4. Technical Data

Factory Default Settings
The unit has the following presetting at time of delivery:
Temperature range
Emissivity
Process interface (PIF)
Interprocess Communication (IPC)
Measurement function
General Specifications
Environmental rating
Ambient temperature
Storage temperature
Relative humidity
Material (housing)
Dimensions
Weight (incl. lens)
Cable length (USB 2.0)
Vibration
Shock
____________________________________________________________________________________________________________
-20...100 °C
1,000
inactive
inactive
Rectangle measure area
IP67 (NEMA-4)
0...50 °C (PI450: 0...70 °C)
-40...70 °C (PI450: -40...85 °C)
10...95 %, non condensing
aluminum, anodized
PI160/ PI200/ PI230: 45 x 45 x 62 - 65 mm (depending on lens)
PI400/ 450/ 640: 46 x 56 x 86 - 90 mm (depending on lens)
PI160: 195 g, PI200/ 230: 215 g, PI400/ PI450/ PI640: 320 g
1 m (Standard), 5 m, 10 m, 20 m
IEC 60068-2-6 (sinus shaped)
IEC 60068-2-64 (broadband noise)
IEC 60068-2-27 (25g and 50g)
optris PI – E2014-05-B
7
