Summary of Contents for DigiPos PowerPoS
- Page 1 DigiPoS PowerPoS & Millennium Technical Manual Socket 370 Series Manual Version T1.3 October 2002...
- Page 2 Updates to this manual and additional information may be found on the Internet at http://www.pc-pos.com/ For any drivers associated with this DigiPoS, please contact your supplier/distributor or you can find the latest versions available for download on the Internet at http://www.pc-pos.com...
-
Page 3: Safety Instructions
Liquid has penetrated into the DigiPoS o The equipment has been exposed to moisture o The DigiPoS is not working well or you can not get it to work according to the User’s Manual o The DigiPoS has been dropped and damaged o The DigiPoS has obvious signs of breakage or physical damage •... - Page 4 DigiPoS PowerPoS & Millennium Technical Manual CAUTION There is a danger of explosion if the CMOS battery is incorrectly replaced. Replace only with the same or equivalent type of battery. Please Contact you’re nearest PC-PoS office for further information and or assistance.
-
Page 5: Table Of Contents
DigiPoS PowerPoS & Millennium Technical Manual CONTENTS Introduction ........................8 Key Features ........................8 Ventilation Requirements ....................10 Cavity Size........................10 Enclosed Spaces......................10 External PSU .........................10 Under Counter Mounting ....................11 DigiPoS Brackets......................11 Technical Specifications ....................12 CPU & FSB Clock Speeds.....................12 Memory .........................12 BIOS..........................12 VIA 82C686B ‘South Bridge’..................13 PCI to ISA Bridge.......................13... - Page 6 DigiPoS PowerPoS & Millennium Technical Manual Digital Flat Panel Output (DVI)...................18 Important Notes ......................19 The System ........................20 Front Panel Orientation ....................20 Rear Panel Orientation ....................21 Internal System Orientation ...................22 The Heat Pipe, Air Tunnel & CPU .................23 Jumper Settings and Connections.................26 Jumpers ........................26...
- Page 7 DigiPoS PowerPoS & Millennium Technical Manual BIOS Set-up Overview ....................43 Main BIOS Screen......................44 Details ........................44 Standard CMOS Features .....................45 General Details ......................45 IDE Options Sub Menus.....................47 Details ........................47 Advanced BIOS Features ....................49 Details ........................49 Advanced Chipset Features ..................52 Details ........................52 Integrated Peripherals ....................54...
-
Page 8: Introduction
Introduction Congratulations on the purchase of your DigiPoS Retail System! You are now the owner of a state-of-the-art DigiPoS Retail System. The DigiPoS Retail System is a solution that offers enhanced features, speed and performance combined with exceptional reliability. It is also a PC that is unrivalled by other conventional Pentium based PCs within the EPoS industry. - Page 9 DigiPoS PowerPoS & Millennium Technical Manual DISK ON CHIP With DigiPoS EPoS Diagnostics Utility Component Description KEYBOARD PORT PS/2 type MOUSE PORT PS/2 type Front panel features include: AC power on/off button 3 LED indicators: Power On/Off, HDD state & LAN state FRONT PANEL 1.44MB FDD...
-
Page 10: Ventilation Requirements
Enclosed Spaces If the DigiPoS is to be located in an enclosed space, i.e. in a closed box or cabinet, there must be sufficient airflow into and out of the enclosed space. Using the above cavity space as an example, forced airflow would have to be fitted to prevent the DigiPoS from overheating. -
Page 11: Under Counter Mounting
DigiPoS Brackets To fit the bracket, simply remove the case screw towards the rear of the DigiPoS and offer up the bracket to the DigiPoS. Then, refit the screw and the DigiPoS can now be secured in position. -
Page 12: Technical Specifications
The Central Processing Unit or CPU fitted in your DigiPoS will depend greatly on what particular model of DigiPoS you have. The Following is a detailed list of the correct type of CPU fitted to each model and their respective settings:... -
