3.4 Balanced Analog Outputs
Output Audio XLR Pinout
PIN DESCRIPTION
1 Ground
2 Signal + Output
3 Signal - Output
The audio outputs are balanced to +4 dBu, with 18 dB of headroom (i.e., inputs clip at +22 dBu).
3.5 AES/EBU Input
PIN DESCRIPTION
1 Ground
2 Signal + Input
3 Signal - Input
3.6 AES/EBU Output
PIN DESCRIPTION
1 Ground
2 Signal + Output
3 Signal - Output

3.7 Network Interfaces

The Z/IP ONE is designed to work on managed private networks or the public Internet. For reliable operation
when connected to the public network, the Z/IP ONE must be placed behind a firewall. These are commonly
included in network address translating routers, commonly called either "NAT routers" or simply "routers."
The Z/IP ONE conjunction with the ZIP server on the public Internet, has technology for automatically creating
connections without requiring port forwarding on most styles of NAT routers. For more information on these
topics, see Chapter 9, Audio Streams and Appendix A, When an IT Department is not Available.
The network interfaces are Ethernet, twisted pair, 100BaseT connectors. Use a CAT5e or CAT6 network cable. The
standard pin-out for an RJ45 style 8-Pin/8-Position miniature modular jack when used for 10/100BaseT Ethernet is:
PIN FUNCTION
1 Transmit +
2 Transmit -
3 Receive +
4 Unused
5 Unused
6 Receive -
7 Unused
8 Unused
Input Audio XLR Pinout
Output Audio XLR Pinout
