  • Page 1 CD-306MPFM...
  • Page 2 Engineering Department Bill of Materials ITEM CODE DESCRIPTION SYMBOL 001-0000S-B90 P.C.B FILTER BOX 001-3909S-N80 P.C.B MAIN BOARD 002-01140-A09 I.C LA1140 IC201 002-03370-A09 I.C LA3370 IC301 002-2313L-B00 I.C PT2313L IC601 002-0790R-H00 I.C DSC-790R 002-1923F-G07 I.C BU1923F IC403 002-07381-J06 TDA7381 IC401 002-07035-T00 I.C KIA7035 002-75823-H00 I.C LC75823...
  • Page 3 ITEM CODE DESCRIPTION SYMBOL 011-A224A-200 RES 1/16W ±5% 220K OHM R102.18 011-A330A-200 RES 1/16W ±5% 33 OHM R28.17.6 011-A331A-200 RES 1/16W ±5% 330 OHM R5.7 011-A332A-200 RES 1/16W ±5% 3.3K OHM R25.29.44.52.149.150 011-A333A-200 RES 1/16W ±5% 33K OHM 011-A334A-200 RES 1/16W ±5% 330K OHM R23.57.58 011-A471A-200 RES 1/16W ±5%...

  • Page 4: Front Pcb

    ITEM CODE DESCRIPTION SYMBOL 035-B0600-RD1 JUMPER WIRE #20 60mm RED 035-B0500-BE1 JUMPER WIRE #20 50mm BLUE 035-E1000-BE1 JUMPER WIRE #26 100mm BLUE 036-A0250-030 3P WAFER P=2.5mm ST 036-D0125-250 25PIN CONNECTOR PITCH P=1.25mm 037-A6100-3B0 3P H'ING P=2.5mm #28 100mm 037-G5300-2B1 3P H'ING P2.5mm 2xSH L=300mm GREY 042-30010-000 FUSE HOLDER 201-EI240-000...
  • Page 5 ITEM CODE DESCRIPTION SYMBOL 011-S153A-200 RES CHIP ±5% 0805 15K OHM R213.212.209.221 011-S184A-200 RES CHIP ±5% 0805 180K OHM R211 011-S203A-200 RES CHIP ±5% 0805 20K OHM R216 011-S204A-200 RES CHIP ±5% 0805 200K OHM R126 011-S220A-200 RES CHIP ±5% 0805 22 OHM R201 011-S222A-200 RES CHIP ±5% 0805...
  • Page 6 ITEM CODE DESCRIPTION SYMBOL SPONGE (3001 COM) 227-30050-E60 CASE CUSHION "B" 93005028 228-3909A-000 CD-FELT CLOTH (BLACK) 216 233-N030W-H00 HEX NUT: M3 IC:1 217 233-N050W-H00 HEX NUT: M5 ACC:1 234-HEX50-120 HEX BOLT: 5x12mm DOUBLE HEAD CARBON STEEL D.Zn 234-MS030-050 SCREW: MS 3x5 (5.5x1x5) BASE PANEL:4 234-PT030-040 SCREW: TTP 3x4 TAP TYPE SIDE-BRACKET:1...
  • Page 7 ITEM CODE DESCRIPTION SYMBOL 431-39096-100 MEMORY-KNOB "6" 431-3909B-300 MEMORY-KNOB-ARM 432-3909A-100 SEL-KNOB 432-3909B-300 SEL-KNOB ARM 434-3909A-100 SCAN-KNOB 434-3909B-300 SCAN-KNOB ARM 437-3909A-100 DISP-KNOB 439-3909A-100 RELEASE-KNOB 440-3987A-3BK HOOK PC BLACK 441-3909B-300 TRIM COVER 442-3909A-100 A/PS-KNOB 445-3909A-100 MODE-KNOB 445-3909B-300 MODE-PTY-A/PS-KNOB ARM 446-3909A-100 TA-KNOB 446-3909B-300 TA-AF-DISP-KNOB ARM 446-3909C-100 AF-KNOB 446-3909D-100 PTY-KNOB 463-0000C-4BK FILTER &...
