Sanyo VDC-HD3500P Service Manual

Megapixel camera
Hide thumbs

Advertisement

SERVICE MANUAL
Megapixel Camera
CONTENTS
SPECIFICATIONS .............................................3
1. DISASSEMBLY ..............................................5
2. ADJUSTMENT ...............................................9
3. PARTS LIST ................................................12
The components designated by a symbol ( ! ) in this schematic diagram designates components whose value are of
special significance to product safety. Should any component designated by a symbol need to be replaced, use only the
part designated in the Parts List. Do not deviate from the resistance, wattage, and voltage ratings shown.
RoHS
This product does not contain any hazardous substances prohibited by the RoHS Directive.
WARNING
You are requested to use RoHS compliant parts for maintenance or repair.
You are requested to use lead-free solder.
(This product has been manufactured using lead-free solder. Be sure to follow the warning given on page 2 when carrying
out repair work.)
NOTE: 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N.S.P. : Not available as service parts.
Design and specifications are subject to change without notice.
L5DE2/XE, XE-C1F, XE-C8F, US-Z, US-C1F, US-C8F (R)
PRODUCT SAFETY NOTICE
FILE NO.
VDC-HD3500P
(Product Code : 117 408 00)
(Product Code : 117 458 00)
(Product Code : 117 458 10)
(Europe, U.K., Southeast Asia)
VDC-HD3500
(Product Code : 117 408 01)
(Product Code : 117 458 01)
(Product Code : 117 458 11)
(U.S.A., Canada, Taiwan, Brazil)
REFERENCE No.SM5310797

Advertisement

loading

  Also See for Sanyo VDC-HD3500P

  Related Manuals for Sanyo VDC-HD3500P

  Summary of Contents for Sanyo VDC-HD3500P

  • Page 1: Table Of Contents

    FILE NO. SERVICE MANUAL VDC-HD3500P Megapixel Camera (Product Code : 117 408 00) (Product Code : 117 458 00) (Product Code : 117 458 10) (Europe, U.K., Southeast Asia) VDC-HD3500 (Product Code : 117 408 01) (Product Code : 117 458 01) (Product Code : 117 458 11) (U.S.A., Canada, Taiwan, Brazil)
  • Page 2 WARNING Do not use solder containing lead. This product has been manufactured using lead-free solder in order to help preserve the environment. Because of this, be sure to use lead-free solder when carrying out repair work, and never use solder containing lead.
  • Page 3: Specifications

    Backlight compensation : Multi-spot evaluative metering, center-weighted evaluative metering, masking, face detection Electronic sensitivity boosting : Auto (32 x max) or Off Electronic shutter : 1/25, 1/50, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 (VDC-HD3500P) Electronic shutter : 1/30, 1/60, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 (VDC-HD3500)
  • Page 4 Network Image/ video compression : H.264/ JPEG Video size (H.264) : (16:9) 1920x1080, 1280x720, 640x360, 320x180 Video size (H.264) : (4:3) 1600x1200, 1280x960, 1024x768, 640x480, 320x240 Video size (JPEG) : (16:9) 1920x1080, 1280x720, 1024x576, 640x360 Video size (JPEG) : (4:3) 2288x1712,1600x1200, 1280x960, 1024x768, 800x600, 640x480, 320x240 Picture quality : QUALITY mode: BASIC, NORMAL, ENHANCED, FINE, SUPER FINE Picture quality : BITRATE mode: User-specified bit rate...
  • Page 5: Disassembly

    1. DISASSEMBLY 1-1. REMOVAL OF CABINET 1. Three special screws 4 x 20 2. Two screws 3 x 4 3. Holder safety 4. Two spacers 14. Screws 3 x 4 5. Three screws 3 x 6 15. Two screws 3 x 6 6.
  • Page 6 1-2. REMOVAL OF CA-2 BOARD AND CA-3 BOARD 1. Two heat sink rub CA2 2. Connector (CN714) 3. Connector (CN713) 4. Two screws 3 x 6 5. Fixer cable 6. Assy, wire (W4003, CN202) 7. Assy, wire (W4002, CN201) 8. Assy, wire (W4007, CN106) 9.
  • Page 7 1-3. REMOVAL OF CA-4 BOARD, ASSY LENS AND BOARD LOCATION 1. Screw 3 x 6 2. Special washer 3. Pipe 4. Screw 3 x 6 5. Arm pan 6. FPC (CN704) 7. Harness (CN702) 8. Harness (CN703) 9. Two screws 2 x 4 10.
  • Page 8 1-4. HEATER POTION BOARD When assembling, organize the cables as illustrated in the figure shown above. (...
  • Page 9: Adjustment

