Table of Contents SAFETY PRECAUTIONS ..........6 APPEARANCE ............11 TECHNICAL SPECIFICATIONS ......... 12 GETTING STARTED ..........13 Charging Battery Device management Main menu overview Notification panel Gestures Working with On-Screen Keyboard Frontlight Connecting to the Internet Inserting Micro SD Card...
Page 3
READING BOOKS ........... 25 Gestures in Reading Mode Reading Menu Social networks & ReadRate Contents Bookmarks Dictionary Notes Reading settings Following Links Loading Files Library APPLICATIONS ............49 Book Store Browser Standard Apps Notes Calculator Calendar & Clock...
Page 4
Scribble Gallery Games Klondike Sudoku Chess Interactive Apps RSS News PocketBook Sync Dropbox PocketBook Send-to-PocketBook SETTINGS .............. 69 Wi-fi Accounts and Synchronization Personalize Languages Date/Time Saving Battery...
Page 5
Maintenance Software About Device FIRMWARE UPDATE ..........83 TROUBLESHOOTING ..........86 CUSTOMER SUPPORT ..........88 COMPLIANCE WITH INTERNATIONAL STANDARDS ...89...
Safety Precautions Before start working with the Device, please, read this section carefully. Following these instructions will help you ensure your safety and extend service life of the Device. Storage, Carriage and Usage Conditions Device operating temperature range is 0°C to 40°C, so don’t ex- pose the Device to excessively high or low temperatures.
Page 7
Safety Srecautions Maintenance Do not leave the Device for a long time in poorly venti- lated environment, e.g. in a car or in closed tight boxes/ packaging. Neither drop nor try to bend the Device. Srotect the screen from objects that may scratch or damage it.
Page 8
Safety Srecautions or modified batteries may cause an explosion and/or damage the Device. Do not use organic or inorganic solvents (e.g. benzoyl etc.) to clean the screen/case. Use a soft cloth to remove dust from the Device’s surface. Apply a few drops of distilled water to remove dirt. Up to five faulty pixels are acceptable in the screen and do not constitute a warrantable defect of the screen.
Page 9
For detailed information about service centres in your region please visit the official website of SocketBook International: http:// www.pocketbook-int.com. RF Safety The Device receives and transmits radio frequencies and may in- terfere with radio communications and other electronic equip- ment.
Page 10
Safety Srecautions Utilization Incorrect disposal of this Device may have adverse im- pacts on the environment and public health. To prevent such consequences follow the device-specific disposal requirements. Recycling of these materials helps pre- serve natural resources. For more information regarding recycling issues please contact local municipal authorities, your domestic waste collection service, store where you purchased the Device, or the authorized service centre.
Appearance 1. Home – return to Main menu 2. Backward – in reading mode turns page backward; in navigation mode – goes to the previous menu or page of the list 3. Forward – turns page forward 4. Menu – open context menu (if available).
Getting Started In this chapter you will learn how to prepare the Device to work and about its main control features. CHARGING BATTERY To extend battery lifetime, it’s recommended to charge the Device for the first time from 8 to 12 hours.
Page 14
Getting Started To charge the battery for the first time, do the following: • Connect the Device to a computer or charger with USB-cable. The device will turn on as soon as charging starts. • When the battery is fully charged, you can discon- nect the cable from the Device which is ready for usage.
Getting Started DEVICE MANAGEMENT Sress On/Off button. When the Device is ready to operate, Main Turn on menu or last opened book will appear, depending on settings. Sress and hold On/Off button for about two seconds until the Turn off Device goes off.
Getting Started MAIN MENU OVERVIEW Slide down to open a Touch to open Calendar Notification panel ‘Recent Books’ is a list of recently opened books Last downloaded books Slide up to open an Application panel...
Getting Started Notification panel Touch or slide down the icon to open a Notifica- tion panel. NOTE: You can open Notification panel also pressing a Menu button. Notification panel gives an easy access to configuration of Wi-fi and Frontlight, Sync of network services, Task man- ager, device...
Getting Started GESTURES CAUTION! Touch screen of the Device is sensitive enough and is a fragile detail. To avoid its damage, please, touch it carefully while controlling the Device with gestures. Opens an element (book, file, folder application or menu item). Touch &...
Getting Started Flick Scrolls lists: move your finger across the screen rapidly. Scaling Changes the image scale: place two fingers on a screen and pinch them together to zoom out or spread them apart to zoom in. WORKING WITH ON-SCREEN KEYBOARD On-screen keyboard is used when it’s necessary to enter text information, for example, for search or network con- nection credentials.
