Specifications - Advent CADNAV1 Installation Manual

For Navigation operation see the included quick start guide or download a full user's manual from
I
f the picture is not centered or does not fill the screen correctly you can adjust the picture size. Access the settings menu by
pressing the Menu button on the side of the Nav Interface Module.
Use the Menu button to scroll through the options and "+" or "-" buttons to adjust the value.
1. Contrast, Brightness and Saturation are all screen adjustments for picture quality.
2. Position H and V are for Horizontal and Vertical Position, use to adjust to fit factory screen as needed.
3. IR-AV1, IR-AV2: NOT USED. Select NONE to insure proper operation.
4. Guide-L, Guide-R-CNTRL -These are controls for the position of the Parking Lines. By selecting + or - you can move the
position of the lines to match the vehicle width.
5. H-Size, V-Size: This will adjust the picture to meet the full screen size of the OEM panel.

Specifications

:
No. Name
1 Video input
2 Synchronized signal strength
3 RGB resolution
4 Av1, Av2, cam video
5 Av1, Av2, cam format
6 Normal power
7 Stand by current
8 Trigger level threshold (Reverse and
switching)
9 Output current of additional control
port 1.2.7
10 Operating temperature range
11 Dimensions
WWW.ADVENTPRODUCTS.COM
Contrast----------------------------50
Brightness-------------------------50
Saturation-------------------------62
Position-H-------------------------23
Position-V-------------------------3
IR-AV1------------------------------NOT USED
R-AV1-------------------------------NOT USED
Guide-L-----------------------------0
Guide-R----------------------------3
Guide-CNTRL---------------------OFF
H - SIZE-----------------------------16
V - SIZE-----------------------------40
For Technical Support Please Call 1- 800-323-4815.
.
Setup Menu
Parameters
0.7Vpp with 75 Ω impedance
3‐5Vpp with 5K impedance negative pulse synchronization.
By changing DIP4 user can select HD/VGA or normal
HD : 800X480 or VGA :640X480
Normal NTSC‐vertical 240 (or 234)
0.7Vpp with 75 Ω impedance
NTSC/PAL/SECAM Automatic switch
4.8W [0.4A @12V]
< 10mA
>5V trigger
Maximum current of 2A.
‐40 +85C
15.6 X 9.2 X 2.2 Cm
