Infinity ENTRA Service Manual page 15

Entra Subwoofer
Part
No.
POWER SUPPLY PCB ASS'Y
Resistors
020-820497-120
021-470301-120
Capacitors
030-100264-300
030-100295-201
034-220515-300
034-220615-301
034-470763-301
Semiconductors
050-001500-000
051-118900-100
051-677000-000
Miscellaneous
052-602000-000
072-040032-000
073-032027-000
083-021805-000
083-022548-000
083-031603-000
091-000130-000
093-105203-300
MISCELLANEOUS
005-009885-000
005-033420-000
008-068701-000
042-010042-000
061-020000-000
061-314002-000
061-800000-000
062-050400-000
062-261313-000
063-062512-000
066-120300-900
070-000030-410
070-040010-210
070-400010-206
070-400010-212
070-400010-812
Electrical Parts List (Cont.)
Description
CARBON RESISTOR 8K2 1/4W J
MO RESISTOR 470R 1W J MB TYPE MO-100
CERAMIC CAPACITOR 0u1/100V K NPO TAPING
UL SAFETY CAPACITOR YS-SC103Z2 10000pF/400V
ELEC. CAPACITOR PC,308 22uF/16V M (R)0511
ELEC.CAPACITOR 220uF/16V M (R)0611 P:5
ELEC.CAPACITOR 4700uF/63V M (R) 25*40
DIODE 15V 1/2W HZ15-3
TRANSISTOR 2SD882P(TO-220)
TRANSISTOR 2SB772 (TO-220)
RECTIFY DIODE KBU8D(SUB-100W) 8A/200V
WAFER 2 P:3.96 3P MALE VH
HEAT SINK PCS 40x24x2.0m/m
LEAD WIRE #22 GND WIRE L:80mm 5TT+5TT
LEAD WIRE #18 UL1015 PCS T187(t0.8)+ B1811T0P-2
4Px120mm CONNECTOR 1 LEAD WIRE #22 +5TT
FUSE HOLDER PCS P/N:CQ-203SP
FUSE:UL GSL(2AG) FUSE:3A,250V,5*20mm
GASKET 97.5x85x36cm
STYROFOAM 335.0x191.0x65.0mm
GASKET SM-55 GASKET 860.0x5.0 t=2.0mm
TRANSFORMER P/N:PT-1739
KNOB ABS HTS-10/20 p20x15m/m UL94V-0 BLK
CORD BUSHING P/N SB4F-2
TRANSISTOR COVER P/N:TW-1
PUSH TERMINAL 4P JK102A,JK102B P/N E405
BUCKET(HI PS 94VO)304.8x177.8x124.2m/m BLK
PLATE 304.8x177.8 t=2.5mm (SPCC)
CABLE TIE PCCV-120S
SCREW TRANSFORMERx4,HEAT SINKx6 M4;4x10m/m BLK
SCREW PC TRAN.x5,TH601x1,GROND WIREx1 PMS M3x10m/m BLK
SCREW PCB VS BRACKETx4,BRACKET VS HEAT SINKx23x6m/m BLK
SCREW 3x12m/m BLK
SCREW RCA JACKx1 PTS-4 3x12 BLK
15
Designator Quantity
R301,304
R303,302
C2,3
C309
C307
C305,306
C303,304
ZD301,302
Q301
Q302
BD2
CN30
CN30
F301
2
2
2
1
1
2
2
2
1
1
1
1
1
1
2
1
2
1
1
40
2
1
2
1
2
2
1
1
3
10
7
6
1
1
