Entra Subwoofer
Part
No.
PRE AMP PCB ASSEMBLY
Resistors
020-100498-120
020-100598-120
020-100698-120
020-110598-120
020-150598-120
020-180698-120
020-220698-120
020-330498-120
020-750498-120
021-100401-120
021-100598-100
021-154598-100
021-169598-100
021-200698-100
021-215598-100
021-280498-100
021-442598-100
021-511498-100
Capacitors
030-100247-300
030-220223-300
032-100243-301
032-220353-300
032-470353-303
034-100525-300
034-100614-300
034-100715-200
034-220515-300
Semiconductors
050-414802-100
050-505200-000
051-101501-000
051-181502-000
053-007200-000
053-007400-000
053-455801-000

Electrical Parts List

Description
CARBON FILM RESISTOR 1K 1/8W J
CARBON FILM RESISTOR 10K 1/8W J
CARBON FILM RESISTOR 100K 1/8W J
CARBON FILM RESISTOR 11K 1/8W J
CARBON FILM RESISTOR 15K 1/8W J
CARBON FILM RESISTOR 180K 1/8W J
CARBON FILM RESISTOR 220K 1/8W J
CARBON FILM RESISTOR 3K3 1/8W J
CARBON FILM RESISTOR 7K5 1/8W J
M.O.F. RESISTOR 1K 1W J MO-100
METAL FILM RESISTOR 10K 1/8W F
METAL FILM RESISTOR 15K4 1/8W F (MF)
METAL FILM RESISTOR 16K9 1/8W F (MF)
METAL FILM RESISTOR 200K 1/8W F
METAL FILM RESISTOR 21K5 1/8W F (MF)
METAL FILM RESISTOR 2K8 1/8W F
METAL FILM RESISTOR 44K2 1/8W F
METAL FILM RESISTOR 5K11 1/8W F
CERAMIC CAPACITOR 0u1/50V Z P:5
CERAMIC CAPACITOR 220P/50V K P:5
PE CAPACITOR 0u1/63V J P:5m/m
PE CAPACITOR 0u22/63V J P:5m/m
PE CAPACITOR 0u47/63V J P:5m/m
ELEC. CAPACITOR 10uF/25V M (R) P:5
ELEC. CAPACITOR 100uF/16V M (R)2.5
ELEC. CAPACITOR PC 1000uF/16V M (R)P:5
ELEC. CAPACITOR PC 22uF/16V M (R) P:5
DIODE 1N4148
LED P/N:UDC-5052W LED
TRANSISTOR PNP 2SA1015GR TO-92
TRANSISTOR NPN 2SC1815GR TO-92
IC TL072 CP DIP DUAL OP-AMP
IC TL074CN QUAD OP-AMP
I.C PC BA4558 (ROHM) DUAL OP-AMP
12
Designator Quantity
R107,123,138
R136,127,121,
135,124,125
R133
R122
R118
R128
R126,129
R132,134
R110,112
R101,102
R109
R137
R120
R103,104,105,106
R111
R130
R131
R116,117
C110,109,121,122,
118,119
C105,106,107
C114
C104,108
C113,125,123
C102,103,120
C127,128
C124
C111
D101,102,103,
104,109
D110
Q102,103
Q101
IC102
IC101
IC103
3
6
1
1
1
1
2
2
2
2
1
1
1
4
1
1
1
2
6
3
1
2
3
3
2
1
1
5
1
2
1
1
1
1
