- Page 1 BEDIENUNGSANWEISUNG mit Montageanweisungen Instructions for use and installation instructions Instructions d’utilisation et avis de montage Gebruiksaanwijzing en montagehandleiding Istruzioni di uso e di montaggio Instrucciones de uso y de montaje Instruções de uso e de montagem KGCT 907.2E...
-
Page 2: Table Of Contents
Installation ........23 Installation in a fitted kitchen Electrical connection KGCT 907.2E... -
Page 3: Your Appliance At A Glance
Ø 140 mm, 1000 Watt Extend/retract sensor buttons cooking area Sensor buttons grill area Sensor cooking zones Off-sensor On-sensor (Stand-by-switch) KGCT 907.2E Sensor-child proof lock (sensor-lock) Cooking zones Ø 140 mm, 1200 Watt Ø 180 mm, 1800 Watt Ø 180 mm, 1800 Watt Ø... -
Page 4: Use Of The Cooking Zones And The Grill Area
– if no cooking zone is activated within 20 minutes (after 10 seconds an acustic signal indicates that the appliance switches itself off after another 10 seconds) – if the appliance is not used 1 minute after starting operation. ” ap- KGCT 907.2E... -
Page 5: Extending And Retracting Cooking Area
In this case press the buttons of the cooking area back into its end position. KGCT 907.2E The cooking setting You have 9 cooking settings available.Select the required cooking setting with the plus- or minus-sensor. It will be indicated in the display. -
Page 6: The Automatic Boost Function
The pan-detection function detects all pans made of metal. The pan-detection function must be deactivated in order to use cooking equipment made of glass or ceramics. If a suitable pan is put onto the cooking zone, “U” is indicated by the display. KGCT 907.2E... -
Page 7: Switching Off The Pan Recognition Function
Moving the pan during cooking can cause the outer ring to switch off if it has KGCT 907.2E not been completely covered. The outer cooking zone circuit can also be switched on and off when the pan-detection function is active. -
Page 8: Child Proof Lock (Sensor-Lock)
If the electronics overheat, the hob will switch off. All 4 LED indicators will flash and a cyclical signal will be heard. Switching off time after 2 hours 3 hours 4 hours 5 hours 10 hours KGCT 907.2E... -
Page 9: Cleaning And Care
Any slight dirt marks from protein, e.g. from meat, is removed and the grill surface shines again. KGCT 907.2E What to do if there is a fault Unplug the appliance befor repair! Check carefully to make sure that the fault is not due to misoperation. - Page 10 The rating plate is lo- cated underneath the cooking area. The rating label is located at the bottom side of the hob. It is also stuck onto the cover page of this operating manual. KGCT 907.2E...
-
Page 11: Installation
The appliance must be installed absolutely horizontally. The Küppersbusch built-in oven EEB 9800 / 9600 can be fitted underneath the zoom-cooking centre KGCT 907.2E. The cooker is Y-type design, providing overheating protection for surrounding surfaces (fitted cupboard components). That means, that this appliance can be placed with its back wall and one side wall next to cupboard or room walls of any height. -
Page 12: Electrical Connection
The conductor colours may be different. The connection diagram and the terminal numbers are the decisive factors. base Three-phase connection 400 V system with 230 V phase against neu- tral conductor Three-phase system 230 V phase against phase 50 Hz Cable to the hob KGCT 907.2E...