    3. Double-click on the DscCalDi.exe. Chroma meter VJ8-0192 4. L5DE2 is selected with Model Code. Spare lump (pattern box) VJ8-0191 5. PAL (VDC-HD3500P) or NTSC (VDC-HD3500) is selected with Video Mode. Collimator VJ8-0260 Spare lump (collimator) VJ8-0282 2-4-1. Computer screen during adjustment 1.
  • Page 10 2-5. Adjustment Adjusting method: 1. Timer Quartz Adjustment 1. Set a distance of 0.5-1.0 cm between camera lens and Adjustment location: CT351 (CA-2) the pattern box. (Do not enter any light.) Measuring location: CL351 (CA-2) 2. Connect the camera’s USB terminal to the computer’ Measuring equipment: Frequency counter USB connector.
  • Page 11 Adjustment location: CCD Black of computer screen Adjustment value determination is effectuated using below val- Measuring location: Computer screen ues. Measuring equipment: The adjustment values fulfill the conditions below, they are Adjusting method: determined as within specifications. 1. Set a distance of 0.5 - 1.0 cm between the pattern box and the camera.
  • Page 12: Parts List

    411 126 4702 SCR PAN+SW+W 3X6 9220 645 099 7884 PLUG,5P (CONNECTOR) 5207 613 220 6556 GASKET,TOP-L5DE2 9250 645 094 6691 CORE,CLAMP,VDC-HD3500P ONLY 5208 613 220 6532 CABINET,BOTTOM-L5DE2 9801 645 101 7161 DISC,CD-ROM L5DE2 PC SOFT WARE, 6001 613 220 7805 ARM,PAN-L5DE2 INSTRUCTION MANUAL (N.S.P)
  • Page 13 5204 5003 NJ611 5203 NJ620 6005 6014 NJ820 8001 NJ617 6013 NJ820 5207 6006 8020 NJ810 8080 NJ820 8070 8050 8120 8000 8100 NJ810 8110 NJ622 NJ830 5201 6001 NJ645 6009 NJ616 5202 6102 NJ618 NJ614 6010 6012 6002 6012 W4009 NJ613 6010...
  • Page 14 ELECTRICAL PARTS Note: 1. Materials of Capacitors and Resistors are abbreviated as follows ; Resistors Capacitors MT-FILM Metallized Film Resistor MT-POLYEST Metallized Polyester Capacitor MT-GLAZE Metallized Glaze Resistor MT-COMPO Metallized Composite Capacitor OXIDE-MT Oxide Metallized Film Resistor TA-SOLID Tantalum Solid Capacitor AL-SOLID Aluminum Solid Capacitor NP-ELECT...
  • Page 15 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION C4304 303 414 9905 NIOBIUM 33U M 6.3V R4301 301 105 1504 MT-GLAZE 1.5K JA 1/16W C4305 303 414 9905 NIOBIUM 33U M 6.3V R4302 301 105 1504 MT-GLAZE 1.5K JA 1/16W C4306 303 320 0607 CERAMIC...
  • Page 16 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION D2004 307 210 1101 ZENER DIODE UDZS7.5B COMPL PWB,CA-2 F/W MAC (N.S.P) D3003 307 201 7600 LED SML-310MT, 613 221 1819 D3501 307 232 6009 DIODE SB05-05C-E D3518 408 064 9807 DIODE XBS104S13-R (BATTERY) D3519 408 064 9807...
  • Page 17 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION (CAPACITORS) C2005 303 433 1102 CERAMIC 1U K 10V C1001 303 384 6409 CERAMIC 4.7U K 6.3V C2006 303 294 6100 CERAMIC 100P J 50V C1002 303 384 6409 CERAMIC 4.7U K 6.3V C2007 303 333 0601 CERAMIC...
  • Page 18 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION C6008 303 381 8109 CERAMIC 1U K 6.3V C6211 303 155 2302 CERAMIC 4700P K 50V C6009 303 393 2607 CERAMIC 22U M 6.3V C6212 303 338 0309 CERAMIC 0.1U K 10V C6021 303 338 0309 CERAMIC...
  • Page 19 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION R1061 301 288 6303 MT-GLAZE 1.1K DC 1/16W R3038 301 225 1408 MT-GLAZE 47K JA 1/16W R1066 301 262 2604 MT-GLAZE 120 DC 1/16W R3039 301 262 0600 MT-GLAZE 22K DC 1/16W R1067 301 226 1506 MT-GLAZE 0.000 ZA 1/16W...
  • Page 20 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION R5216 301 224 8903 MT-GLAZE 100K JA 1/16W R6084 301 226 1506 MT-GLAZE 0.000 ZA 1/16W R5217 301 224 9504 MT-GLAZE 2.2K JA 1/16W R6085 301 226 1506 MT-GLAZE 0.000 ZA 1/16W R5218 301 224 9306 MT-GLAZE...
  • Page 21 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION R6210 301 105 7902 MT-GLAZE 0.000 ZA 1/16W (CAPACITORS) R6211 301 105 7902 MT-GLAZE 0.000 ZA 1/16W C8851 303 428 3609 CERAMIC 0.01U K 350V R6212 301 226 1506 MT-GLAZE 0.000 ZA 1/16W C8852 303 428 3609 CERAMIC...
  • Page 22: Circuit Diagrams & Printed Wiring Boards

