Installation

Connectors

The following figures apply to the SDX-570V.
SATA Power
Connector (*1)
Caution
DO NOT USE both the SATA Power Connector (*1) and Legacy Power
Connector (*2) at the same time.
Using both connectors possible cause the system damage.
10
SATA Signal
Connector
Legacy Power
Connector (*2)
4
3
2
1
5V GND GND 12V
