . . . . . . . . 24 PSI (166 kPa)
VPA 7743722 English 10-2004
4.3GXi-E, 4.3GXi-EF
Outside the U.S.: 90 octane (RON) unleaded gasoline
capacity). Do not use a deep cycle battery as the start battery.
API service rating CF/SH. See Maintenance Schedule on page 64.
Technical Data