    CIRCUIT DIAGRAMS & PRINTED WIRING BOARDS TABLE OF CONTENTS OVERALL WIRING, BLOCK DIAGRAM & CIRCUIT DIAGRAMS Page OVERALL WIRING OVERALL CIRCUIT BLOCK DIAGRAM CA-1 BOARD CMOS IMAGE SENSOR CA-2 BOARD (DM-A) SYSTEM ASIC CA-2 BOARD (DM-B) CODEC CA-2 BOARD (PW-A) POWER CA-2 BOARD (SY-A) SYSTEM CONTROL CA-3 BOARD (PW-B) POWER CA-3 BOARD (SY-B) IRIS DRIVER...
  • Page 23 NOTES: 1. All resistance values in "OHMS" unless otherwise noted. (K=1,000 ; M=1,000,000) 2. All capacitance values in "µF" unless otherwise noted. p=pico farad ; n=nano farad ; µ ,u or U=micro farad 3. All inductance values in "µH" unless otherwise noted. µ...
  • Page 24 OVERALL WIRING, BLOCK DIAGRAM & CIRCUIT DIAGRAMS OVERALL WIRING CA-1 CA-4 CN971 CN522 SY-B DM-A CA-3 FILTER- FILTER- FILTER+ FILTER+ ABF A+ ABF A+ ABF A- ABF A- ABF B+ ABF B+ ABF B- ABF B- IRIS_VCA IRIS_VCA (PW-B) IRIS_REF IRIS_REF CN111 BACKUP_GND...
  • Page 25: Overall Circuit Block Diagram C4

    OVERALL CIRCUIT BLOCK DIAGRAM CA-2 IC112 CN111 VIDEO SD OUT DRIVER (DM-A) CN102 IC104 IC108 CN106 ALARM IN/OUT BUS SW (DM-B) X3501 ALARM IN/OUT IC352 32.768KHz uCOM_RST IC111 IC605, IC606 IC607 8bit MICRO- ENCODER X3502 DDR2 NAND CN201 PROCESSOR 10.000MHz SDRAM FLASH MEMORY AUDIO OUT...
  • Page 26: Board Cmos Image Sensor

    CA-1 BOARD CMOS IMAGE SENSOR CA-1 C1-40700/L5DE2-XE VOLTAGE: POWER ON CN911 DGND DGND XCLR DGND SDIP7 SDIP7 SDIN7 SDIN7 SDIP6 SDIP6 SDIN6 SDIN6 SDIP5 SDIP5 SDIN5 SDIN5 TOUT7 SDIP4 SDIP4 M12 TOUT8 SDIN4 SDIN4 M13 NC SCKIP0 SCKIP0 M14 NC SCKIN0 SCKIN0 N1 NC...
  • Page 27: Board (Dm-A) System Asic