Page 20
Getting Started keyboard layout go to Settings > Languages > Keyboard Layouts. 1. Change case; 2. Enter the typed text; 3. Close the on-screen keyboard; 4. Erase last typed symbol; 5. Change input language. As you type a password (e.g. Wi-Fi credentials) icon will appear on a text field.
Getting Started FRONTLIGHT To turn on/off the frontlight, press and hold the Menu button for 1 second. Also you can adjust the frontlight level using the slider in the notification bar. CONNECTING TO THE INTERNET The Device can be connected to the Internet using Wi-Fi networks.
Page 22
Getting Started 1. At the notification bar go to Settings > Network > Network Access; 2. Select for the Network access checkbox and then further settings appear: Auto connection, Connection to a hidden network, and a list of available Wi-Fi networks. NOTE If there are no available networks or the signal strength is week, Available networks...
Page 23
Getting Started • WPA/WPA2 Enterprise – you will need to spec- ify username, password and domain (if necessary); • WPA/WPA2 PSK – you will need to enter net- work key (up to 64 symbols). 5. Open Advanced settings. Select the idle time be- fore disconnection in the corresponding section.
Getting Started INSERTING MICRO SD CARD The Device already has 4 GB of internal storage, but you can extend it by using micro SD card (up to 32 GB). Insert it to the slot, like it is shown on a figure, and slightly push until card will be fixed.
Reading Books In this chapter you will learn how to read e-books and con- figure reader software for the most comfortable reading. The Device supports next book formats: (includ- SDF, ESUB ing Adobe -protected); FB2, FB2.ZIS, DOC, DOCX, TXT, DjVU, RTF, HTML, HTM, CHM, TCR, SRC, MOBI, ACSM To open a book, touch its icon on Recent Books Library...
Reading Books GESTURES IN READING MODE Close book; Make a bookmark; Turn pages forward; Turn pages backward; Pressing in the center of the screen evokes the Reading Menu Page turning Scaling...
Reading Books READING MENU Book name: touch to see the book info or open ReadRate menu Contents Search Back Bookmark Open ReadRate menu Pull the slider to turn pages or touch the page number to input the digits of needed page...
Reading Books SOCIAL NETWORKS & READRATE Now you will be able to take advantages of social net- works on your Socketbook: share quotations from books, add comments, tell what you are reading or have read, like or don’t like. ReadRate also allows you watching the friends’...
Page 29
Reading Books Reading status and Book Rate 1. Touch one of the options (Now reading, Have read, Plan to read, Recommend Rate with stars from 1 to 5). 2. Enter data (E-mail and password) of one of your accounts: in social networks or in the market Book Store. 3.
Page 30
Reading Books 4. Select social networks, where you want to send news: Facebook, Vkontakte, Odnoklassniki, Twitter, Linke- dIn, Google+ – icons of chosen networks will become hefted. 5. If the chosen social network wasn’t linked to the ReadRate profile, you will be proposed to link them. 6.
Page 31
Reading Books 3. Choose a friend from a list or enter user email to send a recommendation to him/her. 4. Enter a comment and confirm sending by pressing Recommend. Share quotation To share quotation from a book: 1. After continuous touch on the screen in the opened book, creeper of text selection appear.
Page 32
Reading Books 4. All actions of your friends on ReadRate are dis- played in Notification panel of your Device: 5. You can Delete Open event. When you open it all new friends’ actions on ReadRate will be displayed. To delete your social networks accounts information for ReadRate, go to Settings >...
Reading Books CONTENTS If a book has table of contents, you can open it by select- ing the corresponding reading menu item. Content section contains three insets: • Sections (book’s chapters names); • Bookmarks (made during reading); • Notes (graphic or text). If table of contents has more then one level, higher level entry will be marked with ‘+’...
Reading Books BOOKMARKS To create a bookmark, touch right top corner of the screen. A dog ear mark will appear. To delete a bookmark, touch this mark again and confirm deletion. Also you can add/remove bookmarks by selecting the cor- responding reading menu item.
Reading Books DICTIONARY Touch and hold a word to open a panel allowing you to search for translation using one of installed dictionaries or find a word in Google. Also after selecting Dictionary item, a window with dictionary entry of a selected word appears. Next tools are available: Change View resembling...
Reading Books NOTES Notes allows you to save favorite book fragments and make handwritten records directly in the text. All the notes will be displayed in book’s table of contents. To enter notes mode, select Note reading menu section. NOTE Handwritten notes are not available for DjVu books. After you will enter Notes, a tooltip window will appear.
