OPERATING AND MAINTENANCE
ELECTRIC HEATING
UNIT
MODEL NO:
SHW11 (HEATING CYL)
SHW11/12V (HEATING CYL 12V)
SHW11S (HEATING CYL)
MADE IN AUSTRALIA
BY
SPITWATER AUSTRALIA PTY LTD
953 METRY STREET
NORTH ALBURY NSW 2640
AUSTRALIA
WARNING: Read and understand this instruction manual before operating this
unit and retain for future reference.
Failure to follow operating, safety and maintenance instructions outlined in this
manual releases the manufacturer from any responsibility for any accidents or
damage incurred and may render any warranty void.
ORIGINAL INSTRUCTIONS
MANUAL
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Spitwater SHW11
Summary of Contents for Spitwater SHW11
- Page 1 ORIGINAL INSTRUCTIONS OPERATING AND MAINTENANCE MANUAL ELECTRIC HEATING UNIT MODEL NO: SHW11 (HEATING CYL) SHW11/12V (HEATING CYL 12V) SHW11S (HEATING CYL) MADE IN AUSTRALIA SPITWATER AUSTRALIA PTY LTD 953 METRY STREET NORTH ALBURY NSW 2640 AUSTRALIA WARNING: Read and understand this instruction manual before operating this unit and retain for future reference.
- Page 2 SPARE PARTS, ACCESSORIES AND AFTER SALES SERVICE Spitwater has an extensive range of spare parts and accessories to suit all your cleaning needs. For spare parts, accessories and service please contact 1800 SPITWATER (1800 774 892) and to view Spitwater's extensive range of high pressure cleaners online visit www.spitwater.com.au...
-
Page 3: Technical Data
TECHNICAL DATA HEATING HEATING HEATING MODEL CYL 12V PRODUCT SHW11 SHW11/12V SHW11S UNIT PERFORMANCE FLOW RATE 21 MAX 21 MAX 21 MAX PRESSURE 200 MAX 20 MAX 20 MAX PRESSURE NOZZLE OUTLET WATER TEMP MAX °C WATER INLET PRESSURE MAX TEMP MAX °C... -
Page 4: Description Of Symbols
DESCRIPTION OF SYMBOLS The following symbols are used throughout this instruction booklet in order to mark important paragraphs or sections that require particular attention. Their meaning is listed next to them for your attention. The following symbols are used on the unit in order to warn user of potential injury if not cautious. Their meaning is listed next to them for your attention. - Page 5 Always pay attention to the safety instructions provided on each label. Do not alter or remove safety labels WATER INLET CONNECTOR HIGH PRESSURE HOSE HIGH PRESSURE WATER OUTLET HANDLE CONNECTOR BURNER SWITCH SERIAL LABEL (REMOVE PANEL TO VIEW) PLUG (SHW11, TEMPERATURE SHW11/S, ONLY) ADJUSTMENT DIESEL INLET...
-
Page 6: General Safety Precautions
GENERAL SAFETY PRECAUTIONS 1. OBSERVE SAFETY INSTRUCTIONS • Make sure you have read and understood the whole instruction manual before installing, operating or carrying out any maintenance on this unit. • Warnings and serial label on the unit provide important directions and information on the safe use of the unit. - Page 7 4. EXTENSION CORD • If using an extension cord make sure it is according to cross section / maximum length requirements as shown to the right. • Inadequate extension cords can be dangerous. If an extension cord is used, it shall be suitable for outdoor use, and the connection has to be kept dry and off ground.
-
Page 8: Checks And Service
• Refuel in a well ventilated and open area. When fuel and/or lubricants are spilled clean immediately. • DO NOT mix fuel. Incorrect fuels shall not be used as they may prove hazardous. • Use only clean and approved fuel, store in appropriate containers and dispensers 9. -
Page 9: Operational Safety Precautions
OPERATIONAL SAFETY PRECAUTIONS All health and safety regulations applicable to general safe work practices, as well as safe operation of equipment, as well as any specific standard for safe operation of high pressure cleaners according to local regulations must be followed. When operating this unit, 1. -
Page 10: Equipment Safety
Never exceed the maximum working temperature and pressure as indicated on the unit data plate and in this manual. • Only use this unit with cleaning chemicals recommended by Spitwater. The use of other cleaning agents or chemicals may adversely affect the safety of the unit. •... -
Page 11: Storage / Transport
4. When not in use the unit must be stored in a dry building where there is no possibility for the temperature to be at or below 0°C. If necessary to store the unit at or below 0°C contact your authorized Spitwater service agent for advice. -
Page 12: Battery Connection
Visually check 6. BATTERY CONNECTION (SHW11/12V ONLY) for any damage, leaks or other issues. If any problem is found, contact your Spitwater agent • Only a certified Electrician should carry out this immediately. task. - Page 13 Spitwater agent for advice and /or supply. • Make sure the water supply temperature and pressure meet the values specified in the technical data, then turn the water supply on. Visually check for leaks and contact your Spitwater service agent if found. •...
- Page 14 12. Remove the DIESEL tank cap and fill the diesel tank with clean filtered diesel. ONLY USE CLEAN DIESEL IN THIS UNIT, as using any other fuel will create a risk of explosion and damage to the unit.
-
Page 15: Hot Water Mode
CHECK LIST” in the SERVICE / CARE section as a guide. If the unit is damaged or faulty in anyways, DO NOT use it and immediately contact your authorized Spitwater service agent for advice. TO START 1. Always wear appropriate Personal Protective Equipment. -
Page 16: Usage Tips
USAGE TIPS: • Use the unit as necessary to carry out cleaning while trying to minimize where possible opening and closing the spray gun trigger as this will lead to premature wear of the parts. • Do not hold the nozzle too close to the surface to be cleaned as this may damage the nozzle. -
Page 17: Safety Precautions
2. Carry out all regular maintenance and Spitwater recommends that all maintenance is inspections as listed in this manual using carried out by an authorized Spitwater service original Spitwater parts where required. agent using original Spitwater spare parts. 3. Always make sure before carrying out any... -
Page 18: Daily Inspection Checklist
Check for water leaks at high pressure hose fittings. Proper function of switches and temperature controller. STOP operting the unit, Unit is fit, proceed task Contact Spitwater service agent immediately Contact Spitwater service Do It Yourself, agent / Qualified person for... -
Page 19: Troubleshooting Guide
If the fault cannot be identified or corrected stop using the unit immediately and contact your authorized Spitwater service agent to rectify. For service of your Spitwater high pressure cleaner within Australia, call 1800SPITWATER or visit www.spitwater.com.au for further contact details.