    CA-2 BOARD (DM-A) SYSTEM ASIC A_VDD3 A_VDD3 C1114 TP111 TP112 RCU00000C RCU00000C IC112 BH76806FVM QBH76806FVM-J MON_SEL NVCC CN111 C1112 R1126 L1101 ASIC_CVBS_OUT R1103 75;1/10J UOUT BK1608LL121 SD OUT R1008 A_VDD1.8 0;1/16Z STBY Vout 0;1/16Z VOUT 1.8V(VDD) VA112 VIDEO DRIVER AVR-M1608C270MTABB L1004 A_VDD1.2 FBMH1608HL600...
  • Page 28 CA-2 BOARD (DM-A) SYSTEM ASIC [UPPER-LEFT] R1008 A_VDD1.8 0;1/16Z 1.8V(VDD) A_VDD1.2 L1004 FBMH1608HL600 VDD1.2 TO PW-A 1608 A_VDD3 3.3V(AL) TO PW-A, SY-A L1003 Q1004 FBMH1608HL600 UPA650TT-A 1608 AD25 AC25 AL26 AJ17 AE25 AE24 AE14 AA21 AA18 AA17 AA14 AA13 R1093 33K;1/16J Q1005 2SC4081-R...
  • Page 29 CA-2 BOARD (DM-A) SYSTEM ASIC [UPPER-RIGHT] A_VDD3 A_VDD3 C1114 TP111 TP112 RCU00000C RCU00000C IC112 BH76806FVM QBH76806FVM-J MON_SEL CN111 NVCC C1112 R1126 L1101 ASIC_CVBS_OUT R1103 75;1/10J BK1608LL121 UOUT SD OUT 0;1/16Z STBY Vout VOUT VA112 VIDEO DRIVER AVR-M1608C270MTABB VAGND SD OUT R1123 R1102 18;1/16D...
  • Page 30 EV3HB ZUSB_DET QEV3HB------N ZBOOT_COMREQ CA-2 BOARD (DM-A) SYSTEM ASIC [LOWER-LEFT] ASIC_SDO ASIC_SDI ASIC_SCK 16.0X16.0 MRST ZSREQ TO SY-A 0.500000 H=1.35 INA+ INA- INB+ INB- IRIS_VCA IRIS_REF 1.8V(CS)_ON SYSTEM ASIC 1.8V(I/O)_ON 3.0V(CS)_ON TO PW-A 3.3V(MOB) 3.3V(MOB) TO PW-A, DM-B 2SA1576A-R Q1081 R1082 1K;1/10J R1085...
  • Page 31 DQP28 DQP28 DQSP1 DQSP0 DQP29 DQS1 DQS0 DQP29 DQP8 VDDQ DQP30 DQP30 DQP5 VDDQ DQP31 DQP31 DQP9 DQP6 DAP0 DAP0 DQP10 A_VDD3 B------N DQ10 VSSQ NOR FLASH MEMORY DAP1 DAP1 CA-2 BOARD (DM-A) SYSTEM ASIC [LOWER-RIGHT] DQP3 VSSQ DAP2 DAP2 IC121 DQP11 DQP4...
  • Page 32: Board (Dm-B) Codec

