  • Page 1 CD-650UMP/FM...
  • Page 2 Bill of Materials ITEM CODE DESCRIPTION SYMBOL 001-3300S-E20 P.C.B MAIN BOARD 001-0000S-B90 P.C.B FILTER BOX 002-0790R-H00 I.C DSC-790R 002-1923F-G07 I.C BU1923F IC403 002-2313L-B00 I.C PT2313L IC601 002-04558-G00 I.C TJM4558 IC3.2 002-01140-A09 I.C LA1140 002-03370-A09 I.C LA3370 002-07384-J06 I.C TDA7384 IC401 002-07035-T00 I.C KIA7035 002-78L05-F00 I.C...
  • Page 3 ITEM CODE DESCRIPTION SYMBOL 005-00039-A00 ZENER DIODE 1/2W 3.9V 005-00051-A00 ZENER DIODE 1/2W 5.1V ZD1.4.11.8 005-00056-A00 ZENER DIODE 1/2W 5.6V 005-00075-A00 ZENER DIODE 1/2W 7.5V 005-00100-A00 ZENER DIODE 1/2W 10V ZD5.3 006-04330-000 CRYSTAL 4.33MHz 006-04500-000 CRYSTAL 4.5MHz 31 007-05046-7GY I.F.T 7x7mm K5046 GREY 32 009-0201V-A02 TUNER (FM) KCF-201V 010-A0222-000 CHOCK COIL 22mH...

  • Page 4: Filter Box

    ITEM CODE DESCRIPTION SYMBOL 52 011-A224A-200 RES 1/16W +-5% 220K OHM R102 53 011-A330A-200 RES 1/16W +-5% 33 OHM R120.7.121 54 011-A331A-200 RES 1/16W +-5% 330 OHM R71.2.114 55 011-A332A-200 RES 1/16W +-5% 3.3K OHM R112.9.11.10.8.66.13 56 011-A333A-200 RES 1/16W +-5% 33K OHM R138 57 011-A393A-200 RES 1/16W +-5% 39K OHM R128...
  • Page 5 ITEM CODE DESCRIPTION SYMBOL 81 013-B102A-400 POLY.CAP 1000PF 50V C102 82 014-A102C-500 CRE CAP +-10% 0.001uF 50V C80.58.77.59 83 014-A103C-500 CRE CAP +-10% 0.01uF 50V C40.12.13.60.104 C112.114.69.111.89.71.18.110.21. 84 014-A104C-500 CRE CAP +-10% 0.1uF 50V 85 014-A121C-500 CRE CAP +-10% 120PF 50V C25.26.22.23 86 014-A473C-500 CRE CAP +-10% 0.047uF 50V 87 014-A222C-500 CRE CAP +-10% 0.0022uF 50V...

  • Page 6: Front Pcb

    ITEM CODE DESCRIPTION SYMBOL 110 037-A5220-3B0 3PIN H'ING P=2.5mm #26 3x220mm 111 037-G0450-201 RCA 2xSH L=450mm Black W/O H'ING 112 037-G0300-203 RCA 2xSH L=300mm GREY W/O H'ING 113 042-30010-000 FUSE HOLDER 114 201-EI240-000 CHOKE TRANS EI-24 115 221-S0040-040 BARE WIRE D=0.4x40mm 116 230-100BK-100 PLASTICTIE L=100mm 117 231-P0060-130 RUBBER TUBE PVC D=13 L=60mm 1.0mm...

