  • Page 1 CD-811MP/FM...
  • Page 2 ITEM CODE DESCRIPTION SYMBOL 001-7806D-480 P.C.B MAIN BOARD 001-3896S-A60 P.C.B LAMP BOARD 001-3896S-B10 P.C.B SWITCH SW-A BOARD 001-3896S-B11 P.C.B SWITCH SW-B BOARD 002-1923F-G07 I.C BU1923F 1 IC403 002-07384-J06 I.C TDA7384 1 IC401 002-02313-B00 I.C TDA7313D/PT2313L 1 IC106 002-07343-A00 I.C TA7343AP 1 U2 002-01140-A09 I.C LA1140 1 IC201...
  • Page 3 ITEM CODE DESCRIPTION SYMBOL 004-05403-000 DIODE IN5403 1 D5 D10.11.4.16.41.3.201.1.2. 2COR.CDLAST.DSCDC.DSAUX. AREA1.DSTAPE.FMONLY.AREA2. 004-04148-000 DIODE IN4148 MOTORIZED.AREA3.ENTAAL 005-00100-A00 ZENER DIODE 1/2W 10V 2 ZD8.5 005-00033-A00 ZENER DIODE 1/2W 3.3V 1 ZD3 005-00039-A00 ZENER DIODE 1/2W 3.9V 1 ZD7 005-00051-A00 ZENER DIODE 1/2W 5.1V 3 ZD9.2.1 005-00056-A00 ZENER DIODE 1/2W 5.6V 1 ZD4...
  • Page 4 ITEM CODE DESCRIPTION SYMBOL 011-B152A-200 RESISTOR CHIP 0603 ±5% 1.5K OHM 3 R85.139.79 011-B182A-200 RESISTOR CHIP 0603 ±5% 1.8K OHM 1 R163 011-B181A-200 RESISTOR CHIP 0603 ±5% 180 OHM 1 R53 011-B220A-200 RESISTOR CHIP 0603 ±5% 22 OHM 2 R72.68 011-B221A-200 RESISTOR CHIP 0603 ±5% 220 OHM 1 R56 011-B222A-200 RESISTOR CHIP 0603 ±5% 2.2K OHM...
  • Page 5 ITEM CODE DESCRIPTION SYMBOL 013-F107N-000 Chip ELEC CAP 100uF 16V 6.3x5.4mm 6 C108.84.55.148.149.6 013-F474P-000 Chip ELEC CAP 0.47uF 50V 4x5.4mm 4 C98.97.96.95 013-F335P-000 Chip ELEC CAP 3.3uF 50V 4x5.4mm 1 C137 C28.29.142.47.48.33.34. 82 013-F475Q-000 Chip ELEC CAP 4.7uF 25V 4x5.4mm 32.105.19.116.64 013-F476N-001 Chip ELEC CAP 47uF 16V 6.3x5.4mm 10 C94.70.147.125.81.35.85.86.87.14...
  • Page 6 ITEM CODE DESCRIPTION SYMBOL 107 029-B0000-020 ANTENNA JACK D.SCRWE 108 033-S1000-GY0 28# 1P SHIELD WIRE 100mm 109 034-A1612-008 I.S.O 16P W/WIRE 12P LINEIN 110 035-B0400-BK1 JUMPER WIRE #20 40mm BLACK 111 035-B1200-BK1 JUMPER WIRE #20 120mm BLACK 112 035-F0600-BK1 JUMPER WIRE #28 60mm BLACK 113 036-A0200-090 9PIN WAFER P=2.0mm 114 036-B0260-160 16PIN WAFER P=2.6mm 115 036-D0125-250 25PIN CONNECTOR PITCH P=1.25mm...
  • Page 7 ITEM CODE DESCRIPTION SYMBOL 135 011-B222A-200 0603 RES +-5% 2.2K OHM 2 R177.175 136 011-B331A-200 0603 RES +-5% 330 OHM 2 R173.170 137 011-B332A-200 0603 RES +-5% 3.3K OHM 2 R183.178 138 011-B471A-200 0603 RES +-5% 470 OHM 2 R172.174 139 011-B472A-200 0603 RES +-5% 4.7K OHM 4 R187.186.184.1...