    CA-2 BOARD (DM-B) CODEC T6801 S558-5500-25-F R6801 R6812 49.9;1/16F 0;1/16Z R6802 CN683 49.9;1/16F DM-B L6801 R6813 DLP11SN900SL2 0;1/16Z X6851 25.000MHz TXCT R6803 L6802 49.9;1/16F DLP11SN900SL2 R6814 0;1/16Z D2-40800/L5DE2-XE R6804 RXCT VOLTAGE: POWER ON 49.9;1/16F R6862 1M;1/16J R6815 0;1/16Z TO CA-5 CN881 R6806 0;1/10Z ETH_RXDV...
  • Page 33 CA-2 BOARD (DM-B) CODEC [UPPER-LEFT] DM-B D2-40800/L5DE2-XE VOLTAGE: POWER ON L6205 BLM18PG121SN1 3.3V(MOB) 5.0V(AL) 3.3V(MOB) R6209 A_MCLK Q6202 DTC114EUA 0;1/16Z C6204 10;B L6203 BLM18PG121SN1 0;1/16Z A_BCK SVSS BICK R6202 C6205 0.1;B A_LRCLK R6203 SVDD Q6201 560;1/16J A_IDAT DTC343TK AOUT IC621 SDTO R6205 AK4633VN(CCTV)
  • Page 34 CA-2 BOARD (DM-B) CODEC [UPPER-RIGHT] T6801 S558-5500-25-F R6801 R6812 49.9;1/16F 0;1/16Z R6802 CN683 49.9;1/16F TXCT L6801 R6813 DLP11SN900SL2 0;1/16Z X6851 25.000MHz TXCT R6803 L6802 49.9;1/16F DLP11SN900SL2 R6814 0;1/16Z R6804 RXCT 49.9;1/16F R6862 RXCT 1M;1/16J R6815 0;1/16Z TO CA-5 CN881 R6806 0;1/10Z VDDIO_3.3 VDDIO_3.3...
  • Page 35 R6078 0;1/16Z A_BCK AUD0_BCK A_IDAT AUD0_IDAT R6111 10;1/16J ETH_TXC ETH_TXCLK A_LRCLK AUD0_LRCK R6112 10;1/16J ETH_RXER CA-2 BOARD (DM-B) CODEC [LOWER-LEFT] A_MCLK ETH_RXER AUD0_MCLK R6113 10;1/16J ETH_RXDV A_ODAT ETH_RXDV AUD0_ODAT0 R6114 10;1/16J ETH_RXD0 L6009 L6012 L6015 ETH_RXD0 BLM18PG121SN1 BLM18PG121SN1 BLM18PG121SN1 AUD0_ODAT1 R6115 3.3V(MOB) 10;1/16J...
  • Page 36 DATA0 R6078 SD_D1 R6140 100;1/16J DATA1 0;1/16Z DATA2 SD_D2 R6141 100;1/16J SD_CD R6142 100;1/16J CARD CARD/WP A_BCK AUD0_BCK SD_WP R6143 100;1/16J A_IDAT AUD0_IDAT R6111 10;1/16J ETH_TXC ETH_TXCLK A_LRCLK AUD0_LRCK R6112 10;1/16J ETH_RXER CA-2 BOARD (DM-B) CODEC [LOWER-RIGHT] A_MCLK ETH_RXER AUD0_MCLK R6113 10;1/16J ETH_RXDV...
  • Page 37: Board (Pw-A) Power

    CA-2 BOARD (PW-A) POWER 5.0V(AL) TO SY-A F5201 2A32V C5207 R5219 L5202 0;1/16Z VDD1.2 C5208 1AV4L2WN2R0MG TO DM-A 22;B 6.3 2125 C5202 0.1;B PVIN2 PGND2 R5203 PVIN1 PGND1 1K;1/16J REG. 51K;1/16D ISET SYNC/EN C5204 R5218 AGND 1.2V(AS)_ON 0.047;B 10 IC522 TO SY-A SC4624MLTRT R5204...
  • Page 38: Board (Sy-A) System Control

    CA-2 BOARD (SY-A) SYSTEM CONTROL R3034 0;1/8Z 3.3V(AL) TO PW-A, DM-A ZSREQ ZBOOT_COMREQ TO DM-A R3043 47K;1/16J SY-A R3089 100K;1/16J R3038 47K;1/16J Y1-40800/L5DE2-XE VOLTAGE: POWER ON R3040 150K;1/16J C3023 3.3V(AL) S3008 COMREQ SCAN IN1 SKQGAB A10 BAT_OFF DC_IN2 R3056 3.3K;1/16J B9 SREQ SCAN IN2 R3057...
  • Page 39: Board (Pw-B) Power

    CA-3 BOARD (PW-B) POWER PW-B CN402 P2-40800/L5DE2-XE HEATER+ VOLTAGE: POWER ON HEATER- IC433 MC78L12ABD HEATER QMC78L12ABD-G POWER_FAIL 12.0 VOUT IRIS12V F4001 L4001 L4003 6.5V(AL) D4001 3.5A125V FBMH3225HM601N FBMH3225HM102N SJPB-L6 D4002 RF071M2S D4083 CN401 PS2701A-1-F3 R4420 D4003 0;1/16Z RF071M2S 15V(AL) AC24V/+ L4002 L4004 D4004...
  • Page 40: Board (Sy-B) Iris Driver

