Summary of Contents for Microh Ultra Beam 700
- Page 2 Table of content ················································ ························································· ················································ ····································································· ····································································· ················································ ····································································· ················································ ······································ ················································ ················································ ····································································· ····································································· ················································ ························································· ················································ ························································· ················································ ························································· ················································ ················································ ················································ ·························································...
-
Page 3: Open The Box And Checking
1. Open the box and checking Congratulations on choosing our products! Please carefully read this instruction manual in its entirety and keep it well for using reference. This manual contained about the installation and the relative using inform ation of this products. Please according to this manual's relative speaking when using this equipment. - Page 4 CAUTION ! EYEDAMAGES ! Avoid looking directly into the light source (meant especially for epileptics) ! Ø Installation Make sure all parts for fixing the projector are in a good state of repair. Make sure the point of anchorage is stable before positioning the projector. The safety chain must be properly hooked onto the fitting and secured to the framework, so that, if the primary support system fails, the fitting falls as little as possible.
-
Page 5: Operating Determinations
Ø Maintenance Before starting any maintenance work or cleaning the projector, cut off power from the mains supply. After switching off, do not remove any parts of the fitting for at least 10 minutes. After this time the likelihood of the lamp exploding is virtually nill. If it is necess ary to replace the lamp, wait for another 15 minutes to avoid getting burnt. -
Page 6: Rigging The Fixture
The lamp used in this projector is a discharge lamp.After switching off don't attempt to restart the projector until la mp has cooled,this will require approx 15 minutes.Switc hing the lamp on and off at short intervals will reduce the life of both the lamp and the projector.But occasional bre aks will prolong the lamp and projector 4.Rigging the fixture... - Page 7 W hen rigging, derigging or servicing the fixture staying in the area below the installation place, on bridges, under high working places and other endangered areas is forbidden. The operator has to make sure that safety-relating and machine-technical installations are approved by an expert before taking into operation for the first time and after changes before taking into operation another time.
- Page 8 onnection If you wish to change the power supply settings, see the chapter Appendix. Connect the fixture to the mains with the enclosed power cable and plug. The earth has to be connected! Cable EU Cable US International Brown Black Live Light blue White...
-
Page 9: Description Of The Device
4 3 3 DMX Terminator Diagram - For installations where the DMX cable has to run a long distance or is in an electrically noisy environment it is recommended to use a DMX terminator. This help in preventing corruption of the signal by electrical noise. - Page 10 6.Dimension...
-
Page 11: Navigation In The Menu
7 Display Control 7.1 Navigation in the Menu The Control Board o ers several features: you can simply set the starting address, switch on ando the lamp, run the preprogrammed program or make a reset. The main menu is accessed by pressing the Mode-button until the display starts ashing. -
Page 12: Standard Version
7 3 Menu Maps Standard version Set Dmx Address A001~AXXX Value Display PAN Moving…… Auto Program Master Alone Function Mode Music Control Master Alone Time Info Current Time ON/OFF Total Run Time ON/OFF Lamp Run Time ON/OFF Clear Fixture Time ON/OFF Information Temp. - Page 13 wireless version Set Dmx Address A001~AXXX Value Display PAN Moving…… Master Auto Program Alone Function Mode Music Control Master Alone Time Info Current Time ON/OFF Total Run Time ON/OFF Lamp Run Time ON/OFF Clear Fixture Time ON/OFF Information Temp. Info Base Temp ON/OFF Near Lamp Temp...
-
Page 14: Dmx Protocol
8 DMX protocol DMX channel´s functions and their values (Mode1=21DMX Mode2=19DMX): Mode1 Mode2 Name Function DMX Value PAN 8BIT 0-255 Pan 16BIT 0-255 TILT 8BIT 0-255 TILT 16BIT 0-255 max to min speed 0-225 blackout by movement 226-235 Speed pan/tilt movement blackout by all wheel changing 236-245... - Page 15 Speed Fast －>Slow Speed Of CMY 0-255 And Dimmer No Function 0-15 Macro 1 16-31 Macro 2 32-47 Macro 3 48-63 Macro 4 64-79 Macro 5 80-95 Macro 6 96-111 Macro 7 112-127 CMY and color wheel Macro 8 128-143 Macro 9 144-159 Macro 10...
-
Page 16: Maintenance And Cleaning
Shutter closed 0-31 No function (shutter open) 32-63 Strobe effect slow to fast 64-95 No function (shutter open) 96-127 Shutter,strobe Pulse-effect in sequences 128-159 No function (shutter open) 160-191 Random strobe effect slow to fast 192-223 No function (shutter open) 224-255 Intensity 0 to 100% Dimmer... - Page 17 There are no serviceable parts inside the device except for the lam p and the fuse. Please refer to the instructions under "Fitting/Exchanging the lamp ".Maintenance and service operations are only to be carried out by authorized dealers. Replacing the fuse If the lam p burns out, the fine-w ire fuse of the device might fuse, too.
