OPENTEL ODT 1600C User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
ODT 1600C

Advertisement

Table of Contents
loading

Summary of Contents for OPENTEL ODT 1600C

  • Page 1 User’s Manual ODT 1600C...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents 1. SAFETY WARNING 2. GENERAL FEATURES 3. HOW TO CONNECT YOUR RECEIVER 4. HARDWARE DESCRIPTION 5. SYSTEM SETUP 6. MENU OPERATION 7. FIRMWARE UPGRADE THROUGH TERRESTRIAL 8. TROUBLESHOOTING 9. TECHNICAL SPECIFICATIONS...

  • Page 3: Safety Warning

    1. SAFETY WARNING -Do not block the openings with any object, and do not place the product on a bed, sofa, rug, or other similar surface. -If you place the product on a rack or a bookcase, ensure that there is adequate This product has been manufactured to comply with international safety ventilation and that you have followed the manufacturer’s instructions for mounting.

  • Page 4: General Features

    3. HOW TO CONNECT YOUR RECEIVER 2. GENERAL FEATURES - Fully compliant with MPEG-2 & DVB Please DO NOT plug in the main power supply cord until you - Smart Card interface for embedded Conax have finished all the connections. - Input frequency 174 ~ 862 MHz - One input tuner with loop through IF signal - Supports DVB-T modulation schemes: QPSK, 16-QAM and 64-QAM...

  • Page 5: Hardware Description

    4. HARDWARE DESCRIPTION 4) CONNECTING EXTERNAL AUDIO HI-FI SYSTEM To connect any external Audio Hi-Fi system, the receiver is provided with two 4. A. FRONT PANEL RCA connectors at the rear, marked “Audio L and R” respectively to connect the left and right audio. In case of Audio Hi-Fi systems with digital audio input, please connect to S/PDIF.
  • Page 6 4. B. REAR PANEL 4. C. REMOTE CONTROL UNIT 1) ANTENNA IN : Connects the aerial cable. 1) POWER : This is used to switch the receiver to ON/STANDBY mode. In order to get the signal from other receiver instead of the antenna, set “Tuner 5V” 2) MUTE : This key is used to toggle between normal and muted audio.

  • Page 7: System Setup

    5. SYSTEM SETUP 5. A. Automatic Channel Search 15) LAST : This key is used to return to the previous channel. You can automatically detect and save all TV and radio 16) AUDIO : This key is used to select the soundtrack list for the current service channels as follows : and also to select audio mode.

  • Page 8: Menu Operation

    6. MENU OPERATION The main menu is classified into several sub menus which will carry out the 5. B. Manual Channel Search for Transponder various operations individually. You can automatically search and save all TV and radio channels of a transponder as follows : MAIN MENU After installing your antenna and receiver with appropriate connectors, plug in the AC main power and turn on the receiver.
  • Page 9 1. A. CHANNEL LOCK 2. EDIT FAVORITES Select the “Channel Lock” icon using the “left/right” keys (◀·▶). Select the channel that You can edit the favorite channel list (add/delete/move a channel), which facilitates you to you want to lock or unlock from the channel list using the “up/down” keys (▲·▼) and the easily find your favorite channel from the favorite channel list.
  • Page 10 3. INSTALLATION 2. C. MOVE FAVORITE CHANNEL You can choose TV channel list or radio channel list in an alternative way by pressing “Installation” menu helps you setup the“♬” key on the RCU. a variety of parameters necessary By pressing the “FAV” key on the RCU, you can choose your favorite channel group out for receiving signal, adding new of eight favorite groups.
  • Page 11 3. C. PARENTAL CONTROL Check the signal strength. Press the “OK” key to start the “Automatic Channel Search” procedure. This function prevents children or unauthorized persons from watching programs. You can see the progressive status of channel searching. You can also change the PIN-Code (Personal Identification Number). Please note that the “Automatic Channel Search”...

  • Page 12: System Settings

    3. D. TIME SETTING 3. F. FACTORY DEFAULT This is to restore the factory set values in case the user encounters some problems after You can change the time of your receiver and changing any new values of channel data or others data which may cause error. also switch on/off the timer function in this menu.
  • Page 13 5. LANGUAGE SETTINGS 6. CHANNEL LIST This menu helps you to setup menu, audio, This menu helps you to easily select the subtitle language parameters. Select “Language channel that you want to watch. Settings” menu in main menu, and the following The channel list is separately constructed screen will be displayed.

  • Page 14: Firmware Upgrade Through Terrestrial

    8. TROUBLESHOOTING 7. CHANNEL GUIDE Press the “GUIDE” key, and the following screen will be displayed.The titles of the current and next programmes on different channels will appear. About the Receiver The information may include : current time / channel name, name of the current and Problem Solution next programme, the start and total time of...

  • Page 15: Technical Specifications

    9. TECHNICAL SPECIFICATIONS 1. Power Supply 5. Audio Decoder System Decoding : MPEG-1 ISO/IEC 11172-3 Type : SMPS Layer I & II Input Voltage : 100~240VAC 50/60 Hz Audio Mode : Mono, Dual, Stereo, Joint Stereo Fuse Rating : 250V/T2A Sampling Frequency : 32, 44.1, 48 KHz 2.
