- Page 1 Manual ND ISLA UL ing.qxd 6/05/2003 11:50 PÆgina 1 INSTRUCTIONS FOR USE AND INSTA L L ATION INSTRUCTIONS IKD 1157.1 GE-UL...
- Page 2 Manual ND ISLA UL ing.qxd 6/05/2003 Dear client: Congratulations on your choice. We are sure that this modern, functional and practical apparatus, made with top quality materials, will fully satisfy your needs. Please read every section INSTRUCTIONS MANUAL before using your kitchen hood for the first time, to be able to get maximum performance from the apparatus and to avoid breakdowns which may be...
- Page 3 Manual ND ISLA UL ing.qxd 6/05/2003 • Once the kitchen hood has been installed, ensure that the feed cable to the network is not in contact with any live metal edges. • Avoid connecting conductors used exits for fumes produced by a non-electric energy source.
- Page 4 Manual ND ISLA UL ing.qxd 6/05/2003 Instructions for use You may control the kitchen hood's workings by operating the controls as shown in the diagram. To improve draught we recommend to turn the extractor fan on a few minutes before cooking so that the flow of air is continuous and stable when fumes are extracted.
- Page 5 Manual ND ISLA UL ing.qxd 6/05/2003 Proceed with the following checks before calling the Technical Service: Problem The extractor fan ceases to function The extractor ceases to educt strongly or vibrates The lamps do not light up 11:50 PÆgina 5 Problem solving Possible cause The kitchen hood feed cable is not connected to...
- Page 6 Manual ND ISLA UL ing.qxd 6/05/2003 Tec. Cod. Technical Network Code (V) Code 22UL324IS KÜPPERSBUSCH reserves the right to make changes and corrections to its products as it deems necessary, without altering their basic characteristics. Accesories supplied 150/125 mm reduction. Anti-recoil valve.
- Page 7 Manual ND ISLA UL ing.qxd 6/05/2003 Installation On installing the kitchen hood make sure that the Safety Instructions set out on page 2 are complied with. WARNING • : TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY PERSONS, OBSERVE FOLLOWING: a.
- Page 8 Manual ND ISLA UL ing.qxd 6/05/2003 Installation witouth output vent, with active charcoal filters (Optional) When exterior gas extraction to the outside is not possible, then the kitchen hood may be set to purify the air by recycling it through active charcoal filters.
- Page 9 Manual ND ISLA UL ing.qxd 6/05/2003 6) Fit the part (A) if the inner tube (not supplied) is Ø150 or (A) + (B) if it is Ø120. 7) Attach the inner tube with a clamp (not supplied) to (A) or (B) as the case may be. 8) Introduce the upper tubecover (A8) into the lower tubecover (A9).