Page 13: Via 82C686B 'South Bridge
DigiPoS PowerPoS & Millennium Technical Manual VIA 82C686B ‘South Bridge’ Incorporating: • PCI Expansion Slots • ISA Expansion Slots • IDE Ports • Keyboard & Mouse Ports • RS232 ‘Serial’ Ports • Parallel Port • USB Ports • Hardware Monitoring •... -
Page 14: Integrated Super Io Controller
DigiPoS PowerPoS & Millennium Technical Manual Integrated Super IO Controller • Supports 4 serial ports, parallel port, and floppy disk controller functions • Programmable character lengths (5,6,7,8) • Even, odd, stick or no parity bit generation and detection • Programmable baud rate generator •... -
Page 15: Plug And Play Controller
DigiPoS PowerPoS & Millennium Technical Manual PC99-Compatible Power Management Cont. • Normal, doze, sleep, suspend and conserve modes • System event monitoring with two event classes • Primary and secondary interrupt differentiation for individual channels • Dedicated input pins for power/ sleep buttons and external modem ring indicator •... -
Page 16: Advanced, High-Performance Memory Controller
DigiPoS PowerPoS & Millennium Technical Manual General Cont • Five outstanding transactions (four In-Order Queue (IOQ) plus one output latch) • Dynamic deferred transaction support Advanced, High-Performance Memory Controller • DRAM interface runs synchronous (66/66, 100/100, 133/133) mode or pseudo-synchronous (66/100, 100/66, 100/133, 133/100) mode with FSB (for 66 / 66 operation, only external VGA is supported) •... -
Page 17: 2D Hardware Acceleration Features
DigiPoS PowerPoS & Millennium Technical Manual 2D Hardware Acceleration Features • ROP3 Ternary Raster Operation BitBLTs • 8, 16, and 32 bpp mode acceleration Motion Video Architecture • High quality up/down adjustment • Planar to packed format conversion • Motion compensation for full speed DVD playback •... -
Page 18: Onboard Lan Adapter
DigiPoS PowerPoS & Millennium Technical Manual Onboard LAN Adapter • Integrated Fast Ethernet MAC, Physical chip and transceiver in one chip • 10 Mb/s and 100 Mb/s operation • Supports 10 Mb/s and 100 Mb/s N-way Auto-negotiation operation • PCI local bus single-chip Fast Ethernet controller o Compliant to PCI Revision 2.2... -
Page 19: Important Notes
USB connectors. If any other connector is removed or replaced while the power is on, serious damage can occur to the DigiPoS. This is considered to be outside the scope of the warranty and will attract a charge for the repair of any damage caused by this action. -
Page 20: The System
10. CD ROM (Optional) 4. Front Panel & CD ROM Lock 11. LED- CD ROM Activity Indicator 5. LED- DigiPoS Diagnostics Disk On Chip Active 12. CD ROM Drawer Open Button 6. LED- Power Distribution Board Voltages 13. CD ROM Manual Draw Open Catch 7. -
Page 21: Rear Panel Orientation
19) S-Video Out (Optional) 10) Parallel Port 20) TV Out (Optional) If PowerPoS or Millennium does not have the TV-OUT Module installed (which is an optional feature), the S-terminal and RCA TV output will not function. Page 21 of 21... -
Page 22: Internal System Orientation
DigiPoS PowerPoS & Millennium Technical Manual Internal System Orientation 1) Power distribution board 3) HDD/FDD sub chassis 2) Riser Card 4) CD-ROM Page 22 of 22... -
Page 23: The Heat Pipe, Air Tunnel & Cpu
DigiPoS PowerPoS & Millennium Technical Manual The Heat Pipe, Air Tunnel & CPU The thermal transfer pad on CPU heat pipe assembly can be easily damaged if the heat pipe is removed and refitted several times. We therefore recommend that only PC-PoS or authorized agents for PC-PoS attempt to remove the heat pipe. - Page 24 DigiPoS PowerPoS & Millennium Technical Manual The Heat Pipe, Air Tunnel & CPU Cont. Step 2. The CPU can now be gently removed. Since there are extra precautions when re-fitting the CPU, the following steps will take you through how to correctly fit the Socket 370 FC-PGA CPU.
- Page 25 DigiPoS PowerPoS & Millennium Technical Manual The Heat Pipe, Air Tunnel & CPU Cont. Step 3. The CPU should be plugged into the socket firmly, but there is no need to use excessive force. Open Step 4. Use a screwdriver to push the processor from the plastic cavity engraved with “Close”...
