SMART Board® 800i5 series interactive whiteboard system quick installation guide
Composite Video
16
S-Video
HDMI
14
13
15
1
VGA 1
3
SB880i5
10
SB885i5
VGA 1
11
22
4
21
7
9
8
5
SB880i5-MP
SB885i5-MP
19
18
smarttech.com
/kb/154547
smarttech.com/
kb/154546
12
20
2
For cautions, warnings and other important product information,
see Important Information for SMART Board 800i5 series interactive
whiteboard system users (smarttech.com/kb/131396).
1
VGA cable to dedicated computer - (required)
6
2
Extended Control Panel (ECP) cable
3
Mini USB cable from ECP to dedicated computer
4
5V - power cable
5
Camera cable
17
6
3.5 mm audio cable to pen tray (optional)
7
3.5 mm audio cable to speaker system (optional)
smarttech.com/Support800i5
smarttech.com/kb/154546
smarttech.com/kb/154548
SMART Board™ 600i5
and D600i5 Interactive
Whiteboard System
Configuration and User's Guide
SMART GoWire™ Auto-Launch Cable
(GW-MP, GW-MPP)
smarttech.com/kb/147790
SBX800i4
Important: The interactive whiteboard depicted in this video is a SMART Board 600 series
interactive whiteboard. Please refer to your installation guide for instructions specific to
your SMART Board 800 series interactive whiteboard.
downloads.smarttech.com/media/
trainingcenter/videos/uf75/uf75_installation.htm
downloads.smarttech.com/media/
trainingcenter/videos/uf75/uf75_image_adjustment.htm
1/4" (6 mm)
1/2" (13 mm)
1/4" (6 mm)
15
Audio cable connecting left and right speakers
HDMI cable (optional)
8
(optional)
16
Composite video (optional)
9
VGA connection kit - (optional)
17
Cat 5 network cable (optional)
10
VGA cable to optional computer - (optional)
18
SBX800 CAT5-XT extender (optional)
11
USB B mini adapter cable (optional)
19
GoWire™ auto-launch cable (optional)
RS232 to Data Terminal Equipment (DTE)
12
(optional)
20
Cat 5 network cable (optional)
13
S-Video cable (optional)
21
VGA cable (optional)
14
RCA audio cable (optional)
22
USB cable (optional)
youtube.com/
watch?v=Tla3qRV5m1E
youtube.com/
watch?v=yCPWy9kCY4g
