OPERATING INSTRUCTIONS FOR STREAMLIGHT SURVIVOR
Thank you for selecting the Survivor, a truly remarkable portable light. As with any profession-
al tool, reasonable care and maintenance of this product will provide years of dependable
®
service.
Please read this manual before using your Survivor. It includes important safety and operating
instructions and should be saved. Flashlight must be charged before first use.
The Survivor
®
is suitable for use in non-hazardous locations and the following hazardous
locations*:
• For Div. 1 Labeled Product: Class I Div. 1 Groups C & D Temp Code T3C (U.S. Only)
• For Div. 2 Labeled Product: Class I Div. 2 Groups A, B, C, D Temp Code T2
*See product label for the specific ratings for the unit you have.
SAFETY
A. SAVE THESE INSTRUCTIONS. This manual contains important safety and operating
instructions for your Survivor and charger.
B. Before using the battery charger, read all instructions and cautionary markings on the
charger.
C. Don't abuse the cord. Never carry charger by cord or yank it to disconnect the cord
from a receptacle.
D. Plug AC charger directly into an electrical outlet. Do not use an extension cord.
E. Do not operate a damaged charger. Have damaged cords or plugs replaced
immediately.
F.
Do not put any metal objects on to the charging terminals located in the charger holder.
Although there is no electrical shock hazard, this action could cause a burn injury.
G. Remove Survivor from charger holder before attempting any routine cleaning or mainte-
nance. Do not try to repair the unit or charger yourself. Take it to a qualified service
facility or return it to the factory.
H. Use only Streamlight battery pack #90337 (Div. 1) or 90338 (Div. 2). The product's
hazardous locations approval is valid only with the appropriate Streamlight battery.
See the product label for the specific battery required for your light. Do not open
battery, dispose of in fire or short circuit – may ignite, explode, leak or get hot
causing personal injury.
®
I.
A small leakage of liquid from the battery cells may occur under extreme usage or
temperature conditions. This does not necessarily indicate a failure. However, if the
outer case seal is broken and the leakage gets on your skin:
Class I Div. 2 Groups A, B, C, D Temp Code T3C
Class II Div. 2 Groups C & D Class III Temp Code T6
Class II Div. 2 Groups C & D Class III Temp Code T4
®

Advertisement

   Summary of Contents for StreamLight SURVIVOR

  • Page 1

    OPERATING INSTRUCTIONS FOR STREAMLIGHT SURVIVOR ® Thank you for selecting the Survivor, a truly remarkable portable light. As with any profession- al tool, reasonable care and maintenance of this product will provide years of dependable URVIVOR ® service. Please read this manual before using your Survivor. It includes important safety and operating Operating instructions and should be saved.

  • Page 2

    CHARGER has four (4) interchangeable AC and DC power cords which allow connection Survivor in a vehicle. Connect the wires to the vehicle battery or to the unswitched side to a variety of AC and DC power sources. The AC cords are terminated with a plug-in of the ignition switch through a 5 amp fuse;...

  • Page 3

    When new, the battery should yield 90 to 100 minutes of Survivor to warm up for about a half hour before placing it in the charger. If the light and continuous run time, more with intermittent use. Should the performance decrease signifi- charger are colder than 40°F, the charge indicators will not come on until the system warms.

  • Page 4

    Hinge, Clip * Items are not interchangeable. Failure to use appropriate item will compromise product safety and invalidate approval rating. See product label for correct lamp and battery. ** 1 pin required for UL listed Survivor Div. 2 lights only. NFPA...

  • Page 5

    IMPORTANT – Be sure to use genuine Streamlight replacement parts. WARRANTY REGISTRATION: To register the warranty on your Streamlight, complete the card enclosed and mail to Streamlight, Inc., within ten (10) days of purchase. When returning product for warranty repairs, please provide receipt or other proof of purchase.
