Optex RX-40QZ Installation Instructions page 2

4. WIRING
TAMPER
SPARE
( N.C. )
SPARE
(BE) mode only
TAMPER SP
5. LED ON/OFF
Use the pin switch for LED ON/OFF.
8. TROUBLE SHOOTING AND MAINTENANCE
PROBLEM
LED does not light.
LED lights even though no
person is within area.
LED lights but signal is not
sent.
9. SPECIFICATIONS
MODEL
Detection method
Coverage WIDE:40ft - 40ft (12m - 12m) 85° wide
Detection zones
Mounting Height
Sensitivity
Detection speed
LED Alarm Indicater
Alarm period
Alarm output
Tamper switch
Pulse Count
Warm up period
Power input
Current draw
Weight
Operating temperature
Environmental humidity
RF interference
*Specifications and design are subject to change without prior notice.
This unit is designed to detect movement of an intruder and activate an alarm control panel.
Being only a part of a complete system, we can not accept responsibility for any damages
or other consequences resulting from an intrusion.
This Product conforms to the EMC Directive. 89/336 EEC.
ALARM OUTPUT
( N.C. )
POWER INPUT
(9.5 - 16V DC)
ALARM 12V DC
- +
N . C .
6. PULSE COUNT
Use the pin switch for Pulse
Count Selection ( 2 or 4 ).
PROBABLE CAUSE
Incorrect power supply voltage.
(disconnection, low voltage)
Incorrect detection area.
Incorrect polarity to detector.
LED switch is OFF.
Moving object within area. (curtain,wall hanging, etc.)
Rapid temperature changes within area.
(heater,air-conditioner, etc.)
Relay contact is stuck or damaged due to overloading.
Faulty wiring.
RX-40QZ
Passive Infrared
WIDE:78 zones
5 - 8ft (1.5 - 2.4m)
3.6° F ( 2°C ) at 2ft/sec (0.6m/sec)
1 - 5ft/sec (0.3 - 1.5m/sec)
Switchable ON/OFF
Approx. 2.5 sec
N.C. , 28VDC 0.2A max.
N.C. , Open when cover is removed.
Approx. 20 sec 2 or 4
Approx. 30 sec
9.5 - 16V DC
8mA (normal), 11mA (max.) at 12VDC
2.5 oz (70g)
-4°F - +122°F (-20°C - +50°C)
95% max.
No Alarm 20V/m
NOTE
Power wires should not exceed the following lengths.
12V DC
WIRE GAUGE
2
AWG 22 ( 0.33mm )
1700' (520m)
2
AWG 20 ( 0.52mm ) 2690' (820m)
AWG 18 ( 0.83mm ) 2
4290' (1310m)
When using two or more units on one wire, the maximum
length is obtained by dividing the maximum wire length listed above
by the number of units used.
7. EASY WIRING KNOCKOUTS
Press firmly with a screwdriver to open.
Enlarge the hole according to size of wire.
Correct the voltage supply to 9.5 - 16V DC.
See Section 3.
Switch positive and negative at terminal.
Turn on the Switch. (See Section 5 )
Remove object from detection area, or change location
of detector.
Remove the source from area, or change location of
detector.
Check load of output.
The unit needs repair or replacement.
Wire correctly.
FL-60N (Optional Lens for Long Range Curtain Pattern)
Coverage LONG : 60ft - 6ft (18m - 1.8m )Long Range
Detection zones LONG : 20 zones
Dimensions
2.44(62)
14V DC
3700' (1130m)
5830' (1780m)
9350' (2850m)
REMEDY
1.73(44)
inch(mm)
