LaCie SAFE mobile hard drive User’s Manual How To Use This Manual In the toolbar: Previous Page / Next Page Printing: While optimized for onscreen viewing, the pages of this manual are formatted for printing on 8 paper, giving you the option to print the entire manual or just a specific page or section.
3.3. About Authorized Users and Rights 3.4. Rules for Registering Users 4. Connecting Your LaCie SAFE Drive 4.1. Connect the USB 2.0* Cable to Your LaCie Drive and to Your Computer 4.2. Connecting the USB Power Sharing Cable 5. Configuring Your LaCie SAFE Drive 5.1.
Page 4
LaCie SAFE mobile hard drive User’s Manual 7. Helpful Information (cont.) 7.2. Formatting and Partitioning Your Drive 7.2.1. Windows Users 7.2.2. Mac Users 7.3. Optimizing USB 2.0 Connections 7.3.1. What is USB 2.0? 7.3.3. Data Transfers 8. Frequently Asked Questions (FAQ) 9.
LaCie assumes no liability resulting from errors or omissions in this document, or from the use of the information contained herein. LaCie reserves the right to make changes or revisions in the product design or the product manual without reservation and without obligation to notify any person of such revisions and changes.
Page 6
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Manufacturer’s Declaration for CE Certification We, LaCie, hereby certify that this device is in compliance with both the EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community.
General Use Precautions: • Do not expose the LaCie SAFE mobile hard drive to temperatures outside the range of 5° C to 45° C (41° F to 104° F). Doing so may damage the hard drive or disfigure its casing. Avoid placing your LaCie hard drive near a source of heat or exposing it to sunlight (even through a window).
A software wizard guides you step-by-step through the installation process. With all it can do for you, we’re confident that your LaCie SAFE mobile hard drive will quickly become an important storage companion in your day-to-day business and personal computing.
2. Unpacking Your LaCie SAFE Drive Building on years of storage experience, LaCie has teamed up with leaders in the security industry to create a new family of drives that can seamlessly keep your most important data secure from prying eyes. These latest drives are performance-based solutions that provide you with the quality you’ve come to expect from LaCie.
3. Before Installing Your LaCie SAFE Drive Yes, we know you are anxious to start using your new LaCie SAFE mobile hard drive, but because it has extra data security features not found on standard external hard drives, you should take a minute to familiarize yourself with these items first: •...
3.4. Rules for Registering Users The LaCie SAFE drive can save up to 10 fingerprints. Since each registered user (including the Administrator) must register at least two fingerprints, the drive can accommodate a maximum of one Administrator and up to four users.
User’s Manual 4. Connecting Your LaCie Drive Follow these steps to quickly get your LaCie SAFE drive powered on and connected to your computer. Click on a step to get started! • 4.1. Connect the USB 2.0* Cable to Your LaCie Drive and to Your Computer •...
The PS2 power supply adapter cable connects to either of the ports used to connect a keyboard or mouse to your computer. The USB ports (either USB 2.0 or USB 1.1) on your computer can help provide power to your LaCie SAFE drive in case a single USB port does not supply the necessary power to operate your drive.
5. Configuring Your LaCie SAFE Drive Fig. 5.1 The Windows desktop Once the LaCie SAFE drive is connected to a USB port on your computer, the drive's top LED will blink orange and then turn red. After a few seconds, the drive will mount.
For Mac users: If no LaCie SAFE drive icon appears on your desktop, then use the Apple Disk Utility application. To access it, choose Go from the Menu Bar and click on Applications. Open the Utilities folder, and then double-click the Disk Utility icon.
Page 16
Restart to restart your Mac. Now you are ready to use your LaCie SAFE drive. Now that you have your LaCie SAFE mobile hard drive up and running, you can configure it. Click on a step to get started! • 5.2. Setting Up User Names and Privileges •...
Fig. 5.2.3 Agreement for Mac 2. If you agree to the terms of the LaCie license agreement, click on the “I agree” button to continue. If you do not agree and click the “I disagree” button, you won't be able to continue using the First use wizard; click Cancel to quit the program. You will not be able to use your LaCie SAFE drive.
Page 18
User names can be a maximum of 10 characters and may only contain letters (without accents), Important Note: numbers, and spaces. 5. Configuring Your LaCie SAFE Drive Fig. 5.2.5 The user information for Mac page 17...