Reading Books READING SETTINGS You can customize the display of books depending on your preferences. Text Format Books In text format books (TXT, etc.) there are options to configure reader software: font, font size, line spacing, page margins width, hyphenations (on/off), encoding. Line Hyphena- Font...
Page 38
Reading Books PDF & DjVu You can change only the whole page scale only (except Reflow mode for Sinch two fingers together to zoom out or spread them apart to zoom in or slide a finger upwards the right side of screen to zoom in or downwards – to zoom out, respectively.
Page 39
Reading Books Columns – for reading books with columns. To navigate the page use navigation buttons. A page will be turned after bottom edge of the sheet reached; Reflow – in this mode text is formatted to display completely on the screen. Reflow mode is supported for SDF books only.
Reading Books FOLLOWING LINKS To follow a footnote, internal or external link, touch to en- ter links mode. To exit this mode, touch top left corner of the screen. If a link follows to a web-site, it will be opened with Device built-in browser.
Page 41
Reading Books card installed – as two ones). Now you can copy files to the Device or SD card using Explorer or other file manager. ATTENTION! After copying files safely remove the Device before disconnect the cable! Downloading protected e-books (Adobe DRM) Registration at www.adobe.com is required to use e-books in protected format (Sign in >...
Page 42
Reading Books 4. Open Visit the sample eBook library at the bottom of the page to enter the library; 5. Choose a book and click Download item. 6. A download window will appear on the screen. The file name should contain the name of the book and the file extension .acsm.
Page 43
Reading Books into the Device Activation form. Then you will be able to download the book. 4. Download the book. After the download is com- plete, a full version of the book will be available for reading in the Digital Edition folder.
Page 44
4. Choose a book and copy it to your Device. Sync your device with network services You can also upload files to the Device synchronizing de- vice memory with personal accounts of network services PocketBook Sync, Send-to-PocketBook and Dropbox. Variant 1 • Open Settings >...
Page 45
• Select the synchronization option. For detailed information about work with network servic- es see sections PocketBook Sync, Send-to-PocketBook Dropbox PocketBook. Read more about configuring net- work services at the section Accounts and Synchronization. Synchronization status can be viewed on the Notification panel.
Reading Books The icon in the status bar changes to if the error oc- curred during synchronization of one of the services. If all synchronization processes are completed without errors, the icon in the status bar disappears. LIBRARY Library is e-books file manager. Library menu allows to filter, group, sort, change appearance of the section and perform search.
Page 47
Reading Books • Authors; • Bookshelf - create your own shelves with books depending on your interests and preferences; • Series; • Formats. The results of grouping can be be dispalyd as ascending (A-Z) or descending (Z-A). 2. Sorting criteria •...
Reading Books Context menu..opened by continuous touch..and allows proceeding with next file and folder operations: • Book Info - brief information about book/folder; • ReadRate; • Add to bookshelf; • File – file operations: • Copy; • Move; •...
Applications In this chapter you will learn about applications wich are preinstalled on your Device. There is three apps which is brought out to the main menu: • Library; • BookStore; • Browser. The rest of the apps are available at the application bar. To invoke it touch the icon at the main menu.
Applications LIBRARY Library is e-books file manager, which allows to group, sort, change appearance of the section and perform search. Read more about this app at Library. BOOK STORE Book Store application provides quick and convenient licensed content download from Book Store portal (http://www.bookland.com/) to your Device.
Page 51
Applications If the connection with an account is set properly, you get access to all the features of a portal. Sress the Personal Room to expand options for work with a personal account: Exit Personal room...
Page 52
Applications • Top up the balance – top up the balance on a site BookLand or directly on the Device using the bank card (Visa, MasterCard, Maestro); • Purchase history – the list of goods, purchased at the store; • My cards –...
Applications BROWSER This is an application for viewing web-pages. As you start Browser, you are suggested to connect to one of available wireless networks. To enter website address, touch address bar, type an ad- dress from on-screen keyboard appeared and press Enter. To follow a link, just touch it.
Page 54
Applications favorites, adjust scale of displaying web-pages, rotate a screen and configure the browser from Settings section. Under Settings you can clear history and cookies, disable/ enable JavaScript and loading images. To exit Browser, touch the corresponding item in browser menu.
Applications STANDARD APPS Notes In this section you can view all the notes made during reading. After you select a note, the table of contents of the book, where it was made, will open. Slease, read more about notes creation and editing in Notes. Calculator Engineering calculator...
Applications Scribble Application for drawing. To select the drawing tool, use the application control panel: Text: select the position and size of the text box. Text is entered with the on-screen keyboard; Font: change font and its size; Sencil: a tool for drawing thin lines; Marker: a tool for drawing thick lines;...