    CA-3 BOARD (SY-B) IRIS DRIVER SY-B Y2-40800/L5DE2-XE 6.5V(AL) VOLTAGE: POWER ON IRIS12V R9756 0;1/16Z 3.3V(AL) TO PW-B R9751 0;1/16Z CN971 R9757 0;1/16Z R9752 0;1/16Z FILTER- FILTER+ 12.0 CN972 ABF A+ ABF A- FILTER+ ABF B+ FILTER- L9701 ABF B- R9723 BLM11B102SPT Q9704 0;1/10Z...
  • Page 41: Board D/N, Iris, Abf, Cmos Image Sensor Connector

    CA-4 BOARD D/N, IRIS, ABF, CMOS IMAGE SENSOR CONNECTOR CA-5 BOARD ETHERNET TO CA-1 CN911 CA-4 CN701 CA-5 DGND Z1 Z2 Z3 Z4 Z5 Z6 Z7 DGND C4-40800/L5DE2-XE D_GND XCLR XCLR DGND DGND XCLR XCLR C5-40800/L5DE2-XE ETHERNET SDIP7 SDIP7 DGND SDIN7 SDIN7 SDIP7...
  • Page 42: Printed Wiring Boards (P.w.b.)

    PRINTED WIRING BOARDS (P.W.B.) CA-1 P.W.B. (SIDE A) CA-1 P.W.B. (SIDE B) 1AC4B13B0020AA R9111 C9127 C9125 C9119 R9112 C9128 C9121 C9116 R9106 C9118 C9103 C9102 IC911 R9101 C9122 C9112 C9129 C9114 PWB,CA-1 C9123 C9126 CL911 SIDE-B C9132 1AC4B13B0020AA PWB,CA-1 SIDE-A...
  • Page 43 CA-2 P.W.B. (SIDE A) Z3501 Z3501 IC353 X3501 IC353 CN522 CN522 CL608 CN351 CN605 S9909 CL608 REVERSE CL607 R6133 CL601 C3503 CL601 R6134 CN604 SIDE-A R6144 S9902 R6145 R6146 CL606 CL606 NEAR R6147 L5DE2 PWB,CA2 R6135 CL605 CL605 IC607 1AC4B10H3800AC S9903 C1016 R1093...
  • Page 44 CA-2 P.W.B. (SIDE B) 1AC4B10H3800AC Q6002 L5DE2 PWB,CA2 D3501 CL355 R3539 CN547 C3524 R3511 C3525 R3525 R3542 C3515 C3523 SIDE-B CT351 CT351 R3505 R3532 IC352 R3533 R1032 R3507 CL361 R3534 R3508 IC102 CL361 C3511 C1035 C1010 C1044 C1007 C3508 X3502 C3512 R3535 R3529...
  • Page 45 CA-3 P.W.B. (SIDE A) CA-3 P.W.B. (SIDE B) 1AC4B10H3900AB 1AC4B10H3900AB L5DE2/L5DK2 PWB,CA3 L5DE2/L5DK2 PWB,CA3 SIDE-A CN971 SIDE-B CN971 R9701 R9710 R9706 C9714 R9705 Q9704 Q9702 R9708 C9703 C9701 IC971 Q9705 R9702 R9703 C9702 C9706 R9713 Q9703 CN972 R9707 IC981 R9803 R9805 R9801 R9806...
  • Page 46 CA-4 P.W.B. (SIDE A) CA-4 P.W.B. (SIDE B) 1AC4B10H3900BB 1AC4B10H3900BB PWB,CA4 CN701 SIDE-A CN701 CN714 CN714 CN713 PWB.CA4 SIDE-B CN713 CN703 CN702 CN704 CN703 CA-5 P.W.B. (SIDE A) CA-5 P.W.B. (SIDE B) 1AC4B10H3900CB SIDE-A JK881 D8851 D8851 D8853 D8853 D8854 D8854 D8852 D8852...
  • Page 47 SANYO Electric Co., Ltd. Osaka, Japan Nov./’09...
