  • Page 1 CD-484...
  • Page 2 PARTNO DESCRIPTION SPEC SYMBOL 001-0000S-B90 P.C.B FILTER BOX 001-8008S-761 P.C.B MAIN BOARD 002-00240-000 I.C DSD240 IC 302 002-02245-A01 I.C KA2245 IC 101 002-07343-A00 I.C TA7343AP/KIA6043 IC 102 002-0880R-000 I.C DSD880R IC 301 002-1558Q-A05 I.C TDA1558Q1 IC 201 002-1923F-H07 I.C BU1923 IC 103 002-7313D-B06 I.C TDA7313D IC 202...
  • Page 3 PARTNO DESCRIPTION SPEC SYMBOL 011-A010F-200 RESISTOR 1 OHM 1/2W ±5% R105 011-A100A-200 RESISTOR 10 OHM 1/16W ±5% 011-A101A-200 RESISTOR 100 OHM 1/16W ±5% R37.38.40.41.54.74.103 011-A102A-200 RESISTOR 1K OHM 1/16W ±5% R9.19.20.79.85.89.125 011-A103A-200 RESISTOR 10K OHM 1/16W ±5% R21.29.48.35.64.93.101.4.100 011-A104A-200 RESISTOR 100K OHM 1/16W ±5% R53.52.77 011-A105A-200 RESISTOR...
  • Page 4 PARTNO DESCRIPTION SPEC SYMBOL 012-C226C-300 ELECT CAP 22uF 50V ±20% 5x11mm C71.9 012-C335F-300 ELECT CAP 3.3uF 50V ±20% 5x11mm 012-C336C-300 ELECT CAP 33uF 16V ±20% 5x11mm 012-C475C-300 ELECT CAP 4.7uF 16V ±20% 5x11mm C57.55.54.51.49.48.126.127.70 012-G108C-300 ELECT CAP 1000uF 10V ±20% 8x16mm C121.122.84 012-K108C-300 ELECT CAP 1000uF 16V ±20% 10x17mm C123.

  • Page 5: Front Pcb

    PARTNO DESCRIPTION SPEC SYMBOL 112 029-B0000-010 Antenna Jack Double Screw 36A41009 113 032-E0500-054 RAINBOW WIRE 5PIN 3+50+10 114 032-E1100-044 RAINBOW WIRE 4PIN 3+110+10 115 033-S1000-GY0 SHIELD WIRE ANT 1P 100mm 116 034-A1612-005 ISO 16P W/WIRE 12P H/P 117 035-B5300-BE4 JUMPER WIRE #20 530mm BLUE W/FUSE 0. 118 035-E0900-RD1 Jumper Wire #26 90mm RED 3-90-3 TUNER:1 LAMP:2 119 035-E0600-BE1 Jumper Wire #26 60mm Blue 3-60-3...
  • Page 6 PARTNO DESCRIPTION SPEC SYMBOL 148 002-9286B-A01 I.C KS9286B IC201 149 003-933AS-A07 TRANSISTOR 2SA933AS SOT TYPE TR1 /STA1037YR40 004-04148-000 SILICON DIODE IN4148/SDS7000 D1 D2 151 004-SR23G-000 PHOTO DIODE SR-23G IR1 IR2 006-16934-100 CRYSTAL 16.9344MHZ x1 (Small Type) 153 010-D0106-000 COIL 10UH AXIAL EC-36 COIL1 COIL2 154 011-S100A-200 0805 RES ±5% 10 OHM 155 011-S102A-200 0805 RES ±5% 1K OHM...
  • Page 7 PARTNO DESCRIPTION SPEC SYMBOL 187 014-S040C-400 0805 SMT.CAP ±5% 4PF 188 014-S080C-500 0805 SMT.CAP ±10% 8PF 189 014-S102C-500 0805 SMT.CAP ±10% 0.001UF 190 014-S103C-500 0805 SMT.CAP ±10% 0.01UF C2.4.14.16.21.26.30.33 191 014-S104C-500 0805 SMT.CAP ±10% 0.1UF 14 C12.13.22.23.24.31.36.37.44.47-49 192 014-S151C-500 0805 SMT.CAP ±10% 150UF C5.9 193 014-S152C-500 0805 SMT.CAP ±10% 0.0015UF C1.6.10...
  • Page 8 PARTNO DESCRIPTION SPEC SYMBOL 224 218-8058C-E10 DECK BRACKET-F-8058 EGJ T=1.0 225 222-1001S-E06 SLEEVE CASE EGI T0.6 70028039 226 222-3510B-H06 BOTTOM COVER (A/R) EGI T0.6 3510 COM 227 222-8058T-E06 TOP-COVER-8058 EGI T=0.6 CD1888 MODIFY 228 223-1888L-E10 SIDE CHASSIS (L) EGI T1.0 229 223-1888R-E10 SIDE CHASSIS (R) EGI T1.0 225-09007-400 CUSHION BOTTOM 9x7x4mm...
  • Page 9 PARTNO DESCRIPTION SPEC SYMBOL 305-00000-000 INST'S MANUAL 306-00000-006 CARTON BOX (1/6) 264 313-39000-S00 PVC SHEEF TOR-LCD CAP FOR LCD 314-0000T-000 TOP LABEL 266 314-0000W-000 WARRANTY LABEL 267 315-80580-AWE KNOB-COVER PAPER WHITE T-0.1 268 315-36100-AWE LCD LAMP COVER PAPER WHITE 93610096 269 316-BE835-205 LCD FILTER 83.5x20.5x0.1mm NEFAM 319-00000-010 SILICA...
  • Page 10 PARTNO DESCRIPTION SPEC SYMBOL 300 429-8058N-3BK TUNE-GEAR PC(CLEAR) 301 429-8058P-3BK TUNE-KNOB-B-BRACKET PC(CLEAR) 302 430-8058A-1NL EJECT-KNOB ABS(CLEAR) 303 430-8058C-1NL EJECT-KNOB-RDS ABS(CLEAR) (RDS ) 304 430-8058L-1CR EJECT-KNOB-ARM ABS(CLEAR) 305 435-8058D-1NL LOUD-KNOB-ARM ABS(NATURAL) 306 435-8058F-2SE LOUD-RDM-KNOB ACRYL(SKY BLUE) 307 436-8058A-1NL MUTE-KNOB ABS(CLEAR) 308 436-8058C-1CR MUTE-KNOB-ARM ABS(CLEAR) 309 437-8058A-1NL DSP-KNOB ABS(CLEAR)