  • Page 7: Usb Board

    ITEM CODE DESCRIPTION SYMBOL 138 023-D0000-BE0 0603 LED BJS170TS-JPH BLUE SMD LED RF-WNA30TS-N WHITE 139 023-F2835-WE2 800-1000mcd 2.8x3.5x1.9 140 025-TA020-430 TACT SW 2P 4.3mm 180G 141 025-TA02S-430 TACT SW 2P 4.3mm SMD 180G 142 036-H0250-120 DETACHABLE CON 12P PLUG P=2.5mm VOL 12mm Encoder Sw 30DET 15PUS 143 049-E1141-050 E1141A3A L=11.5mm...
  • Page 8 ITEM CODE DESCRIPTION SYMBOL 166 011-B301A-200 0603 RES CHIP +-5% 300 OHM 167 011-B331A-200 0603 RES CHIP +-5% 330 OHM R2.3 168 011-B433A-200 0603 RES CHIP +-5% 43K OHM 169 011-B472A-200 0603 RES CHIP +-5% 4.7K OHM 170 011-B473A-200 0603 RES CHIP +-5% 47K OHM R35.36.37.38.39 171 011-B512A-200 0603 RES CHIP +-5% 5.1K OHM R49.50.51...
  • Page 9 ITEM CODE DESCRIPTION SYMBOL 193 001-7806D-C20 P.C.B CDP BOARD MP3 194 002-0016M-P00 I.C 16M DRAM 195 002-09226-S01 I.C SIL9226X 196 002-09276-H00 I.C S5L9276 197 002-09290-G01 I.C S5L9290 198 002-04001-A01 I.C KA9259D/IP4001 199 003-01504-B03 TRANSISTOR KTA1504S GR (SMD) 200 003-01576-S07 TRANSISTOR 2SA1576 SMD Q2.5.6.3.4 201 004-04148-000 DIODE IN4148...
  • Page 10 ITEM CODE DESCRIPTION SYMBOL 222 011-S913A-200 RES CHIP ±5% 0805 91K OHM R224 223 012-1107B-300 ELECT CAP 100uF 10V +-20% 5x7mm C102.1.124 224 013-D106L-50A Tantal Chip CAP 10uF 10V ±20% "A-Size" C109.110.211.222.?.? 225 013-D476L-50B Tantal Chip CAP 47uF 10V ±20% "B-Size" Q7.C202 226 014-S050C-500 CER CAP CHIP ±10% 0805 5PF 50V C208...
  • Page 11 ITEM CODE DESCRIPTION SYMBOL 250 212-52100-05P PLATE WASHER (Ф5.2) ACC:2 251 214-18880-C00 MAIN FIBER FIBER T0.5 252 214-DECK0-A00 CD FIBER 105x95x0.5mm FOR CD KMC DECK 253 216-3909H-C00 HEAT-SINK AL DIE CASTING 254 216-3300B-C00 HEAT SINK-S AL WHITE 255 217-1001E-E12 MOUNTING STRIP EGI T1.2 AL T=0.5 FOR REMOTE 256 217-3300K-C05 AL-ORNAMENT...
  • Page 12 ITEM CODE DESCRIPTION SYMBOL 279 234-PB017-040 SCREW: TS 1.7x4 PB USB-REFLECTOR:2 280 234-PT026-040 SCREW: TS 2.6x4 TAP TYPE DECK BRT:5 281 234-PT030-040 SCREW: TS 3x6 TTP IC:1 DECK BKT+HEAT SINK:3 282 234-PT030-050 SCREW: TS 3x5 TAP TYPE C MAIN/PCB:4 283 234-PT030-080 SCREW: TS 3x8 TAP TYPE C HEAT-SINK/REAR:2 284 234-PT030-100 SCREW: TS 3x10 TTP HEAT-SINK:1...
  • Page 13 ITEM CODE DESCRIPTION SYMBOL 308 315-33000-DWE REFLECTOR-PAPER REFLECTOR PAPER T=0.1 309 315-33000-EWE KNOB-FILT-PAPER WHITE PAPER T=0.1mm 310 319-00000-010 SILICA PACK 1GM INSTALL CD-ROM (8CM) 311 322-33000-000 FOR USB FLASH MEMORY DRIVER 312 402-3300A-1BK BASE-PANEL ABS BLACK 313 402-3300B-1BK NOSE-PIECE ABS BLACK 314 402-3300C-1BK NOSE-PIECE-BACK ABS BLACK 315 402-7803S-4BK NOSE PIECE CASE...
  • Page 14 (PTY/KNOB:1 TRACK/UP/KNOB) 348 457-3300B-3CR TRACK-UP-DOWN-KNOB-BASE PC CLEAR ABS NATURAL(TRACK/DOWN:1 349 457-3300C-1NL TRACK-DOWN-KNOB ST/KNOB:1 ABS BLACK (SILVER-HOT 350 495-0000R-000 ROADSTAR BADGE STAMPING) 351 463-0000C-4BK FILTER & FUSE BOX P.P BLACK 352 472-6522B-3BK CONNECTOR GUIDE PC BLACK 353 492-3300A-1NL PLAY-STOP-KNOB ABS NATURAL...
