- Page 1 PIX Connect Software for Thermal Imager Operator’s Manual...
- Page 2 Editing video sequences ......... 56 2.2.7. Import/Export layouts ........28 3.4. Saving files .............. 57 2.2.8. Further information ......... 30 2.3. Arranging of thermal image ........31 3.4.1. Setting the recording frame rate ..... 57 optris PIX Connect – E2021-05-A...
- Page 3 Simultaneous frame synchronization via PIF ..143 4.11. Zoom function of snapshots ........101 8. Further information ............ 145 5. Xi camera ..............102 8.1. Options ..............145 5.1. Focus setting ............102 8.1.1. Activating software messages ...... 145 optris PIX Connect – E2021-05-A...
- Page 4 8.1.2. Layouts ............146 8.1.3. Temperature unit .......... 146 8.1.4. Log events ........... 147 8.2. System requirements ..........148 8.3. About software ............148 8.4. Extended Configuration ........149 8.5. Overview shortcuts ..........150 optris PIX Connect – E2021-05-A...
- Page 5 PI and/or Xi infrared camera and corresponding PIX Connect software! The optris PI or Xi calculates the surface temperature based on the emitted infrared energy of objects [► Basics of Infrared Thermometry]. The two-dimensional detector (FPA - Focal Plane Array) or (CMOS - Complementary metal-oxide-semiconductor) allows a measurement depending on the device max.
- Page 6 Fax: +49-30-500 197-10 supplier only and we have no responsibility whatsoever for such products. The manufacturer is not liable for any use of the software PIX Connect E-mail: info@optris.global including data recording. The manufacturer does not carry liability for Internet: www.optris.global...
- Page 7 1.1. Software installation Please install at first the software PIX Connect which is included on the USB stick. The stick contains the software application, the specific calibration data of the imager as well as some sample files. These data will be installed automatically.
- Page 8 (Xi). Note • For installation please be logged in as admin in Windows. When starting the PIX Connect software you should also have admin rights. • Using Windows 10: Go to Windows Settings, click Privacy, and under App Permissions, click on Camera.
- Page 9 In the Tools and Language menu you can choose from a variety of available languages. Note In case your language is not provided you will find a translation tool on the USB stick delivered with the camera. optris PIX Connect – E2021-05-A...
- Page 10 1.4. Software window (example) optris PIX Connect – E2021-05-A...
- Page 11 Distance function: Adjustment of the motor focus to focus the IR picture Menu and Toolbar (Icons) Icon enabling switching between color palettes Status bar: Model and serial number, optic, temperature range, cursor position, device framerate/ display framerate, emissivity, ambient temperature, flag status optris PIX Connect – E2021-05-A...
- Page 12 These additional views are particularly useful when using a touch computer or a tablet. The screen and menu are customized and displayed according to their functions. User Mode Tablet User Mode Touch optris PIX Connect – E2021-05-A...
- Page 13 Configuration window for User Mode Touch and Tablet Note The User Mode Tablet provides only limited functionality. optris PIX Connect – E2021-05-A...
- Page 14 Choice of camera and self-referencing Additional settings of camera and software parameters as line scanner mode; layouts; Tools language; extended settings as merged device configuration and updating the firmware Help Information about software; documentation; SDK; locking application optris PIX Connect – E2021-05-A...
- Page 15 Save screenshot to Distance Acknowledge Alarm file Screenshot to Toggle user mode Close all tools clipboard Digital display (main Capture screen Full screen measure area) Replay captured Digital display IR/Visible Fusion screen (mouse curser) optris PIX Connect – E2021-05-A...
- Page 16 Reference bar Next palette Exit Toggle Minimum, Mean Value, Config merged device About Maximum optris PIX Connect – E2021-05-A...
- Page 17 You can also adjust the color palette via the Icon on the toolbar or the menu View and Shift palette. Gray (Black = Cold) Iron Gray (White = Cold) Iron Hi Alarm Red Rainbow Alarm Green Rainbow Hi Alarm Blue Rainbow Medical Blue Hi optris PIX Connect – E2021-05-A...
- Page 18 Examples of various color palettes: Palette Iron Palette Rainbow Palette Blue Hi Palette Rainbow Hi Palette Rainbow Medical Palette Gray (Black = Cold) optris PIX Connect – E2021-05-A...
- Page 19 These are the following options: Manual The lower and the upper border (Min/Max) can be determined individually. The software continuously defines the upper and the lower border based on the hottest and </> coldest pixel in the image. optris PIX Connect – E2021-05-A...
- Page 20 (3 sigma) set the limits of reference bar. With OPT a contrast optimization is achieved. This function allows an optimum contrast between very low and very high temperatures. Note Palette optimization (OPT) is not available for PI 1M/ 08M/ 05M. optris PIX Connect – E2021-05-A...