-
Page 26: Jumper Settings And Connections
DigiPoS PowerPoS & Millennium Technical Manual Jumper Settings and Connections Jumpers NORMAL DEFAULT CLEAR CMOS JP1 DISK ON CHIP ADDRESS SELECT 1-2,7-8 0C800H-0C9FFH 1-2,9-10 0CC00H-0CDFFH 3-4,7-8 0D000H-0D1FFH DEFAULT 3-4,9-10 0D400H-0D5FFH 5-6,7-8 0D800H-0D9FFH 5-6,9-10 0DC00H-0DDFFH SW2 ON BOARD VGA & PCI... -
Page 27: Connections
DigiPoS PowerPoS & Millennium Technical Manual Connections Name Function RESET JUMPER AUDIO & TV-OUT 20 PIN CONNECTOR VGA1 VGA DSUB 15PIN CONNECTOR VGA2 VGA 10 PIN (2 rows X 5 pins) CONNECTOR USB1 USB1 & USB2 CONNECTOR IDE1 HDD 40 PIN CONNECTOR... -
Page 28: Motherboard Orientation
DigiPoS PowerPoS & Millennium Technical Manual Motherboard Orientation Network Boot Socket Chip Graphics Chip MEMORY Component Side Page 28 of 28... - Page 29 DigiPoS PowerPoS & Millennium Technical Manual COM 1 COM 2 HDD Connector Pin1 Underside Page 29 of 29...
-
Page 30: I/O Interfaces & Power Connectors
DigiPoS PowerPoS & Millennium Technical Manual I/O Interfaces & Power Connectors RS232 Standard Serial Ports 1 2 3 Signal Function Signal Function Carrier Detect (IN) Data Set Ready (In) Receive Data (IN) Request To Send (OUT) Transmit Data (OUT) Clear To Send (IN) -
Page 31: Usb Ports
DigiPoS PowerPoS & Millennium Technical Manual USB Ports Signal Name Wire Colour Comment Cable Power - Data White Data Transfer + Data Green Data Transfer Ground Black Cable Ground Shell Shield Drain Wire USB Data Rates USB 1.1 Low Speed 1.5Mbits / Sec... -
Page 32: Lan Connector
DigiPoS PowerPoS & Millennium Technical Manual LAN Connector 1 2 3 4 5 6 7 8 Wire Colour Description White / Orange Transmit Orange Transmit White / Green Receive Blue Not Used⊗ White / Blue Not Used⊗ Green Receive White / Brown Not Used⊗... -
Page 33: Vga Connector
DigiPoS PowerPoS & Millennium Technical Manual VGA Connector I / O Function I / O Function Red Video Key (Plugged Hole) Green Video Sync Ground Blue Video Monitor ID 0 Monitor ID 2 Monitor ID 1 TTL Ground (Monitor Self Test) -
Page 34: 2.5Mm Barrel Connector
DigiPoS end or the LCD end, first switch off the monitor using the power button on the front of the LCD and then re-attach the cable. If this is not carried out correctly, you risk blowing the fuse or even damaging the DigiPoS if the LCD is left on while trying to re- connect the cable. -
Page 35: Power Distribution On The Millennium & Power Pos
This will almost certainly result in serious damage to the motherboard and possibly to the peripheral as well. If either selecting the wrong voltage or removing the connectors while the devices are powered damages ANY peripheral device or the DigiPoS, a charge may be applied by PC-PoS for any repairs necessary. -
Page 36: Correct Fuse Ratings
(RI) signal. The Ring Indicator is the signal the modem gives to the DigiPoS to tell the software that someone is trying to connect to it. The RI signal is normally found on pin 9 of the d-type connectors and as this is the pin that is used to supply power to the peripherals it is necessary to replace the internal cable connection to the selected port. -
Page 37: Typical Voltage Requirements
Overloading of the voltages is not recommended and can render the DigiPoS inoperable or may even permanently damage circuitry within the DigiPoS. Overloading of any of the Voltages will void all warranties, either on the DigiPoS or any connected peripherals. If any permanent damage occurs, charges will apply for any repairs necessary. -
Page 38: Onboard Diagnostics For The Millennium & Power Pos
Onboard Diagnostics for the Millennium & Power PoS Diagnostic Overview The PowerPoS and the Millennium have built onto the motherboard an area of memory specifically for diagnostic purposes. This memory area and the program stored in it have been designed so that system tests can be run without interfering in any way with the operating system or user applications. -
Page 39: Printer Test
Please note that the Customer Display test will only work with displays that are Epson ESC/PoS compliant, these include all of the Epson displays and the DigiPoS CD-5220 (when set up for ESC/PoS emulation). Start the test by pressing the numbered key next to the menu entry;... -
Page 40: Keyboard Test
DigiPoS PowerPoS & Millennium Technical Manual The display should now start to perform a variety of tests culminating with the following picture. An Example of a Customer Display If this picture fails to appear then there is probably something wrong with the display and should be investigated further by a qualified technician. -
Page 41: Magnetic Card Test
