Installation

3.1 Rack Mounting the Studio Unit

The Z/IP ONE mounts in a 1RU space in a standard 19" rack. The Z/IP ONE does not have an internal fan, and does
not have any special requirements for space above and below the unit. As long as you keep the stirred air in the rack
between 0 and 40 Celsius (32 to 104 degrees Fahrenheit) with a relative humidity of 0 to 98% (non-condensing),
the unit will operate as described.

3.2 Power

Install the power cord included with the Z/IP ONE in the marked AC power connector located in the rear of the
unit. The internal universal switching supply will accept 100-240 VAC (50-60 Hz) input. You should see the blue
front panel LED flash to indicate the unit is booting. Subsequently, the main menu will appear. This process can
take about 90 seconds.
3.3 Balanced Analog Inputs
Input Audio XLR Pinout
PIN DESCRIPTION
1 Ground
2 Signal + Input
3 Signal - Input
Install the left and right analog audio cables in the female XLR connectors marked "CH 1 In" and "CH 2 In" on the
rear panel. The analog audio section accepts audio input with a peak level of +22dBu. In the Audio I/O -> Input
mode Left or Right menu option, each audio input can be configured for the following settings:
Line (+4 dBu nominal)
♦
Microphone
♦
Mic + Phantom Power
♦
Mic Gain Trim
There is a microphone gain trim adjustment option in the Setup->Audio I/O menu for each input, which can be
used to add additional gain when that input is set to microphone level. This setting is ignored when an input is set
to line level. Gain should be adjusted so that the microphone reaches your desired level on peaks.
