Infinity ENTRA Service Manual page 13

Entra Subwoofer
Part
No.
Miscellaneous
072-010058-000
074-030002-000
083-031605-000
083-052618-000
026-200595-263
026-200595-264
MAIN AMP ASSEMBLY
Resistors
020-100398-120
020-100498-120
020-100598-120
020-100698-120
020-150498-120
020-150598-120
020-220498-120
020-220598-120
020-220698-120
020-270398-120
020-270698-120
020-330297-120
020-390598-120
020-470498-120
021-470597-120
020-470598-120
020-560398-120
021-100003-020
021-100201-121
021-100397-120
021-100401-120
021-100496-120
021-330498-120
021-499698-100
021-680296-120
Capacitors
030-100264-300
030-220223-300
030-220244-261
030-470344-200
Electrical Parts List
Description
RCA JACK 2P P/N:052000W1G(Red,White)
TOGGLE SW P/N L101
CONNECTOR LEAD WIRE #26 L:60mm #18 L:70mm
CONNECTOR LEAD WIRE EH2.5-7P+SCN2.5P+7
LEAD WIRE
VR P/N:R1210G-2A1-B20Kx2 10%
VR P/N:R1210N-2A1-B20K 10%
CARBON RESISTOR 100R 1/8W J
CARBON RESISTOR 1K 1/8W J
CARBON RESISTOR 10K 1/8W J
CARBON RESISTOR 100K 1/8W J
CARBON RESISTOR 1K5 1/8W J
CARBON RESISTOR 15K 1/8W J
CARBON RESISTOR 2K2 1/8W J
CARBON RESISTOR 22K 1/8W J
CARBON RESISTOR 220K 1/8W J
CARBON RESISTOR 270R 1/8W J
CARBON RESISTOR 270K 1/8W J
CARBON RESISTOR 33R 1/4W J
CARBON RESISTOR 6 39K 1/8W J
CARBON RESISTOR 4K7 1/8W J
M.O.F. RESISTOR 47K 1/4W J
CARBON RESISTOR 47K 1/8W J
CARBON RESISTOR 560R 1/8W J
M. O. F. RESISTOR 0R1 3WS J
M. O. F. RESISTOR 10R 1W J MO
M. O. F. RESISTOR 100R 1/4W J
M. O. F. RESISTOR 1K 1W J
M. O. F. RESISTOR 1K 1/2W
M. O. F. RESISTOR 3K3 1/8W J
METAL FILM RESISTOR 499K 1/8W F
M. O. F. RESISTOR 68R 1/2W J
CERAMIC CAPACITOR 0u1/100V K NPO
CERAMIC CAPACITOR 220P/50V K P:5
CERAMIC CAPACITOR 22pF/50V J NPO
CERAMIC CAPACITOR PC 470pF/50V 10
13
Designator Quantity
JK101
SW101
CN1
CN101
VR101
VR102
R511,714,719
R506,721,507,702
R503,610,504,510,
512,601,606
R712,725,731
R713,718,721
R607,709,711
R710,742
R502,508,701,703
R603
R715,717
R611
R723,724
R716
R602
R728
R505,604,605
R743
R734,735
R608,609
R726,730
R739
R727,729
R720
R513,509
R732,733
C718,707,708,719
C703,702,717,716
C712,713
C715,714,711,710
1
1
1
1
1
1
3
4
7
3
3
3
2
4
1
2
1
2
1
1
1
3
1
2
2
2
1
2
1
2
2
4
4
2
4