DigiPoS PowerPoS & Millennium Technical Manual Magnetic Card Test The diagnostic software is unable to detect the presence or absence of a magnetic card reader due to the fact that the majority of card readers only transmit data and do not receive data. -
Page 42: Bar Code Scanner Test
DigiPoS PowerPoS & Millennium Technical Manual Bar Code Scanner Test The diagnostic software is unable to detect the presence or absence of a bar code scanner due to the fact that the majority of bar code scanners only transmit data and do not receive data. -
Page 43: Bios Set-Up Overview
The following screenshots are a guide through the CMOS set-up utility for the DigiPoS Millennium & PowerPoS. If you need help at any time during this process, press F1 and a small window will pop up describing the appropriate keys to use and the possible selections for the highlighted item. -
Page 44: Main Bios Screen
DigiPoS PowerPoS & Millennium Technical Manual Main BIOS Screen Phoenix – AwardBIOS CMOS Setup Utility Standard CMOS Features Frequency/Voltage Control Load Fail-Safe Defaults Advanced BIOS Features Load Optimized Defaults Advanced Chipset Features Set Supervisor Password Integrated Peripherals Set User Password Power Management Setup Save &... -
Page 45: Standard Cmos Features
DigiPoS PowerPoS & Millennium Technical Manual Standard CMOS Features Phoenix – AwardBIOS CMOS Setup Utility Standard CMOS Features Date (mm:dd:yy) : Sun, Apr 28 2002 Item Help Time (hh:mm:ss) : 13 : 42 : 39 Menu Level IDE Primary Master... - Page 46 DigiPoS PowerPoS & Millennium Technical Manual General Details Cont. Feature Options Description Auto Auto = Auto detects Display Type CRT = Cathode Ray Tube (Default Setting) LCD = Liquid Crystal Display Select Display Device CRT+LCD CRT+LCD = Dual Output TV = Output to a Television (Optional)
-
Page 47: Ide Options Sub Menus
Removable-disk drives such as Zip drives o CD-ROM drives The DigiPoS BIOS supports up to two IDE disk adapters, called primary and secondary adapters. Each adapter supports one master drive and one optional slave drive in these possible combinations: o 1 Master (3.5”... - Page 48 DigiPoS PowerPoS & Millennium Technical Manual Details Cont. Feature Options Description CHS = Cylinder, Head, Sector LBA = Logical Block Addressing Access Mode Large Large = Large Disk Access Mode Auto Auto = Auto Detect correct mode for HDD in use.
-
Page 49: Advanced Bios Features
DigiPoS PowerPoS & Millennium Technical Manual Advanced BIOS Features Phoenix – AwardBIOS CMOS Setup Utility Advanced CMOS Features Virus Warning [Disabled] Item Help CPU Internal Cache [Enabled] External Cache [Enabled] CPU L2 Cache ECC Checking [Enabled] Menu Level Quick Power On Self Test... - Page 50 Enabled 720Kb, 1.2Mb or 1.44Mb, which is the standard today. Boot Up Floppy Seek Disabled Because only the 1.44Mb is used in the DigiPoS, this function can be disabled to save time during the POST (Power On Self Test). Enabled Boot Up NumLock Status Sets the number lock to on or off after boot up.
- Page 51 DigiPoS PowerPoS & Millennium Technical Manual Details Cont. Feature Options Description Non-OS2 This allows you to access memory over 64MB in OS Select for DRAM > 64Mb OS/2. Enabled Video BIOS Shadow This enables you to move programs from 16 bit...
-
Page 52: Advanced Chipset Features
DigiPoS PowerPoS & Millennium Technical Manual Advanced Chipset Features Phoenix – AwardBIOS CMOS Setup Utility Advanced Chipset Features DRAM Clock [Host CLK] Item Help SDRAM Cycle Length Bank Interleave [Disabled] Memory Hole [Disabled] Menu Level P2C/C2P Concurrency [Enabled] System BIOS Cacheable... - Page 53 DigiPoS PowerPoS & Millennium Technical Manual Details Cont. Feature Options Description Selecting Enabled allows caching of the system BIOS ROM at F0000h-FFFFFh, resulting in better Disabled System BIOS Cacheable system performance. However, if any program Enabled writes to this memory area, a system error may result.
-
Page 54: Integrated Peripherals
DigiPoS PowerPoS & Millennium Technical Manual Integrated Peripherals Phoenix – AwardBIOS CMOS Setup Utility Integrated Peripherals OnChip IDE Channel 0 [Enabled] Item Help OnChip IDE Channel 1 [Enabled] IDE Prefetch Mode [Enabled] Primary Master PIO [Auto] Menu Level Primary Slave PIO... - Page 55 DigiPoS PowerPoS & Millennium Technical Manual Details Cont. Feature Options Description Auto The four IDE PIO (Programmed Input / Output) fields Primary Master PIO Mode 0 let you set a PIO mode (0-4) for each of the four IDE Primary Slave PIO Mode 1 devices that the onboard IDE interface supports.
