ATOMIC CLOCK WITH OUTDOOR WIRELESS TEMPERATURE AND
Instruction Manual
FEATURES:
ATOMIC CLOCK:
LCD1
display
LCD2
display
• WWVB Radio controlled time with manual time setting
• 12/24 hour time display
• Time display: hour, minute, second
• Alarm setting with snooze function
• Calendar display
• Weekday display (3 languages to choose from: English, French and Spanish)
• Time zone setting
• Daylight savings time ON/OFF option (DST)
• ºC or ºF temperature display selectable
• Indoor temperature display
• Outdoor temperature display via 433MHz transmission
• Wall mount or freestanding
• Current moon phase display
WS-8117
MOON PHASE
Battery cover
OUTDOOR TEMPERATURE TRANSMITTER:
Hanging holes
• Remote transmission of outdoor temperature to the atomic clock by 433 MHz signals
• Wall mounting case
Function keys
TO INSTALL AND REPLACE BATTERIES IN THE ATOMIC CLOCK
The atomic clock uses 2 x AA, 1.5V batteries. To install and replace the batteries, please follow the
steps below:
Foldable stand
1.
Insert finger or other solid object in the space at the bottom center of the battery compartment
and lift up to remove the cover.
2.
Insert batteries observing the correct polarity (see marking inside battery compartment).
3.
Replace compartment cover.
DO NOT SET THE CLOCK.
TO INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE TRANSMITTER
The transmitter uses 2 x AA,1.5V batteries. To install and replace the batteries, please follow the
steps below:
1.
Remove the cover.
2.
Insert the batteries, observing the correct polarity (see marking inside battery compartment).
3.
Replace the battery cover on the unit.
Alkaline batteries are recommended for use in both units. Avoid using rechargable batteries.
SETTING UP:
Holder

Advertisement

Table of Contents
loading

Related Manuals for La Crosse Technology WS-8117

Summary of Contents for La Crosse Technology WS-8117

  • Page 1: To Install/Replace Batteries

    • Wall mounting case Function keys TO INSTALL AND REPLACE BATTERIES IN THE ATOMIC CLOCK The atomic clock uses 2 x AA, 1.5V batteries. To install and replace the batteries, please follow the steps below: Foldable stand Insert finger or other solid object in the space at the bottom center of the battery compartment and lift up to remove the cover.

  • Page 2: Function Keys

    To exit the setting modes ATOMIC CLOCK LCD SCREEN DESCRIPTIONS The atomic clock's LCD is divided into 2 sections and once the batteries are inserted, all the segments will light up briefly before displaying the information for time, date, indoor and outdoor temperatures.

  • Page 3: Time Zone Setting

    When the time signal is received for example at 1:00 am, the atomic clock will not attempt to receive the WWVB signal for the remaining hours until 6:00 am. Therefore, the next signal attempt will take place between 12:00 am and 6:00 am the next day.

  • Page 4: 12/24 Hours Time Display Setting

    To return to the normal display mode from anywhere in manual setting mode simply press the SNZ key anytime. • If no keys are pressed for at least 15 seconds in setting mode, the atomic clock will automatically switch back to normal display mode. ALARM SETTING To enter into the alarm setting mode: Hold the ALM key for 4 seconds.

  • Page 5: 433Mhz Reception Check For Outdoor Temperature Transmitter

    Once the outdoor temperature is displayed on the atomic clock, the WWVB tower icon in the clock display will start flashing in the top center of the LCD. This indicates that the clock has detected a radio signal and is trying to receive it. When the time code is received, the WWVB tower becomes permanently lit and the time will be displayed.

  • Page 6: Moon Phase

    Gibbous POSITIONING Before permanently mounting ensure that the atomic clock is able to receive WWVB signals from the desired location. Also, extreme and sudden changes in temperature will decrease the accuracy of the atomic clock, and changes in elevation will result with inaccurate temperatures readings for the next 12 to 24 hours.

  • Page 7: Troubleshooting

    Solution: 1) Replace the batteries. Problem: No reception of WWVB signal 1) It may help reception to face the front of the atomic clock in the general Solution: direction of Ft. Collins, Colorado. 2) Wait overnight for signal. 3) Be sure the atomic clock is at least 6 feet (2 meters) from any electrical devices, i.e.

  • Page 8: Care And Maintenance

    Transmitter: 2 x AA, 1.5V batteries Battery life: about 12 months Dimensions (L x W x H) Atomic clock : 11.41“ x 0.98“ x 7.48“ / 290 x25 x190mm Transmitter: 1.57“ x 0.9“ x 5.04“ / 40 x 23 x 128 mm LIABILITY DISCLAIMER: •...

  • Page 9: Warranty Information

    La Crosse Technology provides a 1-year warranty on this atomic clock. Contact La Crosse Technology immediately upon discovery of any defects covered by this warranty. Before sending the atomic clock in for repairs, contact La Crosse Technology. The atomic clock will be repaired or replaced with the same or similar model.
  • Page 10 Atomic Clock With Outdoor Temperature and Moon Phase This handbook may contain mistakes and printing errors. The information in this handbook is regularly checked and corrections made in the next issue. We accept no liability for technical mistakes or printing errors, or their consequences.
