KTI Networks KSD-800 Specification Sheet page 2

EMI EMS Safety Environmental Tests:
Test Standard Specifications
FCC/EMI FCC Rule Part 15 Class A
CE/EMC/EMI EN55022, CISPR 22 Class A
CE/EMC/Harmonic EN 61000-3-2 < 75 W
CE/EMC/VFF EN 61000-3-3 Clause 5
CE/EMC/EMS EN 55024
Contact:+/-8KV
ESD Test IEC 61000-4-2
Air:+/-16KV
RS Test IEC 61000-4-3 Strength:10V/m
EFT/BURST IEC 61000-4-4
Power:4KV
Surge Immunity IEC 61000-4-5
Signal:0.5KV
CS Test IEC 61000-4-6 Level 3
Magnetic Field Imm. IEC 61000-4-8 50Hz 40A/m
Interruption : C
Voltage Dips Imm. IEC 61000-4-11
Dips : B
Safety EN 60950, IEC 60950
Dielectric Voltage IEEE 802.3 TP, 1500VAC/60sec.
Insulation Resistance IEEE 802.3 TP , 500VDC/10Mohm
-20
Cold Test IEC 68-2-1 Test Ad
+70 O C 40%RH 96hrs
Dry Heat Test IEC 68-2-2 Test Bd
+60 O C 90%RH 96hrs
Damp Heat Test IEC 68-2-3
-20
Storage Test IEC 68-2-48
+85 C 40%RH 96hrs
O
Vibration Test IEC 68-2-34
Ordering Information :
Model Ref.
FX Ports
Distance Temperature
KSD-800-xxx
-1T FX8 ST MMF 2km
-1C FX8 SC MMF 2km
-1C1 FX8 SC MMF 2km
-1SA2 FX8 SC SMF 20km
-1SL2 FX8 SC SMF 20km
FX7 ST MMF
2km
-2T
FX8 ST MMF
2km
FX7 SC MMF
2km
-2C
FX8 SC MMF
2km
FX7 SC MMF
2km
-2C1
FX8 SC MMF
2km
FX7 SC SMF
20km
-2SA2
FX8 SC SMF
20km
FX7 SC SMF
20km
-2SL2
FX8 SC SMF
20km
FX7 SC MMF
2km
-C1SL2
FX8 SC SMF
20km
FCC Part 15 Class A
'
CISPR 22 Class A
Katron Technologies Inc.
15F-7, No. 79, Sec. 1, Hsin Tai Wu Rd.,
Hsi-chih, Taipei Hsien, Taiwan.
Te l :886-2-2698-3878
Fax:886-2-2698-3873
E-mail:kti@ktinet.com.tw
URL:http://www.ktinet.com.tw