Applications Gallery Opens Library in the mode of viewing images (downloaded to the folder Gallery). The opened photo is displayed in a full- screen mode. To set a photo as Power-off Logo, to Rotate or view Information about it, touch the full-screen image to switch to the editing mode and press menu sign in the right top corner of the screen.
Applications Chess You can play versus your friend or the Device. If you are playing against the Device, you can select 10 difficulty levels. INTERACTIVE APPS RSS News Application for adding and reading RSS feeds. To add RSS news feeds, open RSS setup. Select the Add RSS feed tion.
News Archive: by selecting this option you can choose to read the previously stored updating RSS feeds. PocketBook Sync PocketBook Sync service allows you to download all books, chosen on the book store, directly to your Device (or even...
Page 60
Applications PocketBook Sync is convenient because you can choose files from the store in advance and then download them on your Device in any time convenient for you. Usage NOTE: For correct work of SocketBook Sync time and date on the De- vice should be adjusted properly (Settings >...
Page 61
Applications Sync Settings (Settings > Accounts and Synchronization > PocketBook Sync). If Wi-Fi connection has not been acti- vated, the Device will generate a connection request). • choose the store, where you are registered, from the list of content providers, and enter your account data.
Page 62
Applications automatically every half an hour for checking new links (if the Device is not powered off/not in sleeping mode). The list of downloads will be automatically loaded to the queue after successful setting connection. Automatic download is chosen in SocketBook Sync set- tings, the download will start automatically.
Dropbox Pock- etBook sync folder will be created in the Library of the De- vice. The Application > Dropbox PocketBook directory will show up in your Dropbox account, and after synchroniza- tion it will be available from other devices with Dropbox.
Page 64
Applications NOTE The application on your device will have access only to files in the Application > Dropbox PocketBook folder on the server How to synchronize Automatically: 1. Files, added to the directory Application > Drop- box PocketBook on the server and to the sync folder on your Device, will be automatically synchronized when the internet connection is on.
Device, if the Wi-Fi is turned on. How to start using 1. Register for the Send-to-SocketBook service, for this purpose do the following: • Launch application: • from the Applications > Send-to-PocketBook section; • or from Settings > Accounts and Synchroniza- tion > Send-to-PocketBook.
Page 66
Device. After that all applications features will be avail- able for you, and the download folder for received books will be created in the library — Send to PocketBook. How to get files Automatically: 1. Files, sent to the service email address of your Device,...
Page 67
Device Library, when the internet connection is on. Down- load folder is available after authorization from the locations: • Applications > Send-to-PocketBook; • Settings > Accounts and synchronizations > Send- to-PocketBook > Go to folder of the context menu of the Download folder; • Library > Send-to-PocketBook.
Page 68
Applications The list of trusted senders Documents can be downloaded on the Device, if they are sent from the address, contained in the ‘white list’ (a list of the trusted senders). The address, specified at registration, is contained in the list by default.
Settings In this chapter you will learn how configure the interface and software features of the Device for the most comfortable usage. Select Settings Notification panel to configure the Device. All changes will be applied after exiting the section. If you will encounter any problems with new settings, you will be able to start the Device in safe mode with factory defaults.
Book Store — in this section you can enter Login Password for authorization in the Book Store. PocketBook Sync — There are the following settings for the SocketBook Sync service: • PocketBook Sync Status: or off. The service is turned on automatically at the autorization. If you are not...
Page 71
Settings going to use the service for a long period, you can turn off to optimize the Device productivity. • Establishing Connection: Automatically (connec- tion will be established automatically every half an hour to check for new links (if the Device is not powered off/ not in sleeping mode)) or Manually (the connection is estab-...
Page 72
Settings • Information about service — more detailed about service. Send-to-PocketBook — the following options are available: • PocketBook account: your account email. • Login/Log out: if you are not authorized in the application, input your contact email address and pass- word, to authorize.
Page 73
Settings • Download folder: location of received files. The Send-to-PocketBook folder is set by default. You can choose any other folder or create a new one in the internal Device storage or on the external SD-card. • About service — more detailed about service.
Page 74
Sync Folder: location of synced files. You can also move files to Sync folder, if you want to sync them with Dropbox Pocketbook directory on the server. The Dropbox PocketBook folder on the Device is set by default. You can choose another folder or create a new one in the internal Device storage or on the external SD-card.
Settings Adobe DRM Authorization item are displayed. After re- moving all protected DRM documents will be unavailable. PERSONALIZE Boot Logo – image displayed during the Device starts. Logos are stored in system/logo internal storage folder, so you can copy an image you’d like to be displayed during startup.