- Page 56 DigiPoS PowerPoS & Millennium Technical Manual Details Cont. Feature Options Description ECP Mode Use DMA Select a DMA channel for the parallel port for use (If ECP Mode Selected) during ECP mode. You may have a device that requires an EPP parallel Parallel Port EPP Type EPP1.9...
- Page 57 DigiPoS PowerPoS & Millennium Technical Manual Details Cont. Feature Options Description 300-303H 310-313H MPU-401 Select a base I/O address for the MPU-401 interface 320-323H 330-333H Page 57 of 57...
-
Page 58: Power Management Setup
DigiPoS PowerPoS & Millennium Technical Manual Power Management Setup Phoenix – AwardBIOS CMOS Setup Utility Power Management Setup Item Help Power Management [Press Enter] PM Control by APM [No] Video Off Option [Always On] Menu Level Video Off Method [V/H SYNC+Blank]... -
Page 59: Power Management Sub Menu
DigiPoS PowerPoS & Millennium Technical Manual Power Management Sub Menu Phoenix – AwardBIOS CMOS Setup Utility Power Management Item Help Power Management [User Define] HDD Power Down [Disable] Doze Mode [Disable] Menu Level Suspend Mode [Disable] : Move +/-/PU/PD: Value... -
Page 60: Wake Up Events Sub Menu
Options Description Only valid if your monitor supports DPMS None This setting allows you to bring the DigiPoS out of Doze LPT & COM or suspend mode if there is activity on either the LPT port, Com Ports or Both. -
Page 61: Pnp/Pci Configurations
DigiPoS PowerPoS & Millennium Technical Manual PnP/PCI Configurations Phoenix – AwardBIOS CMOS Setup Utility PnP/PCI Configurations Item Help PNP OS Installed [Yes] Reset Configuration Data [Disabled] Menu Level Resources Controlled By [Auto(ESCD)] x IRQ Resources Press Enter Select Yes if you are... - Page 62 DigiPoS PowerPoS & Millennium Technical Manual Detail Cont. Feature Options Description When resources are controlled manually, assign each system DMA channel as one of the following types, depending on the type of device using the interrupt: Legacy ISA Devices compliant with the original PC AT...
-
Page 63: Pc Health Status
DigiPoS PowerPoS & Millennium Technical Manual PC Health Status Phoenix – AwardBIOS CMOS Setup Utility PC Health Status Item Help Current CPU Temp. 36°C/96°F Current System Temp. 39°C/102°F Current CPUFAN1 Speed 6553 RPM Menu Level Current CPUFAN2 Speed 5041 RPM VCore 1.77 V... -
Page 64: Frequency/Voltage Control
DigiPoS PowerPoS & Millennium Technical Manual Frequency/Voltage Control Phoenix – AwardBIOS CMOS Setup Utility Frequency/Voltage Control Item Help Auto Detect DIMM/PCI Clk [Enabled] Spread Spectrum [Disabled] CPU Host/PCI Clock [Disabled] Menu Level : Move +/-/PU/PD: Value F10 : Save ESC : Exit... -
Page 65: Operating System Dependant Settings
Operating System Dependant Settings The defaults that were covered above are generalised and some settings need to be altered in order to gain the maximum performance from your DigiPoS when using certain operating systems. The following list describes the operating system dependant settings and their reasons. -
Page 66: Windows 95 & Nt
DigiPoS PowerPoS & Millennium Technical Manual Windows 95 & NT The USB Support in Windows 95 (even OSR2) has never been ‘outstanding’ and we therefore advise that this function is disabled if you are not using USB devices. Advanced Chipset Features... -
Page 67: Warranty Policy
All freight costs to return the DigiPoS back to PC-PoS are the responsibility of the customer except where special authorization for freight exemption has been granted by a PC-PoS management representative. -
Page 68: Pc-Pos Global Office Locations
DigiPoS PowerPoS & Millennium Technical Manual PC-PoS Global Office Locations PC-PoS Australia PC-PoS North America Physical Location: 309B Commissioners Rd. W. Unit 7, 10 Bradford Street, London, Ontario Alexandria NSW 2015. Canada Postal Address: N6J 1Y4 P O Box 180, Tel: (519) 474 7987 Rosebery NSW 1445.
