Introduction
Feature
Video
Audio
Interface
I/O Chip
PC Card Sockets
Storage
Modem
LAN
Indicators
1 - 4 System Specifications L295P/L297P
Specifications L295P (A/B/T)
Video RAM - Shared Memory Architecture (SMA) Supporting DDR Video Shared Memory up to 64MB
2D Hardware Accelerator (for block level transfers of data integrating an extensive set of instructions for 3D)
SoundBlaster
Three Audio Jacks for Headphone-Out, Line-In, and Microphone-In
Two Built-In Speakers (3W)
One Serial Port (16550A Compatible, 9 Pin Shell, up to 115Kbps)
One Parallel Port (25pin Shell, SPP/Bi-Direction/ECP/EPP Mode Support)
One External CRT Port (15-pin D-sub)
Three Audio Jacks For Headphone-out, Line-in, and Microphone-in
One RJ-45 Jack for 100M/10M Ethernet LAN
One RJ-11 Port for Modem (optional)
One IEEE 1394 Port (6 Pin Un-Powered) (optional with the Mini-PCI /IF IEEE 1394 Module)
One Mini-PCI /IF IEEE 1394 Module (optional)
Supports Two Type II Slots or One Type III PCMCIA Slot (Cardbus Support)
One 3.5", 1.44MB 3-Mode Floppy Disk Drive (Interchangeable With 6-in-1 Card Reader Module or Video-Capture
One 3.5", 25.4mm Height Hard Disk Drive (Ultra-66/100 I/F Support)
One Bay for the Optional 12.7mm Height ATAPI CD-ROM, or CD-RW, or DVD-ROM, or DVD-ROM & CD-RW Combo,
Removable Internal 56k MDC Data/Fax Modem (optional)
On Board 10/100Mbps Base Auto-Detection
LED Indicators (HDD/FDD/CD Device activity, Power)
Specifications L297P (B/D)
865-G Integrated Chipset
AC97' Compatible
™ ™
and Windows Sound System Compatible
Two Built-In Speakers (2W)
Two PS/2 Ports (Keyboard & Mouse)
Four USB 2.0 Ports
Winbond W83627HF
Module)
or DVD/RW+R
