- Page 1 DISHWASHER USE AND CARE MANUAL MODEL: IGVS6607-UL GUIDE D’ENTRETIEN ET D’UTILISATION DU LAVE-VAISSELLE MODÈLE: IGVS6607-UL MANUAL DE USO Y CUIDADO PARA LAVADORA DE PLATOS MODÈLO: IGVS6607-UL 9000279028 Rev A 07/07...
-
Page 4: Table Of Contents
Important Safety Instructions - Save This Information WARNING Misuse of the dishwasher can result in serious injury or death. Do not use the dishwasher in any way not covered in this manual or for any purpose other than those explained on the following pages. -
Page 5: Important Safety Instructions
Under certain conditions, hydrogen gas may be produced in a hot water system that has not been used for two weeks or more. Hydrogen gas is explosive. Before using a dishwasher that is connected to a hot water system that has been unused for two weeks or longer, turn on all hot water faucets and let the water ow from each for several minutes. -
Page 6: Dishwasher Features And Options
Dishwasher Features and Options Noise Reduction System: A two-pump motor system, the Suspension Motor™, and triple insulation make this dishwasher one of the quietest in North America. Stainless Steel Maxi Tub: A rust-free, hygienic interior surface with a lifetime warranty. -
Page 7: Dishware Materials
Dishware Materials NOTE: Before using your dishwasher for the first time, check the information in this section. Some items are not dishwasher safe and should be hand-washed; others require special loading. Contact the item’s manufacturer if you are unsure about the item’s dishwasher suitability. - Page 8 NOTE: When pushing the top rack into the dishwasher, push it until it stops against the back of the tub so the top rack spray arm will connect to the water supply. Do not push the top rack with the door.
- Page 9 With the silverware basket tops down, load the silverware basket following the patterns suggested in Figures 10 and 11). Place knives with their handles up, and forks and spoons with their handles down. If large or oddly-shaped items are to be loaded into the silverware basket with the tops up, load the items so that they do not nest together.
-
Page 10: Adding Detergent And Rinse Agent
To avoid dishwasher damage, do not use hand dishwashing products in your dish- washer. This dishwasher uses less water so you need to use less detergent. With soft water, 1 tablespoon (15ml) of detergent will clean most loads. The detergent dispenser cup has lines that measure detergent to 1 tablespoon (15ml) and 1.75 tablespoons (25ml). -
Page 11: Wash Cycle Options
For lightly soiled items with easy to remove food soils. Rinse and Hold Allows you to rinse the food soil off of a partial load and hold them in the dishwasher until there is a full load. Wash Cycle Options... - Page 12 Hidden Top Controls (See Figure 20) 1. Open the dishwasher door just far enough to expose the control panel. 3. Wait at least ten seconds or until the water noises stop before opening the dishwasher door. WARNING You could be seriously scalded if you allow hot water to splash out of the dishwasher.
-
Page 13: Dishware Drying
Dishware Drying At the end of the cycle the dishwasher will stop and a period of condensation drying will follow. After drying, the cycle is complete and: • the “Clean” light will illuminate (select models). • the completion signal will sound (select models). - Page 14 This dishwasher has a filter system that consists of a Large Object Trap/Cylinder Filter assembly and a Fine Filter. The filter system is located on the inside of your dishwasher under the lower rack and is easily accessible.
- Page 15 Flush the Cylinder Filter clean by holding it under running water. To Remove the Fine Filter: 1. Lift the Fine Filter from the dishwasher floor as shown in Figure 30 A and flush it clean by holding it under running water.
-
Page 16: Wash Cycle Information/Sanitized
THE NSF S YMBOL A dishwasher or a dishwasher cycle that has the NSF symbol has been certified by the NSF International to meet very strict requirements of wash time and water temperature to ensure dishware and kitchenware sanitization. These requirements are explained in the document NSF/ANSI 184, Residential Dishwashers. - Page 17 Cycle Chart Data Power Scrub Plus 120 - 135 i n i o l l i n i 27.4 F ° ° 0 ° 6 F ° Auto Regular Auto Plus Wash 120 - 135 105 - 125 23.2 27.4 26.4 150°-160°...
-
Page 18: Self Help
If the dishwasher completes the cycle, but the run time seems exceptionally long, it may be due to cold incoming water. Before starting the dishwasher, open the hot water faucet at the sink nearest the dishwasher. Run the water until it runs hot, then turn off the water and start the dishwasher. - Page 19 (excludes labor charges). Lifetime Warranty against Stainless Steel Rust Through: Küppersbusch will replace your dishwasher with the same model or a current model that is substantially equivalent or better in functionality, if the inner liner should rust through (excludes labor charges).
-
Page 20: Model Number
Please be sure to include your model information listed below as well as an explanation of the problem and the date it originated. You will find the model and serial number information on the label located on the right edge of the dishwasher door as shown in Figure 32. - Page 21 Küppersbusch reserves the right to change spec cations or design without notice. Some models are cert ed for use in Canada. Küppersbusch is not responsible for products which are transported from the United States for use in Canada. Check with your local Canadian distributor or dealer. Küppersbusch se réserve le dr au Canada.