Fig. 5.3.5 Successful fingerprint registration in Windows and Mac 5. Configuring Your LaCie SAFE Drive Fig. 5.3.2 Begin registering a fingerprint in Mac Fig. 5.3.4 Swipe dialog in Mac Your finger should lie flat in the recess.
Page 20
Additional Users. Fig. 5.3.6 Configuration complete in Windows 6. Congratulations! Your LaCie SAFE drive is now ready to use! Click Finish to either unlock the drive or continue adding users before unlocking the drive. 5. Configuring Your LaCie SAFE Drive Fig.
2. To begin using the drive, click “Unlock drive” and swipe one of your registered fingers over the fingerprint sensor. For more on how to use your LaCie SAFE drive once it has been set up, see section 6. Using Your LaCie SAFE Drive.
6. Using Your LaCie SAFE Drive Once you’ve set up your LaCie SAFE drive with at least one user, then you can start to use it. If the drive is currently discon- nected, first connect it (see section 4. Connecting Your LaCie Drive for more information). Now you are ready to get started! •...
Fig. 6.2.1 The Welcome screen in Windows 2. This is the first screen you will see with normal use. To unlock your LaCie SAFE drive, place a registered finger flat in the recess of the fingerprint sensor. Make sure the top of your finger touches the top of the recess and slide it down slowly. Continue swiping your finger until the drive recognizes you.
1. If you click Configure, then this dialog appears. Click “New user...” to add a new user. For more on adding users, see sec- tion 5.3. Registering Additional Users. 6. Using Your LaCie SAFE Drive Fig. 6.2.4 Unlocking the drive in Mac Fig.
3. A dialog appears confirming that the user can no longer access the drive. Click OK to return to the Configure window. Fig. 6.2.7 Removing a user in Windows Fig. 6.2.9 Confirming removal in Mac 6. Using Your LaCie SAFE Drive page 24...
Page 26
5. A dialog appears, confirming that you want to reset the drive. You will have to confirm this twice. The drive will then be initialized. To reconfigure it, refer to section 4. Connecting Your LaCie Drive and section 5. Configuring Your LaCie SAFE Drive.
2. Now you’ll see this dialog. From here you can change any information about the user including the user name, permissions, and fingerprint registration. See section 5.2. Setting Up User Names and Privileges and section 5.3. Registering User Finger- prints for more information. 6. Using Your LaCie SAFE Drive Fig. 6.2.14 Changing a user profile in Mac page 26...
Page 28
The last fingerprint for an existing user cannot be removed; a new fingerprint must first be registered. Important Info: Every user can have Administration privileges. 6. Using Your LaCie SAFE Drive Fig. 6.2.16 Removing a fingerprint in Mac page 27...
6.4. Disconnecting and Locking Your Drive To lock your LaCie SAFE drive once you are finished using it, first unmount it. Then disconnect the drive by disconnecting the cable. Your drive, and its data, are now inaccessible to unauthorized users.
7.1. File System Formats Your LaCie SAFE mobile hard drive comes formatted with the FAT 32 file system format. This is the only file system format that is accessible on both PC and Mac platforms. LaCie drives are pre-formatted as FAT 32 volumes and can be used across multiple platforms (for example, Windows 2000/XP, and Mac OS X).
MS-DOS File System This is the Microsoft file system, more typically known as FAT 32. This is the file system to use if you are going to be using your LaCie hard drive between Macs and Windows operating systems. UNIX File System This is the file system based on UNIX, and is preferable for users developing UNIX-based applications within Mac OS 10.x.
User’s Manual 7.2. Formatting And Partitioning Your LaCie Hard Drive Once you have set-up your LaCie Hard Drive, you can reformat or partition it to suit your needs. 7.2.1. Windows Users • Windows 2000 and XP – Use the Disk Management Utility, which is native to the operating system.
Page 33
5) After Windows launches a warning, click Yes to continue. 6) At this screen, you will be prompted to enter a name for the hard drive (it is LACIE by default), select a file system format, and allocate unit size. Click OK to continue.
You should see a volume that represents your internal hard drive, and one labeled LaCie SAFE drive. 6) Select the LaCie drive, and then click on the Partition tab. 7) From the Volume Scheme: button, choose...
Page 35
LaCie SAFE mobile hard drive User’s Manual 8) In the Volume Information section, create a name for each partition, choose the volume format (Mac OS Extended, Mac OS Standard or UNIX File System) and the volume size. Important Info: Please refer to section 7.1. File System Formats, for a more detailed discussion on the differences between the two systems.
