Made By:
Spitwater Australia Pty Ltd
953 Metry St
North Albury , NSW , Australia
WARNING:
FAILURE
INSTRUCTIONS LISTED IN THIS MANUAL RELEASES THE MANUFACTURER
FROM ANY RESPONSIBILITY FOR ACCIDENTS OR DAMAGES TO BOTH
HUMANS AND OBJECTS AND MAY RENDER ANY WARRANTY VOID
OPERATING & MAINTENANCE
MANUAL
INDUSTRIAL DIRECT FIRED
DIESEL/KEROSENE HEATERS
NOT FOR DOMESTIC USE – SPACE HEATING ONLY
TO
FOLLOW
IC 25
OPERATING,
SAFETY
AND
MAINTENANCE
Advertisement
Table of Contents
Related Manuals for Spitwater IC 25 SPITFIRE
Summary of Contents for Spitwater IC 25 SPITFIRE
- Page 1 OPERATING & MAINTENANCE MANUAL INDUSTRIAL DIRECT FIRED DIESEL/KEROSENE HEATERS IC 25 NOT FOR DOMESTIC USE – SPACE HEATING ONLY Made By: Spitwater Australia Pty Ltd 953 Metry St North Albury , NSW , Australia WARNING: FAILURE FOLLOW OPERATING, SAFETY MAINTENANCE...
-
Page 3: Technical Data
TECHNICAL DATA Model IC25 Fuel Supply Diesel Kerosene Heat Output 21.00 kcal/h 18500 Fuel Consumption kg/h 2.10 Air Flow m³/h 1000 Electricity Supply 230/1/50 V//Hz Pressure 0.42 Motor 300/2.5 Limit Thermostat Tank Size Weight Dimensions LxWxH 1125x513x680 The manufacturer reserves the right to modify design features and technical data without notice. INTRODUCTION The SPITFIRE range of portable heaters has been designed to give safe, efficient and reliable service when the correct operating sequences are followed and proper attention is given to cleaning and maintenance procedures. -
Page 4: Operating Instructions
INSTALLATION AND OPERATING INSTRUCTIONS INSTALLATION (All Models) Identify your unit from the model description on the serial number label affixed to the heater and the exploded views contained in this manual. Where necessary. Fit wheels on axle using the clips and cover supplied. Fit axle assembly and support to the tank using the bolts supplied. Fill the Fuel Tank using clean filtered fuel. -
Page 5: Maintenance
MAINTENANCE General Every refill clean fuel filter Every 150 hours wash inlet filter with mild detergent and dry. Filter must be thoroughly dry before replacing and must not be oiled. Outlet filter: Clean and if necessary replace the outlet filter after the first 30 hours of running in. Every 150 hours clean by blowing air from the inside surface out. - Page 6 EXPLODED VIEWS...
- Page 9 PARTS LISTING DESCRIPTION IC25 DESCRIPTION IC25 DESCRIPTION IC25 FILTER HOLDER 100141 HIGH/V.CABLE-mm.4 100184 ELECTRICAL BOX 100122 OUTLET FILTER 100130 FUEL HOSE 260008 COVER ELEC.BOX 100124 CORK GASKET 100156 FUEL PIPE 260009 FAN THERMOSTAT 33041/D COMPR. PLATE 100125 GASKET 100210 RELAYS 33253 COMPR.DOG 100123...