  • Page 8 ITEM CODE DESCRIPTION SYMBOL 163 004-04148-000 DIODE IN4148 5 D1.2.3.4.5 164 004-SR23G-000 PHOTO DIODE SR-23G 2 SQ2.1 165 006-16934-000 RESONATOR 16.9344MHz 3PIN 1 X2 166 011-B102A-200 RES CHIP ±5% 0603 1K OHM 8 R42.57.22.37.34.27.21.12 167 011-B103A-200 RES CHIP ±5% 0603 10K OHM 7 R1.2.44.39.53.54.45 168 011-B104A-200 RES CHIP ±5% 0603...
  • Page 9 ITEM CODE DESCRIPTION SYMBOL 192 013-D476L-50B Tantal Chip CAP 47uF 10V +-20% "B-Size" 1 C67 193 014-B030C-500 CER CAP CHIP ±10% 3PF 50V 0603 1 C35 194 014-B102C-500 CER CAP CHIP ±10% 0.001uF 50V 0603 2 C62.27 195 014-B103C-500 CER CAP CHIP ±10% 0.01uF 50V 0603 8 C29.15.23.2.36.44.43.17 C68.75.31.24-26.28.14.12.9.6.
  • Page 10 ITEM CODE DESCRIPTION SYMBOL 220 212-28020-03P PVC SHEET 28x20x0.3mm 1 PVC T=0.3mm 221 212-52090-14S SPRING WASHER 5.2x9x1.4mm 222 212-52100-05P PLATE WASHER 5.2x10x0.5mm 223 212-65097-05F FLAT-WASHER-C 1 FIBER T-0.5 224 214-DECK0-A00 CD FIBER 105x95x0.5mm 1 FOR CD KMC DECK 225 216-7803H-C00 HEAT-SINK 1 AL DIE CASTING BLACK 226 216-3896B-C00 HEAT SINK-S 1 AL WHITE...
  • Page 11 ITEM CODE DESCRIPTION SYMBOL 249 220-3896G-000 GUIDE-SHAFT 2 BSBM 250 220-3896L-000 LEADING-BLOCK-SHAFT-L 1 BSBM 251 220-3896R-000 LEADING-BLOCK-SHAFT-R 2 BSBM 252 222-7803B-E10 BOTTOM COVER 1 EGI T=1.0mm 253 222-3896S-E06 SLEEVE-CASE 1 EGI T=0.6mm 254 222-3896T-E06 TOP COVER 1 EGI T=0.6mm 255 223-3896D-A10 RELEASE CHASSIS (D.H) 1 45# 钢板...
  • Page 12 ITEM CODE DESCRIPTION SYMBOL 278 234-PA050-160 SCREW TS 5x16 PA 1 ACCESSORY:1 motor+front.bracket:2 tact pcb+front-bracket:2 hook-l+rel- chassis:2 hook-r+rel-chassis:2 leading-block-f+rel-chas:1 top- panel+bot-panel:1leading-block- 279 234-PM020-03B SCREW PM 2x3 BLACK a+front bk:1 280 234-BMT20-040 SCREW TTP 2x4 BM TAP TYAE 4 SUB:PCB:4 281 234-PM026-030 SCREW 2.6x3 PM WHITE 1 bottom-cover+front-bracket:1 282 234-PM030-160 SCREW PM 3x16 WHITE 2 heatsink+main bracket(ic)
  • Page 13 ITEM CODE DESCRIPTION SYMBOL 304 313-20010-A00 CD GUIDE SHEET 1 P.V.C (BLACK) T1.0 305 313-38960-R00 VFD-SIDE-COVER-W 2 PVC T=0.3 BLACK 306 313-78030-A00 MAIN-INSULATING-PLATE 1 PC T=0.1mm 307 314-7802T-000 TOP LABEL 308 314-7802W-000 WARRANTY LABEL 309 315-78030-A00 GLOSS-SILVER-REFLECTOR-PAPER 2 REFLECTOR PAPER 310 315-78030-B00 REFLECTOR-PAPER 1 REFLECTOR PAPER 311 315-78030-C00 FILTER-PAPER...
  • Page 14 ITEM CODE DESCRIPTION SYMBOL 332 431-78062-1NL MEMERY-KNOB-2 1 ABS NATURAL 333 431-78063-1NL MEMERY-KNOB-3 1 ABS NATURAL 334 431-78064-1NL MEMERY-KNOB-4 1 ABS NATURAL 335 431-78065-1NL MEMERY-KNOB-5 1 ABS NATURAL 336 431-78066-1NL MEMERY-KNOB-6 1 ABS NATURAL 337 435-7806A-2CR LOUD-KNOB 1 ACRYL CLEAR 338 440-3896L-3BK HOOK-L-R 2 PC BLACK 339 441-3896A-1NL TRIM COVER...