To use the newly-enhanced USB 2.0 performances, your computer must be equipped with a USB 2.0 host bus adapter card (sold separately, such as the LaCie USB 2.0 PCI Card, or integrated by your PC manufacturer) and the appropriate drivers.
1) Make sure that the USB 2.0 cable is connected tightly and securely on both ends of the cable, from the drive to the computer. If you are using a USB 2.0 cable other than the one supplied with your LaCie drive, check that it is USB 2.0 certified.
First, make sure that you are swiping your finger the right direction (the front of the drive should be facing you) and that you are touching the sensor for 10 seconds. Also, be sure to wait a few seconds after connecting the LaCie SAFE drive to the USB port on your computer.
Page 39
Should I keep a backup of the data stored on the SAFE drive? It’s always a good idea to keep a backup, or even two backups, of your data. LaCie provides a full range of products for back- ing up data, including tape drives and CD and DVD burners.
9. Troubleshooting Your LaCie Drive In the event that your LaCie SAFE Hard Drive is not working correctly, please refer to the following checklist to find out where the problem is coming from. If you have gone through all of the points on the checklist and your drive is still not working cor- rectly, please have a look at the FAQs that are regularly published on our Web site –...
Page 41
If you cannot see the device, recheck the cables and try the other troubleshooting solutions listed here. Consult LaCie Technical Support. See section 11. Contacting Customer Support for more details. Check the documentation for your Operating System. Check section 2.2. Minimum System Requirements.
Page 42
Simply ignore this message. The drive will remount to the desktop. LaCie drives conserve power by spinning down when you set your computer to sleep mode, and when the computer is “woken” from sleep, it does not give the drive enough time to spin-up from its sleep mode.
Page 43
LaCie SAFE mobile hard drive User’s Manual Tech Note: Technically, you can connect up to 127 devices to a single USB bus. For more than two devices, you must make new connections using a peripheral called a "hub." A hub, which you hook up directly to a USB connector on your computer, usually has 4 or 7 output connections enabling you to connect the same number of peripherals.
FAQs that are regularly published on our Web site – www.lacie.com. One of these FAQs may provide an answer to your specific question. You can also visit the drivers pages, where the most recent software updates will be available.
If you have asked yourself all of the pertinent questions in the troubleshooting checklist, and you still can’t get your LaCie drive to work properly, contact us via the provided Web link. Before contacting us, make sure that you are in front of your computer and that you have the following information on hand: •...
LaCie SAFE mobile hard drive User’s Manual LaCie Australia Contact Us At: http://www.lacie.com/au/contact/ LaCie Canada Contact Us At: http://www.lacie.com/caen/contact/ (English) LaCie Finland Contact Us At: http://www.lacie.com/fi/contact LaCie Germany Contact Us At: http://www.lacie.com/de/contact/ LaCie Japan Contact Us At: http://www.lacie.co.jp LaCie Norway Contact Us At: http://www.lacie.com/no/contact/...
• The broken part is a replacement part such as a pickup tray, etc. • The tamper seal on the drive casing is broken. LaCie and its suppliers accept no liability for any loss of data during the use of this device, or for any of the problems caused as a result.
LaCie SAFE mobile hard drive User’s Manual Glossary Backup – (1) The act of creating at least one additional copy of data onto a different (and safe) storage device from where it can be retrieved at a later time if needed. (2) A copy of a file, directory, or volume on a separate storage device from the original, for the purposes of retrieval in case the original is erased, damaged, or destroyed.
Page 49
LaCie SAFE mobile hard drive User’s Manual Driver (peripheral manager) – A software component that enables the computer system to communicate with a peripheral. Most peripherals will not operate correctly – if at all – if the appropriate drivers are not installed on the system.
Page 50
LaCie SAFE mobile hard drive User’s Manual Interface – The protocol data transmitters, data receivers, logic and wiring that link one piece of computer equipment to another, such as a hard drive to an adapter or an adapter to a system bus. Protocol means a set of rules for operating the physical interface, such as: do not read or write before the drive is ready.
Page 51
LaCie SAFE mobile hard drive User’s Manual RAM (Random Access Memory) – Generally referred to as a computer’s “memory.” An integrated circuit memory chip that allows information to be stored and retrieved by a microprocessor or controller. The information can be stored or accessed in any order, and all storage locations are equally accessible.
