1. Overview

1.2 Rear View

DMX OUT DMX OUT
1. DMX Out
2. DMX In
3. Link Out
4. Link In
5. Master/ Slave 1,2
Selector
6. DC Input
7. Power Switch
DMX IN DMX IN LINK OUT LINK OUT
This connector sends DMX value to the DMX pack.
This connector accepts DMX input signals.
This connector is used to plug into Link In on the next unit.
This connector is used to plug into Link Out on the
another unit.
Move to right for Master, center for Slave 1 and left
for Slave 2.
DC 9V, 500mA min.
This switch turns on/off the power.
Control Control
LINK IN LINK IN
Slave 2 Slave 1 Slave 2 Slave 1 Master Master
DMX
OUT
2 1 1
3
LINK
1 - Ground OUT
2 - Data-
3 - Data+
4 - NC
1 5
5 - NC
2 4
3
POWER POWER
9VDC,500mA 9VDC,500mA
DC INPUT DC INPUT
IN
2
3
IN
5 1
4 2
3
6