Page 76
Settings NOTE You can also set your own picture as a logo from the Gallery application. Read about it in the Gallery section. Complete Page Refresh. Select the amount of page turned before the screen will be updated completely. Always item provides the best quality, but consumes the most power.
Settings LANGUAGES Language. Select the Device’s interface language. Keyboard Layouts. Under this section you can add up to 3 keyboard layouts. Available Dictionaries. Under this section you can un- check dictionaries you don’t want to be displayed in the list during the translation or in Dictionary application;...
Settings SAVING BATTERY Here you can see battery level and set parameters, which help to save battery charge: • Battery Percentage; • Auto screen lock — set time of idleness, after which the Device is locked: off, 5 min, 10 min. •...
Page 79
Settings save there system settings. You will be suggested to enter the file name from on-screen keyboard; Library This section is intended for optimization of Library database. • Library Data Update – set the parameters for Library database update: • –...
Page 80
Settings Privacy • Protect Configurations by Password — in this sec- tion you can protect your setting by password. Select Password section and type the password from on-screen keyboard. Now each time you try to enter Settings section, you will be asked to enter the password. You can remove or change password by selecting the corresponding item.
Settings CAUTION! If you need to erase all data on the Device, use this feature only, don’t try to format the Device internal memory via SC. Format SD card – this action will erase all data from the external microSD card. Factory Reset –...
Settings Auto Update – turn on/off automatic check for updates. Thirdd-Party Apps — license and information about third- party applications, used on the Device. ABOUT DEVICE The following information about Device will be displayed: Device Model (model, serial number, hardware platform, Wi-Fi MAC address), Memory (operative memory, total and available internal...
Firmware Update WARNING! Firmware Update is a responsible operation, during which management software of the Device will be changed. In case of improper execution control program may be damaged and will require treatment in the service centre. Slease perform the upgrade procedure in accordance with the instructions below.
(Set- tings > About Device > Software > Auto Update). In this case, the Device will use Wi-Fi connection only. Manual Update 1. Open site www.pocketbook-int.com. Select your country. 2. Click the Support button on top menu. Select hard- ware model of your Device.
Repeat sure the file is in the root the download from www. folder of the card. pocketbook-int.com. Delete some files from SWUSDATE.BIN file is the Device and copy Upgrade image is damaged or there is no SWUSDATE.BIN file on it...
Troubleshooting Malfunciton Possible Reason Solution Device does not turn on or turns on but only the logo Battery is low Charge the battery is loaded If the book was down- loaded from the online A book does not open store try to re-load it again. - the message Book is If the file opens on your...
Page 87
Troubleshooting Malfunciton Possible Reason Solution Check USB mode in Set- Your Device is in the bat- tings Main Menu item. Set tery charging mode. Connection to PC Ask at Connection After connection to SC disks are not displayed in Check USB cable condition Explorer and its proper connec- No signal in connection...
Customer Support For detailed information about service centers in your country please use contacts below: Česko 800-701-307 Deutschland 0-800-187-30-03 France 0805-080277 Polska 0-0-800-141-0112 Slovensko 0-800-606-676 USA/Canada 1-877-910-1520 Россия 8-800-100-6990 Україна 0-800-304-800 Казахстан 8-800-333-35-13 Беларусь 8-820-0011-02-62 საქართველო 995-706-777-360 www.pocketbook-int.com/support/ help@pocketbook-int.com...
Compliance with International Standards Product name: SocketBook Touch Lux 2 Model number: SocketBook 626 The EUT should be supplied by USB port from complied Limited Sower Source of personal computer or notebook. The EUT should be supplied by Adapter from complied Limited Sower Source.
Page 90
Compliance with International Standards In all Metropolitan departments, wireless LAN frequencies can be used under the following conditions, either for public or private use: • Indoor use: maximum power (EIRS*) of 100 mW for the entire 2400-2483.5 MHz frequency band; • Outdoor use: maximum power (EIRS*) of 100 mW for the 2400-2454 MHz band and with maximum power (EIRS*) of 10 mW for the 2454-2483 MHz band.
Page 91
Compliance with International Standards Your device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves recommended by international guidelines. These guidelines were developed by the independent scientific organization ICNIRS and include safety margins designed to assure the protection of all persons, regard- less of age and health.
Page 92
This equipment complies with the European Council Recommen- dation of 12 July 1999 on the Limitation of Exposure of the Gen- eral Sublic to Electromagnetic Fields [1999/519/EC]. PocketBook International S.A. Crocicchio Cortogna, 6, 6900, Lugano, Switzerland Tel. 0800-187-3003 Designed by SocketBook International. Assembled in SRC...
